Airbag System (Diagnostics): Other — Subaru Forester SH (2007-2011)

PROCEDURE

Step	Check	Yes	No
1 CHECK WARNING LIGHT . Check whether the airbag warning light in the combination meter is lit.	Does the airbag warning light illuminate?	Go to step 2 .	Perform the diagnosis according to phenomenon of the problem.
2 READ DTC . Turn the ignition switch to OFF. Connect the Subaru Select Monitor to the data link connector. Turn the ignition switch to ON and run the Subaru Select Monitor. Read the DTC. Refer to OPERATION , Read Diagnostic Trouble Code (DTC). NOTE: If the communication function of the Subaru Select Monitor cannot be executed normally, check the communication circuit. Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor. Record all DTCs and freeze frame data.	Is DTC displayed?	Go to step 3 .	Move to "Airbag Warning Light Failure". Refer to AIR-BAG WARNING LIGHT FAILURE .
3 PERFORM DIAGNOSIS . Judge the possible cause from "List of Diagnostic Trouble Code (DTC)". Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . Inspect the DTC using "List of Diagnostic Trouble Code (DTC)". Repair the trouble cause. Perform the Clear Memory Mode. Refer to CLEAR MEMORY MODE . Perform the Inspection Mode. Refer to INSPECTION MODE . Read any other DTCs displayed.	Is DTC displayed?	Perform the procedure 1) to 5) in step 3.	Finish the diagnosis.

NOTE
If the communication function of the Subaru Select Monitor cannot be executed normally, check the communication circuit. Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor.

BASIC DIAGNOSTIC PROCEDURE

Scheme 161

Scheme 161: CHECK

Scheme 162

Scheme 162: CAUTION

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

When servicing a vehicle, be sure to turn the ignition switch to OFF, disconnect the ground terminal from the battery, and wait for 20 seconds or more before starting work.
The airbag system is fitted with a backup power source. After disconnecting the battery ground cable, the airbag may deploy if you do not wait for 20 seconds or more before starting airbag system servicing.
If sensors, airbag module, airbag control module, pretensioner or harness is deformed or damaged, replace with new parts.
Do not use the airbag system and pretensioners on other vehicles. When replacing parts, be sure to replace them with new parts.
When checking the airbag system, be sure to use a digital circuit tester. Use of an analog circuit tester may cause the airbag to activate erroneously due to a minimal current inside tester.
When checking, use a test harness (1). Damage to connector terminal causes malfunction. Do not directly put the tester probe on airbag connector terminal.
Do not drop the airbag system parts, or keep them at high temperature of 85°C (153°F) or more, or let water, oil or grease get on them; the internal parts may be damaged and reliability greatly lowered.
If damage, open circuit or rust is found on airbag system wiring harness, do not use a soldering equipment to repair. Replace the faulty harness with a new genuine part.
Install the wiring harness securely with the specified clips to avoid interference or tangled with other parts.
Do not allow water or oil to come in contact with the connector terminals. Also, do not touch the connector terminals.
Do not disassemble driver's airbag module, passenger's airbag module, side or curtain airbag modules, or pretensioner.
The airbag module cannot be used again if deployed once.
After removal, keep the airbag module with the pad side facing upward on a dry, clean and flat surface away from heat, light sources, moisture and dust.
Do not check continuity of the airbag modules for driver's side, passenger's side and curtain, or the pretensioner.
The removed front seat with airbag module must be kept at least 200 mm (8 in) away from walls and other objects.
When painting or performing sheet metal work on the front part of the vehicle, including the front wheel apron, front fender and front side frame, remove the front sub sensors and wiring harness of airbag system.
When painting or repairing sheet metal work on the side of the vehicle, including the side sill, center pillar, front and rear doors, rear crossmember and rear floorpan, remove the side airbag sensors, satellite safing sensor and wiring harness of the airbag system.
Do not discard undeployed airbag modules. They could easily cause a serious accident if accidentally deployed.
When storing a removed airbag module, do not place it with the pad side facing downward. Do not place any objects on the airbag module. Do not pile up the airbag module. If the airbag inflates for some reason when an airbag module pad is touching other objects, it may cause serious accident.

Scheme 175

PREPARATION TOOL

CAUTION

To measure the voltage and resistance of airbag system component, be sure to use the specified test harness.

GENERAL TOOL

TOOL NAME	REMARKS
Circuit tester	Used for measuring resistance, voltage and current.
Oscilloscope	Used for measuring the sensor.

