SPECIFICATION
| Engine | Model | 2.5 L | ||
|---|---|---|---|---|
| Cylinder arrangement | Horizontally opposed, liquid cooled, 4-cylinder, 4-stroke gasoline engine | |||
| Valve system mechanism | Belt driven Single overhead camshaft 4 valve/cylinder | |||
| Bore x Stroke | Mm (in) | 99.5 x 79.0 (3.917 x 3.110) | ||
| Piston displacement | Cm 3 (cu. in) | 2,457(150) | ||
| Compression ratio | 10.0 | |||
| Compression pressure (at 200 - 300 RPM) | KPa (kg/cm 2 , psi) | 1,020 - 1,275 (10.4 - 13.0, 148 - 185) | ||
| Number of piston rings | Pressure ring: 2, Oil ring: 1 | |||
| Intake valve timing | Constant | Open | BTDC 0° | |
| Close | ABDC 58° | |||
| Low speed | Open | BTDC 0° | ||
| Close | ABDC - 10° | |||
| High speed | Open | BTDC 14° | ||
| Close | ABDC 62° | |||
| Exhaust valve timing | Open | BBDC 30° | ||
| Close | ATDC 14° | |||
| Valve clearance | Mm (in) | Intake | 0.20±0.04 (0.0079±0.0016) | |
| Exhaust | 0.25±0.04 (0.0098±0.0016) | |||
| Idling speed [at neutral position on MT, or "P" or "N" position on AT] | RPM | MT | 650±100 (No load) 850±100 (A/CON) | |
| AT | 700±100 (No load) 850±100 (A/C ON) | |||
| Ignition order | 1 --> 3 --> 2 --> 4 | |||
| Ignition timing | BTDC/RPM | MT | 10°±8°/650 | |
| AT | 15°±10°/700 | |||
SPECIFICATION
Note. US: Undersize OS: Oversize
| Belt tension adjuster | Protrusion of adjuster rod | Mm (in) | 5.2 - 6.2 (0.205 - 0.244) | ||
|---|---|---|---|---|---|
| Valve rocker arm | Clearance between shaft and arm | Mm (in) | Standard | 0.020 - 0.054 (0.0008 - 0.0021) | |
| Camshaft | Bending limit | Mm (in) | 0.025 (0.0010) | ||
| Thrust clearance | Mm (in) | Standard | 0.030 - 0.090 (0.0012 - 0.0035) | ||
| Cam lobe height mm (in) | Intake | Constant | Standard | 40.075 - 40.175 (1.5778 - 1.5817) | |
| Low speed | Standard | 35.496 - 35.596 (1.3975 - 1.4014) | |||
| High speed | Standard | 40.315 - 40.415 (1.5872 - 1.5911) | |||
| Exhaust | Standard | 39.289 - 39.389 (1.5468 - 1.5507) | |||
| Camshaft journal O.D. | Mm (in) | 31.928 - 31.945 (1.2570 - 1.2577) | |||
| Camshaft journal hole I.D. | Mm (in) | 32.000 - 32.018 (1.2598 - 1.2605) | |||
| Oil clearance | Mm (in) | Standard | 0.055 - 0.090 (0.0022 - 0.0035) | ||
| Cylinder head | Surface warpage limit (Mating surface with cylinder block) | Mm (in) | 0.035 (0.0014) | ||
| Grinding limit | Mm (in) | 0.1 (0.004) | |||
| Standard height | Mm (in) | 97.5 (3.84) | |||
| Valve seat | Seating angle | 90° | |||
| Contacting width | Mm (in) | Intake | Standard | 0.8 - 1.4(0.03 - 0.055) | |
| Exhaust | Standard | 1.2 - 1.8(0.047 - 0.071) | |||
| Valve guide | Inside diameter | Mm (in) | 6.000 - 6.012 (0.2362 - 0.2367) | ||
