DEFINITION OF TERMS

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

CHECK FOR INTERMITTENT PROBLEMS

HINT

Inspect the vehicle ECM using check mode. Intermittent problems are easier to detect with the Techstream when the ECM is in check mode. In check mode, the ECM uses 1 trip detection logic, which is more sensitive to malfunctions than normal mode (default), which uses 2 trip detection logic.

1. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) .
2. Switch the ECM from normal mode to check mode using the Techstream.Refer to «CHECK MODE PROCEDURE»(ref-493432-S20362634172012081000000) .
3. Perform a simulation test.Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-493289-S22966865862012081000000) .
4. Check and wiggle the harness(es), connector(s) and terminal(s).Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-493289-S22966865862012081000000) .

REGISTRATION

Note. The Vehicle Identification Number (VIN) must be input into the replacement ECM.

HINT

The VIN is in the form of a 17-digit alphanumeric vehicle identification number. The Techstream is required to register the VIN.

1. DESCRIPTION (Using the Techstream) HINT: This registration section consists of two parts: Read VIN and Write VIN. Read VIN: Explains the VIN reading process in a flowchart. This process allows the VIN stored in the ECM to be read in order to confirm that the two VINs, provided with the vehicle and stored in the vehicle ECM, are the same. Write VIN: Explains the VIN writing process in a flowchart. This process allows the VIN to be input into the ECM. If the ECM is replaced, or the ECM VIN and vehicle VIN do not match, the VIN can be registered, or overwritten in the ECM by following this procedure.
2. READ VIN Confirm the vehicle VIN. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / VIN / VIN Read.
3. WRITE VIN Confirm the vehicle VIN. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / VIN / VIN Write.

CHECKING MONITOR STATUS

The purpose of the monitor result (mode 06) is to allow access to the results for on-board diagnostic monitoring tests of specific components/systems that are not continuously monitored. Examples are the catalyst and evaporative emission (EVAP) system.

The monitor result allows the OBD II scan tool to display the monitor status, test value, minimum test limit and maximum test limit. These data are displayed after the vehicle has been driven to run the monitor.

When the test value is not between the minimum test limit and maximum test limit, the ECM (PCM) interprets this as a malfunction. When the component is not malfunctioning, if the difference of the test value and test limit is very small, the component will malfunction in the near future.

Perform the following procedure to view the monitor status. Although this procedure references the Lexus/Toyota diagnostic tester, it can be checked using a generic OBD II scan tool. Refer to your scan tool operator's manual for specific procedures.

1. PERFORM MONITOR DRIVE PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON and the Techstream on. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Drive the vehicle in accordance with the applicable drive pattern described in Readiness Monitor Drive Pattern.Refer to «READINESS MONITOR DRIVE PATTERN»(ref-493432-S35388683572012081000000) . Do not turn the ignition switch off. NOTE: The test results will be lost if the ignition switch is turned off.
2. ACCESS MONITOR RESULT Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / Result. Confirm the monitor status for each component. HINT: The monitor status for each component is displayed in the Result column. Pass: The component is functioning normally. Fail: The component is malfunctioning. Display the test results for a monitor by selecting the icon in the Details column for that monitor. Display the test value for an item listed under Test Results by selecting the icon in the Details column for that item.
3. CHECK COMPONENT STATUS Compare the test value with the minimum test limit and maximum test limit. If the test value is between the minimum test limit and maximum test limit, the component is functioning normally. If not, the component is malfunctioning. The test value is usually significantly more or less than the test limit. If the test value is on the borderline of the test limit, the component will malfunction in the near future. HINT: The monitor result might on rare occasions be Pass even if the malfunction indicator lamp (MIL) is illuminated. This indicates the system malfunctioned on a previous driving cycle. This might be caused by an intermittent problem.
4. MONITOR RESULT INFORMATION If you use a generic scan tool, multiply the value by the scaling value listed below. A/F SENSOR (SENSOR 1) Monitor ID Test ID Scaling Unit Description $01 $8E Multiply by 0.001 V A/F sensor deterioration level $01 $91 Multiply by 0.004 mA A/F sensor current HO2 SENSOR (SENSOR 2) Monitor ID Test ID Scaling Unit Description $02 $07 Multiply by 0.001 V Minimum sensor voltage $02 $08 Multiply by 0.001 V Maximum sensor voltage $02 $8B Multiply by 0.001 Seconds 0.35 - 0.2 V sensor switch time $02 $8D Multiply by 0.001 Seconds Duration that sensor voltage drops to 0.2 V during fuel cut $02 $8F Multiply by 0.0003 g Maximum oxygen storage capacity CATALYST Monitor ID Test ID Scaling Unit Description $21 $A9 Multiply by 0.0003 No dimension Oxygen storage capacity of catalyst ADVANCE/RETARDED VVT INTAKE SIDE Monitor ID Test ID Scaling Unit Description $35 $81 Multiply by 0.01 Seconds Forced movement of oil control valve time ADVANCE/RETARDED VVT EXHAUST SIDE Monitor ID Test ID Scaling Unit Description $35 $85 Multiply by 0.01 Seconds Forced movement of oil control valve time EVAP Monitor ID Test ID Scaling Unit Description $3D $C9 Multiply by 0.001 kPa Test value for small leak (P0456) $3D $CA Multiply by 0.001 kPa Test value for gross leak (P0455) $3D $CB Multiply by 0.001 kPa Test value for leak detection pump stuck OFF (P2401) $3D $CD Multiply by 0.001 kPa Test value for leak detection pump stuck ON (P2402) $3D $CE Multiply by 0.001 kPa Test value for vent valve stuck OFF (P2420) $3D $CF Multiply by 0.001 kPa Test value for vent valve stuck ON (P2419) $3D $D0 Multiply by 0.001 kPa Test value for reference orifice low flow (P043E) $3D $D1 Multiply by 0.001 kPa Test value for reference orifice high flow (P043F) $3D $D4 Multiply by 0.001 kPa Test value for purge VSV stuck closed (P0441) $3D $D5 Multiply by 0.001 kPa Test value for purge VSV stuck open (P0441) $3D $D7 Multiply by 0.001 kPa Test value for purge flow insufficient (P0441) REAR OXYGEN SENSOR HEATER Monitor ID Test ID Scaling Unit Description $42 $91 Multiply by 0.001 Ohm Oxygen sensor heater resistance bank 1 sensor 2 MISFIRE Monitor ID Test ID Scaling Unit Description $A1 $0B Multiply by 1 Time Total EWMA* misfire count of all cylinders in last ten driving cycles $A1 $0C Multiply by 1 Time When ignition switch is ON, total misfire count of all cylinders in last driving cycle is displayed. While engine is running, total misfire count of all cylinders in current driving cycle is displayed. $A2 $0B Multiply by 1 Time Total EWMA* misfire count of cylinder 1 in last ten driving cycles $A2 $0C Multiply by 1 Time When ignition switch is ON, total misfire count of cylinder 1 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 1 in current driving cycle is displayed. $A3 $0B Multiply by 1 Time Total EWMA* misfire count of cylinder 2 in last ten driving cycles $A3 $0C Multiply by 1 Time When ignition switch is ON, total misfire count of cylinder 2 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 2 in current driving cycle is displayed. $A4 $0B Multiply by 1 Time Total EWMA* misfire count of cylinder 3 in last ten driving cycles $A4 $0C Multiply by 1 Time When ignition switch is ON, total misfire count of cylinder 3 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 3 in current driving cycle is displayed. $A5 $0B Multiply by 1 Time Total EWMA* misfire count of cylinder 4 in last ten driving cycles $A5 $0C Multiply by 1 Time When ignition switch is ON, total misfire count of cylinder 4 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 4 in current driving cycle is displayed. HINT: *: EWMA (Exponential Weighted Moving Average) misfire counts for last 10 driving cycles (calculated) Calculation: 0.1 x (current counts) + 0.9 x (previous average) Initial value for (previous average) = 0

