Bolt tightening procedure for cylinder head cover - AR01.20-P-5014-03MCC
| Number | Designation | Engine 132.9 | |
|---|---|---|---|
| BA01.20-P-1002-01I | Bolt, cylinder head cover to cylinder head | Nm | 10 |
CRANKCASE VENTILATION, CYLINDER HEAD COVER
Scheme 1
- Screw in bolts (1 to 10) for cylinder head cover in a number of stages according to the represented sequence all the way and tighten using the prescribed torque. Loosen bolts for the cylinder head cover in reverse order of the tightening procedure.
Tightening procedure for cylinder head bolts - AR01.30-P-5800-01MCC
| Number | Designation | Engine 132.9 | ||
|---|---|---|---|---|
| BA01.30-P-1001-01K | Bolt, cylinder head to crankcase | Stage 1 | Nm | 25 |
| Stage 2 | Angle° | 90 | ||
| Stage 3 | Angle° | 90 | ||
| Stage 4 | Angle° | |||
CYLINDER HEAD
Scheme 2
- Tighten cylinder head bolt (1 to 8) in stages in sequence of the tightening procedure. Direction of travel see arrow.
Tightening torques: Smart: Complete engine, crankcase ventilation, cylinder head, crankcase - BA01.00-Z-9999CZ
MODEL all
| Crankcase, timing case cover, end cover | ENGINE 134.910 /911, 135.930 /950 | BA01.40-P-1000-01O |
|---|---|---|
| Crankcase, timing case cover, end cover | ENGINE 660.940 /950 | BA01.40-P-1000-01N |
| Crankcase, timing case cover, end cover | ENGINE 132.9, 160.910 /920 /921 /922 /923 | BA01.40-P-1000-01M |
| Crankcase, timing case cover, end cover | ENGINE 639.9 in MODEL 454.0 | BA01.40-P-1000-01V |
| Crankcase, timing case cover, end cover | ENGINE 122.9 in MODEL 454.0 | BA01.40-P-1000-01U |
| Crankcase ventilation, cylinder head cover | ENGINE 122.950, 134.910 /911, 135.930/950 | BA01.20-P-1000-01K |
| Crankcase ventilation, cylinder head cover | ENGINE 660.940 /950 /951 | BA01.20-P-1000-01J |
| Crankcase ventilation, cylinder head cover | ENGINE 132.9, 160.910 /920 /921 /922 /923 | BA01.20-P-1000-01I |
| Crankcase ventilation, cylinder head cover | ENGINE 639.939 | BA01.20-P-1000-01O |
| Cylinder head | ENGINE 122.950 | BA01.30-P-1000-01T |
| Cylinder head | ENGINE 639.939 | BA01.30-P-1000-01R |
| Cylinder head | ENGINE 134.910 /911, 135.930 /950 | BA01.30-P-1000-01N |
| Cylinder head | ENGINE 660.940 /950 /951 | BA01.30-P-1000-01L |
| Cylinder head | ENGINE 132.9, 160.910 /920 /921 /922 /923 | BA01.30-P-1000-01K |
| Oil pan | ENGINE 122.950, 134.910 /911, 135.930/950 | BA01.45-P-1000-01L |
| Oil pan | ENGINE 660.940 /950 /951 | BA01.45-P-1000-01K |
| Oil pan | ENGINE 132.9, 160.910 /920 /921 /922 /923 | BA01.45-P-1000-01J |
| Oil pan | ENGINE 639.939 | BA01.45-P-1000-01P |
Test specifications for cylinder bore - BE01.40-P-1000-01P
Engine 132
| Number | Designation | Engine 132.910/930 | ||
|---|---|---|---|---|
| BE01.40-P-1001-01P | Ø of cylinder bore | Standard size | Mm | 72.010 to 72.025 |
| Out-of-roundness (in a new condition) | Mm | 0.01 | ||
| Wear limit in longitudinal and transverse direction | Mm | 0.15 | ||
TEST SPECIFICATIONS FOR CYLINDER BORE
See also:
• AS00.00-Z-0010-01A