GENERAL TOOL DESCRIPTION CHART

Scheme 176

Scheme 176: LOCATION

Connector No.	(AB1)	(AB2)	(AB6)	(AB7)	(AB9)	(AB10)	(AB13)	(AB16)	(AB17)	(AB18)	(AB19)	(AB20)
Pin	6	4	30	4	4	4	2	2	20	20	2	2
Color	Yellow	Yellow	Yellow	Yellow	Yellow	Yellow	Yellow	Yellow	Yellow	Yellow	Yellow	Yellow
Male/Female	Female	Female	Female	Male	Female	Male	Female	Female	Female	Female	Female	Male
Connector No.	(AB21)	(AB23)	(AB24)	(AB25)	(AB26)	(AB28)	(AB31)	(AB32)	(AB33)	(AB34)	(AB37)	(AB38)
Pin	2	4	2	2	2	4	2	4	2	4	2	2
Color	Black	Yellow	Yellow	Yellow	Black	Yellow	Black	Yellow	Black	Yellow	Orange	Black
Male/Female	Female	Female	Female	Male	Female	Female	Female	Female	Female	Female	Female	Female
Connector No.	(AB41)	(AB43)	(AB53)	(AB56)	(AB58)	(AB59)	(AB60)	(AB62)
Pin	2	18	6	3	3	6	2	3
Color	Yellow	Black	Gray	Brown	Gray	Gray	Yellow	Brown
Male/Female	Female	Female	Female	Male	Female	Male	Male	Female

CONNECTOR REFERENCE CHART

Refer to AIRBAG CONNECTOR .

Scheme 177

Scheme 177: ELECTRICAL SPECIFICATION

Terminal numbers in airbag control module connector are shown in the illustration.
Airbag warning light illuminates when the connector is removed from airbag control module.

Item		Control module terminal No.
Data link connector		(1) - 16
Combination meter		(1) - 11
Battery power supply	Dedicated fuse	(1) - 21
Passenger's airbag module level one	+	(1) - 4
		(1) - 3
Passenger's airbag module level two	+	(1) - 1
		(1) - 2
Driver's airbag module level one	+	(1) - 5
		(1) - 6
Driver's airbag module level two	+	(1) - 8
		(1) - 7
Front sub sensor LH	+	(1) - 30
		(1) - 28
Front sub sensor RH	+	(1) - 29
		(1) - 27
Ground line (GND)		(1) - 25
Ground line (GND)		(1) - 26
Passenger's airbag OFF indicator		(1) - 17
Passenger's airbag ON indicator		(1) - 23
Passenger's seat belt warning light (integrated module)		(1) - 15
Seat belt pretensioner LH	+	(2) - 5
		(2) - 6
Side airbag sensor LH Curtain airbag sensor LH	+	(2) - 24
		(2) - 23
Side airbag module LH	+	(2) - 1
		(2) - 2
Curtain airbag module LH	+	(2) - 4
		(2) - 3
Seat belt pretensioner RH	+	(3) - 4
		(3) - 3
Side airbag sensor RH Curtain airbag sensor RH	+	(3) - 17
		(3) - 18
Side airbag module RH	+	(3) - 8
		(3) - 7
Curtain airbag module RH	+	(3) - 5
		(3) - 6
Satellite safing sensor	+	(2) - 20
		(2) - 21
Occupant detection control module	+	(3) - 16
		(3) - 24

TERMINAL SIGNAL REFERENCE CHART

DETECTING CONDITION

Defective harness connector

Recreate the circumstance by referring to the conditions described in the checklist.

Airbag warning light is faulty.
Airbag control module to airbag warning light circuit is shorted or open.
Grounding circuit is faulty.
Airbag control module is faulty.
Connection of (AB1) and (B31) is improper.
Connection of (AB6, AB17, and AB18) to airbag control module is improper.

CAUTION

Before diagnosing the airbag system, be sure to turn the ignition switch to OFF, disconnect the ground terminal from the battery, and wait 20 seconds or more before starting to work. When replacing the airbag module, seat belt pretensioner, roll connector, control module and sensor, reconnect each part and check that the warning light operates properly. When inspecting the airbag main harness, disconnect the airbag module connectors of the driver's and passenger's seats for safety. When inspecting the airbag rear harness, disconnect the side airbag module connector, curtain airbag module connector and seat belt pretensioner connector for safety reasons.

