INSTALLATION
Install in the reverse order of removal.
| CAUTION | Be sure to use SUBARU genuine air cleaner element depending on the engine type when replacing the air cleaner elements. Otherwise engine performance may be damaged. |
Note. Make sure there is no foreign material in the air cleaner case. When installing the air cleaner case (rear), align the protrusion of the air cleaner case (rear) to the hole on the air cleaner case (front) to install.
Scheme 501
Tightening torque
Clamp (A)
3 N.m (0.3 kgf-m, 2.2 ft-lb)
Install in the reverse order of removal.
Tightening torque
Bolt (A)
6 N.m (0.6 kgf-m, 4.4 ft-lb)
NUT (B)
7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
Note. When installing the air cleaner case (rear), align the protrusion of the air cleaner case (rear) to the hole on the air cleaner case (front) to install.
Tightening torque
Clamp (A)
3 N.m (0.3 kgf-m, 2.2 ft-lb)
Install in the reverse order of removal.
Tightening torque
Clamp (A), (B)
3 N.m (0.3 kgf-m, 2.2 ft-lb)
Bolt (C)
6.5 N.m (0.7 kgf-m, 4.8 ft-lb)
Scheme 502
Install in the reverse order of removal.
REMOVAL
The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to "Air Cleaner Case" for the removal procedure. Refer to REMOVAL , Air Cleaner Case .
The resonator chamber and air cleaner case are integrated into one unit; therefore, refer to "Air Cleaner Case" for installation procedure. Refer to INSTALLATION , Air Cleaner Case .
