Engine Timing (Coupe): Overhaul Smart Fortwo II

Mechanical 3 illustrations ~295 words

602 589 02 40 00 Assembly links - WS05.00-P-0171C

FG 05/18/Set C

ENGINE all

Use

Assembly links (3 in total) for simplex roller chain, duplex roller chain and duplex bushed roller chain for connecting repair chain to installed chain

Assembly links must not be left in the engine

Scheme 177

Scheme 177: 602 589 02 40 00 Assembly links - WS05.00-P-0171C
Scheme 177: 602 589 02 40 00 Assembly links - WS05.00-P-0171C

Scheme 178

Scheme 178
Scheme 178

111 589 25 61 00 Valve assembly tools kit - WS05.00-P-3137BA

FG 05/Set B

ENGINE 104, 111, 112, 113, 119, 120, 122, 132, 134, 135, 155, 156, 159, 160, 166, 266, 271, 272, 273, 601, 602, 603, 604, 605, 606, 611 /980, 612 /965 /966, 613, 628, 629, 639, 640, 642, 646, 647, 648, 651, 660, 668

ENGINE 648.960 in MODEL 220

Separate part111 589 25 61 06 Thrust forkFG05/Set CWS05.00-P-3137-06C
Separate part111 589 25 61 12 Fixing bracketFG05/Set CWS05.00-P-3137-12C
Separate part111 589 25 61 19 Step spacingFG05/Set CWS05.00-P-3137-19C
Separate part111 589 25 61 03 Lever handleFG05/Set CWS05.00-P-3137-03C
Separate part111 589 25 61 05 Detent depressorFG05/Set CWS05.00-P-3137-05C

Use

Assembly tool for valve springs in a plastic case.

Note. For engines with tappet holes in cylinder head assembly of the valve keys is performed automatically by the assembly cartridges.

Scheme 179

Scheme 179
Scheme 179

Consisting of

Part 1 Empty case

Part 2 Impact pin

Part 3 Lever handle

Part 4 Extension

Part 5 Detent depresser for thrust piece

Part 6 Thrust fork for assembly cartridges

Part 7 Thrust piece for detent depresser

Part 8 Assembly cartridge length 83 mm (gasoline engine)

Part 9 Assembly cartridge length 102 mm (diesel engine)

Part 10 Pilot bushing length 28.6 mm (gasoline engine)

Part 11 Pilot bushing length 53 mm (diesel engine)

Part 12 Retaining fork M 6 X 15 mm

Part 13 Retaining fork M 7 X 25 mm

Part 14 Retaining fork M 7 X 30 (bolt length 60 mm)

Part 15 Retaining fork M 8 X 20 mm

Part 16 Threaded hook M6 X 23 mm

Part 17 Threaded hook M7 X 23 mm

Part 18 Threaded hook M8 X 20 mm

Part 19 Grid with a joint bearing