Scheme 34

Scheme 35

Scheme 36

1. PURPOSE OF READINESS TESTS The On-Board Diagnostic (OBD II) system is designed to monitor the performance of emission-related components, and indicate any detected abnormalities with DTCs (Diagnostic Trouble Codes). Since various components need to be monitored during different driving conditions, the OBD II system is designed to run separate monitoring programs called Readiness Monitors. To view the monitor status, enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / Current. When the Readiness Monitor status displays Complete, the necessary conditions have been met for running the performance tests for that Readiness Monitor. A generic OBD II scan tool can also be used to view the Readiness Monitor status. HINT: Many state Inspection and Maintenance (I/M) programs require the vehicle Readiness Monitor status to show Complete before beginning emission tests. The Readiness Monitor is reset to Incomplete if: The ECM has lost battery power or blown a fuse. DTCs have been cleared. The conditions for running the Readiness Monitor have not been met. If the Readiness Monitor status shows Incomplete, follow the appropriate Readiness Monitor Drive Pattern to change the status to Complete. WARNING: Strictly observe posted speed limits, traffic laws, and road conditions when performing these drive patterns. NOTE: These drive patterns represent the fastest method of satisfying all conditions necessary to achieve complete status for each specific Readiness Monitor. In the event of a drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed. In most cases, the Readiness Monitor will still achieve complete status upon completion of the drive pattern. To ensure completion of the Readiness Monitors, avoid sudden changes in vehicle load and speed (driving up and down hills and/or sudden acceleration).
2. CATALYST MONITOR (ACTIVE AIR-FUEL RATIO CONTROL TYPE) Preconditions The monitor will not run unless: The MIL is off. Drive Pattern (1) Connect the Techstream to the DLC3. (2) Turn the ignition switch to ON. (3) Turn the Techstream on. (4) Clear DTCs (if output).Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . (5) Start the engine and warm it up. (6) Drive the vehicle at between 64 and 113 km/h (40 and 70 mph) for at least 10 minutes. Monitor Status Check the Readiness Monitor status displayed on the Techstream. If the status does not switch to Complete, extend the driving time.
3. EVAP SYSTEM MONITOR (KEY-OFF TYPE) Preconditions The monitor will not run unless: The fuel tank is less than 90% full. The altitude is less than 8000 ft. (2438 m). The vehicle is stationary. The engine coolant temperature is between 4.4 and 35°C (40 and 95°F). The intake air temperature is between 4.4 and 35°C (40 and 95°F). The vehicle was driven in a city area (or on a freeway) for 10 minutes or more. Monitor Conditions Turn the ignition switch off and wait for 6, 8 or 10.5 hours depending on certain vehicle conditions. HINT: Do not start the engine until after checking Readiness Monitor status. If the engine is started, the step described above must be repeated. Monitor Status Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Check the Readiness Monitor status displayed on the Techstream. If the status does not switch to Complete, restart the engine, make sure that the preconditions have been met, and then perform the Monitor Conditions procedure again.
4. AIR-FUEL RATIO (A/F) AND HEATED OXYGEN (HO2) SENSOR MONITORS (ACTIVE AIR-FUEL RATIO CONTROL TYPE) Preconditions The monitor will not run unless: 2 minutes or more have elapsed since the engine was started. The Engine Coolant Temperature (ECT) is 75°C (167°F) or higher. Cumulative driving time at a vehicle speed of 48 km/h (30 mph) or more exceeds 6 minutes. Air-fuel ratio feedback control is performed. Drive Pattern for Front A/F Sensor and HO2 Sensor (1) Connect the Techstream to the DLC3. (2) Turn the ignition switch to ON. (3) Turn the Techstream on. (4) Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . (5) Start the engine and warm it up until the ECT reaches 75°C (167°F) or higher. (6) Drive the vehicle at a speed between 60 km/h (38 mph) and 120 km/h (75 mph) for at least 10 minutes. (7) Change the transmission to 2nd gear. (8) Accelerate the vehicle to 64 km/h (40 mph) or more by depressing the accelerator pedal for at least 10 seconds. (9) Release the accelerator pedal for at least 8 seconds without depressing the brake pedal in order to execute fuel-cut control. (10) Allow the vehicle to decelerate until the vehicle speed decreases to less than 10 km/h (6 mph). (11) Repeat steps (8) through (10) above at least 3 times in one driving cycle. Monitor Status Check the Readiness Monitor status displayed on the Techstream. If the status does not switch to Complete, make sure that the preconditions have been met, and then perform steps (5) through (11) in the Drive Pattern above.
5. AIR-FUEL RATIO (A/F) AND HEATED OXYGEN (HO2) SENSOR HEATER MONITORS (FRONT A/F AND REAR HO2 SENSOR TYPE) Preconditions The monitor will not run unless: The MIL is off. Drive Pattern (1) Connect the Techstream to the DLC3. (2) Turn the ignition switch to ON. (3) Turn the Techstream on. (4) Clear DTCs (if output).Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . (5) Start the engine. (6) Allow the engine to idle for 10 minutes or more. (7) Drive the vehicle at 40 km/h (25 mph) or more for at least 2 minutes. Monitor Status Check the Readiness Monitor status displayed on the Techstream. If the status does not switch to Complete, make sure that the preconditions have been met, and repeat steps (5) to (7) described in the Drive Pattern above.

