Automatic Transaxle (Service Information): Overview Scion xB II рестайлинг

Automatic Trans 10 illustrations ~501 words

Scheme 34

Scheme 34: ON-VEHICLE INSPECTION
Scheme 34: ON-VEHICLE INSPECTION
  1. INSPECT AUTOMATIC TRANSAXLE FLUID HINT: Drive the vehicle until the engine and transaxle are at normal operating temperature. Fluid temperature 70 to 80 °C (158 to 176 °F) Park the vehicle on a level surface and engage the parking brake. With the engine idling and the brake pedal depressed, shift the shift lever into all positions from P to L, and then return it to the P position. Pull out the oil level gauge and wipe it clean. Push it fully back into the pipe. Pull it out and check that the fluid level is within the HOT range. If there is any leakage, repair or replace O-rings, FIPG, oil seals, plugs or other parts.

Scheme 35

Scheme 35: ILLUSTRATION
Scheme 35: ILLUSTRATION

Scheme 36

Scheme 36: ILLUSTRATION
Scheme 36: ILLUSTRATION

Scheme 37

Scheme 37: REMOVAL
Scheme 37: REMOVAL

Scheme 38

Scheme 38
Scheme 38
  1. REMOVE BATTERY . Refer to «REMOVAL - Step 6»(/scion/xb/ii-2010-2015/remont/cooling-fan/#engine-cooling-system-service-information)
  2. REMOVE NO. 2 BATTERY CARRIER See step 24
  3. REMOVE AIR CLEANER CAP SUB-ASSEMBLY WITH NO. 1 AIR CLEANER HOSE. Refer to «REMOVAL - Step 3»(ref-511385-S40287811472012102600000)
  4. REMOVE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY See step 26
  5. REMOVE AIR CLEANER CASE SUB-ASSEMBLY See step 27
  6. REMOVE SPEED SENSOR NT Disconnect the speed sensor NT connector. Remove the bolt and remove the speed sensor NT. Remove the O-ring from the speed sensor NT.
  7. REMOVE SPEED SENSOR NC Disconnect the speed sensor NC connector. Remove the bolt and remove the speed sensor NC. Remove the O-ring from the speed sensor NC.

Scheme 39

Scheme 39: INSPECTION
Scheme 39: INSPECTION

Scheme 40

Scheme 40
Scheme 40
  1. INSPECT SPEED SENSOR NT Measure the resistance. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 560 to 680 ohms If the resistance value is not as specified, replace the speed sensor NT.
  2. INSPECT SPEED SENSOR NC Measure the resistance. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 560 to 680 ohms If the resistance value is not as specified, replace the speed sensor NC.

Scheme 41

Scheme 41
Scheme 41
  1. INSTALL SPEED SENSOR NC Coat a new O-ring with ATF, and install it into the speed sensor NC. Install the speed sensor NC with the bolt. Torque: 8.8 N*m (90 kgf*cm, 78 in.*lbf) Connect the speed sensor NC connector.
  2. INSTALL SPEED SENSOR NT Coat a new O-ring with ATF, and install it into the speed sensor NT. Clean the bolt and bolt hole. Apply adhesive to 2 or 3 threads of the bolt. Adhesive Toyota Genuine Adhesive 1324, Three Bond 1324or equivalent Install the speed sensor NT with the bolt. Torque: 11 N*m (115 kgf*cm, 8 ft.*lbf) Connect the speed sensor NT connector.
  3. INSTALL AIR CLEANER CASE SUB-ASSEMBLY See step 33
  4. INSTALL AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY See step 34
  5. INSTALL AIR CLEANER CAP SUB-ASSEMBLY WITH NO. 1 AIR CLEANER HOSE. Refer to «INSTALLATION - Step 2»(ref-511385-S27801980002012102600000)
  6. INSTALL NO. 2 BATTERY CARRIER See step 36
  7. INSTALL BATTERY . Refer to «INSTALLATION - Step 20»(/scion/xb/ii-2010-2015/remont/cooling-fan/#engine-cooling-system-service-information)
  8. INSPECT FOR AUTOMATIC TRANSAXLE FLUID LEAK

Scheme 42

Scheme 42: ILLUSTRATION
Scheme 42: ILLUSTRATION

Scheme 43

Scheme 43: ILLUSTRATION
Scheme 43: ILLUSTRATION
