Automatic Transaxle (Diagnostics - Introduction): Diagnosis Scion xB II рестайлинг

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. The ECM from this system is connected to the CAN and multiplex communication system. Therefore, before starting troubleshooting, make sure to check that there is no trouble in the CAN and multiplex communication systems.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS Refer to the Customer Problem Analysis. Refer to «GENERAL INFORMATION»(ref-511289-S15614226692012102600000) . NEXT: Go to next step
3. INSPECT BATTERY VOLTAGE Standard voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding. NEXT: Go to next step
4. CONNECT THE TECHSTREAM TO DLC3* NEXT: Go to next step
5. CHECK AND CLEAR DTCS AND FREEZE FRAME DATA* Refer to the DTC Check/Clear. Refer to «DTC CHECK / CLEAR»(ref-511386-S20833347322012102600000) . NEXT: Go to next step
6. VISUAL INSPECTION NEXT: Go to next step
7. SETTING CHECK MODE DIAGNOSIS* Refer to the Check Mode Procedure. Refer to «CHECK MODE PROCEDURE»(ref-511386-S34754363522012102600000) . NEXT: Go to next step
8. PROBLEM SYMPTOM CONFIRMATION Refer to the Road Test. Refer to «ROAD TEST»(ref-511386-S01518391072012102600000) . RESULT Result Proceed to Symptom does not occur A Symptom occurs B B --> GO TO STEP 10 A: Go to next step
9. SYMPTOM SIMULATION Refer to the Electronic Circuit Inspection Procedure. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-511289-S39503723992012102600000) . NEXT: Go to next step
10. DTC CHECK* Refer to DTC Check/Clear. Refer to «DTC CHECK / CLEAR»(ref-511386-S20833347322012102600000) . RESULT Result Proceed to DTC is not output A DTC is output B B --> GO TO STEP 18 A: Go to next step
11. BASIC INSPECTION Refer to Automatic Transmission Fluid. Refer to «ON-VEHICLE INSPECTION»(ref-511376-S19310264342012102600000) . Refer to Park/Neutral Position Switch. Refer to «ON-VEHICLE INSPECTION»(ref-511376-S36069016742012102600000) . Refer to Shift Lock Control Unit Assembly. Refer to «ON-VEHICLE INSPECTION»(ref-511376-S15840614582012102600000) . NG --> GO TO STEP 21 OK: Go to next step
12. MECHANICAL SYSTEM TESTS Refer to the Mechanical System Tests. Refer to «MECHANICAL SYSTEM TESTS»(ref-511386-S37581461522012102600000) . NG --> GO TO STEP 17 OK: Go to next step
13. HYDRAULIC TEST Refer to the Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-511386-S15693943782012102600000) . NG --> GO TO STEP 17 OK: Go to next step
14. MANUAL SHIFTING TEST Refer to the Manual Shifting Test. Refer to «MANUAL SHIFTING TEST»(ref-511386-S15929890062012102600000) . NG --> GO TO STEP 16 OK: Go to next step
15. PROBLEM SYMPTOMS TABLE CHAPTER 1 Refer to the Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE»(ref-511386-S09199791672012102600000) . NG --> GO TO STEP 19 OK: Go to next step
16. PROBLEM SYMPTOMS TABLE CHAPTER 2 Refer to the Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE»(ref-511386-S09199791672012102600000) . NEXT: Go to next step
17. PART INSPECTION NG --> GO TO STEP 21 OK: Go to next step
18. DTC CHART Refer to the Diagnostic Trouble Code Chart. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-511386-S05353409872012102600000) . NEXT: Go to next step
19. CIRCUIT INSPECTION NEXT: Go to next step
20. IDENTIFICATION OF PROBLEM NEXT: Go to next step
21. REPAIR OR REPLACE NEXT: Go to next step
22. CONFIRMATION TEST NEXT --> END