Scheme 178

Scheme 178: WIRING DIAGRAM

Step	Check	Yes	No
1 READ DTC . Read the DTC. Refer to OPERATION , Read Diagnostic Trouble Code (DTC).	Is DTC displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK POOR CONTACT . Turn the ignition switch to OFF, disconnect the battery ground cable, and wait for 20 seconds or more. Confirm that the connectors of airbag control module (AB6, AB17, and AB18) are securely connected.	Is there poor contact in connectors (AB6, AB17, and AB18)?	If the poor contact of the connector is not fixed, replace the airbag main harness along with body harness or replace the airbag control module. Refer to AIRBAG CONTROL MODULE .	Go to step 3 .
3 CHECK AIRBAG MAIN HARNESS . Remove the instrument panel lower cover and disconnect the connectors (AB7) and (AB2). Remove the console front panel and disconnect the connectors (AB10) and (AB9). Disconnect the connectors (AB6, AB17, and AB18) from the airbag control module, and connect the connector (1 AG) in the test harness AG. Connect the battery ground terminal and turn the ignition switch to ON. Connect the connectors (7AG) and (8AG) in the test harness AG. NOTE: After the fault has been cleared, disconnect the connectors (7AG) and (8AG).	Does the airbag warning light go off?	Go to step 4 .	Go to step 5 .
4 CHECK GROUND CIRCUIT . Turn the ignition switch to OFF, disconnect the battery ground cable, and wait for 20 seconds or more. Disconnect the connectors (AB6, AB17, and AB18) from airbag control module. Connect the connector (1 AG) in the test harness AG to the body harness connectors (AB6, AB17, and AB18). Measure the resistance between connector (2AG) in the test harness AG and chassis ground. Connector & terminal (2AG) No. 4 - Chassis ground: (2AG) No. 3 - Chassis ground	Is the resistance less than 10 ohms?	Replace the airbag control module. Refer to AIRBAG CONTROL MODULE .	Repair the chassis ground circuit.
5 CHECK AIRBAG MAIN HARNESS AND BULKHEAD HARNESS . Disconnect the connectors (7AG) and (8AG). Remove the combination meter. Measure the resistance between the combination meter connector and test harness AG connector (2AG). Connector & terminal (2AG) No. 5 - (i10) No. 36	Is the resistance less than 10 ohms?	Check the combination meter.	Go to step 6 .
6 CHECK POOR CONTACT OF CONNECTORS (AB1) AND (B31) . Turn the ignition switch to OFF, disconnect the battery ground terminal, and wait 20 seconds or more. Confirm that there is a firm contact between connectors (AB1) and (B31).	Is there poor contact in connectors (AB1) and (B31)?	Repair the bulkhead harness or replace the airbag main harness along with body harness.	Go to step 7 .
7 CHECK AIRBAG MAIN HARNESS . Check the airbag main harness for defect.	Is there any defect in the airbag main harness?	Replace the airbag main harness along with bulkhead harness.	Repair the bulkhead harness.

NOTE
After the fault has been cleared, disconnect the connectors (7AG) and (8AG).

DIAGNOSTIC PROCEDURE

Fuse No. 5 (in fuse box) is blown out.
Body harness circuit is open.
Airbag warning light is faulty.
Airbag main harness is faulty.
Airbag control module is faulty.

