SPECIAL TOOL
SPECIAL TOOL CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 498575400 OIL PRESSURE GAUGE ASSY Used for measuring oil pressure. 498897200 OIL PRESSURE ADAPTER Used together with oil pump cover installed on when measuring line pressure. 498897800 OIL PRESSURE ADAPTER SET Used for measuring transfer clutch pressure. 498277200 STOPPER SET Used for removing and installing automatic transmission assembly to engine. Used for preventing the torque converter from dropping off. 398527700 PULLER ASSY Used for removing the extension case roller bearing. Used for removing the extension oil seal. Used for removing the front differential side retainer bearing outer race. Used for removing the front differential side retainer oil seal. 498057300 INSTALLER Used for installing the extension oil seal. 498077000 REMOVER Used for removing the differential taper roller bearing. 18658AA020 (Newly adopted tool) WRENCH COMPL RETAINER Used for removing and installing the differential side retainer. Existing SST (18630AA010) with the handle removed. Use together with a commercially sold spinner handle. WRENCH COMPL RETAINER (18630AA010) can also be used. 398487700 DRIFT Used for installing the front differential taper roller bearing. 498255400 PLATE Used for measuring the backlash of hypoid gear. 498247001 MAGNET BASE Used for measuring the gear backlash. Used together with DIAL GAUGE (498247100). 498247100 DIAL GAUGE Used for measuring the gear backlash. Used together with MAGNET BASE (498247001). 498517000 REPLACER Used for removing the front roller bearing. 499787700 WRENCH Used for removing and installing the drive pinion lock nut. 398643600 GAUGE Used for measuring total end play, extension end play and drive pinion height. 398744300 PISTON GUIDE Used for measuring height from mating surface of the main case to pressure plate. 499737100 PULLER SET Used for removing the reduction driven gear assembly. 498077600 REMOVER Used for removing the ball bearing. 18667AA010 HOLDER Used for removing and installing the drive pinion lock nut. Used as a handle to rotate gear when checking tooth contact. 1B022XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system. 18675AA000 DIFFERENTIAL SIDE OIL SEAL INSTALLER Used for installing the differential side retainer oil seal. 18654AA000 INSTALLER Used for removing and installing the ball bearing. 28399SA010 OIL SEAL PROTECTOR Used for protecting oil seal when installing front drive shaft. 18763AA000 COMPRESSOR SHAFT Used for disassembling multi-plate clutch for shift transmission. 18765AA000 COMPRESSOR SUPPORT Used for disassembling multi-plate clutch for shift transmission. 18676AA020 TORX® WRENCH Used for disassembling torque converter case. 18854AA000 ANGLE GAUGE Used for tightening parking support. 498077300 REMOVER Used for removing ball bearing of reduction driven gear. 499587100 OIL SEAL INSTALLER Used for installing the oil seal. 499787500 ADAPTER Used for removing and installing drive pinion lock nut. 499575400 GAUGE Used for measuring the height of total end play. 18762AA000 COMPRESSOR SPECIAL TOOL Used for disassembling multi-plate clutch for shift transmission. 499755602 PRESS Used for installing the parking gear. 18680AA010 GEAR HOLDER Used for removing reduction driven gear assembly. (2-piece set) 18766AA000 SUPPORT PULLER Used for removing reduction driven gear assembly. 18767AA000 REMOVER Used to pull out the parking gear. Used to pull out the bearing from the VTD assembly. 41099AJ010 (Newly adopted tool) SPECIAL TOOL H6 Used for removing and installing transmission. For H6 engine. 18360AA020 (Newly adopted tool) HANGER Used for removing and installing transmission. For H6 engine. 99099AJ000 (Newly adopted tool) SPECIAL TOOL ENGINE HANGER Used for removing and installing transmission. (Weight of 350 kg (772 lb) is supported) Used together with SPECIAL TOOL CHAIN BALANCER (99099AJ010) and sling chain (general tool). 99099AJ010 (Newly adopted tool) SPECIAL TOOL CHAIN BALANCER Used for removing and installing transmission. (Weight of 350 kg (772 lb) is supported) Used together with SPECIAL TOOL ENGINE HANGER (99099AJ000) and sling chain (general tool). Used to hang the engine while balancing it with the sling chain inserted in this tool
