Engine Control System (2AR-FE) (P0365-P1603) (Diagnostic Codes): Other Toyota RAV4 IV

Testing & Diagnostics 17 illustrations ~10407 words

MONITOR STRATEGY

Related DTCsP0365: Exhaust camshaft position sensor range check (running) P0367: Exhaust camshaft position sensor range check (Low voltage) P0368: Exhaust camshaft position sensor range check (High voltage)
Required Sensors/Components (Main)Exhaust camshaft position sensor
Required Sensors/Components (Related)Crankshaft position sensor
Frequency of OperationContinuous
Duration5 seconds: Exhaust camshaft position sensor range check (running) (P0365) 4 seconds: Exhaust camshaft position sensor range check (P0367, P0368)
MIL OperationImmediate
Sequence of OperationNone

TYPICAL ENABLING CONDITIONS

Monitor runs whenever following DTCs not storedP0367, P0368 (Exhaust Camshaft Position Sensor)
Engine speed600 rpm or more
Ignition switchON
StarterOFF
Battery voltage8 V or higher
Exhaust camshaft position sensor voltage0.3 to 4.7 V

P0365 EXHAUST CAMSHAFT POSITION SENSOR RANGE CHECK (RUNNING)

Monitor runs whenever following DTCs not storedP0365 (Exhaust Camshaft Position Sensor)
StarterOFF
Ignition switchON
Time after ignition switch turned from off to ON2 seconds or more
Battery voltage8 V or higher

P0367, P0368 EXHAUST CAMSHAFT POSITION SENSOR RANGE CHECK

TYPICAL MALFUNCTION THRESHOLDS

Exhaust camshaft position signalNo signal

P0365 EXHAUST CAMSHAFT POSITION SENSOR RANGE CHECK (RUNNING)

Exhaust camshaft position sensor voltageBelow 0.3 V

P0367 EXHAUST CAMSHAFT POSITION SENSOR RANGE CHECK (LOW VOLTAGE)

Exhaust camshaft position sensor voltageHigher than 4.7 V

P0368 EXHAUST CAMSHAFT POSITION SENSOR RANGE CHECK (HIGH VOLTAGE)

COMPONENT OPERATING RANGE

Exhaust camshaft position sensorExhaust camshaft position sensor output voltage fluctuates while camshaft revolving 3 exhaust camshaft position sensor signals per 2 crankshaft revolutions
Exhaust camshaft position sensor voltage0.3 to 4.7 V

Scheme 380

Scheme 380: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Start the engine.
  5. Idle the engine for 10 seconds or more [B].
  6. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  7. Input the DTC: P0365, P0367 or P0368.
  8. Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
  9. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  10. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  11. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP0420: Catalyst Deterioration
Required Sensors/Components (Main)Air fuel ratio sensor Heated oxygen sensor
Required Sensors/Components (Related)Intake air temperature sensor Mass air flow meter Crankshaft position sensor Engine coolant temperature sensor
Frequency of OperationOnce per driving cycle
DurationApproximately 30 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs not storedP0010 (VVT Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0013 (Exhaust VVT Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0017 (Exhaust VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0037, P0038, P102D (Rear Oxygen Sensor Heater) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0136, P0137, P0138, P0139, P0607 (Rear Oxygen Sensor) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0351 - P0354 (Igniter) P0500 (Vehicle Speed Sensor)
Battery voltage11 V or higher
Intake air temperature10°C (14°F) or higher
Engine coolant temperature75°C (167°F) or higher
Atmospheric pressure76 kPa (570 mmHg) or higher
IdlingOFF
Engine speedLess than 4000 rpm
Air fuel ratio sensor statusActivated
Fuel system statusClosed loop
Engine load10 to 80%
All of the following conditions are metCondition 1, 2 and 3
1. Mass air flow rate2.5 to 60 g/sec
2. Front catalyst temperature (estimated)620 to 865°C (1148 to 1589°F)
3. Rear catalyst temperature (estimated)400 to 770°C (752 to 1418°F)
Shift position4th or higher
Oxygen Storage Capacity (OSC) of Three-Way Catalytic Converter (TWC)Less than 0.14 g

MONITOR RESULT

Refer to Checking Monitor Status.Refer to CHECKING MONITOR STATUS .

