Automatic Transaxle (Diagnostic Codes & Circuit Tests): Diagnosis Scion xB II рестайлинг

Automatic Trans 32 illustrations ~7540 words

INSPECTION PROCEDURE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR . Inspect the fuses for circuits related to this system before performing the following inspection procedure.

  1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data. Follow the instructions on the Techstream and read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note Neutral Position SW Signal PNP switch status/ ON or OFF Shift lever: In P or N: ON Not in P or N: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect. Shift SW Status (P Range) PNP switch status/ ON or OFF Shift lever: P: ON Not P: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect. Shift SW Status (R Range) PNP switch status/ ON or OFF Shift lever: R: ON Not R: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect. Shift SW Status (N Range) PNP switch status/ ON or OFF Shift lever: N: ON Not N: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect. Sports Shift Up SW Sport shift up switch status/ ON or OFF ON: Continuously shift to "+" (up-shift) OFF: Release "+" (up-shift) - Sports Shift Down SW Sport shift down switch status/ ON or OFF ON: Continuously shift to "-" (down-shift) OFF: Release "-" (down-shift) - Sports Mode Selection SW Sport mode select switch status/ ON or OFF Shift lever: ON S, "+" and "-" : ON Not on S, "+" and "-" : OFF - Shift SW Status (D Range) PNP switch status/ ON or OFF Shift lever: D: ON Not D: OFF When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect.

Scheme 509

Scheme 509: PROCEDURE
Scheme 509: PROCEDURE

Scheme 510

Scheme 510
Scheme 510

Scheme 511

Scheme 511
Scheme 511

Scheme 512

Scheme 512
Scheme 512

Scheme 513

Scheme 513
Scheme 513

Scheme 514

Scheme 514
Scheme 514
  1. CHECK PARK/NEUTRAL POSITION SWITCH ASSEMBLY (POWER SOURCE) Disconnect the park/neutral position switch connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B16-2 (RB) - Body ground Ignition switch ON 11 to 14 V Ignition switch off Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Park/Neutral Position Switch) Turn the ignition switch off. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (PARK/NEUTRAL POSITION SWITCH - BATTERY) OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (ECM OUTPUT SIGNAL) Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B16-4 (B) - Body ground Ignition switch ON 11 to 14 V Ignition switch off Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Park/Neutral Position Switch) Turn the ignition switch off. NG --> See step 7 OK: Go to next step
  3. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 4 (B) - 5 (L) Shift lever in P or N Below 1 ohms Shift lever not in P and N 10 kohms or higher 2 (RB) - 6 (PL) Shift lever in P Below 1 ohms Shift lever not in P 10 kohms or higher 2 (RB) - 1 (RL) Shift lever in R Below 1 ohms Shift lever not in R 10 kohms or higher 2 (RB) - 9 (NL) Shift lever in N Below 1 ohms Shift lever not in N 10 kohms or higher 2 (RB) - 7 (DL) Shift lever in D Shift lever in S, "+" or "-" Below 1 ohms Shift lever not in D Shift lever not in S, "+" and "-" 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Wire) NG --> See step 9 OK: Go to next step
  4. CHECK TRANSMISSION CONTROL SWITCH (POWER SOURCE) Reconnect the park/neutral position switch connector. Disconnect the transmission control switch connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition C33-6 (IG) - Body ground Ignition switch ON 11 to 14 V Ignition switch off Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Transmission Control Switch) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (TRANSMISSION CONTROL SWITCH - BATTERY) OK: Go to next step
  5. INSPECT TRANSMISSION CONTROL SWITCH Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 6 (IG) - 13 (S) Shift lever in S, "+" or "-" Below 1 ohms Shift lever not in S, "+" and "-" 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Control Switch) NG --> See step 10 OK: Go to next step
  6. CHECK HARNESS AND CONNECTOR (BATTERY - ECM) Reconnect the transmission control switch connector. Disconnect the ECM connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B33-73 (P) - Body ground Ignition switch ON Shift lever in P 11 to 14 V B33-53 (R) - Body ground Ignition switch ON Shift lever in R 11 to 14 V* B33-54 (N) - Body ground Ignition switch ON Shift lever in N 11 to 14 V B33-56 (D) - Body ground Ignition switch ON Shift lever in D 11 to 14 V B33-74 (S) - Body ground Shift lever in S, "+" or "-" 11 to 14 V B33-73 (P) - Body ground Ignition switch ON Shift lever not in P Below 1 V B33-53 (R) - Body ground Ignition switch ON Shift lever not in R Below 1 V B33-54 (N) - Body ground Ignition switch ON Shift lever not in N Below 1 V B33-56 (D) - Body ground Ignition switch ON Shift lever not in D Below 1 V B33-74 (S) - Body ground Shift lever not in S, "+" and "-" Below 1 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) HINT: *: The voltage will drop slightly due to the turning on of the back up light. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
  7. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B16-4 (B) - B33-52 (NSW) Always Below 1 ohms B16-4 (B) - Body ground Always 10 kohms or higher B33-52 (NSW) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
  8. REPLACE ECM. Refer to «REMOVAL»(ref-511385-S33230492262012102600000)
  9. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-511376-S13470537822012102600000)
  10. REPLACE SHIFT LOCK CONTROL UNIT ASSEMBLY (TRANSMISSION CONTROL SWITCH). Refer to «REMOVAL»(ref-511376-S25985831472012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