CHECK MODE PROCEDURE

HINT

Techstream only

Compared to normal mode, check mode is more sensitive to malfunctions. Therefore, check mode can detect malfunctions that cannot be detected in normal mode.

Note. All the stored DTCs and freeze frame data are cleared if: 1) the ECM is changed from normal mode to check mode or vice versa; or 2) the ignition switch is turned from ON to ACC or off while in check mode. Before changing modes, always check and note any DTCs and freeze frame data.

Scheme 37

1. CHECK MODE PROCEDURE Check and ensure the following conditions: Battery voltage is 11 V or higher. Throttle valve is fully closed. Transmission is in the P or N (neutral) position. A/C switch is off. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / Check Mode. Switch the ECM from normal mode to check mode. Check that the MIL flashes as shown in the illustration. Start the engine. Check that the MIL turns off. Simulate the conditions of the malfunction described by the customer. Check DTCs and freeze frame data using the Techstream.

FAIL-SAFE CHART

If any of the following DTCs are stored, the ECM enters fail-safe mode to allow the vehicle to be driven temporarily or stops fuel injection.

HINT

1. *1: The vehicle can be driven slowly when the accelerator pedal is depressed firmly and slowly. If the accelerator pedal is depressed quickly, the vehicle may speed up and slow down erratically.
2. *2: Misfire-related fail-safe operations occur when catalyst overheat malfunctions occur.