CAUTION

LIST

DTC	Display	Diagnosis content	Reference
11	Driver's Airbag failure	Airbag main harness circuit is open, shorted or shorted to ground. Airbag module harness (Driver's side) circuit is open, shorted or shorted to ground. Roll connector circuit is open, shorted or shorted to ground. Airbag control module is faulty. Driver's airbag module is faulty.	Refer to DTC 11 DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
12	Passenger's Airbag failure	Airbag main harness circuit is open, shorted or shorted to ground. Airbag module harness (Passenger's side) circuit is open, shorted or shorted to ground. Airbag control module is faulty. Passenger's airbag module is faulty.	Refer to DTC 12 PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
15	Driver's Airbag failure	Airbag main harness circuit (Driver's side) is shorted to power supply. Airbag module harness circuit (Driver's side) is shorted to power supply. Roll connector is shorted to power supply. Airbag control module is faulty. Driver's airbag module is faulty.	Refer to DTC 15 DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
16	Passenger's Airbag failure	Airbag main harness circuit (Passenger's side) is shorted to power supply. Airbag module harness circuit (Passenger's side) is shorted to power supply. Airbag control module is faulty. Passenger's airbag module is faulty.	Refer to DTC 16 PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
21	Airbag ECU failure	Airbag control module is faulty.	Refer to DTC 21 AIRBAG ECM FAILURE , Diagnostic Chart with Trouble Code.
22	Front Airbag: Firing output	Front airbag module and seat belt pretensioner (LH/RH) are inflated.	Refer to DTC 22 FRONT AIRBAG FIRING OUTPUT , Diagnostic Chart with Trouble Code.
26	Passenger's Airbag indicator failure	Passenger's airbag indicator is faulty. Airbag control module is faulty. Airbag main harness circuit is open, shorted or shorted to ground. Body harness circuit is open.	Refer to DTC 26 PASSENGER'S AIRBAG INDICATOR FAILURE , Diagnostic Chart with Trouble Code.
27	ODS Communication error	Occupant detection control module communication is faulty. Airbag rear harness circuit is open, shorted, shorted to ground or shorted to power supply. Occupant detection harness is faulty. Airbag control module is faulty. Occupant detection system is faulty.	Refer to DTC 27 ODS COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
29	ODS failure	Occupant detection sensor is faulty. Occupant detection control module is faulty. Occupant detection harness is faulty. Fuse No. 25 (in joint box) is blown.	Refer to "Occupant Detection System" for details on DTC 29. Refer to DTC 29 ODS FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC).
2A	ODS Calibration error	System calibration (Rezeroing) of the occupant detection system was not ended normally.	Refer to "Occupant Detection System" for details on DTC 2A. Refer to DTC 2A ODS CALIBRATION ERROR , Diagnostic Procedure with Diagnostic Trouble Code (DTC).
2B	ODS System wrong parts	Wrong airbag control module was installed. Wrong occupant detection system was installed. Occupant detection system is faulty.	Refer to "Occupant Detection System" for details on DTC 2B. Refer to DTC 2B ODS SYSTEM WRONG PARTS , Diagnostic Procedure with Diagnostic Trouble Code (DTC).
2C	Belt tension Sensor failure	Passenger's seat belt tension sensor is faulty. Occupant detection system is faulty. Airbag rear harness circuit is open, shorted, shorted to ground or shorted to power supply. Occupant detection harness is faulty.	Refer to "Occupant Detection System" for details on DTC 2C. Refer to DTC 2C BELT TENSION SENSOR FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC).
33	Front Sub Sensor RH failure	Front sub sensor (RH) is faulty.	Refer to DTC 33 FRONT SUB SENSOR RH FAILURE , Diagnostic Chart with Trouble Code.
34	Front Sub Sensor LH failure	Front sub sensor (LH) is faulty.	Refer to DTC 34 FRONT SUB SENSOR LH FAILURE , Diagnostic Chart with Trouble Code.
37	Buckle Switch RH failure	Passenger's buckle switch circuit is open, shorted or shorted to ground. Occupant detection system is faulty. Occupant detection harness is faulty.	Refer to "Occupant Detection System" for details on DTC 37. Refer to DTC 37 BUCKLE SWITCH RH FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC).
39	Seatbelt Warning failure	Airbag control module is faulty. Body integrated unit is faulty. Harness circuits between body integrated unit and airbag control module are open, shorted or shorted to ground.	Refer to DTC 39 SEAT BELT WARNING FAILURE , Diagnostic Chart with Trouble Code.
41	Side Airbag RH failure	Side airbag harness (RH) circuit is faulty. Side airbag module (RH) is faulty. Airbag control module is faulty.	Refer to DTC 41 SIDE AIRBAG RH FAILURE , Diagnostic Chart with Trouble Code.
