Engine mounts, engine supports - BA22.10-P-1000-01M
Engine 132, 160, 780.009
| Number | Designation | Engine 132.9 | Engine 160.922 | Engine 160.923 | ||
|---|---|---|---|---|---|---|
| BA22.10-P-1001-01M | Bolt, engine support to cylinder head | Initial torque | Nm | 28 | 28 | |
| Retightening torque | Nm | 23 | 23 | |||
| BA22.10-P-1002-01M | Bolt, rear engine support to transmission | Initial torque | Nm | 28 | 28 | |
| Retightening torque | Nm | 23 | 23 | |||
| BA22.10-P-1003-01M | Bolt, front engine support to crankcase | Initial torque | Nm | 28 | 28 | |
| Retightening torque | Nm | 23 | 23 | |||
| BA22.10-P-1004-01M | Bolt, front engine support to frame-type integral support | Nm | 58 | 58 | ||
| BA22.10-P-1005-01M | Bolt, rear engine support to frame-type integral support | Nm | 58 | 58 | ||
| BA22.10-P-1006-01M | Bolt, right engine mount to frame-type integral support | Nm | 56 | |||
| BA22.10-P-1007-01M | Bolt, right engine mount to timing case cover | Nm | 80 | |||
| BA22.10-P-1008-01M | Bolt, left engine mount to major assembly carrier | Nm | 56 | |||
| BA22.10-P-1009-01M | Bolt, left engine mount to transmission | Nm | 80 | |||
| BA22.10-P-1010-01M | Bolt, torque support to frame-type integral support | Nm | 115 | |||
| BA22.10-P-1011-01M | Bolt, torque support to front engine mount carrier | Nm | 115 | |||
| BA22.10-P-1012-01M | Bolt, carrier for front engine mount to transmission | Nm | 23 | |||
| BA22.10-P-1013-01M | Bolt, carrier for front engine mount to crankcase | Nm | 56 | |||
| BA22.10-P-1014-01M | Bolt, right engine support to engine | Nm | ||||
ENGINE MOUNTS, ENGINE SUPPORTS
| Number | Designation | Engine 160.910 | Engine 160.920 | Engine 160.921 | ||
|---|---|---|---|---|---|---|
| BA22.10-P-1001-01M | Bolt, engine support to cylinder head | Initial torque | Nm | 28 | 28 | 28 |
| Retightening torque | Nm | 23 | 23 | |||
| BA22.10-P-1002-01M | Bolt, rear engine support to transmission | Initial torque | Nm | 28 | 28 | 28 |
| Retightening torque | Nm | 23 | 23 | |||
| BA22.10-P-1003-01M | Bolt, front engine support to crankcase | Initial torque | Nm | 28 | 28 | 28 |
| Retightening torque | Nm | 23 | 23 | |||
| BA22.10-P-1004-01M | Bolt, front engine support to frame-type integral support | Nm | 58 | 58 | 58 | |
| BA22.10-P-1005-01M | Bolt, rear engine support to frame-type integral support | Nm | 58 | 58 | 58 | |
| BA22.10-P-1006-01M | Bolt, right engine mount to frame-type integral support | Nm | ||||
| BA22.10-P-1007-01M | Bolt, right engine mount to timing case cover | Nm | ||||
| BA22.10-P-1008-01M | Bolt, left engine mount to major assembly carrier | Nm | ||||
| BA22.10-P-1009-01M | Bolt, left engine mount to transmission | Nm | ||||
| BA22.10-P-1010-01M | Bolt, torque support to frame-type integral support | Nm | ||||
| BA22.10-P-1011-01M | Bolt, torque support to front engine mount carrier | Nm | ||||
| BA22.10-P-1012-01M | Bolt, carrier for front engine mount to transmission | Nm | ||||
| BA22.10-P-1013-01M | Bolt, carrier for front engine mount to crankcase | Nm | ||||