CONFIRMATION DRIVING PATTERN

HINT

Performing this confirmation pattern will activate the catalyst monitor. This is very useful for verifying the completion of a repair.

Scheme 381

Scheme 381: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON.
  3. Turn the Techstream on.
  4. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  5. Enter the following menus: Powertrain / Engine and ECT / Monitor.
  6. Check that Catalyst / Status 2 is Incomplete.
  7. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
  8. Drive the vehicle at between 64 and 113 km/h (40 and 70 mph) for at least 10 minutes or more [B].
  9. The monitor items will change to Complete as Catalyst monitor operates.
  10. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
  11. Check if any DTCs (pending DTCs) are set.

HINT

If Catalyst does not change to Complete, and no pending DTCs are stored, extend the driving time.

PROCEDURE

  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0420 A P0420 and other DTCs B HINT: If any DTCs other than P0420 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
  2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine and warm it up. Turn the Techstream on. Run the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F sensor. Perform the Active Test operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio sensor and heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Standard Tester Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (A/F) +25% Rich Below 3.1 V -12.5% Lean Higher than 3.4 V O2S B1S2 (HO2) +25% Rich Higher than 0.55 V -12.5% Lean Below 0.4 V RESULT Status AFS Voltage B1S1 Status O2S B1S2 A/F Condition and A/F and HO2 Sensors Condition Misfire Main Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Three-Way Catalytic Converter (TWC) Gas leak from exhaust system A Lean Lean/Rich A/F sensor malfunction - A/F sensor B Rich Lean/Rich A/F sensor malfunction - A/F sensor Lean/Rich Lean HO2 sensor malfunction - HO2 sensor Gas leak from exhaust system C Lean/Rich Rich HO2 sensor malfunction - HO2 sensor Gas leak from exhaust system Lean Lean Actual air-fuel ratio lean May occur Extremely rich or lean actual air-fuel ratio Gas leak from exhaust system D Rich Rich Actual air-fuel ratio rich - Extremely rich or lean actual air-fuel ratio Gas leak from exhaust system Lean: During Control the Injection Volume for A/F sensor, the A/F sensor output voltage (AFS Voltage) is consistently higher than 3.4 V, and the HO2 sensor output voltage (O2S) is consistently below 0.4 V. Rich: During Control the Injection Volume for A/F sensor, the AFS Voltage is consistently below 3.1 V, and the O2S is consistently higher than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F sensor of the Active Test, the output voltage of the HO2 sensor alternates correctly. B --> See step 5 C --> See step 9 D --> See step 6 A: Go to next step
  3. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leak. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
  4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493432-S02175369332012081000000)
  5. REPLACE AIR FUEL RATIO SENSOR (SENSOR 1). Refer to «REMOVAL»(ref-493433-S13636630482012081000000)
  6. GO TO NEXT STEP AFTER CHECKING ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-493440-S17883421332012081000000)
  7. REPLACE EXHAUST MANIFOLD CONVERTER SUB-ASSEMBLY (TWC: FRONT CATALYST) Replace the exhaust manifold converter sub-assembly.Refer to «REMOVAL»(ref-493450-S28060751972012081000000) . NEXT --> See step 8
  8. REPLACE CENTER EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST). Refer to «REMOVAL»(ref-493450-S32279710002012081000000)
  9. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leak. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK --> See step 10
  10. REPLACE HEATED OXYGEN SENSOR (SENSOR 2). Refer to «REMOVAL»(ref-493433-S35123086992012081000000)
Required Sensors/ComponentsCanister pump module
Frequency of OperationOnce per driving cycle
DurationWithin 2 minutes
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs not storedP0451, P0452, P0453 (EVAP System)
EVAP key-off monitor runs when all of following conditions met
Atmospheric pressure70 to 110 kPa-a (525 to 825 mmHg-a)
Battery voltage10.5 V or higher
Vehicle speedLess than 4 km/h (2.5 mph)
Ignition switchOff
Time after key-off5, 7 or 9.5 hours
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of following conditions met before key-offConditions 1 and 2
1. Duration that vehicle is driven5 minutes or more
2. EVAP purge operationPerformed
ECT4.4 to 35°C (40 to 95°F)
IAT4.4 to 35°C (40 to 95°F)

"Saturated" indicates that the EVAP pressure change is below 0.286 kPa-g (2.14 mmHg-g) in 60 seconds.

