Engine Control System (2AR-FE) (P0010-P0351) (Diagnostic Codes): Wiring Toyota RAV4 IV

WIRING DIAGRAM

Refer to DTC P0010.Refer to WIRING DIAGRAM .

Refer to DTC P0013.Refer to WIRING DIAGRAM .

Refer to DTC P0335.Refer to WIRING DIAGRAM .

Refer to DTC P0340.Refer to WIRING DIAGRAM .

Refer to DTC P0365.Refer to WIRING DIAGRAM .

Refer to DTC P2195.Refer to WIRING DIAGRAM .

Refer to DTC P0136.Refer to WIRING DIAGRAM .

Refer to DTC P0102.Refer to WIRING DIAGRAM .

Scheme 296

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
5. Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
6. Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. HINT: Drive while keeping the engine load as stable as possible.
7. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
8. Input the DTC: P0101.
9. Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
10. If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
11. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
12. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493432-S34411502992012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to DTC P0112.Refer to WIRING DIAGRAM .

Refer to DTC P0115.Refer to WIRING DIAGRAM .

Refer to DTC P0136.Refer to WIRING DIAGRAM .

Refer to DTC P2195.Refer to WIRING DIAGRAM .

Wiring diagram of the ignition system.

Scheme 297

Scheme 298

Refer to DTC P0335.Refer to WIRING DIAGRAM .
