FRONT WASHER ADJUSTMENT
Adjust washer nozzles so fluid sprays at proper place on windshield, according to washer spray dimensions table and illustration. See appropriate FRONT WASHER SPRAY DIMENSIONS table. (Scheme 1)
| Dimension | (1) Inches (mm) |
|---|
| A | 13.78 (350) |
| B | 3.94 (100) |
| C | 2.36 (60) |
| (1) All measurements are made from center line of windshield. |
| (1) | All measurements are made from center line of windshield. |
FRONT WASHER SPRAY DIMENSIONS (FORESTER)
| Dimension | (1) Inches (mm) |
|---|
| A | 15.75 (400) |
| B | 5.90 (150) |
| C | 3.94 (100) |
| (1) All measurements are made from center line of windshield. |
| (1) | All measurements are made from center line of windshield. |
FRONT WASHER SPRAY DIMENSIONS (IMPREZA)
| Dimension | (1) Inches (mm) |
|---|
| A | 13.78 (350) |
| B | 3.94 (100) |
| C | 7.87 (200) |
| (1) All measurements are made from center line of windshield. |
| (1) | All measurements are made from center line of windshield. |
FRONT WASHER SPRAY DIMENSIONS (LEGACY & OUTBACK)
Scheme 1
FRONT WIPER ARM ADJUSTMENT
Turn ignition switch to RUN position. Ensure wipers are off and movement has stopped. Turn ignition switch to OFF position. Adjust wiper arm during installation to set blade(s) in correct position. See FRONT WIPER ARM DIMENSION table. (Scheme 2)
| Dimension | Inches (mm) |
|---|
| Forester, Legacy & Outback | (1) |
| Impreza |
| A | .6-1.2 (15-30) |
| B | 1.0-1.6 (25-40) |
| (1) Position blade ends on upper end of ceramic print on bottom of windshield. |
| (1) | Position blade ends on upper end of ceramic print on bottom of windshield. |
FRONT WIPER ARM DIMENSION
Scheme 2
