SPECIAL TOOL

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 1B022XU0 (Newly adopted tool) SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system

Scheme 143

Scheme 143: SPECIAL TOOL

TEST HARNESS H

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FA030 TEST HARNESS H Used when measuring voltage and resistance of front sub sensor and satellite safing sensor

Scheme 144

TEST HARNESS N

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA000 TEST HARNESS N Used when measuring voltage and resistance of driver's airbag module and seat belt pretensioner

Scheme 145

TEST HARNESS P

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA020 TEST HARNESS P Used when measuring voltage and resistance of driver's airbag module harness

Scheme 146

Scheme 147

TEST HARNESS Q

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA040 TEST HARNESS Q Used when measuring voltage and resistance of driver's airbag module

Scheme 148

TEST HARNESS AG

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG070 TEST HARNESS AG Used when measuring voltage and resistance of airbag control module

Scheme 149

Scheme 150

TEST HARNESS AJ

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FG000 TEST HARNESS AJ Used when measuring power supply and resistance of side airbag harness

Scheme 151

TEST HARNESS V

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG010 TEST HARNESS V Used when measuring voltage and resistance of side airbag sensor and curtain airbag sensor

Scheme 152

TEST HARNESS AB

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA000 TEST HARNESS AB Used when measuring voltage and resistance of occupant detection system

Scheme 153

Scheme 154

TEST HARNESS AC

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA010 TEST HARNESS AC Used for diagnosing seat belt tension sensor

Scheme 155

TEST HARNESS AD

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA020 TEST HARNESS AD Used when measuring voltage and resistance of the seat belt tension sensor

Scheme 156

Scheme 157

TEST HARNESS AE

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA030 TEST HARNESS AE Used for diagnosing seat belt tension sensor. Used together with the test harness Y

Scheme 158

AIRBAG RESISTOR

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299PA040 AIRBAG RESISTOR Used in replacement of airbag module for which resistance value is same as airbag module. Two ST are required for diagnosis of two-stage inflator type airbag module

Scheme 159

TEST HARNESS AI

SPECIAL TOOL DESCRIPTION CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG090 TEST HARNESS AI Used when diagnosing the side airbag sensor and curtain airbag sensor. Used together with the test harness V

Scheme 160