42	Side Airbag LH failure	Side airbag harness (LH) circuit is faulty. Side airbag module (LH) is faulty. Airbag control module is faulty.	Refer to DTC 42 SIDE AIRBAG LH FAILURE , Diagnostic Chart with Trouble Code.
45	Side Airbag RH failure	Side airbag harness (RH) is shorted to power supply. Airbag control module is faulty.	Refer to DTC 45 SIDE AIRBAG RH FAILURE , Diagnostic Chart with Trouble Code.
46	Side Airbag LH failure	Side airbag harness (LH) is shorted to power supply. Airbag control module is faulty.	Refer to DTC 46 SIDE AIRBAG LH FAILURE , Diagnostic Chart with Trouble Code.
53	Side Airbag Sensor RH failure	Side airbag sensor (RH) is faulty.	Refer to DTC 53 SIDE AIRBAG SENSOR RH FAILURE , Diagnostic Chart with Trouble Code.
54	Side Airbag Sensor LH failure	Side airbag sensor (LH) is faulty.	Refer to DTC 54 SIDE AIRBAG SENSOR LH FAILURE , Diagnostic Chart with Trouble Code.
55	Side/Curtain Airbag: Firing output	Side airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.	Refer to DTC 55 SIDE CURTAIN AIRBAG FIRING OUTPUT , Diagnostic Chart with Trouble Code.
58	Curtain Airbag Sensor RH failure	Curtain airbag sensor (RH) is faulty.	Refer to DTC 58 CURTAIN AIRBAG SENSOR RH FAILURE , Diagnostic Chart with Trouble Code.
59	Curtain Airbag Sensor LH failure	Curtain airbag sensor (LH) is faulty.	Refer to DTC 59 CURTAIN AIRBAG SENSOR LH FAILURE , Diagnostic Chart with Trouble Code.
61	Belt Pretensioner RH failure	Seat belt pretensioner (RH) circuit is open, shorted or shorted to ground. Airbag control module is faulty. Pretensioner is faulty. Pretensioner harness is faulty.	Refer to DTC 61 BELT PRETENSIONER RH FAILURE , Diagnostic Chart with Trouble Code.
62	Belt Pretensioner LH failure	Seat belt pretensioner (LH) circuit is open, shorted or shorted to ground. Airbag control module is faulty. Pretensioner is faulty. Pretensioner harness is faulty.	Refer to DTC 62 BELT PRETENSIONER LH FAILURE , Diagnostic Chart with Trouble Code.
65	Belt Pretensioner RH failure	Seat belt pretensioner (RH) circuit is shorted to power supply. Pretensioner is faulty. Pretensioner harness is faulty. Airbag control module is faulty.	Refer to DTC 65 BELT PRETENSIONER RH FAILURE , Diagnostic Chart with Trouble Code.
66	Belt Pretensioner LH failure	Seat belt pretensioner (LH) circuit is shorted to power supply. Pretensioner is faulty. Pretensioner harness is faulty. Airbag control module is faulty.	Refer to DTC 66 BELT PRETENSIONER LH FAILURE , Diagnostic Chart with Trouble Code.
71	Driver's Airbag failure	Airbag main harness circuit is open, shorted or shorted to ground. Airbag module harness (Driver's side) circuit is open, shorted or shorted to ground. Roll connector circuit is open, shorted or shorted to ground. Airbag control module is faulty. Driver's airbag module is faulty.	Refer to DTC 71 DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
72	Passenger's Airbag failure	Airbag main harness circuit is open, shorted or shorted to ground. Airbag module harness (Passenger's side) circuit is open, shorted or shorted to ground. Airbag control module is faulty. Passenger's airbag module is faulty.	Refer to DTC 72 PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
75	Driver's Airbag failure	Airbag main harness circuit (Driver's side) is shorted to power supply. Airbag module harness circuit (Driver's side) is shorted to power supply. Roll connector is shorted to power supply. Airbag control module is faulty. Driver's airbag module is faulty.	Refer to DTC 75 DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
76	Passenger's Airbag failure	Airbag main harness circuit (Passenger's side) is shorted to power supply. Airbag module harness circuit (Passenger's side) is shorted to power supply. Airbag control module is faulty. Passenger's airbag module is faulty.	Refer to DTC 76 PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
91	Curtain Airbag Module RH Failure	Curtain airbag harness (RH) circuit is faulty. Curtain airbag module (RH) is faulty. Airbag control module is faulty.	Refer to DTC 91 CURTAIN AIRBAG MODULE RH FAILURE , Diagnostic Chart with Trouble Code.
92	Curtain Airbag Module LH Failure	Curtain airbag harness (LH) circuit is faulty. Curtain airbag module (LH) is faulty. Airbag control module is faulty.	Refer to DTC 92 CURTAIN AIRBAG MODULE LH FAILURE , Diagnostic Chart with Trouble Code.
95	Curtain Airbag Module RH Failure	Curtain airbag harness (RH) is shorted to power supply. Curtain airbag module (RH) is faulty. Airbag control module is faulty.	Refer to DTC 95 CURTAIN AIRBAG MODULE RH FAILURE , Diagnostic Chart with Trouble Code.
96	Curtain Airbag Module LH Failure	Curtain airbag harness (LH) is shorted to power supply. Curtain airbag module (LH) is faulty. Airbag control module is faulty.	Refer to DTC 96 CURTAIN AIRBAG MODULE LH FAILURE , Diagnostic Chart with Trouble Code.
