Engine Intake System - Intake (Induction) (H4DOTC): Other Subaru Forester SH

GENERAL TOOL

GENERAL TOOL REFERENCE

CAUTION

1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Vehicle components are extremely hot after driving. Be wary of receiving burns from heated parts.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from the battery.

Scheme 66

Scheme 67

1. Disconnect the ground cable from battery.
2. Remove the air intake duct (rear). Refer to «REMOVAL»(ref-325300-S04200539772009071800000) , Air Intake Duct .
3. Disconnect the connector (A) from mass air flow and intake air temperature sensor.
4. Remove the clip (B) from the air cleaner case.
5. Open the air cleaner case, and remove the air cleaner element.

Scheme 68

OIL PIPE AND WATER PIPE

1. Check that there are no oil leaks or water leaks from the pipe attachment section.
2. Check for cracks or loose connections.