Scheme 38

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note Vehicle Speed Vehicle speed/ Min.: 0 km/h, Max.: 255 km/h Actual vehicle speed The speed indicated on the speedometer. Engine Speed Engine speed/ Min.: 0 rpm, Max.: 16383 rpm 600 to 700 rpm: Idling - Calculate Load Load calculated by ECM/ Min.: 0%, Max.: 100% 10 to 30%: Idling 10 to 30%: Running without load (2500 rpm) - Vehicle Load Vehicle load/ Min.: 0%, Max.: 25700% Actual vehicle load - MAF Air flow rate from Mass Air Flow (MAF) meter/ Min.: 0 g/sec., Max.: 655.35 g/sec. 1 to 3 g/sec.: Idling If the value is approximately 0.0 g/sec.: The Mass Air Flow (MAF) meter power source circuit is open. VG circuit is open or shorted. If the value is 160.0 g/sec. or more: The E2G circuit is open. Atmosphere Pressure Atmospheric pressure/ Min.: 0 kPa, Max.: 255 kPa Equivalent to atmospheric pressure (absolute pressure) - Coolant Temp Engine coolant temperature/ Min.: -40°C, Max.: 140°C 80 to 100°C (176 to 212°F): After warming up If the value is -40°C (-40°F), the sensor circuit is open. If the value is 140°C (284°F), the sensor circuit is shorted. Intake Air Intake air temperature/ Min.: -40°C, Max.: 140°C Equivalent to ambient air temperature If the value is -40°C (-40°F), the sensor circuit is open. If the value is 140°C (284°F), the sensor circuit is shorted. Engine Run Time Engine run time/ Min.: 0 seconds, Max.: 65535 seconds Time after engine start Service data. Initial Engine Coolant Temp Initial engine coolant temperature/ Min.: -40°C, Max.: 120°C Close to ambient air temperature Service data. Initial Intake Air Temp Initial intake air temperature/ Min.: -40°C, Max.: 120°C Close to ambient air temperature Service data. Battery Voltage Battery voltage/ Min.: 0 V, Max.: 65.5 V 11 to 14 V: Idling - Accelerator Position Accelerator pedal position Min.: 0%, Max.: 399.99% Actual accelerator pedal position - Accel Sens. No. 1 Volt % Absolute Accelerator Pedal Position (APP) No. 1/ Min.: 0%, Max.: 100% 10 to 22%: accelerator pedal released 52 to 90%: accelerator pedal fully depressed - Accel Sens. No. 2 Volt % Absolute APP No. 2/ Min.: 0%, Max.: 100% 24 to 40%: accelerator pedal released 68 to 99%: accelerator pedal fully depressed - Accel Sensor Out No. 1 APP sensor No. 1 voltage/ Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: accelerator pedal released 2.6 to 4.5 V: accelerator pedal fully depressed - Accel Sensor Out No. 2 APP sensor No. 2 voltage/ Min.: 0 V, Max.: 4.98 V 1.2 to 2.0 V: accelerator pedal released 3.4 to 4.98 V: accelerator pedal fully depressed - Accelerator Idle Position Whether or not accelerator pedal position sensor detecting idle/ ON or OFF ON: Idling - Accel Fully Close Learn #1 Accelerator fully closed learned value No. 1/ Min.: 0 deg, Max.: 124.5 deg - ETCS service data. Accel Fully Close Learn #2 Accelerator fully closed learned value No. 2/ Min.: 0 deg, Max.: 124.5 deg - ETCS service data. Throttle Sensor Volt % Throttle valve opening percentage according to throttle position sensor/ Min.: 0%, Max.: 100% 10 to 22%: Accelerator pedal released 64 to 96%: Accelerator pedal fully depressed Value calculated based on the voltage at terminal VTA1 Throttl Sensor #2 Volt % Throttle valve opening percentage according to throttle position sensor No. 2/ Min.: 0%, Max.: 100% 42 to 62%: Accelerator pedal released 92 to 100%: Accelerator pedal fully depressed Value calculated based on the voltage at terminal VTA2 ST1 Brake pedal signal/ ON or OFF ON: Brake pedal depressed - System Guard System guard/ ON or OFF - ETCS service data. Open Side Malfunction Open side malfunction/ ON or OFF - ETCS service data. Throttle Idle Position Whether or not throttle position sensor detecting idling/ ON or OFF ON: Accelerator pedal released OFF: Accelerator pedal fully depressed - Throttle Require Position Required throttle position/ Min.: 0 V, Max.: 4.9 V 0.5 to 1.1 V: Idling - Throttle Sensor Position* Throttle position sensor/ Min.: 0%, Max.: 100% 0%: Accelerator pedal released 50 to 80%: Accelerator pedal fully depressed Recognition value for throttle opening angle on ECM Throttle Position No. 1 Throttle position sensor No. 1 output voltage/ Min.: 0 V, Max.: 4.9 V 0.5 to 1.1 V: Accelerator pedal released 3.2 to 4.8 V: Accelerator pedal fully depressed 0.6 to 1.4 V: Fail-safe operating - Throttle Position No. 2 Throttle position sensor No. 2 output voltage/ Min.: 0 V, Max.: 4.9 V 2.1 to 3.1 V: Accelerator pedal released 4.6 to 4.9 V: Accelerator pedal fully depressed 2.1 to 3.1 V: Fail-safe operating - Throttle Position Command Throttle position command value/ Min.: 0 V, Max.: 4.9 V 0.5 to 4.8 V - Throttle Sens Open Pos #1 Throttle sensor opener position No. 1/ Min.: 0 V, Max.: 4.9 V 0.6 to 1.4 V ETCS service data. Throttle Sens Open Pos #2 Throttle sensor opener position No. 2/ Min.: 0 V, Max.: 4.9 V 1.7 to 2.5 V ETCS service data. Throttle Motor Current Throttle actuator current/ Min.: 0 A, Max.: 19.9 A 0 to 3.0 A: Idling ETCS service data. Throttle Motor DUTY Throttle actuator/ Min.: 0%, Max.: 100% 10 to 22%: Idling after engine warmed up ETCS service data. Throttle Motor Duty (Open) Throttle actuator duty ratio (open)/ Min.: 0%, Max.: 100% 0 to 40%: Idling ETCS service data. Throttle Motor Duty (Close) Throttle actuator duty ratio (close)/ Min.: 0%, Max.: 100% 0 to 40%: Idling ETCS service data. Throttle Fully Close Learn Throttle valve fully closed (learned value)/ Min.: 0, Max.: 4.98 V 0.4 to 1.0 V: Accelerator pedal released - +BM Voltage +BM voltage/ Min.: 0, Max.: 19.9 10 to 15 V: Idling ETCS service data. Actuator Power Supply Actuator power supply/ ON or OFF ON: Idling ETCS service data. Throttle Position Throttle valve opening angle/ Min.: 0 deg, Max.: 499.99 deg - For use when engine stall, starting problems or rough idle is present. ISC Flow Flow rate calculated using information from each sensor/ Min.: 0 L/s, Max.: 79.99 L/s - For use when engine stall, starting problems or rough idle is present. ISC Position Requested opening amount calculated using ISC control/ Min.: 0 deg, Max.: 499.99 deg - For use when engine stall, starting problems or rough idle is present. ISC Feedback Value ISC feedback compensation amount/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. ISC Learning Value ISC learned compensation amount/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. Electric Load Feedback Val Compensation flow rate according to electrical load/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. Air Conditioner FB Val Compensation flow rate according to air conditioner load/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. PS Feedback Val Compensation flow rate according to power steering load/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. Low Revolution Control Low engine speed control operation state/ ON or OFF - For use when engine