ROAD TEST

1. PROBLEM SYMPTOM CONFIRMATION Based on the result of the customer problem analysis, try to reproduce the symptoms. If the problem is that the transaxle does not shift up or down or the shift point is too high or too low, conduct the following road test referring to the automatic shift schedule and simulate the problem symptoms.
2. ROAD TEST Perform a road test. WARNING: Check for safety before performing any tests. NOTE: Be sure to inspect and adjust the engine before performing these tests. Perform the road test with the engine coolant temperature between 60 to 100°C (140 and 212°F) and the ATF temperature is between 50 to 80°C (122 to 176°F). Perform these tests with the air conditioning off. Inspection Procedure Transmission Control Switch Test With the vehicle stationary and the shift lever in D, move the shift lever to S and return it to D. Check that the meter display changes from D to the appropriate S range and then back again. S Position Test With the vehicle stationary and the shift lever in S, move the shift lever to "+" and "-". Check that the meter display changes between S ranges properly. D Position Shift Test While driving the vehicle normally, check that the transaxle shifts up and down through each gear properly. Lock-up Function While driving on a level surface at a constant speed in the lock-up range (70 km/h (43 mph) or more) with the shift lever in D, lightly depress the accelerator pedal and check that the engine speed does not change abruptly. P Position Test Stop the vehicle on an incline (approximately 5° or more). Then move the shift lever to P and release the parking brake. Check that the parking lock pawl holds the vehicle in place. Abnormal Noise and Vibration Check for abnormal noise and vibration while driving the vehicle forward and backward, and during shift operations. Fluid Leakage After performing all other road test inspections, check for fluid leakage.

PROBLEM SYMPTOMS TABLE

HINT

1. Use the tables below to help determine the cause of the problem symptom. The potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the tables. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. The Matrix Chart is divided into 2 chapters. When troubleshooting, check Chapter 1 first. If instructions are given in Chapter 1 to proceed to 2, proceed as instructed.
3. If the instruction "Proceed to next circuit inspection shown in problem symptoms table" is given in the flowchart for each circuit, proceed to the next suspected area in the table.
4. If the problem still occurs even though there are no malfunctions in any of the circuits, check the ECM and replace it if necessary.

CHAPTER 1: ELECTRICAL CIRCUIT MATRIX CHART

HINT

*: When the circuit is defective, a DTC may be stored.

CHAPTER 2: ON-VEHICLE REPAIR AND OFF-VEHICLE REPAIR

Scheme 486

Scheme 487

Scheme 488

Scheme 489

Scheme 490

1. CHECK ECM Measure the voltage of the ECM connector. HINT: Each ECM terminal's standard voltage is shown in the table below. In the table, first follow the information under "Condition". Look under "Terminal No. (Symbol)" for the terminals to be inspected. The standard voltage between the terminals is shown under "Specified Condition". Use the illustration above as a reference for the ECM terminals. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A36-16 (SFTU) - B33-104 (E1) W-L - BR Up-shift position switch signal Ignition switch ON Shift lever in S 11 to 14 V Ignition switch ON Shift lever "+" position (up-shift) Below 1 V A36-36 (STP) - B33-104 (E1) L - BR Stop light switch signal Brake pedal depressed 7.5 to 14 V Brake pedal released Below 1 V A36-48 (STA) - B33-104 (E1) LG -BR Park/Neutral position switch signal Cranking 6.0 V or more A36-51 (SFTD) - B33-104 (E1) R - BR Down-shift position switch signal Ignition switch ON Shift lever in S 11 to 14 V Ignition switch ON Shift lever "-" position (down-shift) Below 1 V B33-52 (NSW) - B33-104 (E1) W - BR Park/Neutral position switch signal Ignition switch ON Shift lever in P or N Below 2 V Ignition switch ON Shift lever not in P or N 11 to 14 V B33-53 (R) - B33-104 (E1) R - BR R shift position switch signal Ignition switch ON Shift lever in R 11 to 14 V Ignition switch ON Shift lever not in R Below 1 V B33-54 (N) - B33-104 (E1) B - BR N shift position switch signal Ignition switch ON Shift lever in N 11 to 14 V Ignition switch ON Shift lever not in N Below 1 V B33-56 (D) - B33-104 (E1) P - BR D shift position switch signal Ignition switch ON Shift lever in D 11 to 14 V Ignition switch ON Shift lever not in D Below 1 V B33-57 (SL1+) - B33-77 (SL1-) G - P SL1 solenoid signal Engine idle speed Pulse generation (See waveform 1 (Scheme 487) ) Ignition switch ON Pulse generation (See waveform 1 (Scheme 487) ) 1st gear Pulse generation (See waveform 1 (Scheme 487) ) Not in 1st gear Below 1 V B33-58 (SL2+) - B33-59 (SL2-) Y - R SL2 solenoid signal Engine idle speed Pulse generation (See waveform 2 see scheme 12 ) Ignition switch ON Pulse generation (See waveform 2 see scheme 12 ) 1st or 2nd gear Pulse generation (See waveform 2 see scheme 12 ) 3rd or 4th gear Below 1 V B33-72 (THO1) - B33-95 (ETHO) LG - BR ATF temperature sensor signal ATF temperature 115°C (239°F) or more Below 1.5 V B33-73 (P) - B33-104 (E1) V - BR P shift position switch signal Ignition switch ON Shift lever in P 11 to 14 V Ignition switch ON Shift lever not in P Below 1 V B33-74 (S) - B33-104 (E1) L - BR S shift position switch signal Ignition switch ON Shift lever in S 11 to 14 V Ignition switch ON Shift lever not in S Below 1 V B33-76 (SLT+) - B33-75 (SLT-) R - GR SLT solenoid signal Engine idle speed Pulse generation B33-78 (S4) - B33-104 (E1) W - BR S4 solenoid signal Ignition switch ON Below 1 V 4th gear 11 to 14 V Not in 4th gear Below 1 V B33-79 (DSL) - B33-104 (E1) G - BR DSL solenoid signal Vehicle speed 65 km/h (40 mph), lock-up (ON to OFF) Below 1 V Vehicle driving under lock-up position Pulse generation (See waveform 3) B33-101 (NC+) - B33-102 (NC-) R - W Speed sensor NC signal Vehicle speed 30 km/h (19 mph): (3rd gear) Engine speed 1400 RPM Pulse generation (See waveform 4) B33-125 (NT+) - B33-124 (NT-) W - L Speed sensor NT signal Vehicle speed 20 km/h (12 mph) Pulse generation (See waveform 5) Using an oscilloscope, check the waveform 1. WAVEFORM 1 Terminal SL1+ - SL1- Tool Setting 5 V/DIV., 1 msec./DIV. Condition Engine idle speed Using an oscilloscope, check the waveform 2. WAVEFORM 2 Terminal SL2+ - SL2- Tool Setting 5 V/DIV., 1 msec./DIV. Condition Engine idle speed Using an oscilloscope, check the waveform 3. WAVEFORM 3 Terminal DSL - E1 Tool Setting 10 V/DIV., 100 msec./DIV. Condition Vehicle speed 65 km/h (40 mph), lock-up (ON to OFF) Using an oscilloscope, check the waveform 4. WAVEFORM 4 Terminal NC+ - NC- Tool Setting 1 V/DIV., 1 msec./DIV. Condition Vehicle speed 30 km/h (19 mph): (3rd gear) Engine speed 1400 RPM Using an oscilloscope, check the waveform 5. WAVEFORM 5 Terminal NT+ - NT- Tool Setting 5 V/DIV., 0.5 msec./DIV. Condition Vehicle speed 20 km/h (12 mph)