| Protrusion above head | Mm (in) | Intake | 20.0 - 21.0 (0.787 - 0.827) | ||
| Exhaust | 16.5 - 17.5 (0.650 - 0.689) | ||||
| Valve | Head edge thickness | Mm (in) | Intake | Standard | 0.8 - 1.2 (0.03 - 0.047) |
| Exhaust | Standard | 1.0 - 1.4 (0.039 - 0.055) | |||
| Stem outer diameter | Mm (in) | Intake | 5.950 - 5.965 (0.2343 - 0.2348) | ||
| Exhaust | 5.945 - 5.960 (0.2341 - 0.2346) | ||||
| Valve stem gap | Mm (in) | Standard | Intake | 0.035 - 0.062 (0.0014 - 0.0024) | |
| Exhaust | 0.040 - 0.067 (0.0016 - 0.0026) | ||||
| Overall length | Mm (in) | Intake | 120.6 (4.75) | ||
| Exhaust | 121.7 (4.79) | ||||
| Valve spring | Free length | Mm (in) | 55.2 (2.173) | ||
| Squareness | 2.5°, 2.4 (0.094) or less | ||||
| Tension/spring height | N (kgf, lb)/mm (in) | Set | 235.3 - 270.7 (24 - 27.6, 52.9 - 60.8)/45.0 (1.772) | ||
| Lift | 578.9 - 639.9 (59.1 - 65.3, 130.3 - 143.9)/34.7 (1.366) | ||||
| Cylinder block | Surface warpage limit (mating with cylinder head) | Mm (in) | 0.025 (0.00098) | ||
| Grinding limit | Mm (in) | 0.1 (0.004) | |||
| Standard height | Mm (in) | 201.0 (7.91) | |||
| Cylinder inner diameter | Mm (in) | Standard | A | 99.505 - 99.515 (3.9175 - 3.9179) | |
| B | 99.495 - 99.505 (3.9171 - 3.9175) | ||||
| Taper | Mm (in) | Standard | 0.015 (0.0006) | ||
| Out-of-roundness | Mm (in) | Standard | 0.010 (0.0004) | ||
| Piston clearance | Mm (in) | Standard | 0.010 - 0.010 (-0.00039 - 0.00039) | ||
| Cylinder inner diameter boring limit (diameter) | Mm (in) | To 100.005 (3.9372) | |||
| Piston | Outer diameter | Mm (in) | Standard | A | 99.505 - 99.515 (3.9175 - 3.9179) |
| B | 99.495 - 99.505 (3.9171 - 3.9175) | ||||
| 0.25 (0.0098) OS | 99.745 - 99.765 (3.9270 - 3.9278) | ||||
| 0.50 (0.0197) OS | 99.995 - 100.015 (3.9368 - 3.9376) | ||||
| Piston pin | Clearance between piston and piston pin | Mm (in) | Standard | 0.004 - 0.008 (0.0002 - 0.0003) | |
| Degree of fit | Piston pin can be fitted into position with thumb at 20°C (68°F). | ||||
| Piston ring | Ring closed gap | Mm (in) | Top ring | Standard | 0.20 - 0.35 (0.0079 - 0.0138) |
| Second ring | Standard | 0.37 - 0.52 (0.0144 - 0.0203) | |||
| Oil ring | Standard | 0.20 - 0.50 (0.0079 - 0.0197) | |||
| Ring groove gap | Mm (in) | Top ring | Standard | 0.040 - 0.080 (0.0016 - 0.0031) | |
| Second ring | Standard | 0.030 - 0.070 (0.0012 - 0.0028) | |||
| Connecting rod | Bend or twist per 100 mm (3.94 in) in length | Mm (in) | Limit | 0.10 (0.0039) | |
| Thrust clearance | Mm (in) | Standard | 0.070 - 0.330 (0.0028 - 0.0130) | ||
| Bearing of large end | Oil clearance | Mm (in) | Standard | 0.016 - 0.044 (0.00063 - 0.0017) | |
| Bearing size (Thickness at center) | Mm (in) | Standard | 1.492 - 1.501 (0.0587 - 0.0591) | ||