stall, starting problems or rough idle is present. Neutral Control Neutral control operation state/ ON or OFF - For use when engine stall, starting problems or rough idle is present. N Range Status Shift lever N status/ ON or OFF - For use when engine stall, starting problems or rough idle is present. Eng Stall Control FB Flow Intake air compensation flow rate/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. Deposit Loss Flow Flow loss due to deposits/ Min.: -40 L/s, Max.: 39.99 L/s - For use when engine stall, starting problems or rough idle is present. Injector (Port) Injection period of the No. 1 cylinder/ Min.: 0 ms, Max.: 32.64 ms 1.0 to 3.0 ms: Idling - Injection Volum (Cylinder 1) Injection volume (cylinder 1)/ Min.: 0 ml, Max.: 2.048 ml 0.05 to 0.15 ml: Idling The quantity of fuel injection volume for 10 times. Fuel Pump/Speed Status Fuel pump/speed status/ ON or OFF - - Vacuum Pump Key-off EVAP system pump status/ ON or OFF - - TCV Status TCV status/ ON or OFF ON: Coolant temperature and intake air temperature -10°C or less or 60°C or higher and engine started - Current Fuel Type Current fuel type Gasoline/petrol - EVAP (Purge) VSV Purge VSV control duty/ Min.: 0%, Max.: 100% 0 to 50%: Idling, under purge control The order signal from the ECM. Evap Purge Flow Purge flow/ Min.: 0%, Max.: 102.3% 0 to 10%: Idling - Purge Density Learn Value Learned value of purge density/ Min.: -50, Max.: 350.000 -40 to 0%: Idling Service data. Vapor Pressure Pump Vapor pressure/ Min.: 33.853 kPa (253.918 mmHg), Max.: 125.596 kPa (942.048 mmHg) Approximately 100 kPa (750 mmHg): Ignition switch ON The EVAP system pressure is monitored by the canister pressure sensor. Vapor Pressure (Calculated) Calculated EVAP system pressure/ Min.: -5.632 kPa (-42.243 mmHg), Max.: 715.264 kPa (5364.923 mmHg) Approximately 100 kPa (750 mmHg): Ignition switch ON - EVAP System Vent Valve Key-off EVAP system vent valve status/ ON or OFF - - EVAP Purge VSV VSV status for EVAP control/ ON or OFF - - Purge Cut VSV Duty Purge cut VSV duty/ Min.: 0%, Max.: 399.99% - - Target Air-Fuel Ratio Air-fuel ratio/ Min.: 0, Max.: 1.998 0.8 to 1.2: During idling - AF Lambda B1S1 Short-term fuel trim (for Bank 1 Sensor 1)/ Min.: 0, Max.: 1.99 Value less than 1 (0.000 to 0.999) = Rich 1 = Stoichiometric air-fuel ratio Value more than 1 (1.001 to 1.999) = Lean - AFS Voltage B1S1 Air fuel ratio sensor output voltage (for Bank 1 Sensor 1)/ Min.: 0 V, Max.: 7.99 V 2.6 to 3.8 V: Idling Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. AFS Current B1S1 Air fuel ratio sensor current (for Bank 1 Sensor 1)/ Min.: -128 mA, Max.: 127.99 mA -0.5 to 0.5 mA: Idling Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check the output voltage of the sensor. A/F Heater Duty #1 A/F heater duty ratio Min.: 0%, Max.: 399.99% 0 to 100% - O2S B1S2 Heated oxygen sensor output voltage (for Bank 1 Sensor 2)/ Min.: 0 V, Max.: 1.27 V 0.0 to 0.9 V: Vehicle driven at 70 km/h (44 mph) Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. O2S Impedance B1S2 Sub heated oxygen sensor impedance (for Bank 1 Sensor 2)/ Min.: 0 ohms, Max.: 21247.67 ohms 5 to 15000 ohms After driving for approx. 10 min. in an urban area. O2 Heater B1S2 Heated oxygen sensor heater/ ON or OFF - - O2 Heater Curr Val B1S2 Heated oxygen sensor current (for Bank 1 Sensor 2)/ Min.: 0 A, Max.: 4.99 A - - Short FT #1 Short-term fuel trim of bank 1/ Min.: -100%, Max.: 99.2% -20 to +20% This item refers to the short-term fuel compensation used to maintain the air-fuel ratio at the stoichiometric air-fuel ratio. Long FT #1 Long-term fuel trim of bank 1/ Min.: -100%, Max.: 99.2% -20 to +20% This item refers to the overall fuel compensation carried out in the long-term to compensate a continual deviation of the short-term fuel trim from the central value. Total FT #1 Total fuel trim of bank 1 Average value for fuel trim system of bank 1/ Min.: -0.5, Max.: 0.496 -0.28 to 0.2: Idling - Fuel System Status #1 Fuel system status (Bank 1)/ OL, CL, OL Drive, OL Fault or CL Fault CL: Idling after warming up OL (Open Loop): Has not yet satisfied the conditions to go to closed loop. CL (Closed Loop): Using the heated oxygen sensor as feedback for fuel control. OL Drive: Open loop due to driving conditions (fuel enrichment). OL Fault: Open loop due to a detected system fault. CL Fault: Closed loop but the heated oxygen sensor, which is used for fuel control, is malfunctioning. Fuel System Status #2 Fuel system status (Bank 2)/ OL, CL, OL Drive, OL Fault or CL Fault Unused OL (Open Loop): Has not yet satisfied the conditions to go to closed loop. CL (Closed Loop): Using the heated oxygen sensor as feedback for fuel control. OL Drive: Open loop due to driving conditions (fuel enrichment). OL Fault: Open loop due to a detected system fault. CL Fault: Closed loop but the heated oxygen sensor, which is used for fuel control, is malfunctioning. IGN Advance Ignition timing advance for No. 1 cylinder/ Min.: -64 deg., Max.: 63.5 deg. BTDC 0 to 15°: Idling - Knock Feedback Value Feedback value of knocking/ Min.: -64° CA, Max.: 1983.9° CA -20 to 0° CA: Vehicle driven at 70 km/h (44 mph) Service data. Knock Correct Learn Value Correction learned value of knocking/ Min.: -64° CA, Max.: 1983.9° CA 0 to 20° CA: Vehicle driven at 70 km/h (44 mph) Service data. Idle Spark Advn Ctrl #1 Individual cylinder timing advance compensation amount (No. 1): Min.: 0°CA, Max.: 15.93°CA - For use when engine stall, starting problems or rough idle is present. Idle Spark Advn Ctrl #2 Individual cylinder timing advance compensation amount (No. 2): Min.: 0°CA, Max.: 15.93°CA - For use when engine stall, starting problems or rough idle is present. Idle Spark Advn Ctrl #3 Individual cylinder timing advance compensation amount (No. 3): Min.: 0°CA, Max.: 15.93°CA - For use when engine stall, starting problems or rough idle is present. Idle Spark Advn Ctrl #4 Individual cylinder timing advance compensation amount (No. 4): Min.: 0°CA, Max.: 15.93°CA - For use when engine stall, starting problems or rough idle is present. ACIS VSV VSV status for ACIS control/ ON or OFF - - IAC Sensor Voltage Intake air control valve position sensor output voltage/ Min.: 0 V, Max.: 4.99 V - If valve is 0.2 V or less IAC1 circuit shorted VCIA circuit open If valve is 4.8 V or higher VCIA and IAC1 circuit short-circuited IAC1 circuit open EIA1 circuit open Intake Air Control Position Intake air control valve position/ Min.: -250°, Max.: 249.99° - - VVT Control Status #1 Variable valve timing (VVT) control status (Bank 1)/ ON or OFF - - VVT Advance Fail VVT control failure status/ ON or OFF ON: VVT control failure - VVT Aim Angle #1 VVT aim angle (Bank 1)/ Min.: 0%, Max.: 100% 0 to 100% VVT duty signal value during forced operation. VVT Change Angle #1 VVT change angle (Bank 1)/ Min.: 0° FR, Max.: 60° FR 0 to 55° FR: Idling