| BA22.10-P-1014-01M | Bolt, right engine support to engine | Nm | ||||
ENGINE MOUNTS, ENGINE SUPPORTS
| Number | Designation | Engine 780.009 | ||
|---|---|---|---|---|
| BA22.10-P-1001-01M | Bolt, engine support to cylinder head | Initial torque | Nm | |
| Retightening torque | Nm | |||
| BA22.10-P-1002-01M | Bolt, rear engine support to transmission | Initial torque | Nm | |
| Retightening torque | Nm | |||
| BA22.10-P-1003-01M | Bolt, front engine support to crankcase | Initial torque | Nm | |
| Retightening torque | Nm | |||
| BA22.10-P-1004-01M | Bolt, front engine support to frame-type integral support | Nm | ||
| BA22.10-P-1005-01M | Bolt, rear engine support to frame-type integral support | Nm | ||
| BA22.10-P-1006-01M | Bolt, right engine mount to frame-type integral support | Nm | 56 | |
| BA22.10-P-1007-01M | Bolt, right engine mount to timing case cover | Nm | ||
| BA22.10-P-1008-01M | Bolt, left engine mount to major assembly carrier | Nm | ||
| BA22.10-P-1009-01M | Bolt, left engine mount to transmission | Nm | ||
| BA22.10-P-1010-01M | Bolt, torque support to frame-type integral support | Nm | 115 | |
| BA22.10-P-1011-01M | Bolt, torque support to front engine mount carrier | Nm | 115 | |
| BA22.10-P-1012-01M | Bolt, carrier for front engine mount to transmission | Nm | 23 | |
| BA22.10-P-1013-01M | Bolt, carrier for front engine mount to crankcase | Nm | ||
| BA22.10-P-1014-01M | Bolt, right engine support to engine | Nm | 56 | |
ENGINE MOUNTS, ENGINE SUPPORTS
001 589 01 16 03 box wrench - WS22.00-P-0008-03B
FG22/09/28/Set B
MODEL 163, 164, 171, 203, 210, 211, 215, 219, 220, 221, 230, 251, 451
Use
Box wrench SW16 from set of engine mount wrenches 001 589 01 16 00.
Scheme 227
Scheme 228
Scheme 229
001 589 01 16 09 Box wrench bit - WS22.00-P-0008-09B
FG22/09/28/Set B
MODEL 163, 164, 171, 203, 210, 211, 215, 219, 220, 221, 230, 251, 451
Use
Box wrench bit SW17 from set of engine mount wrenches 001 589 01 16 00
Scheme 230
001 589 01 16 00 Engine mount wrench set - WS22.00-P-0008B
FG 22/07/09/28/61/ Set B
MODEL all
| Further use | 001 589 01 16 00 Engine mount wrench set | WS09.00-P-0010B | |
|---|---|---|---|
| Further use | 001 589 01 16 00 Engine mount wrench set | WS28.00-P-0088B | |
| Separate part | FG22/Set B | 001 589 01 16 01 Plug-in adapter | WS22.00-P-0008-01B |
| Separate part | FG22/Set B | 001 589 01 16 02 Box wrench bit | WS22.00-P-0008-02B |
| Separate part | FG22/Set B | 001 589 01 16 03 Box wrench | WS22.00-P-0008-03B |
| Separate part | FG22/Set B | 001 589 01 16 04 Wrench socket | WS22.00-P-0008-04B |
| Separate part | FG22/Set B | 001 589 01 16 05 Wrench socket | WS22.00-P-0008-05B |
| Separate part | FG22/Set B | 001 589 01 16 06 Wrench socket | WS22.00-P-0008-06B |
| Separate part | FG22/Set B | 001 589 01 16 07 Angled piece | WS22.00-P-0008-07B |
| Separate part | FG22/Set B | 001 589 01 16 09 Box wrench bit | WS22.00-P-0008-09B |
| Separate part | FG22/Set B | 001 589 01 16 08 Plug-in joint adapter | WS22.00-P-0008-10B |
Use
Set of engine mount wrenches for removing/installing the engine mount and diagonal struts.