One of following conditions met
EVAP pressure just after reference pressure measurement startedHigher than -1 kPa-g (-7.5 mmHg-g)
Reference pressureBelow -4.85 kPa-g (-36.4 mmHg-g)
Reference pressure1.057 kPa-g (-7.93 mmHg-g) or higher
Reference pressureNot saturated within 60 seconds
Reference pressure difference between first and second0.9 kPa-g (6.75 mmHg-g) or higher

Refer to CHECKING MONITOR STATUS.Refer to CHECKING MONITOR STATUS .

Scheme 382

Scheme 382: CONFIRMATION DRIVING PATTERN

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
  5. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All readiness.
  6. Input the DTC: P043E, P043F, P2401, P2402 or P2419.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to Checking Monitor Status.Refer to CHECKING MONITOR STATUS .

Scheme 383

Scheme 383: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Start the engine and wait 15 minutes or more [B].
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
  6. Input the DTC: P0441.
  7. Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed You should perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NOTE: The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
  8. Turn the ignition switch to ON and turn the Techstream on.
  9. Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation) [D].
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
  11. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  12. Input the DTC: P0441.
  13. Check the DTC judgment result [E]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  14. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  15. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  16. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Required Sensors/ComponentsCanister pump module
Frequency of OperationOnce per driving cycle: P0451 sensor fixed/flat Continuous: P0451 sensor noise, P0452 and P0453
Duration0.5 seconds: P0452 and P0453 2 minutes: P0451
MIL OperationImmediate: P0452 and P0453 2 driving cycles: P0451
Sequence of OperationNone
Monitor runs whenever following DTCs not storedP0452, P0453 (EVAP System)
Atmospheric pressure (absolute pressure)70 to 110 kPa-a (525 to 825 mmHg-a)
Battery voltage10.5 V or higher
Intake air temperature4.4 to 50°C (40 to 122°F)
Either of following conditions metA or B
A. Engine conditionRunning
B. Time after key-off5, 7 or 9.5 hours

P0451 (NOISE MONITOR)

Monitor runs whenever following DTCs not storedP0452, P0453 (EVAP System)
Battery voltage10.5 V or higher
Intake air temperature4.4 to 50°C (40 to 122°F)
Atmospheric pressure (absolute pressure)70 to 110 kPa-a (525 to 825 mmHg-a)
Time after key-off5, 7 or 9.5 hours

P0451 (FIXED/FLAT MONITOR)

Monitor runs whenever following DTCs not storedNone
Either of following conditions met(a) or (b)
(a) Ignition switchON
(b) Soak timerON

P0452 AND P0453

Frequency that EVAP pressure change 0.3 kPa-g (2.25 mmHg-g) or higher10 times or more in 10 seconds

P0451: CANISTER PRESSURE SENSOR NOISE

EVAP pressure change during reference pressure measurementBelow 0.65 kPa-g (4.87 mmHg-g)

P0451: CANISTER PRESSURE SENSOR FIXED/FLAT

EVAP pressureBelow 42.1 kPa-a (315.7 mmHg-a)

P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE

EVAP pressureHigher than 123.8 kPa-a (928.5 mmHg-a)

P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Enter the following menus: Powertrain / Engine and ECT / Data List / Intake Air.
  4. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
  6. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All readiness.
  7. Input the DTC: P0451, P0452 or P0453.
  8. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  9. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  10. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  11. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 384

Scheme 384: WIRING DIAGRAM
Required Sensors/ComponentsPurge VSV and canister pump module
Frequency of OperationOnce per driving cycle
DurationWithin 15 minutes (varies with amount of fuel in tank)
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs not storedP0451, P0452, P0453 (EVAP System)
EVAP key-off monitor runs when all of following conditions met
Atmospheric pressure70 to 110 kPa-a (525 to 825 mmHg-a)
Battery voltage10.5 V or higher
Vehicle speedLess than 4 km/h (2.5 mph)
Ignition switchOff
Time after key-off5, 7 or 9.5 hours
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of following conditions met before-key offConditions 1 and 2
1. Duration that vehicle is driven5 minutes or more
2. EVAP purge operationPerformed
ECT4.4 to 35°C (40 to 95°F)
IAT4.4 to 35°C (40 to 95°F)