Displacement angle during forced operation. VVT OCV Duty #1 VVT OCV operation duty (Bank 1)/ Min.: 0%, Max.: 100% 0 to 100% Requested duty value for forced operation. VVT Ex Hold Lrn Val #1 VVT exhaust hold duty ratio learned value (Bank 1)/ Min.: 0%, Max.: 100% 0 to 80%: Idling - VVT Ex Chg Angle #1 VVT exhaust change angle (for Bank 1)/ Min.: 0° FR, Max.: 60° FR 0 to 45° FR: Idling Displacement angle during forced operation. VVT Ex OCV Duty #1 VVT exhaust OCV duty (for Bank 1)/ Min.: 0%, Max.: 100% 0 to 100%: Idling Requested duty value for forced operation. VN Turbo Type Variable nozzle turbo type/ Not Avl or Commo or Vacuum or CAN Com Not Avl (Unused) - Catalyst Temp B1S1 Catalyst temperature (for Bank 1 Sensor 1)/ Min.: -40°C, Max.: 6513.5°C - - Catalyst Temp B1S2 Catalyst temperature (for Bank 1 Sensor 2)/ Min.: -40°C, Max.: 6513.5°C - - Starter Signal Starter signal/ ON or OFF ON: Cranking - Starter Control Starter switch status/ ON or OFF ON: Cranking - Power Steering Signal Record Power steering switch signal/ ON or OFF - - Starter Relay Starter relay status/ ON or OFF ON: Cranking - ACC Relay ACC relay status/ ON or OFF ON: Cranking - Neutral Position SW Signal PNP switch status/ ON or OFF ON: P or N position - Stop Light Switch Stop light switch/ ON or OFF ON: Brake pedal depressed - A/C Signal A/C switch status/ ON or OFF ON: A/C ON - Idle Up Signal Idle up signal/ ON or OFF - - Closed Throttle Position SW Closed throttle position switch/ ON or OFF ON: Throttle fully closed OFF: Throttle open - Fuel Cut Condition Fuel cut condition/ ON or OFF ON: Fuel cut operating - Immobiliser Communication Immobiliser communication/ ON or OFF ON: Normal - Check Mode Check mode/ ON or OFF ON: Check mode ON Refer to Check Mode Procedure.Refer to «CHECK MODE PROCEDURE»(ref-493432-S20362634172012081000000) . SPD Test Result Check mode result for vehicle speed sensor/ Compl or Incmpl - - Misfire Test Result Check mode result for misfire monitor/ Compl or Incmpl - - OXS1 Test Result Check mode result for heated oxygen sensor (Bank 1)/ Compl or Incmpl - - A/F Test Results #1 Check mode result for air fuel ratio sensor (Bank 1)/ Compl or Incmpl - - Complete Parts Monitor Comprehensive component monitor/ Not Avl or Avail - - Fuel System Monitor Fuel system monitor/ Not Avl or Avail - - Misfire Monitor Misfire monitor/ Not Avl or Avail - - EGR/VVT Monitor EGR/VVT monitor/ Not Avl or Avail - - EGR/VVT Monitor EGR/VVT monitor/ Compl or Incmpl - - O2S(A/FS) Heater Monitor O2S (A/FS) heater monitor/ Not Avl or Avail - - O2S(A/FS) Heater Monitor O2S (A/FS) heater monitor/ Compl or Incmpl - - O2S(A/FS) Monitor O2S (A/FS) monitor/ Not Avl or Avail - - O2S(A/FS) Monitor O2S (A/FS) monitor/ Compl or Incmpl - - A/C Monitor A/C monitor/ Not Avl or Avail - - A/C Monitor A/C monitor/ Compl or Incmpl - - 2nd Air Monitor 2nd air monitor/ Not Avl or Avail - - 2nd Air Monitor 2nd air monitor/ Compl or Incmpl - - EVAP Monitor EVAP monitor/ Not Avl or Avail - - EVAP Monitor EVAP monitor/ Compl or Incmpl - - Heated Catalyst Monitor Heated catalyst monitor/ Not Avl or Avail - - Heated Catalyst Monitor Heated catalyst monitor/ Compl or Incmpl - - Catalyst Monitor Catalyst monitor/ Not Avl or Avail - - Catalyst Monitor Catalyst monitor/ Compl or Incmpl - - Component Monitor ENA Comprehensive component monitor/ Unable or Enable - - Component Monitor CMPL Comprehensive component monitor/ Compl or Incmpl - - Fuel System Monitor ENA Fuel system monitor/ Unable or Enable - - Fuel System Monitor CMPL Fuel system monitor/ Compl or Incmpl - - Misfire Monitor ENA Misfire monitor/ Unable or Enable - - Misfire Monitor CMPL Misfire monitor/ Compl or Incmpl - - EGR/VVT Monitor ENA EGR/VVT monitor/ Unable or Enable - - EGR/VVT Monitor CMPL EGR/VVT monitor/ Compl or Incmpl - - Heater Monitor ENA O2S (A/FS) heater monitor/ Unable or Enable - - Heater Monitor CMPL O2S (A/FS) heater monitor/ Compl or Incmpl - - O2S(A/FS) Monitor ENA O2S (A/FS) monitor/ Unable or Enable - - O2S(A/FS) Monitor CMPL O2S (A/FS) monitor/ Compl or Incmpl - - A/C Monitor ENA A/C monitor/ Unable or Enable - - A/C Monitor CMPL A/C monitor/ Compl or Incmpl - - 2nd Air Monitor ENA 2nd air monitor/ Unable or Enable - - 2nd Air Monitor CMPL 2nd air monitor/ Compl or Incmpl - - EVAP Monitor ENA EVAP monitor/ Unable or Enable - - EVAP Monitor CMPL EVAP monitor/ Compl or Incmpl - - Heated Cat Monitor ENA Heated catalyst monitor/ Unable or Enable - - Heated Cat Monitor CMPL Heated catalyst monitor/ Compl or Incmpl - - Catalyst Monitor ENA Catalyst monitor/ Unable or Enable - - Catalyst Monitor CMPL Catalyst monitor/ Compl or Incmpl - - TC Terminal TC terminal status/ ON or OFF - - # Codes (Include History) Number of codes/ Min.: 0, Max.: 255 - The number of stored DTCs. MIL MIL status/ ON or OFF ON: MIL on - MIL ON Run Distance MIL on run distance/ Min.: 0 km, Max.: 65535 km Distance after DTC stored - Running Time from MIL ON Running time from MIL on/ Min.: 0 minutes, Max.: 65535 minutes Equivalent to running time after MIL on - Time after DTC Cleared Time after DTC cleared/ Min.: 0 minutes, Max.: 65535 minutes Equivalent to time after DTCs cleared - Distance from DTC Cleared Distance after DTC cleared/ Min.: 0 km, Max.: 65535 km Equivalent to driven distance after DTCs cleared - Warmup Cycle Cleared DTC Warm-up cycle after DTC cleared/ Min.: 0, Max.: 255 - The number of warm-up cycles after the DTC is cleared. Dist Batt Cable Disconnect Distance after battery cable disconnected/ Min.: 0 km, Max.: 65535 km Total distance vehicle driven after battery cable disconnected - IG OFF Elapsed Time Time after ignition switch off/ Min.: 0 minutes, Max.: 655350 minutes Cumulative time after ignition switch off - OBD Requirements OBD requirement OBD2 - Number of Emission DTC Emission-related DTCs - The number of emission-related DTCs. TC and TE1 TC and TE1 terminal of DLC3/ ON or OFF - - Ignition Trig. Count Ignition counter/ Min.: 0, Max.: 800 0 to 800 - Cylinder #1 Misfire Count to Cylinder #4 Misfire Count Misfire counter of cylinder 1 to 4/ Min.: 0, Max.: 255 0 to 16 - All Cylinders Misfire Count All cylinders misfire counter/ Min.: 0, Max.: 255 0 to 16 - Misfire RPM Engine speed for first misfire range/ Min.: 0 rpm, Max.: 6375 rpm 0 rpm: Misfire 0 - Misfire Load Engine load for first misfire range/ Min.: 0 g/rev, Max.: 3.98 g/rev 0 g/rev: Misfire 0 - Misfire Margin Misfire monitoring/ Min.: -100%, Max.: 99.21% -100 to 99.2% The misfire detecting margin. Catalyst OT MF F/C Catalyst over temperature misfire prevention F/C/ Not Avl or Avail Avail: Cat OT MF F/C available Not Avl: Cat OT MF F/C not available - Cat OT MF F/C History Catalyst over temperature misfire prevention F/C history/ ON or OFF ON: Fuel cut operation history exists - Cat OT MF F/C Cylinder #1 Display of fuel cut operation in No. 1 cylinder (if certain level of misfire