Component description for the camshaft adjuster - GF05.20-P-1110MCC
ENGINE 132.9 in MODEL 451.3/4
Location
The camshaft adjuster is located on the side on the engine on the intake camshaft.
Task
The camshaft adjuster allows the intake camshaft to be turned in the direction "advanced" (large valve overlap) or "retarded" (low valve overlap).
Scheme 145
Component description for adjustable camshaft timing solenoid - GF05.20-P-2100MCC
ENGINE 132.9 in MODEL 451.3/4
Location
The adjustable camshaft timing solenoid is located at the upper right on the cylinder head.
Task
The adjustable camshaft timing solenoid controls the oil pressure for the camshaft adjuster.
Scheme 146
Scheme 147
Function
Actuation of the adjustable camshaft timing solenoid takes place map-controlled via the ME-SFI [ME] control unit (N3/10).
The adjustable camshaft timing solenoid integrated in the oil circuit guides the engine oil, according to actuation, through the ME-SFI [ME] control unit (N3/10), via the oil pressure line "advanced" or the oil pressure line "retarded" to the camshaft adjuster.
Excess engine oil in the engine oil circuit is led back via the return on the adjustable camshaft timing solenoid.