| 0.03 (0.0012) US | 1.510 - 1.513 (0.0594 - 0.0596) | ||||
| 0.05 (0.0020) US | 1.520 - 1.523 (0.0598 - 0.0600) | ||||
| 0.25 (0.0098) US | 1.620 - 1.623 (0.0638 - 0.0639) | ||||
| Bushing of small end | Clearance between piston pin and bushing | Mm (in) | Standard | 0 - 0.022 (0 - 0.0009) | |
| Crankshaft | Bend limit | Mm (in) | 0.035 (0.0014) | ||
| Crank pin | Out-of-roundness | Mm (in) | 0.003 (0.0001) | ||
| Cylindricality | Mm (in) | 0.004 (0.0002) | |||
| Grinding limit (dia.) | Mm (in) | To 51.750 (2.0374) | |||
| Crank journal | Out-of-roundness | Mm (in) | 0.005 (0.0002) | ||
| Cylindricality | Mm (in) | 0.006 (0.0002) | |||
| Grinding limit (dia.) | Mm (in) | To 59.758 (2.3527) | |||
| Crank pin outer diameter | Mm (in) | Standard | 51.984 - 52.000 (2.0466 - 2.0472) | ||
| 0.03 (0.0012) US | 51.954 - 51.970 (2.0454 - 2.0461) | ||||
| 0.05 (0.0020) US | 51.934 - 51.950 (2.0446 - 2.0453) | ||||
| 0.25 (0.0098) US | 51.734 - 51.750 (2.0368 - 2.0374) | ||||
| Crank journal outer diameter | Mm (in) | Standard | 59.992 - 60.008 (2.3619 - 2.3625) | ||
| 0.03 (0.0012) US | 59.962 - 59.978 (2.3607 - 2.3613) | ||||
| 0.05 (0.0020) US | 59.942 - 59.958 (2.3599 - 2.3605) | ||||
| 0.25 (0.0098) US | 59.742 - 59.758 (2.3520 - 2.3527) | ||||
| Thrust clearance | Mm (in) | Standard | 0.030 - 0.115 (0.0012 - 0.0045) | ||
| Oil clearance | Mm (in) | Standard | 0.010 - 0.030 (0.0001 - 0.0012) | ||
| Main bearing | Main bearing mm (in) | #1, #3 | Standard | 1.998 - 2.011 (0.0787 - 0.0792) | |
| 0.03(0.0012) US | 2.017 - 2.020 (0.0794 - 0.0795) | ||||
| 0.05 (0.0020) US | 2.027 - 2.030 (0.0798 - 0.0799) | ||||
| 0.25 (0.0098) US | 2.127 - 2.130 (0.0837 - 0.0839) | ||||
| #2, #4, #5 | Standard | 2.000 - 2.013 (0.0787 - 0.0793) | |||
| 0.03 (0.0012) US | 2.019 - 2.022 (0.0795 - 0.0796) | ||||
| 0.05 (0.0020) US | 2.029 - 2.032 (0.0799 - 0.0800) | ||||
| 0.25 (0.0098) US | 2.129 - 2.132 (0.0838 - 0.0839) | ||||
SPECIFICATION
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
Scheme 74
Scheme 75
Refer to "Cylinder Head" for removal and installation procedures of the intake and exhaust valves. Refer to REMOVAL , Cylinder Head . Refer to INSTALLATION , Cylinder Head .
Refer to "Cylinder Block" for removal and installation procedures of pistons. Refer to REMOVAL , Cylinder Block . Refer to INSTALLATION , Cylinder Block .
Refer to "Cylinder Block" for removal and installation procedures of connecting rod.
Refer to REMOVAL , Cylinder Block . Refer to INSTALLATION , Cylinder Block .
Refer to "Cylinder Block" for removal and installation procedures of the crankshaft. Refer to REMOVAL , Cylinder Block . Refer to INSTALLATION , Cylinder Block .
