PROCEDURE
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK PRE-INSPECTION. Ask the customer when and how the trouble occurred using the interview check list. Ref. to CHECK LIST FOR INTERVIEW . Check the following items which may be affecting the AT trouble. General inspection Ref. to INSPECTION , General Description. Oil leakage Stall speed test Ref. to STALL TEST . Line pressure test Ref. to LINE PRESSURE TEST . Transfer clutch pressure test Ref. to TRANSFER CLUTCH PRESSURE TEST . Time lag test Ref. to TIME LAG TEST . Road test Ref. to ROAD TEST . Inhibitor switch Ref. to INHIBITOR SWITCH . | Is the item that is thought to influence the AT problem working properly? | Go to step 2 . | Repair or replace the items which may be affecting the AT trouble. |
| 2 CHECK AT OIL TEMP LIGHT. Turn the ignition switch to ON and wait for at least 2 seconds. | Does the AT OIL TEMP light illuminate? | Go to step 3 . | Check the AT OIL TEMP light. |
| 3 CHECK AT OIL TEMP LIGHT. Start the engine and wait for two seconds or more. | Does the AT OIL TEMP light blink? | Go to step 4 . | Go to step 6 . |
| 4 CHECK DTC. Read the DTC. Ref. to OPERATION , Read Diagnostic Trouble Code (DTC). NOTE: If the communication function of Subaru Select Monitor cannot be executed normally, check communication circuit. Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , Diagnostic Procedure for Subaru Select Monitor Communication. | Is DTC displayed on Subaru Select Monitor? | Record all DTC. Go to step 5 . | Go to step 6 . NOTE: When the AT OIL TEMP light blinks, check if the learning has completed. |
| 5 CHECK INFORMATION STORED IN FREEZE FRAME DATA. Using the Subaru Select Monitor, check the freeze frame data. | Are freeze frame data recorded? Record the freeze frame data. | Go to step 7 . | Go to step 7 . |
| 6 PERFORM GENERAL DIAGNOSTICS. Inspect using "Diagnostic Procedure without Diagnostic Trouble Code (DTC)". Ref. to DIAGNOSTIC PROCEDURE WITHOUT DIAGNOSTIC TROUBLE CODE (DTC) . Perform the Clear Memory Mode. Perform the Inspection Mode. Ref. to INSPECTION MODE . Read the DTC. | Is DTC displayed on Subaru Select Monitor? | Go to step 7 . | Finish the diagnosis. |
| 7 PERFORM DIAGNOSIS. Inspect using "Diagnostic Procedure with Diagnostic Trouble Code (DTC)". Ref. to DIAGNOSTIC PROCEDURE WITH DIAGNOSTIC TROUBLE CODE (DTC) . NOTE: For DTC table, refer to "List of Diagnostic Trouble Code (DTC)". Ref. to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . Repair the trouble cause. Perform the Clear Memory Mode. Perform the Inspection Mode. Ref. to INSPECTION MODE . Read the DTC. | Is DTC displayed on Subaru Select Monitor? | Inspect again using Diagnostic Procedure with Diagnostic Trouble Code (DTC). Ref. to DIAGNOSTIC PROCEDURE WITH DIAGNOSTIC TROUBLE CODE (DTC) . | Finish the diagnosis. |
| NOTE |
|---|
| If the communication function of Subaru Select Monitor cannot be executed normally, check communication circuit. Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , Diagnostic Procedure for Subaru Select Monitor Communication. |
| NOTE |
|---|
| When the AT OIL TEMP light blinks, check if the learning has completed. |
| NOTE |
|---|
| For DTC table, refer to "List of Diagnostic Trouble Code (DTC)". Ref. to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . |
DIAGNOSIS PROCEDURE
CHECK
Check the following items when a problem has occurred.
Note. Use copies of this page for interviewing customers.
Scheme 647
SUPPLEMENTAL RESTRAINT SYSTEM "AIRBAG"
The airbag system wiring harness is routed near the TCM.
| CAUTION | All the airbag system wiring harnesses and connectors are colored yellow. Do not use an electric test equipment to check these circuits. Be careful not to damage the airbag system wiring harness when performing diagnostics or servicing the TCM. |
MEASUREMENT
When measuring the voltage and resistance of the ECM, TCM or each sensor, use a tapered pin with a diameter of less than 0.64 mm (0.025 in) in order to avoid poor contact. Do not insert a pin of more than 0.65 mm (0.026 in) diameter.
