SPECIAL TOOL
SPECIAL TOOL CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 18801AA000 (Newly adopted tool) OIL PRESSURE GAUGE ASSY Used for measuring the secondary hydraulic pressure (line pressure). 18658AA020 (Newly adopted tool) WRENCH COMPL RETAINER Used for removing and installing the differential side retainer. 18681AA000 (Newly adopted tool) PRESSURE GAUGE ADAPTER Used for measuring oil pressure. NOTE: Used together with the genuine O-ring (part No. 806911080). 41099AJ000 (Newly adopted tool) FRONT MOUNTING H4 Used for holding and balancing the engine unit. 18769AA000 (Newly adopted tool) EXPANDER PULLER Used for removing and installing the secondary pulley assembly. 10004AA180 (SUBARU genuine part) ENGINE HANGER REAR Used for removing and installing the automatic transmission assembly. (ENGINE HANGER REAR for turbo model) 99099AJ000 (Newly adopted tool) ENGINE HANGER Used for removing and installing the automatic transmission assembly. Used together with CHAIN BALANCER (99099AJ010). 99099AJ010 (Newly adopted tool) CHAIN BALANCER Used for removing and installing the automatic transmission assembly. Used together with ENGINE HANGER (99099AJ000). 498897700 OIL PRESSURE ADAPTER SET Used for measuring the secondary pressure (line pressure) and transfer clutch hydraulic pressure. 498575400 OIL PRESSURE GAUGE ASSY Used for measuring the transfer clutch hydraulic pressure. 498277200 STOPPER SET Used for removing and installing automatic transmission assembly to engine. Used for preventing the torque converter from dropping off. 398527700 PULLER ASSY Used for removing the extension case oil seal. Used for removing the roller bearing of the primary pulley and secondary pulley. Used for removing the bearing of reduction driven gear. Used for removing the differential side retainer bearing outer race. 498057300 INSTALLER Used for installing the extension case oil seal. 18632AA000 TRANSMISSION STAND Used for disassembling and assembling the transmission. 498255400 PLATE Used for measuring the backlash of hypoid gear. 498247001 MAGNET BASE Used for measuring the backlash of hypoid gear. Used together with DIAL GAUGE (498247100). 498247100 DIAL GAUGE Used for measuring the backlash of hypoid gear. Used together with DIAL GAUGE (498247101). 18675AA000 DIFFERENTIAL SIDE OIL SEAL INSTALLER Used for installing the differential side retainer oil seal. 18762AA000 COMPRESSOR SPECIAL TOOL Used for disassembling multi-plate clutch for shift transmission. 18765AA000 COMPRESSOR SUPPORT Used for disassembling multi-plate clutch for shift transmission. 18763AA000 COMPRESSOR SHAFT Used for disassembling multi-plate clutch for shift transmission. 28399SA010 OIL SEAL PROTECTOR Used for protecting oil seal when installing front drive shaft. 18667AA010 HOLDER Used for removing and installing the drive pinion lock nut. Used as a handle to rotate gear when checking tooth contact. 18270KA020 SOCKET (E20) Used for removing and installing the hypoid driven gear. Used for removing and installing the drive pinion shaft retainer. 398497701 SEAT Used for removing and installing the ball bearing. 398177700 INSTALLER Used for removing and installing the ball bearing and tapered roller bearing. 398643600 GAUGE Used for measuring the total end play, extension end play and drive pinion height. 899864100 REMOVER Used for removing and installing the ball bearing. 498077000 REMOVER Used for removing the differential taper roller bearing. 18657AA010 INSTALLER Used for installing the oil seal of inhibitor switch. 18620AA000 ADAPTER WRENCH Used for removing and installing the drive pinion shaft lock nut. 18651AA000 INSTALLER Used for installing the differential taper roller bearing. 18720AA000 REMOVER Used for removing ball bearing of reduction driven gear. 18854AA000 ANGLE GAUGE Used for installing the drive plate. 20299AG010 PRESS SNAP RING Used for installing the bearing of reduction driven gear. 398791600 REMOVER Used for removing and installing the shifter arm spring pin. 399513600 INSTALLER Used for removing the bearing of the oil pump chain sprocket. 499267300 STOPPER PIN Used for adjusting the inhibitor switch. 499277100 BUSHING 1-2 INSTALLER Used for removing the transfer reduction driven gear. 499277200 INSTALLER Used for removing the transfer reduction driven gear. 499575400 GAUGE Used for measuring height of end play. 499737100 PULLER SET Used for measuring the transfer end play. Use the rack only. 499575600 GAUGE Used for measuring height of end play. 499787700 WRENCH Used for measuring the differential pinion shaft backlash. 499757002 INSTALLER Used for removing the transfer reduction driven gear. 18767AA000 REMOVER Used for removing the transfer reduction driven gear. 499755602 PRESS SNAP RING Used for installing the ball bearing, roller bearing and oil seal. 498077600 REMOVER Used for removing the ball bearing of the rear drive shaft. 1B022XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system