P0455 (PATTERN A), P0456

Monitor runs whenever following DTCs not storedP0451, P0452, P0453 (EVAP System)
Atmospheric pressure70 to 110 kPa-a (525 to 825 mmHg-a)
Battery voltage10.5 V or higher
Vehicle speedLess than 4 km/h (2.5 mph)
Ignition switchOff
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of following conditions met before key-offConditions 1 and 2
1. Duration that vehicle driven5 minutes or more
2. EVAP purge operationPerformed
ECT4.4 to 45°C (40 to 113°F)
IAT4.4 to 45°C (40 to 113°F)

P0455 (PATTERN B)

EVAP pressure when vacuum introduction completeHigher than [reference pressure x 0.2]

P0455: EVAP GROSS LEAK

EVAP pressure when vacuum introduction completeBetween reference pressure and [reference pressure x 0.2]

P0456: EVAP SMALL LEAK

Refer to Checking Monitor Status.Refer to CHECKING MONITOR STATUS .

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
  5. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P0455 or P0456.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP0500: Vehicle speed sensor "A" pulse input error
Required Sensors/Components (Main)Vehicle Speed Sensor (VSS) Combination meter Skid control ECU
Required Sensors/Components (Related)Park/Neutral Position (PNP) switch Engine Coolant Temperature (ECT) sensor Crankshaft Position (CKP) sensor Throttle Position (TP) sensor Mass Air Flow (MAF) meter
Frequency of OperationContinuous
Duration2 seconds
MIL OperationImmediate
Sequence of OperationNone
Monitor runs whenever following DTCs not storedNone
Time after ignition switch turned from off to ON3 seconds or more
Battery voltage8 V or higher
Ignition switchON
StarterOFF
EngineRunning
Transmission counter gear revolution300 rpm or more
When either condition below is metCondition A or B
A. When both conditions below are met
Engine coolant temperature20°C (68°F) or higher
Time after park/neutral position switch turned from on to off2 seconds or more
B. When both conditions below are met
Engine coolant temperatureBelow 20°C (68°F)
Time after park/neutral position switch turned from on to off30 seconds or more
Vehicle speed sensor signalNo pulse input

Scheme 385

Scheme 385: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Start the engine.
  5. Drive the vehicle at 24 km/h (15 mph) or more for a total of 30 seconds or more [B].
  6. Stop the vehicle.
  7. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  8. Input the DTC: P0500.
  9. Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  10. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  11. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  12. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 386

Scheme 386: WIRING DIAGRAM
Related DTCsP0505: ISC function
Required Sensors/Components (Main)ETCS (Electronic Throttle Control System)
Required Sensors/Components (Related)Crankshaft position sensor Engine coolant temperature sensor Vehicle speed sensor
Frequency of OperationOnce per driving cycle
Duration10 minutes
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs not storedP0010 (VVT Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0013 (Exhaust VVT Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0017 (Exhaust VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0351 - P0354 (Igniter) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) P0705 (Shift Lever Position Switch) P0748, P0778 (Pressure Control Solenoid) P0982, P0983 (Shift Solenoid)
EngineRunning
Either condition is met1 or 2
1. Both of following conditions A and B met
A. Engine speed - Target engine speedLess than -100 rpm, or more than 150 rpm (A/C off and NSW off) Less than -100 rpm, or more than 200 rpm (A/C on or NSW on)
B. IAC flow rate learned value0.9 L/sec. or less, or 6 L/sec. or more for 5 seconds or more
2. Both of following conditions C and D met
C. Frequency that both of following conditions (a) and (b) met5 times or more
(a) Engine speed - Target engine speedLess than -100 rpm, or more than 150 rpm (A/C off and NSW off) Less than -100 rpm, or more than 200 rpm (A/C on or NSW on)
(b) Vehicle conditionStopped after being driven at 10 km/h (6.25 mph) or more
D. Either condition is met(c) or (d)
(c) IAC flow rate learned value0.9 L/sec. or less, or 6 L/sec. or more
(d) Amount of change of IAC flow rate learned value+2.56 L/sec. or more, or -2.56 L/sec. or less