BATTERY
Measure the battery voltage and specific gravity of the electrolyte.
Standard voltage: 12 V or more
Specific gravity: 1.260 or more
TRANSMISSION GROUND
Make sure that the ground terminal bolt is tightened securely.
Tightening torque: 7 N.m (0.7 kgf-m, 5.2 ft-lb)
Scheme 648
ATF LEVEL
Make sure that ATF level is the specified amount. Ref. to INSPECTION , Automatic Transmission Fluid.
Scheme 649
FRONT DIFFERENTIAL OIL LEVEL
Make sure the front differential oil level is the specified amount. Ref. to INSPECTION , Differential Gear Oil.
Scheme 650
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance, voltage and current. |
| Oscilloscope | Used for measuring the sensor. |
GENERAL TOOL CHART
Scheme 651
Scheme 652
Scheme 653
Scheme 654
Scheme 655
Scheme 656
Scheme 657
Note. Measure after warming up.
| Item | Connector No. | Terminal No. | Measuring condition | Measured value | Resistance between terminal and chassis ground | Remarks |
|---|---|---|---|---|---|---|
| P/L solenoid output | B55 | 6 | Engine ON, "P" range, accelerator OFF, brake ON | 3.5 - 7.5 V | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Driving frequency 300 Hz |
| I/C oil pressure switch input | B55 | 20 | While driving at 1st - 3rd of manual mode | 6 V or more | ||
| While driving at 4th or 5th of manual mode | Less than 1.5 V | |||||
| Power GND | B55 | 12 | Always | Approx. 0 V | ||
| CAN communication line (+) | B54 | 21 | ||||
| CAN communication line (-) | B54 | 20 | ||||
| ATF temperature sensor 1 input | B55 | 17 | Ignition switch ON ATF temperature 20°C (68°F) | 3.5 - 4.3 V | 2.5 - 7.0 kohms | Measure the resistance with TCM by itself and the connector disconnected. |
| Ignition switch ON ATF temperature 80°C (176°F) | 1 - 2.2 V | 0.3 - 0.8 kohms | ||||
| Backup power supply | B54 | 24 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | ||||||
| I/C solenoid output | B55 | 3 | While driving at 1st - 3rd of manual mode | 5 V or more | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Driving frequency 300 Hz |
| While driving at 4th or 5th of manual mode | Less than 1.5 V | |||||
| H & LR/C solenoid output | B55 | 5 | While driving at 2nd of manual mode | 5 V or more | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Driving frequency 300 Hz |
| While driving at 1st and 3rd - 5th of manual mode | Less than 1.5 V | |||||
| Power GND | B55 | 13 | Always | Approx. 0 V | ||
| Analog GND | B55 | 18 | Always | Approx. 0 V | ||
| Fr/B solenoid output | B55 | 4 | While driving at other than 4th of manual mode | 5 V or more | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Driving frequency 300 Hz |
| While driving at 4th of manual mode | Less than 1.5 V | |||||
| L/U solenoid output | B55 | 7 | When lock-up | 3 V or more | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Driving frequency 300 Hz |
| When not lock-up | Less than 1 V | |||||
| D/C solenoid output | B55 | 1 | While driving at 1st or 5th of manual mode | 5 V or more | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Driving frequency 300 Hz |
| While driving at 2nd-4th of manual mode | Less than 1.5 V | |||||
| D/C oil pressure switch input | B55 | 22 | While driving at 1st or 5th of manual mode | 6 V or more | ||
| While driving at 2nd-4th of manual mode | Less than 1.5 V | |||||
| Data link signal (Subaru Select Monitor communication line) | B54 | 8 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | Less than 1 V | |||||
| Sensor GND (analog) | B55 | 16 | Always | Approx. 0 V | ||
| H&LR/C oil pressure switch input | B55 | 14 | While driving at 2nd of manual mode | 6 V or more | ||
| While driving at 3rd - 5th of manual mode | Less than 1.5 V | |||||
| Fwd/B solenoid output | B55 | 19 | While driving at 1st or 2nd of manual mode | 5 V or more | Driving frequency 300 Hz | |
| While driving at 3rd - 5th of manual mode | Less than 1.5 V | |||||
| Fwd/B oil pressure switch input | B55 | 21 | While driving at 1st or 2nd of manual mode | Less than 1.5 V | ||
| While driving at 3rd - 5th of manual mode | 6 V or more | |||||