  1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data. Follow the instructions on the Techstream and read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note A/T Oil Temperature 1 A/T OIL TEMP1 No. 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approximately 80°C (176°F) Equal to ambient temperature while engine is cold If value is -40°C (-40°F) or "150°C (302°F) or more," ATF temperature sensor circuit is open or shorted HINT: When DTC P0712 is output and the Techstream output is 150°C (302°F) or more, there is a short circuit. When DTC P0713 is output and the Techstream output is -40°C (-40°F), there is an open circuit. Measure the resistance between terminal THO1 (THO) and the body ground. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or more Short circuit HINT: If a circuit related to the ATF temperature sensor becomes open, P0713 is set in approximately 0.5 seconds. It is not necessary to inspect the circuit when P0711 is set.

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

  1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data. Follow the instructions on the Techstream and read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note A/T Oil Temperature 1 A/T OIL TEMP1 No. 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approximately 80°C (176°F) Equal to ambient temperature while engine is cold If value is -40°C (-40°F) or "150°C (302°F) or more", ATF temperature sensor circuit is open or shorted HINT: When DTC P0712 is output and the Techstream output is 150°C (302°F) or more, there is a short circuit. When DTC P0713 is output and the Techstream output is -40°C (-40°F), there is an open circuit. Measure the resistance between terminal THO1 (THO) and the body ground. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or more Short circuit HINT: If a circuit related to the ATF temperature sensor becomes open, P0713 is set in approximately 0.5 seconds. It is not necessary to inspect the circuit when P0711 is set.

Scheme 515

Scheme 515: PROCEDURE
Scheme 515: PROCEDURE

Scheme 516

Scheme 516
Scheme 516
  1. INSPECT TRANSMISSION WIRE (ATF TEMPERATURE SENSOR) Disconnect the transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (THO) - 6 (E2) Always 79 ohms to 156 kohms 1 (THO) - Body ground Always 10 kohms or higher 6 (E2) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Wire) HINT: If the resistance is out of the specified range of either of the ATF temperatures shown in the table below, the driveability of the vehicle may decrease. ATF Temperature Specified Condition 10°C (50°F) 5 to 8 kohms 25°C (77°F) 2.5 to 4.5 kohms 110°C (230°F) 0.22 to 0.28 kohms NG --> See step 3 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Reconnect the transmission wire connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-72 (THO1) - B33-95 (ETHO) Always 79 ohms to 156 kohms B33-72 (THO1) - Body ground Always 10 kohms or higher B33-95 (ETHO) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
  3. REPAIR OR REPLACE TRANSMISSION WIRE (ATF TEMPERATURE SENSOR). Refer to «REMOVAL»(ref-511376-S36093232142012102600000)
  4. REPLACE ECM. Refer to «REMOVAL»(ref-511385-S33230492262012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

  1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data. Follow the instructions on the Techstream and read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note SPD (NT) Input turbine speed/ Min.: 0 RPM Max.: 12750 RPM Lock-up ON (after warming up engine): Input turbine speed (NT) equal to engine speed. Lock-up OFF (idling with shift lever in N): Input turbine speed (NT) nearly equal to engine speed. Data is displayed in increments of 50 RPM HINT: SPD (NT) is always 0 RPM while driving: Open or short in the sensor or circuit. SPD (NT) is always more than 0 RPM and less than 300 RPM while driving the vehicle at 50 km/h (31 mph) or more: Sensor trouble, improper installation, or intermittent connection trouble of the circuit.

Scheme 517

Scheme 517: PROCEDURE
Scheme 517: PROCEDURE

Scheme 518

Scheme 518
Scheme 518

Scheme 519

Scheme 519
Scheme 519
  1. INSPECT SPEED SENSOR NT (INSTALLATION) Check the speed sensor NT installation. OK Installation bolt is tightened properly and there is no clearance between the sensor and transaxle case. TEXT IN ILLUSTRATION *a Correct *b Incorrect *c Clearance NG --> SECURELY INSTALL SENSOR OR REPLACE SPEED SENSOR NT OK: Go to next step
  2. INSPECT SPEED SENSOR NT Disconnect the speed sensor NT connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 560 to 680 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Speed Sensor NT) NG --> See step 4 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (SPEED SENSOR NT - ECM) Reconnect the speed sensor NT connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-125 (NT+) - B33-124 (NT-) 20°C (68°F) 560 to 680 ohms B33-125 (NT+) - Body ground Always 10 kohms or higher B33-124 (NT-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
  4. REPLACE SPEED SENSOR NT. Refer to «REMOVAL»(ref-511376-S21763030762012102600000)
  5. REPLACE ECM. Refer to «REMOVAL»(ref-511385-S33230492262012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 520

Scheme 520: INSPECTION PROCEDURE
Scheme 520: INSPECTION PROCEDURE
  1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. Follow the instructions on the Techstream and perform the Active Test. Tester Display Test Part Control Range Diagnostic Note Activate the Lock Up Control shift solenoid DSL to set automatic transaxle to lock-up condition ON/OFF Possible to check shift solenoid valve DSL operation [Vehicle Condition] Throttle valve opening angle: Less than 35% Vehicle speed: 60 km/h (36 mph) or more HINT: This test can be conducted when the vehicle speed is 60 km/h (36 mph) or more. This test can be conducted in 3rd or 4th gear. Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: When changing the accelerator pedal opening angle while driving, if the engine speed does not change, lock-up is ON. Slowly release the accelerator pedal in order to decelerate. (Do not fully release the pedal as that will close the throttle valve and lock-up may be turned OFF.)