Scheme 387

Scheme 387: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or more) with all the accessories switched off [B].
  5. Idle the engine for 10 minute or more [C].
  6. Accelerate the vehicle to 10 km/h (6.25 mph) or more, and then idle the engine [D].
  7. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  8. Input the DTC: P0505.
  9. Check the DTC judgment result [E]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, repeat step [D] 4 times, allowing 20 seconds or more between each repetition, and then check the DTC judgment result [F].
  10. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  11. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  12. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0505 A P0505 and other DTCs B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
  2. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> See step 6 OK: Go to next step
  3. CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage.Refer to «ON-VEHICLE INSPECTION»(ref-493442-S42628386862012081000000) . OK No leakage from air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
  4. INSPECT THROTTLE BODY (THROTTLE VALVE) Check the throttle valve condition. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 7 OK --> See step 8
  5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493432-S02175369332012081000000)
  6. REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL»(ref-493428-S24242854822012081000000)
  7. REPLACE THROTTLE BODY. Refer to «REMOVAL»(ref-493433-S25324289982012081000000)
  8. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
Related DTCsP050A: Cold start idle air speed control system
Required Sensors/Components (Main)Throttle body
Required Sensors/Components (Related)Mass air flow meter Engine Coolant Temperature (ECT) sensor
Frequency of OperationOnce per driving cycle
Duration10 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs not storedP0010 (VVT Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0013 (Exhaust VVT Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0017 (Exhaust VVT System - Misalignment) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0365, P0367, P0368 (Exhaust VVT Sensor) P0351 - P0354 (Igniter) P0500 (Vehicle Speed Sensor) P0705 (Shift Lever Position Switch)
Battery voltage8 V or higher
Time after engine start3 seconds or more
StarterOFF
ECT at engine start10°C (14°F) or higher
ECT10 to 50°C (14 to 122°F)
Engine idling time3 seconds or more
Fuel-cutOFF
Vehicle speedLess than 3 km/h (1.875 mph)
Time after shift position changed1 second or more
Atmospheric pressure76 kPa (570 mmHg) or higher
Accumulated mass air flowVaries with ECT (Example: Less than 21.9 g)

Scheme 388

Scheme 388: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
  5. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C.
  6. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
  7. Idle the engine for 1 minute or more [B].
  8. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  9. Input the DTC: P050A.
  10. Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C].
  11. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  12. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  13. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP050B: Cold start ignition timing performance
Required Sensors/Components (Main)Throttle with motor body assembly
Required Sensors/Components (Related)Mass air flow meter Engine Coolant Temperature (ECT) sensor
Frequency of OperationOnce per driving cycle
Duration10 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs not storedP0010 (VVT Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0013 (Exhaust VVT Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0017 (Exhaust VVT System - Misalignment) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0351 - P0354 (Igniter) P0500 (Vehicle Speed Sensor) P0705 (Shift Lever Position Switch)
Battery voltage8 V or higher
Time after engine start3 seconds or more
StarterOFF
ECT at engine start10°C (14°F) or higher
ECT10 to 50°C (14 to 122°F)
Engine idling time3 seconds or more
Fuel-cutOFF
Vehicle speedLess than 3 km/h (1.875 mph)
Atmospheric pressure76 kPa (570 mmHg) or higher
Accumulated time when ignition timing retard value is cut off5 seconds or more
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
  5. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C.
  6. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
  7. Idle the engine for 1 minute or more [B].
  8. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  9. Input the DTC: P050B.
  10. Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C].
  11. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  12. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  13. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P050B is output A P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 20 A: Go to next step
  2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine and warm it up. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Short FT #1 and Long FT #1. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1 values to obtain the total Fuel Trim OK Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
  3. INSPECT THROTTLE BODY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. OK --> See step 14 NG --> See step 4
  4. REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly.Refer to «REMOVAL»(ref-493433-S25324289982012081000000) . NEXT --> See step 14
  5. CHECK PCV HOSE Check the PCV hose connections.Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-493442-S03721092742012081000000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 10 OK: Go to next step
  6. CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. OK No leaks in the air induction system. NG --> See step 11 OK: Go to next step
  7. INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK The air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
  8. PERFORM ACTIVE TEST USING TECHSTREAM (OCV OPERATION) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Tester Operation Specified Condition OCV OFF Normal engine speed OCV ON Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 13 OK: Go to next step
  9. READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 9.38 g/sec. and 14.08 g/sec. (shift lever: N; A/C: Off). OK --> See step 14 NG --> See step 15
  10. REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 14
  11. REPAIR OR REPLACE AIR INDUCTION SYSTEM Repair or replace the air induction system. NEXT --> See step 14
  12. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
  13. CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
  14. CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 15 A --> See step 22
  15. CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM.Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-493289-S18206983812012081000000) . HINT: Repair any problems. NEXT: Go to next step
  16. CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
  17. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B1-5 (VG) - B30-94 (VG) Always Below 1 ohms B1-4 (E2G) - B30-117 (E2G) Always Below 1 ohms B1-5 (VG) or B30-94 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  18. REPLACE MASS AIR FLOW METER Replace the mass air flow meter.Refer to «REMOVAL»(ref-493433-S16373475662012081000000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter assembly. NEXT: Go to next step
  19. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 21 A --> END
  20. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493432-S02175369332012081000000)
  21. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
  22. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493432-S11365856792012081000000)
Related DTCsP0560: ECM system voltage
Required Sensors/Components (Main)ECM
Required Sensors/Components (Related)
Frequency of OperationContinuous
Duration3 seconds
MIL OperationImmediate (MIL illuminated after next engine start)
Sequence of OperationNone
Monitor runs whenever following DTCs not storedNone
ECM power sourceBelow 3.5 V

