SPECIAL TOOL
SPECIAL TOOL SPECIFICATION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 498575400 OIL PRESSURE GAUGE ASSY Used for measuring oil pressure. 498897200 OIL PRESSURE GAUGE ADAPTER Used at the oil pump housing when measuring reverse clutch pressure and line pressure. 498897700 OIL PRESSURE ADAPTER SET Used for measuring transfer clutch pressure. 498277200 STOPPER SET Used for removing and installing automatic transmission assembly to engine. 398527700 PULLER ASSY Used for removing the extension case roller bearing. Used for removing the extension oil seal. Used for removing the front differential side retainer bearing outer race. Used for removing the front differential side retainer oil seal. 498057300 INSTALLER Used for installing the extension oil seal. 41099AC000 ENGINE SUPPORT ASSY Used for supporting the engine. 498077000 REMOVER Used for removing the differential taper roller bearing. 499247400 INSTALLER Used for installing the transfer outer snap ring. Used together with the GUIDE (499257300). 499257300 SNAP RING OUTER GUIDE Used for installing the transfer outer snap ring. Used together with the INSTALLER (499247400). 18630AA010 WRENCH COMPL RETAINER Used for removing and installing the differential side retainer. WRENCH ASSEMBLY (499787000) can also be used. 398437700 DRIFT Used for installing the converter case oil seal. 398487700 INSTALLER Used for installing the front differential taper roller bearing. 398673600 COMPRESSOR Used for removing and installing the clutch spring. 498255400 PLATE Used for measuring the backlash of hypoid gear. 399893600 PLIERS Used for removing and installing the clutch spring. 498247001 MAGNET BASE Used for measuring the gear backlash. Used together with DIAL GAUGE (498247100). 498247100 DIAL GAUGE Used for measuring the gear backlash. Used together with MAGNET BASE (498247001). 498517000 REPLACER Used for removing the front roller bearing. 398623600 SEAT Used for removing the spring of the transfer clutch piston. 499267300 STOPPER PIN Used for installing the inhibitor switch. 499787700 WRENCH Used for removing and installing the drive pinion lock nut. 499787500 ADAPTER Used for removing and installing the drive pinion lock nut. 398643600 GAUGE Used for measuring the total end play, extension end play and drive pinion height. 498627100 SEAT Used for holding the low clutch piston retainer spring when installing snap ring. 499577000 GAUGE Used for measuring the mating surface of the transmission to the end face of the reduction gear. 499737000 PULLER Used for removing the reduction driven gear assembly. 499737100 PULLER SET Used for removing the reduction drive gear assembly. 498077600 REMOVER Used for removing the ball bearing. 498937110 HOLDER Used for removing and installing the drive pinion lock nut. 498677100 COMPRESSOR Used for installing the 2-4 brake snap ring. 498437000 HIGH CLUTCH PISTON GUIDE Used for installing the high clutch piston. 498437100 LOW CLUTCH PISTON GUIDE Used for installing the low clutch piston. 899580100 INSTALLER Used for press-fitting the ball bearing of the transfer clutch. 28399SA010 OIL SEAL PROTECTOR Used for installing the axle shaft. 18675AA000 DIFFERENTIAL SIDE OIL SEAL INSTALLER Used for installing the differential side retainer oil seal. 398497701 INSTALLER Used for installing the needle bearing. 899524100 PULLER SET Use only the bolt. Used together with the PULLER SET (499737100). Used together with the PULLER (499737000). Puller Cap 499247300 INSTALLER Used for installing the oil pump housing retainer oil seal. 398791600 REMOVER Used for removing the shifter arm spring pin. 1B022XU0 (Newly adopted tool) SUBARU SELECT MONITOR III KIT Troubleshooting for electrical system