Scheme 491

Scheme 492

1. DESCRIPTION When troubleshooting On-Board Diagnostic (OBD II) vehicles, the vehicle must be connected to the OBD II scan tool (complying with SAE J1987). Various data output from the vehicle's ECM can then be read. OBD II regulations require that the vehicle's on-board computer illuminates the Malfunction Indicator Lamp (MIL) on the instrument panel when the computer detects a malfunction in: The emission control system/components The powertrain control components (which affect vehicle emissions) The computer In addition, the applicable Diagnostic Trouble Codes (DTCs) prescribed by SAE J2012 are recorded in the ECM memory. When the malfunction does not reoccur, the MIL stays illuminated until the ignition switch is turned off, and the MIL turns OFF when the engine is started. However, the DTCs remain recorded in the ECM memory. To check DTCs, connect the Techstream to the Data Link Connector 3 (DLC3) of the vehicle. The Techstream displays DTCs, the freeze frame data and a variety of the engine data. The DTCs and freeze frame data can be cleared with the Techstream. Refer to «DTC CHECK / CLEAR»(ref-511386-S20833347322012102600000) .
2. NORMAL MODE AND CHECK MODE The diagnosis system operates in "normal mode" during normal vehicle use. In normal mode, "2-trip detection logic" is used to ensure accurate detection of malfunctions. "Check mode" is also available to technicians as an option. In check mode, "1-trip detection logic" is used for simulating malfunction symptoms and increasing the system's ability to detect malfunctions, including intermittent malfunctions.
3. 2-TRIP DETECTION LOGIC When a malfunction is first detected, the malfunction is temporarily stored in the ECM memory (1st trip). If the same malfunction is detected during the next drive cycle, the MIL is illuminated (2nd trip).
4. FREEZE FRAME DATA Freeze frame data records the engine conditions (fuel system, calculated load, engine coolant temperature, fuel trim, engine speed, vehicle speed, etc.) when a malfunction is detected. When troubleshooting, freeze frame data can help determine if the vehicle was running or stopped, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred. The Techstream records freeze frame data in 5 different instances: 1) 3 times before the DTC is set, 2) once when the DTC is set, and 3) once after the DTC is set. These data can be used to simulate the vehicle's condition around the time when the malfunction occurred. The data may help find the cause of the malfunction, or judge if the DTC is being caused by a temporary malfunction or not.
5. DATA LINK CONNECTOR 3 (DLC3)
6. CHECK MIL Check that the MIL illuminates when turning the ignition switch to ON. If the MIL does not illuminate, there is a problem in the MIL circuit. Refer to «MIL Circuit»(ref-511387-S21014897772012102600000) . When the engine is started, the MIL should turn off.