| Front vehicle speed sensor input | B55 | 24 | While driving at 2nd and 20 km/h (12 MPH) of manual mode | Approx. 500 - 700 RPM | Use the Subaru Select Monitor. | |
| While driving at 4th and 80 km/h (50 MPH) of manual mode | Approx. 2,000 - 2,500 RPM | Use the Subaru Select Monitor. | ||||
| Inhibitor switch 1 input | B55 | 8 | Ignition switch ON, "P" range | Less than 0.5 V | ||
| Ignition switch ON, "N" range | 5 V or more | |||||
| Inhibitor switch 2 input | B55 | 9 | Ignition switch ON, "P" range | 5 V or more | ||
| Ignition switch ON, "D" range | Less than 0.5 V | |||||
| Ignition power supply | B55 | 27 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | Less than 1 V | |||||
| Rear vehicle speed sensor input | B55 | 23 | While driving at 2nd and 20 km/h (12 MPH) of manual mode | Approx. 500 - 700 RPM | Use the Subaru Select Monitor. | |
| While driving at 4th and 80 km/h (50 MPH) of manual mode | Approx. 2,000 - 2,500 RPM | Use the Subaru Select Monitor. | ||||
| Fr/B oil pressure switch input | B55 | 15 | While driving at other than 4th of manual mode | Less than 1.5 V | ||
| While driving at 4th of manual mode | 6 V or more | |||||
| Turbine speed sensor 1 input | B55 | 26 | 2nd gear of manual mode, turbine speed sensor is 2,000 RPM (Read from Subaru Select Monitor) | Approx. 0 RPM | Use the Subaru Select Monitor. | |
| 4th of manual mode, turbine speed sensor is 2,000 RPM (Read from Subaru Select Monitor) | Approx. 1,900 - 2,100 RPM | Use the Subaru Select Monitor. | ||||
| Inhibitor switch 3 input | B55 | 10 | Ignition switch ON, "R" range | 5 V or more | ||
| Ignition switch ON, "D" range | Less than 0.5 V | |||||
| Control GND 1 | B54 | 23 | Ignition switch ON | Approx. 0 V | ||
| Ignition switch OFF | ||||||
| Control GND 2 | B54 | 22 | Ignition switch ON | Approx. 0 V | ||
| Ignition switch OFF | ||||||
| Inhibitor switch 4 input | B55 | 11 | Ignition switch ON, "P" range | Less than 0.5 V | ||
| Ignition switch ON, "D" range | 5 V or more | |||||
| Back-up light relay output | B54 | 13 | Ignition switch ON, "R" range | Less than 1 V | 90 - 110 ohms (ATF temperature 25°C (77°F)) | |
| Ignition switch ON, other than "R" range | 8 V or more | |||||
| AWD solenoid output | B55 | 2 | Engine ON, "P" range or "N" range, accelerator OFF | Less than 1 V | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Driving frequency 300 Hz |
| Engine ON, "D" range, accelerator OFF, brake ON | 2 V or more | |||||
| Turbine speed sensor 2 input | B55 | 25 | 2nd gear of manual mode, turbine speed sensor is 2,000 RPM (Read from Subaru Select Monitor) | Approx. 1,200 - 1,500 RPM | Use the Subaru Select Monitor. | |
| 4th of manual mode, turbine speed sensor is 2,000 RPM (Read from Subaru Select Monitor) | Approx. 1,900 - 2,100 RPM | Use the Subaru Select Monitor. | ||||
| PN signal output | B54 | 11 | Ignition switch ON, Other than "P" range or "N" range | 8 V or more | ||
| Ignition switch ON, "P" range or "N" range | Less than 1 V | |||||
| Ignition power supply 1 | B54 | 26 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | Less than 1 V | |||||
| Ignition power supply 2 | B54 | 19 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | Less than 1 V | |||||
| Ignition power supply 3 | B54 | 18 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | Less than 1 V | |||||
| Ignition power supply 4 | B54 | 25 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | Less than 1 V | |||||
| Paddle shift DOWN switch | B54 | 4 | Ignition switch ON, Paddle shift DOWN switch ON | Less than 1 V | ||
| Ignition switch ON, Paddle shift DOWN switch OFF | 8 V or more | |||||
| Paddle shift UP switch | B54 | 5 | Ignition switch ON, Paddle shift UP switch ON | Less than 1 V | ||
| Ignition switch ON, Paddle shift UP switch OFF | 8 V or more | |||||
| Manual mode switch | B54 | 6 | Ignition switch ON, Manual mode switch ON | Less than 1 V | ||
| Ignition switch ON, Manual mode switch OFF | 8 V or more |
TCM CONNECTOR REFERENCE
| CAUTION | Observe the traffic law when driving on public roads. |
- Shift the select lever to "D" range, and then drive the vehicle with changing the gear from 1st to 5th.