malfunction is detected)/ ON or OFF ON: Fuel cut operating - Cat OT MF F/C Cylinder #2 Display of fuel cut operation in No. 2 cylinder (if certain level of misfire malfunction is detected)/ ON or OFF ON: Fuel cut operating - Cat OT MF F/C Cylinder #3 Display of fuel cut operation in No. 3 cylinder (if certain level of misfire malfunction is detected)/ ON or OFF ON: Fuel cut operating - Cat OT MF F/C Cylinder #4 Display of fuel cut operation in No. 4 cylinder (if certain level of misfire malfunction is detected)/ ON or OFF ON: Fuel cut operating - Engine Speed (Starter Off) Engine speed when starter off/ Min.: 0 rpm, Max.: 51199 rpm - For use when engine stall, starting problems or rough idle is present. Starter Count Number of times starter turned on after ignition switch turned to ON/ Min.: 0, Max.: 255 - For use when engine stall, starting problems or rough idle is present. Run Dist of Previous Trip Distance driven during previous trip/ Min.: 0 km, Max.: 655.35 km - Before 5 seconds elapse after starting the engine, which is the DTC P1604 (Startability Malfunction) detection duration, this parameter indicates the distance driven during the previous trip. After 5 seconds elapse after starting the engine, this parameter indicates the distance driven during the current trip calculated from the vehicle speed signal. HINT: Run Dist of Previous Trip in the freeze frame data present when the startability malfunction occurred (DTC P1604 detected) indicates the distance driven during the previous trip, but in all other cases, such as for the snapshot data of the Data List (real-time measurements), or for freeze frame data present when DTCs other than P1604 were detected, the value indicates the distance driven during the current trip. Engine Starting Time Time elapsed after engine started (interval between ignition switch ON and off)/ Min.: 0 ms, Max.: 655350 ms - For use when engine stall, starting problems or rough idle is present. Previous Trip Coolant Temp Engine coolant temperature during previous trip/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Previous Trip Intake Temp Intake air temperature during previous trip/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Engine Oil Temperature Engine oil temperature (estimated temperature)/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Previous Trip Eng Oil Temp Engine oil temperature during previous trip/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Ambient Temp for A/C Ambient temperature for A/C/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Previous Trip Ambient Temp Ambient temperature during previous trip/ Min.: -40°C, Max.: 215°C - For use when engine stall, starting problems or rough idle is present. Engine Start Hesitation History of hesitation during engine start/ ON or OFF - - Low Rev for Eng Start History of low engine speed after engine start/ ON or OFF - - Minimum Engine Speed Minimum engine speed/ Min.: 0 rpm, Max.: 51199 rpm - For use when engine stall, starting problems or rough idle is present. Fuel Cut Elps Time Time elapsed after engine runs at high speed/ Min.: 0 sec, Max.: 68746 sec - The time elapsed after a fuel cut after high engine speed has occurred (more than the rpm at which fuel cut occurs + 500 rpm). Tumble C.V Duty Ratio Intake air control valve duty ratio/ Min.: -128%, Max.: 127% - - Electric Fan Motor Electric fan motor status/ ON or OFF - - Brake Override System Brake override system status/ ON or OFF ON: Brake override system operating - Idle Fuel Cut Fuel cut idle/ ON or OFF ON: Fuel cut operating Idle Fuel Cut is "ON" when the throttle valve is fully closed and the engine speed is more than 2800 rpm. FC TAU Fuel cut TAU: Fuel cut during very light load/ ON or OFF ON: Fuel cut operating The fuel cut being performed under a very light load to prevent the engine combustion from becoming incomplete. Immobiliser Fuel Cut Status of the immobiliser fuel cut/ ON or OFF - - Immobiliser Fuel Cut History Status of the immobiliser fuel cut history/ ON or OFF - - Electrical Load Signal 1 Electrical load signal/ ON or OFF - - Electrical Load Signal 3 Electrical load signal/ ON or OFF - - Model Code Model code - The identifying model code: ASA3# Engine Type Engine type - The identifying engine type: 2ARFE Cylinder Number Number of cylinders/ Min.: 0, Max.: 255 - The identifying number of cylinders: 4 Transmission Type Transmission type - The identifying transmission type: ECT 4th Destination Destination - The identifying destination: A (America) Model Year Model year/ Min.: 1900, Max.: 2155 - The identifying model year: 201# Engine Speed of Cyl #1 Engine speed for cylinder 1/ Min.: 0 rpm, Max.: 25600 rpm - Output only when Check the Cylinder Compression is performed using the Active Test. Engine Speed of Cyl #2 Engine speed for cylinder 2/ Min.: 0 rpm, Max.: 25600 rpm - Output only when Check the Cylinder Compression is performed using the Active Test. Engine Speed of Cyl #3 Engine speed for cylinder 3/ Min.: 0 rpm, Max.: 25600 rpm - Output only when Check the Cylinder Compression is performed using the Active Test. Engine Speed of Cyl #4 Engine speed for cylinder 4/ Min.: 0 rpm, Max.: 25600 rpm - Output only when Check the Cylinder Compression is performed using the Active Test. Av Engine Speed of All Cyl Engine speed for all cylinders/ Min.: 0 rpm, Max.: 25600 rpm - Output only when Check the Cylinder Compression is performed using the Active Test. HINT: *: Excluding throttle valve opening percentage due to Idle Speed Control (ISC). Normal Condition: If no idling conditions are specified, make sure the shift lever is in N or P, and the A/C switch and all accessory switches are off.
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. Tester Display Test Part Control Range Diagnostic Note Control the Injection Volume Change injection volume -12.5 to 24.8% All the injectors are tested at the same time. Perform the test at less than 3000 rpm. The injection volume can be changed in 1% graduations within the control range. Control the Injection Volume for A/F Sensor Change injection volume -12.5, 0 or +12.5% Perform the test at less than 3000 rpm. Control the Injection Volume for A/F Sensor enables the checking and graphing of the A/F (Air Fuel Ratio) sensor and Heated Oxygen (HO2) sensor voltage outputs. To conduct the test, enter the following menus: Active Test / Control the Injection Volume for A/F Sensor / Data List / A/F Control System / AFS Voltage B1S1 and O2S B1S2. Activate the VSV for Intake Control Activate VSV for intake control ON/OFF - Activate the VSV for Evap Control Activate purge VSV control ON/OFF - Control the Fuel Pump / Speed Activate fuel pump (C/OPN Relay) ON/OFF The test is possible when the following conditions are met: The ignition switch is ON. The engine is stopped. Connect the TC and TE1 Turn on and off TC and CG (TE1) connection