DTC CHECK / CLEAR

Note. When the diagnosis system is changed from normal mode to check mode or vice versa, all DTCs and freeze frame data recorded in normal mode are cleared. Before changing modes, always check and make a note of DTCs and freeze frame data.

HINT

1. DTCs which are stored in the ECM can be displayed on the Techstream. The Techstream can display the current, pending and permanent DTCs.
2. If a malfunction is detected during the current driving cycle, current and permanent DTCs are stored.
3. Some DTCs are not stored if the ECM does not detect the same malfunction again during a second consecutive driving cycle. However, such malfunctions, detected on only one occasion, are stored as pending DTCs.
4. Current and pending DTCs can be cleared by using the Techstream or by disconnecting the cable from the negative battery terminal. However, permanent DTCs cannot be cleared using either of these two methods.
5. After clearing current DTCs using the Techstream (or by disconnecting the cable from the negative battery terminal), permanent DTCs are cleared when the system is determined to be normal for the relevant DTCs and then the universal trip is performed.

2-TRIP DETECTION EXAMPLES

Scheme 493

Scheme 494

Scheme 495

1. CHECK DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check the DTC(s) and freeze frame data, and then write them down. Check the details of the DTC(s). Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-511386-S05353409872012102600000) .
2. CLEAR DTC (Pending and Current DTC) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Clear the DTCs.
3. CLEAR DTC (Pending and Current DTC without using Techstream) Perform either of the following operations: Disconnect the cable from the negative (-) battery terminal for more than 1 minute. Remove the EFI MAIN and ETCS fuses from the engine room relay block located inside the engine compartment for more than 1 minute.
4. CLEAR PERMANENT DTC HINT: Even if the following procedure is not performed, permanent DTCs are cleared if no malfunctions are detected during 3 consecutive driving cycles. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check if permanent DTCs are stored. HINT: If permanent DTCs are not output, it is not necessary to continue this procedure. Clear DTCs. Perform the universal trip. Idle the engine for 30 seconds or more. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more. HINT: It is possible to complete the drive pattern even if the vehicle decelerates to less than 40 km/h (25 mph) during the driving cycle, provided that the vehicle is driven at 40 km/h (25 mph) or more for a total of 5 minutes. When accelerating through the gears, make sure the vehicle is driven so all gears are used in order and no gears are skipped. Allow 10 minutes or more to elapse from the time the engine is started. Turn the ignition switch off. Wait 15 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check that the permanent DTCs have been cleared. HINT: If the permanent DTCs have not been cleared, perform the universal trip again. The permanent DTCs are cleared when the universal trip is completed.

Scheme 496

1. DESCRIPTION Check mode has a higher sensitivity to malfunctions and can detect malfunctions that normal mode cannot detect. Check mode can also detect all the malfunctions that normal mode can detect. In check mode, DTCs are detected with 1-trip detection logic.
2. CHECK MODE PROCEDURE Make sure that the following conditions are met: Battery positive voltage 11 V or more. Throttle valve fully closed. Shift lever in P or N. A/C off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / Check Mode. Check that the MIL flashes as shown in the illustration. NOTE: All DTCs and freeze frame data will be cleared if: 1) the Techstream is used to change the ECM from normal mode to check mode or vice versa; or 2) during check mode, the ignition switch is turned from ON to ACC or off. Before changing to check mode, make notes of the DTCs and freeze frame data. Start the engine. The MIL should turn off after the engine starts. Perform "Monitor Drive Pattern" for the ECT test. Refer to «MONITOR DRIVE PATTERN»(ref-511386-S28463559162012102600000) or simulate the conditions of the malfunction described by the customer. After simulating the malfunction conditions, use the Techstream to check the DTC and freeze frame data.