- When driving the vehicle at 5th speed of "D" range, set the gear to manual mode and drive the vehicle by downshifting using "-" of the paddle shift switch from 5th --> 4th, 4th --> 3rd, 3rd --> 2nd, and 2nd --> 1st. NOTE: At shifting down, drive the vehicle at least 10 seconds in each speed.
- Shift the select lever to "R" range and drive the vehicle for 2 seconds or more.
PREPARATION FOR LEARNING
- Warm up or cool down the vehicle until the ATF temperature displayed on the Subaru Select Monitor is 60 - 80°C (140 - 176°F).
- Shift the select lever to "P" range.
- Apply the electronic parking brake.
- Lift up the vehicle. CAUTION: While working, be sure to keep the lower edge of the tires 30 cm or more above the ground as vehicle will vibrate.
- Connect the Subaru Select Monitor to data link connector.
- Turn the ignition switch to ON.
- Select {AT related learning & inspecting mode} in the «Transmission Diagnosis» screen of the Subaru Select Monitor.
- Select {AT learning mode} in the «AT related learning & inspecting mode» screen of the Subaru Select Monitor.
- Follow the messages displayed on the Subaru Select Monitor screen when working.
SIMPLE LEARNING
Note. Simple learning is performed with the vehicle lifted, without actually running the vehicle.
| CAUTION | Do not turn the power of the Subaru Select Monitor to OFF or disconnect the data link connector during the operation. |
- Follow the messages displayed on the Subaru Select Monitor screen when working. NOTE: During "SHIFT control system learning in progress" and "AWD control system learning in progress", AT OIL TEMP light in the combination meter starts blinking at 2 Hz and the learning operation starts. The following message is displayed on the screen when the AT OIL TEMP light in the combination meter goes off. When the learning ended abnormally, AT OIL TEMP light blinks at 4 Hz.
- "AT learning normally ended." is displayed, simple AT learning is completed. NOTE: If communication error occurs during learning, retry the "AT learning mode" from the beginning. If the message "Execute AT learning again after fixing troubles of the vehicle" is displayed during learning, select [OK] to display the List of Diagnostics Trouble Code. After repairing the locations indicated by the DTC, start the "AT learning mode" over from the beginning. If the message "AT learning ended abnormally." is displayed, start the "AT learning mode" over from the beginning. MESSAGE CHART Message Main reasons for abnormal termination AT learning ended abnormally. Fault is detected during AT learning. The accelerator pedal is depressed during AT learning. Operation which is not directed is performed during AT learning. Brake pedal not stepped on firmly enough. Electronic parking brake not applied strongly enough Abnormal idle speed increase, etc. For detailed operation procedures, refer to PC application help for Subaru Select Monitor.
DRIVING CHECK
Drive the vehicle to check that there is no malfunction such as shifting shock.
When shifting shock is felt, perform learning again. When reducing of shifting shock is not felt, check that other parts are normal.