BB	Roll Over: Firing output	Curtain airbag module (LH/RH) and seat belt pretensioner (LH/RH) are inflated.	Refer to DTC BB ROLL OVER: FIRING OUTPUT , Diagnostic Chart with Trouble Code.
E2 E3 E4	Front Sensor Bus RH Communication error	Open or short circuit in harness (RH) between airbag control module and front sub sensor. Front sub sensor (RH) is faulty. Airbag control module is faulty.	Refer to DTC E2 FRONT SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC E3 FRONT SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC E4 FRONT SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
E6 E7 E8	Front Sensor Bus LH Communication error	Open or short circuit in harness (LH) between airbag control module and front sub sensor. Front sub sensor (LH) is faulty. Airbag control module is faulty.	Refer to DTC E6 FRONT SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC E7 FRONT SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC E8 FRONT SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
E9 EA EB EC	Side Sensor Bus RH Communication error	Open or short circuit in harness (RH) between airbag control module and side sensor. Side airbag sensor (RH) or curtain airbag sensor (RH) is faulty. Airbag control module is faulty.	Refer to DTC E9 SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC EA SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC EB SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC EC SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
ED EE	Side Sensor Bus RH Communication error	Open or short circuit in harness (RH) between airbag control module and side sensor. Side airbag sensor (RH) or curtain airbag sensor (RH) is faulty. Airbag control module is faulty.	Refer to DTC ED SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC EE SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
F1 F2 F3 F4	Side Sensor Bus LH Communication error	Open or short circuit in harness (LH) between airbag control module and side sensor. Side airbag sensor (LH) or curtain airbag sensor (LH) is faulty. Airbag control module is faulty.	Refer to DTC F1 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC F2 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC F3 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC F4 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
F5 F6	Side Sensor Bus LH Communication error	Open or short circuit in harness (LH) between airbag control module and side sensor. Side airbag sensor (LH) or curtain airbag sensor (LH) is faulty. Airbag control module is faulty.	Refer to DTC F5 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC F6 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
F8 F9 FA	Satellite Sensor Bus Communication error	Open or short circuit in harness between airbag control module and satellite safing sensor. Satellite safing sensor is faulty. Airbag control module is faulty.	Refer to DTC F8 SATELLITE SENSOR BUS COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC F9 SATELLITE SENSOR BUS COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Refer to DTC FA SATELLITE SENSOR BUS COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
3A	Front Sub Sensor RH false installation	Front sensor (RH) is misinstalled. Airbag control module is faulty.	Refer to DTC 3A FRONT SUB SENSOR RH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
3B	Front Sub Sensor LH false installation	Front sensor (LH) is misinstalled. Airbag control module is faulty.	Refer to DTC 3B FRONT SUB SENSOR LH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
3C	Satellite Sensor Bus failure	Satellite safing sensor is faulty.	Refer to DTC 3C SATELLITE SENSOR BUS FAILURE , Diagnostic Chart with Trouble Code.
3D	Satellite Sensor false installation	Satellite safing sensor is misinstalled. Airbag control module is faulty.	Refer to DTC 3D SATELLITE SENSOR FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
5A	Side Airbag Sensor RH false installation	Side A/B sensor is misinstalled. Airbag control module is faulty.	Refer to DTC 5A SIDE AIRBAG SENSOR RH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
5B	Side Airbag Sensor LH false installation	Side A/B sensor is misinstalled. Airbag control module is faulty.	Refer to DTC 5B SIDE AIRBAG SENSOR LH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
5C	Curtain Airbag Sensor RH false installation	Curtain A/B sensor is misinstalled. Airbag control module is faulty.	Refer to DTC 5C CURTAIN AIRBAG SENSOR RH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
5D	Curtain Airbag Sensor LH false installation	Curtain A/B sensor is misinstalled. Airbag control module is faulty.	Refer to DTC 5D CURTAIN AIRBAG SENSOR LH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.

DIAGNOSTIC TROUBLE CODE CHART
