Engine Mechanical (H4SO): Adjustments Subaru Forester SH

ADJUSTMENT

Note. Adjustment of valve clearance should be performed while engine is cold.

Scheme 76

1. Set #1 cylinder piston to top dead center of compression stroke by rotating the crank pulley clockwise using the socket wrench. NOTE: When the arrow mark (A) on cam sprocket LH is at the top position, the #1 cylinder piston is at top dead center of the compression stroke.
2. Adjust the #1 cylinder valve clearance. Loosen the valve rocker nut and screw. Set a suitable thickness gauge. While noting the valve clearance, tighten the valve rocker adjusting screw. When the specified valve clearance is obtained, tighten the valve rocker nut. NOTE: Insert a thickness gauge in a direction as horizontal as possible with respect to the valve stem end face. Lift up the vehicle and adjust the exhaust valve clearances. Valve clearance: Intake 0.20±0.04 mm (0.0079±0.0016 in) Exhaust 0.25±0.04 mm (0.0098±0.0016 in) Tightening torque: 9.75 N.m (1.0 kgf-m, 7.2 ft-lb)
3. Adjust the valve clearance in #3, #2 and #4 cylinder in the same adjustment procedure as #1 cylinder in this order. NOTE: Be sure to set the cylinder pistons to their respective top dead centers on compression stroke before adjusting valve clearances. By rotating the crank pulley clockwise every 180° from the state that #1 cylinder piston is on the top dead center of compression stroke, #3, #2 and #4 cylinder pistons come to the top dead center of compression stroke in this order.
4. Ensure the valve clearances of each cylinder are within specifications. If necessary, readjust the valve clearances.

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

1. Set the vehicle on a lift.
2. Change the bolt mounting position from (A) to (B), and completely open the front hood. Tightening torque: 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
3. Remove the V-belt cover.
4. Collect the refrigerant from the A/C system. Refer to «PROCEDURE»(ref-325325-S26489702442009071800000) , Refrigerant Recovery Procedure .
5. Release the fuel pressure. Refer to «RELEASING OF FUEL PRESSURE»(ref-325305-S19314969582009071800000) , PROCEDURE, Fuel .
6. Disconnect the battery cable, and then remove the battery from the vehicle body.
7. Remove the air intake duct (rear), air cleaner case and air intake chamber. Refer to «REMOVAL»(ref-325315-S30653479982009071800000) , Air Intake Duct . Refer to «REMOVAL»(ref-325315-S39932705032009071800000) , Air Cleaner Case . Refer to «REMOVAL»(ref-325315-S02698974742009071800000) , Air Intake Chamber .
8. Remove the under cover.
9. Remove the radiator from the vehicle. Refer to «REMOVAL»(ref-325303-S32974862152009071800000) , Radiator .
10. Disconnect the A/C pressure hoses from A/C compressor.
11. Remove the air intake chamber stay.
12. Disconnect the following connectors and cables. Front oxygen (A/F) sensor connector Rear oxygen sensor connector Engine ground terminal Remove the bolt, and disconnect the engine harness connector from the bulk head harness connector and rear engine hanger. Generator connector and terminal A/C compressor connector Power steering switch connector
13. Disconnect the following hoses. Brake booster vacuum hose Heater inlet and outlet hoses
14. Remove the power steering pump. Remove the front side belts. Refer to «FRONT SIDE BELT»(ref-325301-S19102835222009071800000) , REMOVAL, V-belt . Remove the bolts which secure the power steering pump to the bracket. Place the power steering pump on the right side wheel apron.
15. Lift up the vehicle.
16. Remove the front and center exhaust pipes. Refer to «REMOVAL»(ref-325320-S27719048492009071800000) , Front Exhaust Pipe .
17. Disconnect the engine ground terminal from the cylinder head.
18. Remove the bolts and nuts which hold lower side of transmission to engine. AT model MT model
19. Remove the nuts which hold the engine mount to the front crossmember.
20. Separate the torque converter clutch from drive plate. (AT model) Lower the vehicle. Remove the service hole plug. Remove the bolts which hold torque converter clutch to drive plate. Remove all bolts while turning the crankshaft with a socket wrench.
21. Remove the pitching stopper.
22. Disconnect the fuel hoses from fuel pipe. Disconnect the quick connector on the fuel delivery line by pushing the ST in the direction of the arrow. ST 42099AE000 QUICK CONNECTOR RELEASE Remove the clip and disconnect the evaporation hose from the pipe. CAUTION: Be careful not to spill fuel. Catch the fuel from hoses using a container or cloth.
23. Support the engine with a lifting device and wire ropes.
24. Support the transmission with a garage jack. CAUTION: Doing this is very important to prevent the transmission from lowering due to its own weight.
25. Separation of engine and transmission. CAUTION: Before removing the engine away from transmission, check to be sure no work has been overlooked. Remove the starter. Refer to «REMOVAL»(ref-325316-S07256448182009071800000) , Starter . Set the ST to torque converter clutch case. (AT model) ST 498277200 STOPPER SET Remove the bolts which hold upper side of transmission to engine. AT model MT model
26. Remove the engine from vehicle. Slightly raise the engine. Raise the transmission with garage jack. Move the engine horizontally until main shaft is withdrawn from clutch cover. Slowly move the engine away from engine compartment. NOTE: Be careful not to damage adjacent parts or body panels with crank pulley, oil level gauge, etc.
27. Remove the engine mount.