LIST
| DTC | Item | Content of diagnosis | Reference |
|---|---|---|---|
| P0705 | Transmission Range Sensor Circuit (PRNDL Input) | Inhibitor switch malfunction, open or short circuit | Ref. to DTC P0705 TRANSMISSION RANGE SENSOR CIRCUIT (PRNDL INPUT) , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0712 | Transmission Fluid Temperature Sensor Circuit Low Input | ATF temperature sensor 1 is faulty or input signal circuit is open. | Ref. to DTC P0712 TRANSMISSION FLUID TEMPERATURE SENSOR CIRCUIT LOW INPUT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0713 | Transmission Fluid Temperature Sensor Circuit High Input | ATF temperature sensor 1 is faulty or input signal circuit is shorted. | Ref. to DTC P0713 TRANSMISSION FLUID TEMPERATURE SENSOR CIRCUIT HIGH INPUT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0715 | Input/Turbine Speed Sensor Circuit | Turbine speed sensor 1 malfunction, open or shorted input signal circuit | Ref. to DTC P0715 INPUT/TURBINE SPEED SENSOR CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0719 | Brake Switch Circuit Low | Brake switch malfunction, open input signal circuit, body integrated unit malfunction, or CAN communication error | Ref. to DTC P0719 BRAKE SWITCH CIRCUIT LOW , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0720 | Output Speed Sensor Circuit | Front vehicle speed sensor malfunction, open or shorted input signal circuit, ground, power supply | Ref. to DTC P0720 OUTPUT SPEED SENSOR CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0724 | Brake Switch Circuit High | Brake switch malfunction, shorted input signal circuit, body integrated unit malfunction, or CAN communication error | Ref. to DTC P0724 BRAKE SWITCH CIRCUIT HIGH , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0731 | Gear 1 Incorrect Ratio | Vehicle speed sensor, turbine speed sensor, control valve, or gear shift clutch malfunction | Ref. to DTC P0731 GEAR 1 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0732 | Gear 2 Incorrect Ratio | Vehicle speed sensor, turbine speed sensor, control valve, or gear shift clutch malfunction | Ref. to DTC P0732 GEAR 2 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0733 | Gear 3 Incorrect Ratio | Vehicle speed sensor, turbine speed sensor or gear shift clutch malfunction | Ref. to DTC P0733 GEAR 3 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0734 | Gear 4 Incorrect Ratio | Vehicle speed sensor, turbine speed sensor or gear shift clutch malfunction | Ref. to DTC P0734 GEAR 4 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0735 | Gear 5 Incorrect Ratio | Vehicle speed sensor, turbine speed sensor or gear shift clutch malfunction | Ref. to DTC P0735 GEAR 5 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0736 | Reverse Incorrect Ratio | Vehicle speed sensor, turbine speed sensor or gear shift clutch malfunction | Ref. to DTC P0736 REVERSE INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0741 | Torque Converter Clutch Circuit Performance or Stuck Off | Lock-up clutch is faulty or valve is stuck. | Ref. to DTC P0741 TORQUE CONVERTER CLUTCH CIRCUIT PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0743 | Torque Converter Clutch Circuit Electrical | L/U solenoid circuit or L/U solenoid unit malfunction | Ref. to DTC P0743 TORQUE CONVERTER CLUTCH CIRCUIT ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0748 | Pressure Control Solenoid "A" Electrical | Line pressure solenoid circuit or line pressure solenoid unit malfunction | Ref. to DTC P0748 PRESSURE CONTROL SOLENOID "A" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0751 | Shift Solenoid "A" Performance or Stuck Off | Fr/B solenoid malfunction | Ref. to DTC P0751 SHIFT SOLENOID "A" PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0753 | Shift Solenoid "A" Electrical | Fr/B solenoid circuit or Fr/B solenoid unit malfunction | Ref. to DTC P0753 SHIFT SOLENOID "A" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0756 | Shift Solenoid "B" Performance or Stuck Off | I/C solenoid malfunction | Ref. to DTC P0756 SHIFT SOLENOID "B" PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0758 | Shift Solenoid "B" Electrical | I/C solenoid circuit or I/C solenoid unit malfunction | Ref. to DTC P0758 SHIFT SOLENOID "B" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0761 | Shift Solenoid "C" Performance or Stuck Off | H&LR/C solenoid malfunction | Ref. to DTC P0761 SHIFT SOLENOID "C" PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0763 | Shift Solenoid "C" Electrical | H&LR/C solenoid circuit or H&LR/C solenoid unit malfunction | Ref. to DTC P0763 SHIFT SOLENOID "C" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0766 | Shift Solenoid "D" Performance or Stuck Off | D/C solenoid malfunction | Ref. to DTC P0766 SHIFT SOLENOID "D" PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0768 | Shift Solenoid "D" Electrical | D/C solenoid circuit or D/C solenoid unit malfunction | Ref. to DTC P0768 SHIFT SOLENOID "D" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0771 | Shift Solenoid "E" Performance or Stuck Off | Fwd/B solenoid malfunction | Ref. to DTC P0771 SHIFT SOLENOID "E" PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0773 | Shift Solenoid "E" Electrical | Fwd/B solenoid circuit or Fwd/B solenoid unit malfunction | Ref. to DTC P0773 SHIFT SOLENOID "E" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0801 | Reverse Inhibit Control Circuit | Shift lock solenoid is faulty or output signal circuit is open or shorted. | Ref. to DTC P0801 REVERSE INHIBIT CONTROL CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0817 | Starter Disable Circuit | Open or short in PN signal output circuit ECM power supply malfunction TCM+B fuse is blown. | Ref. to DTC P0817 STARTER DISABLE CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0957 | Backup Light Relay Circuit Low | Open or shorted back-up light relay output circuit or relay OFF malfunction | Ref. to DTC P0957 BACKUP LIGHT RELAY CIRCUIT LOW , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0958 | Backup Light Relay Circuit High | Shorted back-up light relay output circuit or relay ON malfunction | Ref. to DTC P0958 BACKUP LIGHT RELAY CIRCUIT HIGH , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1706 | AT Vehicle Speed Sensor Circuit Malfunction (Rear wheel) | Rear vehicle speed sensor malfunction, open or shorted input circuit, ground, power supply | Ref. to DTC P1706 AT VEHICLE SPEED SENSOR CIRCUIT MALFUNCTION (REAR WHEEL) , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1707 | AT AWD Solenoid Valve Circuit Malfunction | AWD solenoid circuit or AWD solenoid unit malfunction | Ref. to DTC P1707 AT AWD SOLENOID VALVE CIRCUIT MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1710 | Torque Converter Turbine 2 Speed Signal Circuit Malfunction | Turbine speed sensor 2 malfunction, open or shorted input circuit, ground, power supply | Ref. to DTC P1710 TORQUE CONVERTER TURBINE 2 SPEED SIGNAL CIRCUIT MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1718 | AT CAN Communication Circuit | Open CAN communication bus off, shorted ECM, ABS/VDCCM, body integrated unit malfunction | Ref. to DTC P1718 AT CAN COMMUNICATION CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1724 | AT EEPROM Error | TCM EEPROM malfunction | Ref. to DTC P1724 AT EEPROM ERROR , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1817 | Sports Mode Switch Circuit (Manual Switch) | Open or shorted manual mode switch or switch malfunction | Ref. to DTC P1817 SPORTS MODE SWITCH CIRCUIT (MANUAL SWITCH) , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1840 | Transmission Fluid Pressure Sensor Switch A Circuit | Open or shorted Fr/B fluid pressure switch or switch malfunction | Ref. to DTC P1840 TRANSMISSION FLUID PRESSURE SENSOR SWITCH A CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1841 | Transmission Fluid Pressure Sensor Switch B Circuit | Open or shorted Fwd/B fluid pressure switch or switch malfunction | Ref. to DTC P1841 TRANSMISSION FLUID PRESSURE SENSOR SWITCH B CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1842 | Transmission Fluid Pressure Sensor Switch C Circuit | Open or shorted I/O fluid pressure switch or switch malfunction | Ref. to DTC P1842 TRANSMISSION FLUID PRESSURE SENSOR SWITCH C CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1843 | Transmission Fluid Pressure Sensor Switch D Circuit | Open or shorted D/C fluid pressure switch or switch malfunction | Ref. to DTC P1843 TRANSMISSION FLUID PRESSURE SENSOR SWITCH D CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1844 | Transmission Fluid Pressure Sensor Switch E Circuit | Open or shorted H&LR/C fluid pressure switch or switch malfunction | Ref. to DTC P1844 TRANSMISSION FLUID PRESSURE SENSOR SWITCH E CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
LIST OF DIAGNOSTIC TROUBLE CODE