Scheme 389

Scheme 389: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Wait 5 seconds or more.
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P0560.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 390

Scheme 390: WIRING DIAGRAM
Related DTCsP0606: ECM RAM error
Required sensors/Components (Main)ECM
Required sensors/Components (Related)None
Frequency of operationContinuous
Duration16 seconds
MIL operationImmediate
Sequence of operationNone
Monitor runs whenever following DTCs not storedNone
Main CPU and sub CPU mirroringFail

Scheme 391

Scheme 391: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Wait 16 seconds or more.
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P0604.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P0604) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTC.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No output A P0604 B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493432-S11365856792012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
Related DTCP0606: ECM range check
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of OperationContinuous
Duration16 seconds
MIL OperationImmediate
Sequence of OperationNone
Monitor runs whenever following DTCs not storedNone
DMA communicationNo response
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Wait 16 seconds or more.
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P0606.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P0606) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No output A P0606 B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493432-S11365856792012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
Related DTCsP0607: Control module performance
Required sensors/Components (Main)ECM
Required sensors/Components (Related)Heated oxygen sensor
Frequency of operationContinuous
Duration60 seconds
MIL operationImmediate
Sequence of operationNone
Monitor runs whenever the following DTCs are not storedNone
EngineRunning
Estimated HO2 sensor temperature450 to 750°C (842 to 1382°F)
Heated oxygen sensor transistorsFail

Scheme 392

Scheme 392: CONFIRMATION DRIVING PATTERN
  1. Stop the engine for 30 minutes or more [A].
  2. Connect the Techstream to the DLC3.
  3. Turn the ignition switch to ON and turn the Techstream on.
  4. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [B].
  5. Start the engine, and wait 2 minutes [C].
  6. Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [D].
  7. Idle the engine for 1 minute [E].
  8. Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle [F].
  9. Drive the vehicle at 56 to 80 km/h (35 to 50 mph) for 5 minutes or more [G].
  10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  11. Input the DTC: P0607, P0136, P0137 or P0138.
  12. Check the DTC judgment result [H]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [D] through [H].
  13. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  14. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  15. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 393