DATA LIST / ACTIVE TEST

1. READ DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data. Follow the instructions on the Techstream and read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note Neutral Position SW Signal PNP switch status/ ON or OFF Shift lever: P or N: ON Not P or N: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect. HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-511425-S02851758892012102600000) . Stop Light Switch Stop light switch status/ ON or OFF Brake pedal Depressed: ON Released: OFF - SPD (NT) Input shaft speed/ Min.: 0 RPM Max.: 12750 RPM Lock-up is ON (after warming up engine): Input turbine speed (NT) is equal to engine speed OFF (idling with shift lever in N): Input turbine speed (NT) is nearly equal to engine speed Data is displayed in increments of 50 RPM. SPD (NC) Counter gear speed/ Min.: 0 RPM Max.: 12750 RPM 4th when shift lever in D (after warming up the engine): Intermediate shaft speed (NC) becomes close to the engine speed Data is displayed in increments of 50 RPM. Shift SW Status (P Range) PNP switch status/ ON or OFF Shift lever: P: ON Not P: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect. HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-511425-S02851758892012102600000) . Shift SW Status (R Range) PNP switch status/ ON or OFF Shift lever: R: ON Not R: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect. HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-511425-S02851758892012102600000) . Shift SW Status (N Range) PNP switch status/ ON or OFF Shift lever: N: ON Not N: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect. HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-511425-S02851758892012102600000) . Sports Shift Up SW Sport shift up switch status/ ON or OFF ON: Continuously shift to "+" (up-shift) OFF: Release "+" (up-shift) - Sports Shift Down SW Sport shift down switch status/ ON or OFF ON: Continuously shift to "-" (down-shift) OFF: Release "-" (down-shift) - Sports Mode Selection SW Sport mode select switch status/ ON or OFF Shift lever: S, "+" and "-" : ON Not S, "+" and "-" : OFF - Shift SW Status (D Range) PNP switch status/ ON or OFF Shift lever: D: ON Not D: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect. HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-511425-S02851758892012102600000) . A/T Oil Temperature 1 No. 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approximately 80°C (176°F) Equal to ambient temperature while engine cold If value is -40°C (-40°F) or "150°C (302°F) or more", ATF temperature sensor circuit is open or shorted. Lock Up Lock-up/ ON or OFF Lock-up Operating: ON Not operating: OFF - Shift Status ECM gear shift command/ 1st, 2nd, 3rd or 4th Shift lever position D: 1st, 2nd, 3rd or 4th S: 1st, 2nd, 3rd or 4th - SLT Solenoid Status Shift solenoid SLT status/ ON or OFF Accelerator pedal depressed: OFF Accelerator pedal released: ON - DSL Solenoid Status Lock-up solenoid status/ ON or OFF Lock-up solenoid Operating: ON Not operating: OFF - AT Fluid Flex lock-up judder judgment/ ON or OFF ON: Judder judgment occurs OFF: Judder judgment does not occur
2. PERFORM ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows the relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. Follow the instructions on the Techstream and perform the Active Test. Tester Display Test Part Control Range Diagnostic Note Activate the Solenoid (SLT)* Operate the shift solenoid SLT and raise line pressure ON or OFF HINT: OFF: Line pressure up (when Active Test "Activate the Solenoid (SLT)" is performed, ECM commands SLT solenoid to turn OFF) ON: No action (normal operation) [Vehicle Condition] Vehicle stopped Engine idling Activate the Solenoid (S4) Operate the shift solenoid S4 ON or OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Lock Up Control shift solenoid DSL to set automatic transaxle to lock-up condition ON or OFF Possible to check shift solenoid valve DSL operation [Vehicle Condition] Throttle valve opening angle: Less than 35% Vehicle speed: 60 km/h (36 mph) or more Control the Shift Position Operate shift solenoid valve and set each shift position by yourself Press "-->" button: Shift up Press "<--" button: Shift down Possible to check operation of shift solenoid valves [Vehicle Condition] Vehicle speed: 50 km/h (31 mph) or less Activate the Solenoid (DSL) Operate the shift solenoid DSL ON or OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL1) Operate the shift solenoid SL1 ON or OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL2) Operate the shift solenoid SL2 ON or OFF [Vehicle Condition] Engine stopped Shift lever in P or N HINT: *: Activate the Solenoid (SLT) in the Active Test is performed to check the line pressure changes by connecting SST to the automatic transaxle, which is used in the Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-511386-S15693943782012102600000) as well. Please note that the pressure values in the Active Test and Hydraulic Test are different.

DIAGNOSTIC TROUBLE CODE CHART

If a DTC is displayed during the DTC check, check the circuit listed in the table below and proceed to article given.

HINT

1. *1: "Comes on" means the Malfunction Indicator Lamp (MIL) illuminates.
2. *2: "DTC stored" means the ECM memorizes the trouble code if the ECM detects the DTC detection condition.
3. These DTCs may be output when the clutch, brake, gear components, etc., inside the automatic transaxle are damaged.

AUTOMATIC TRANSAXLE SYSTEM