ON/OFF ON: TC and TE1 are connected. OFF: TC and TE1 are disconnected. Control the Idle Fuel Cut Prohibit Prohibit idling fuel cut control ON/OFF The idling fuel-cut is turned ON when the throttle valve is fully closed and the engine speed is more than 2800 rpm. Prohibit the Catalyst OT Misfire prevent F/C Prohibit catalyst overheat malfunction prevention fuel cut operation during misfire ON/OFF ON: Fuel cut prohibited Confirm that the vehicle is stopped and the engine speed is 3000 rpm or less. Control the Electric Cooling Fan Control electric cooling fan motor ON/OFF - Activate the Starter Relay Activate the starter relay ON/OFF The engine is stopped. Activate the ACC Cut Relay Activate the ACC CUT relay ON/OFF The engine is stopped. Control the ETCS Open/Close Slow Speed Throttle actuator Close/Open The test is possible when the following conditions are met: The ignition switch is ON. The engine is stopped. The accelerator pedal is fully depressed (APP: 58 degrees or more). Control the ETCS Open/Close Fast Speed Throttle actuator Close/Open Control the VVT Linear (Bank1) Control VVT (Bank 1) Between -128 and 127% The engine stalls or idles roughly when the VVT actuator is operated at 100%. The test is possible during idle. DTCs related to the VVT system may be stored due to Active Test operation, but this does not indicate a malfunction. Control the VVT System (Bank1) Turn on and off OCV (Camshaft Timing Oil Control Valve) ON/OFF The engine stalls or idles roughly when the OCV is turned ON. The engine is running and idles normally when the OCV is OFF. The test is possible during idle. DTCs related to the VVT system may be stored due to Active Test operation, but this does not indicate a malfunction. Control the VVT Exhaust Linear (Bank 1) Control VVT (Bank 1) Between -128 and 127% The engine stalls or idles roughly when the VVT actuator is operated at 100%. The test is possible during idle. DTCs related to the VVT system may be stored due to Active Test operation, but this does not indicate a malfunction. Activate the Vacuum Pump Leak detection pump ON/OFF - Activate the VSV for Vent Valve Vent valve ON/OFF - Control the IAC Duty Ratio Control intake air control valve duty ratio Between -100 and 100% - Control the Select Cylinder Fuel Cut Selected cylinder (cylinder #1 to #4) injector fuel cut #1/#2/#3/#4 ON/OFF The test is possible while the vehicle is stopped and the engine is idling.*1 Control the All Cylinders Fuel Cut All cylinder fuel cut ON/OFF The test is possible while the vehicle is stopped and the engine is idling.*1 Check the Cylinder Compression*2 Check the cylinder compression pressure (measuring engine speed for each cylinder) ON/OFF Fuel injection and ignition stop in all the cylinders. NOTE: *1: If the display of the Catalyst OT MF F/C item of the Data List is Not Avl, perform this Active Test with the vehicle stopped and the engine idling. If the display of the Catalyst OT MF F/C item of the Data List is Avail, perform this Active Test as described below. Stop the engine and turn the ignition switch to ON to turn Control the Cylinder #1 Fuel Cut (to Control the Cylinder #4 Fuel Cut) ON. Start the engine. HINT: *2: When cranking the engine, each cylinder measures the engine speed. In this Active Test, the fuel and ignition of all cylinders is cut. The engine must then be cranked for approximately 10 seconds. At this time, the speed of each cylinder is measured. If the speed of one cylinder is more than the other cylinders, it can be determined that the compression pressure of that cylinder is lower than the other cylinders. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Check the Cylinder Compression. HINT: To display the entire Data List, press the pull down menu button next to Primary. Then select Compression. Push the snapshot button to turn the snapshot function on. HINT: Using the snapshot function, data can be recorded during the Active Test. While the engine is not running, press the RIGHT or LEFT button to change Check the Cylinder Compression to ON. HINT: After performing the above procedure, Check the Cylinder Compression will start. Fuel injection for all cylinders is prohibited and each cylinder engine speed measurement enters standby mode. Crank the engine for about 10 seconds. HINT: Continue to crank the engine until the values change from the default value (51199 rpm). NOTE: Do not crank the engine continuously for 20 seconds or more. If it is necessary to crank the engine again after Check the Cylinder Compression has been changed to ON and the engine has been cranked once, press Exit to return to the Active Test menu screen. Then change Check the Cylinder Compression to ON and crank the engine. Use a fully-charged battery. Monitor the engine speed (Engine Speed of Cyl #1 to #4) displayed on the Techstream. HINT: At first, the Techstream displays extremely high cylinder engine speed values. After approximately 10 seconds of engine cranking, each cylinder engine speed measurement will change to the actual engine speed. Stop cranking the engine, and then change "Check the Cylinder Compression" to OFF after the engine stops. NOTE: If the Active Test is changed to OFF while the engine is being cranked, the engine will start. Push the snapshot button to turn the snapshot function off. Select "Stored Data" on the Techstream screen, select the recorded data and display the data as a graph. HINT: If the data is not displayed as a graph, the change of the values cannot be observed. Check the change in engine speed values. HINT: As the data values of the Active Test return to their default values when cranking is stopped, the engine speed value of each cylinder cannot be observed. Therefore, it is necessary to use the data recorded with the snapshot function to check the engine speed values recorded during cranking.
3. SYSTEM CHECK (Only for Techstream) HINT: Performing a System Check in the Utility menu enables the system, which consists of multiple actuators, to be operated without removing any parts. In addition, it can show whether or not any DTCs are stored, and can detect potential malfunctions in the system. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility. Perform the System Check by referring to the table below. Tester Display Test Part Control Range Diagnostic Note Evaporative System Check (Automatic Mode) Perform 6 steps in order to operate EVAP key-off monitor automatically 35°C (95°F) or less If no DTCs in Pending after performing this test, system functioning normally Refer to EVAP System.Refer to «EVAP System»(ref-493439-S42578108452012081000000) Evaporative System Check (Manual Mode) Perform 6 steps in order to operate EVAP key-off monitor manually 35°C (95°F) or less Used to detect malfunctioning parts Refer to EVAP System.Refer to «EVAP System»(ref-493439-S42578108452012081000000)