Scheme 393: PROCEDURE
  1. CHECK ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . RESULT Result Proceed to P0607 and P0136, P0137 or P0138 are output A P0607 is output B B --> See step 3 A: Go to next step
  2. INSPECT DTC (P0136, P0137 OR P0138) Refer to the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-493440-S39201578802012081000000) . Then proceed to "INSPECT ECM". If P0137 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-493440-S39201578802012081000000) . Then proceed to "INSPECT ECM". If P0138 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-493440-S39201578802012081000000) . Then proceed to "INSPECT ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT --> See step 6
  3. CHECK FOR EXHAUST GAS LEAK Allow the engine to idle and rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair them and proceed to "PERFORM CONFIRMATION DRIVING PATTERN". If no exhaust gas leaks are present proceed to "PERFORM CONFIRMATION DRIVING PATTERN". HINT: If no exhaust gas leaks are present, a malfunction in the heated oxygen sensor circuit is suspected. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. NEXT: Go to next step
  4. PERFORM CONFIRMATION DRIVING PATTERN Clear DTC.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Connect the Techstream to the DLC3. Start the engine. Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher. Perform the driving pattern. Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle. Drive the vehicle between 56 and 80 km/h (35 and 50 mph) for 5 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0136, P0137, P0138 and/or P0607 A Only P0607 B No DTC output C B --> See step 7 C --> See step 6 A: Go to next step
  5. INSPECT DTC (P0136, P0137 OR P0138) Refer to the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-493440-S39201578802012081000000) . Then proceed to "INSPECT ECM". If P0137 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-493440-S39201578802012081000000) . Then proceed to "INSPECT ECM". If P0138 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-493440-S39201578802012081000000) . Then proceed to "INSPECT ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT: Go to next step
  6. INSPECT ECM Clear DTC.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Stop the engine and wait for 30 minutes. Connect the Techstream to the DLC3. Start the engine and allow it to idle for 2 minutes. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check the DTCs. RESULT Result Proceed to DTC is not output A P0607 is output B B --> See step 8 A --> END
  7. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
  8. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
Related DTCsP060A: ECM CPU error
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationContinuous
Duration16 seconds
MIL operationImmediate
Sequence of operationNone
Monitor runs whenever the following DTCs are not storedNone
When either condition below is metCondition 1 or 2
1. When all conditions below are met
CPU reset1 time or more
Learned TP - Learned APP0.4 V or higher
Electronic throttle actuatorOFF
2. CPU reset2 times or more
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Wait 16 seconds or more.
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P060A.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P060A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTC.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the battery negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No output A P060A B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493432-S11365856792012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
Related DTCsNone
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationOnce per driving cycle
Duration16 seconds
MIL operationImmediate
Sequence of operationNone
Monitor runs whenever following DTCs not storedNone
When one of the following conditions is met
AD converterFail
Knock sensor circuitFail
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Wait 16 seconds or more.
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P060B.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK DTC Clear DTC.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Check DTC. RESULT Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327, P0328 are output C B --> See step 3 C --> See step 4 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493432-S11365856792012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
  4. GO TO DTC (P0327, P0328). Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor)»(ref-493440-S08099928582012081000000)
Related DTCsP060D: Internal control module, Accelerator pedal position
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationContinuous
Duration1 second
MIL operationImmediate
Sequence of operationNone
Monitor runs whenever following DTCs not storedNone
Difference of main APP and sub APP0.3 V or higher
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Wait 16 seconds or more.
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P060D.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P060D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTC.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No output A P060D B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493432-S11365856792012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
Related DTCsP060E: Internal control module, Throttle position
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationContinuous
Duration1 second
MIL operationImmediate
Sequence of operationNone
Monitor runs whenever following DTCs not storedNone
DMA communication errorNot detected
When one of following conditions is metCondition 1 or 2
1. Difference of main TP and sub TP0.3 V or higher
2. Value of main brake switch signal and sub brake switch signalDifferent
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Wait 16 seconds or more.
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P060E.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P060E) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTC.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No output A P060E B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493432-S11365856792012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
Related DTCsP0617: Starter signal
Required Sensors/Components (Main)ST relay Park/Neutral Position (PNP) switch Ignition switch
Required Sensors/Components (Related)Vehicle Speed Sensor (VSS) Crankshaft Position (CKP) sensor
Frequency of OperationContinuous
Duration20 seconds
MIL OperationImmediate
Sequence of OperationNone
Monitor runs whenever following DTCs not storedNone
Battery voltage10.5 V or higher
Vehicle speed20 km/h (12.4 mph) or more
Engine speed1000 rpm or more
Starter signalON

Scheme 394

Scheme 394: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Idle the engine for 5 minutes or more [B].
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P0617.
  7. Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E].
  8. Drive the vehicle at 24 km/h (15 mph) or more for 20 seconds or more [D].
  9. Check the DTC judgment result [E].
  10. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  11. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  12. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP062F: Internal control module EEPROM error
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationOnce per driving cycle
Duration3 times
MIL operationImmediate
Sequence of operationNone
Monitor runs whenever following DTCs not storedNone
Time after engine start10 seconds or more
Battery voltage8 V or higher
Ignition switchON
StarterOFF
Permanent fault code dataMismatch (3 times or more)