Scheme 101

1. Install the engine mount onto the engine. Tightening torque: 35 N.m (3.6 kgf-m, 25.8 ft-lb)
2. Apply a small amount of grease to splines of main shaft. (MT model)
3. Position the engine in engine compartment and align it with transmission. NOTE: Be careful not to damage adjacent parts or body panels with crank pulley, oil level gauge, etc.
4. Tighten the bolts which hold upper side of transmission to engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb) AT model MT model
5. Remove the lifting device and wire ropes.
6. Remove the garage jack.
7. Install the pitching stopper. Tightening torque: T1:50 N.m (5.1 kgf-m, 36.9 ft-lb) T2:58 N.m (5.9 kgf-m, 42.8 ft-lb)
8. Remove the ST from the torque converter clutch case. (AT model) NOTE: Be careful not to drop the ST into the torque converter clutch case when removing the ST. ST 498277200 STOPPER SET
9. Install the starter. Refer to «INSTALLATION»(ref-325316-S02097978352009071800000) , Starter .
10. Install the torque converter clutch to drive plate. (AT model) Tighten the bolts which hold torque converter clutch to drive plate. Tighten other bolts while rotating the crankshaft using socket wrench. NOTE: Be careful not to drop bolts into the torque converter clutch housing. Tightening torque: 25 N.m (2.5 kgf-m, 18.4 ft-lb) Install the service hole plug.
11. Install the power steering pump. Install the power steering pump to the bracket. Tightening torque: Refer to "COMPONENT" of "Power Steering" for the tightening torque . Refer to «COMPONENT»(ref-325326-S32161679162009071800000) , General Description . Connect the power steering switch connector. Install and adjust the front side belt. Refer to «FRONT SIDE BELT»(ref-325301-S23605295592009071800000) , INSTALLATION, V-belt .
12. Lift up the vehicle.
13. Tighten the bolts and nuts which hold lower side of the transmission to engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb) AT model MT model
14. Tighten the nuts which hold the engine mount to the crossmember. Tightening torque: 85 N.m (8.7 kgf-m, 62.7 ft-lb)
15. Install the engine ground terminal to the cylinder head. Tightening torque: 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
16. Install the front and center exhaust pipe. Refer to «INSTALLATION»(ref-325320-S17605180082009071800000) , Front Exhaust Pipe .
17. Lower the vehicle.
18. Connect the following hoses. Fuel delivery hose and evaporation hose Heater inlet and outlet hoses Brake booster vacuum hose
19. Connect the following connectors and terminals. Front oxygen (A/F) sensor connector Rear oxygen sensor connector Engine harness connectors Tightening torque: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb) Generator connector and terminal Tightening torque: 15 N.m (1.5 kgf-m, 11.1 ft-lb) A/C compressor connector
20. Install the air intake chamber stay. Tightening torque: 16 N.m (1.6 kgf-m, 11.8 ft-lb)
21. Tighten the engine ground cable. Tightening torque: 14 N.m (1.4 kgf-m, 10.3 ft-lb)
22. Install the A/C pressure hoses. Refer to «INSTALLATION»(ref-325325-S11602039362009071800000) , Hose and Pipe .
23. Install the radiator to the vehicle. Refer to «INSTALLATION»(ref-325303-S03785754692009071800000) , Radiator .
24. Install the air intake duct (rear), air cleaner case and air intake chamber. Refer to «INSTALLATION»(ref-325315-S11089239642009071800000) , Air Intake Duct . Refer to «INSTALLATION»(ref-325315-S22952708492009071800000) , Air Cleaner Case . Refer to «INSTALLATION»(ref-325315-S09948998262009071800000) , Air Intake Chamber .
25. Install the under cover.
26. Install the battery in the vehicle, and connect cables.
27. Fill engine coolant. Refer to «FILLING OF ENGINE COOLANT»(ref-325303-S16537224662009071800000) , REPLACEMENT, Engine Coolant .
28. Check the ATF level and replenish it if necessary. Refer to «INSPECTION»(ref-325309-S11821766972009071800000) , Automatic Transmission Fluid .
29. Charge the A/C system with refrigerant. Refer to «PROCEDURE»(ref-325325-S06059658022009071800000) , Refrigerant Charging Procedure .
30. Install the V-belt cover. Tightening torque: 13 N.m (1.3 kgf-m, 9.6 ft-lb)
31. Change the bolt mounting position from (B) to (A), and close the front hood. Tightening torque: 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
32. Lower the vehicle from the lift.
