Engine Intake System - Intake (Induction) (H4DOTC): Removal & Installation Subaru Forester SH

Mechanical 11 illustrations ~411 words

INSTALLATION

Install in the reverse order of removal.

CAUTIONBe sure to use SUBARU genuine air cleaner element depending on the engine type when replacing the air cleaner elements. Otherwise engine performance may be damaged.

Note. Check that there are no foreign objects in the air cleaner case.

Install in the reverse order of removal.

Note. When installing the air cleaner case (rear), align the protrusion of the air cleaner case (rear) to the hole on the air cleaner case (front) to install.

Scheme 54

Scheme 54: INSTALLATION

Tightening torque

Bolt (A)

6 N.m (0.6 kgf-m, 4.4 ft-lb)

Nut (B)

7.5 N.m (0.8 kgf-m, 5.5 ft-lb)

Tightening torque

2.5 N.m (0.3 kgf-m, 1.8 ft-lb)

Scheme 55

Scheme 55

Install in the reverse order of removal.

REMOVAL

  1. Remove the collector cover.
  2. Disconnect the ground cable from the battery.
  3. Remove the intake manifold. Refer to «REMOVAL»(ref-325306-S22805286222009071800000) , Intake Manifold .
  4. Remove the sensor, engine harness and fuel pipe attached to the intake manifold. Refer to «DISASSEMBLY»(ref-325306-S32133092572009071800000) , Intake Manifold .
  5. Remove the intake duct from intake manifold.

Scheme 56

Scheme 56

Install in the reverse order of removal.

Tightening torque

17 N.m (1.7 kgf-m, 12.5 ft-lb)

Scheme 57

Scheme 57: REMOVAL

Scheme 58

Scheme 58

Scheme 59

Scheme 59
  1. Remove the collector cover.
  2. Disconnect the air by-pass pipe (A) and vacuum hose (B) from the air by-pass valve.
  3. Loosen the clamp (C) which connects the air intercooler and intake duct.
  4. Remove the bolts which secure the intercooler to the turbocharger.
  5. Remove the bolts which secure the intercooler to the intercooler stay, and remove the intercooler.
  6. Remove the brake booster vacuum hose from the brake booster vacuum hose clip (A), and re-A: REMOVAL move the intercooler stay.

Scheme 60

Scheme 60

Install in the reverse order of removal.

Note. Use new O-rings. Be careful not to pinch the O-ring.

Tightening torque

16 N.m (1.6 kgf-m, 11.8 ft-lb)

Scheme 61

Scheme 61: INSTALLATION

Tightening torque: 3 N.m (0.3 kgf-m, 2.2 ft-lb)

Scheme 62

Scheme 62
  1. Install the collector cover.
  2. Disconnect the air by-pass pipe (A) and vacuum hose (B) from the air by-pass valve (C).
  3. Remove the air by-pass valve (C) from the inter-cooler.

Scheme 63

Scheme 63

Install in the reverse order of removal.

Note. Use new O-rings. Be careful not to pinch the O-ring.

Tightening torque

6.5 N.m (0.7 kgf-m, 4.8 ft-lb)

Scheme 64

Scheme 64: INSTALLATION

The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to "Air Cleaner Case" for the removal procedure. Refer to REMOVAL , Air Cleaner Case .

The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to "Air Cleaner Case" for installation procedure. Refer to INSTALLATION , Air Cleaner Case .