Scheme 395

Scheme 395: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Wait 30 seconds or more.
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P062F.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTC.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No output A P062F B B --> See step 2 A --> See step 3
  2. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
  3. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493432-S11365856792012081000000)
Related DTCsP0630: VIN not programmed
Required Sensors/Components (Main)ECM
Required Sensors/Components (Related)
Frequency of OperationContinuous
Duration0.325 seconds
MIL OperationImmediate
Sequence of OperationNone
Battery voltage8 V or higher
Ignition switchON
StarterOFF
VIN codeNot programmed
VIN codeProgrammed
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Wait 5 seconds or more.
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P0630.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  8. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  9. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0630) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0630 A P0630 and other DTCs B If any DTCs other than P0630 are output, troubleshoot those DTCs first. NOTE: If P0630 is output, the VIN must be input into the ECM using the Techstream. However, all DTCs are cleared automatically by the Techstream when inputting the VIN. If DTCs other than P0630 are output, check them first. B --> See step 3 A: Go to next step
  2. INPUT VIN Input the VIN.Refer to «REGISTRATION»(ref-493432-S34142713542012081000000) . NEXT --> END
  3. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493432-S02175369332012081000000)
Related DTCsP0657: ETCS power supply
Required sensors/Components (Main)ECM
Required sensors/Components (Related)Throttle actuator
Frequency of operationOnce per driving cycle
DurationWithin 1 second
MIL operationImmediate
Sequence of operationNone
Throttle actuator power supply voltage7 V or higher
Electronic throttle actuator power supplyON
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on.
  6. Wait 5 seconds or more [A].
  7. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  8. Input the DTC: P0657.
  9. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  10. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  11. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  12. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P0657) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTC.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON for 10 seconds. Turn the ignition switch off. Turn the ignition switch to ON. Connect the Techstream to the DLC3. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No output A P0657 B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493432-S11365856792012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
Related DTCsP0724: Stop light switch/Range check/Rationality
Required sensors/Components (Main)Stop light switch
Required sensors/Components (Related)Speed sensor
Frequency of OperationContinuous
Duration5 times
MIL Operation2 driving cycles
Sequence of OperationNone

The stop light switch remains ON during STOP and GO 5 times.

Monitor runs whenever following DTCs not storedNone
GO: Vehicle speed30 km/h (18.65 mph) or more
STOP: Vehicle speedLess than 3 km/h (1.86 mph)

GO AND STOP ARE DEFINED AS FOLLOWS

Stop light switch statusStuck on

Scheme 396

Scheme 396: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
  4. Wait 5 seconds after clear DTCs.
  5. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
  6. Input the DTC: P0724.
  7. Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [C] through [E].
  8. Start the engine [C].
  9. Accelerate the vehicle to 30 km/h (19 mph) or more, depress the brake pedal and decelerate the vehicle to 3 km/h (1.8 mph) or less [D]. Repeat step [D] 5 times.
  10. Check the DTC judgment result [E].
  11. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
  12. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  13. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ VALUE USING TECHSTREAM (STOP LIGHT SWITCH) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Stop Light Switch. Read the values displayed on the Techstream. OK Item Measurement Item: Range (display) Normal Condition Stop Light Switch Stop light switch status: ON or OFF ON: Brake pedal is depressed OFF: Brake pedal is released NG --> See step 2 OK --> See step 4
  2. INSPECT STOP LIGHT SWITCH See step 2 NG --> See step 5 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (STOP LIGHT SWITCH - ECM) Disconnect the ECM connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A9-39 (ST1-) - Body ground Brake pedal released 11 to 14 V Brake pedal depressed 0 to 3 V A9-29 (STP) - Body ground Brake pedal released 0 to 3 V Brake pedal depressed 11 to 14 V Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
  4. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493432-S11365856792012081000000)
  5. REPLACE STOP LIGHT SWITCH. Refer to «REMOVAL»(ref-493453-S37294564642012081000000)
  6. REPLACE ECM. Refer to «REMOVAL»(ref-493433-S09832564842012081000000)