Scheme 521

Scheme 521: PROCEDURE
Scheme 521: PROCEDURE

Scheme 522

Scheme 522
Scheme 522

Scheme 523

Scheme 523
Scheme 523
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0741) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0741 is output A P0741 and other DTCs are output B HINT: If any other codes besides P0741 are output, perform troubleshooting for those DTCs first. B --> See step 8 A: Go to next step
  2. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE DSL) Disconnect the transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 (DSL) - Body ground 20°C (68°F) 11 to 13 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Wire) NG --> See step 4 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Reconnect the transmission wire connector. Disconnect the B33 ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-79 (DSL) - Body ground 20°C (68°F) 11 to 13 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
  4. INSPECT SHIFT SOLENOID VALVE DSL Remove the shift solenoid valve DSL. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - Solenoid body 20°C (68°F) 11 to 13 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve DSL) Connect the battery positive (+) lead to the terminal of the solenoid valve connector, and the negative (-) lead to the solenoid body. Then check that the valve moves and makes an operating sound. OK Valve moves and makes operating sound. NG --> See step 9 OK: Go to next step
  5. CHECK TRANSMISSION WIRE OK The connectors and pins are securely installed. There is no open or short on the wire harness. NG --> See step 10 OK: Go to next step
  6. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. OK There are no foreign objects on each valve. NG --> See step 11 OK: Go to next step
  7. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-511376-S10013809382012102600000) . OK The torque converter clutch operates normally. NG --> See step 12 OK --> See step 13
  8. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-511386-S05353409872012102600000)
  9. REPLACE SHIFT SOLENOID VALVE DSL. Refer to «DISASSEMBLY - Step 5»(ref-511376-S20930637052012102600000)
  10. REPAIR OR REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-511376-S36093232142012102600000)
  11. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-511376-S29109510052012102600000)
  12. REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY. Refer to «REMOVAL»(ref-511376-S04699610272012102600000)
  13. REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY. Refer to «REMOVAL»(ref-511376-S04699610272012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

  1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. Follow the instructions on the Techstream and perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART»(ref-511386-S41264955452012102600000) . Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valve and set each shift lever position by yourself Press "-->" button: Shift up Press "<--" button: Shift down Possible to check operation of shift solenoid valves [Vehicle Condition] 50 km/h (31 mph) or less HINT: This test can be conducted when the vehicle speed is 50 km/h (31 mph) or more. This shift position commanded by the ECM is shown in the Data List/Shift display on the Techstream.

Scheme 524

Scheme 524: PROCEDURE
Scheme 524: PROCEDURE
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0746) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0746 is output A P0746 and other DTCs are output B HINT: If any other codes besides P0746 are output, perform the troubleshooting for those DTCs first. B --> See step 5 A: Go to next step
  2. INSPECT SHIFT SOLENOID VALVE SL1 Remove the shift solenoid valve SL1. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SL1) Connect the battery positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes operating sound. NG --> See step 6 OK: Go to next step
  3. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. OK There are no foreign objects on each valve. NG --> See step 7 OK: Go to next step
  4. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-511376-S10013809382012102600000) . OK The torque converter clutch operates normally. NG --> See step 8 OK --> See step 9
  5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-511386-S05353409872012102600000)
  6. REPLACE SHIFT SOLENOID VALVE SL1. Refer to «DISASSEMBLY - Step 2»(ref-511376-S20930637052012102600000)
  7. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-511376-S29109510052012102600000)
  8. REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY. Refer to «REMOVAL»(ref-511376-S04699610272012102600000)
  9. REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY. Refer to «REMOVAL»(ref-511376-S04699610272012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 525

Scheme 525: PROCEDURE
Scheme 525: PROCEDURE

Scheme 526

Scheme 526
Scheme 526

Scheme 527

Scheme 527
Scheme 527
  1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL1) Disconnect the transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 5 (SL1+) - 10 (SL1-) 20°C (68°F) 5.0 to 5.6 ohms 5 (SL1+) - Body ground Always 10 kohms or higher 10 (SL1-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Wire) NG --> See step 3 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Reconnect the transmission wire connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-57 (SL1+) - B33-77 (SL1-) 20°C (68°F) 5.0 to 5.6 ohms B33-57 (SL1+) - Body ground Always 10 kohms or higher B33-77 (SL1-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
  3. INSPECT SHIFT SOLENOID VALVE SL1 Remove the shift solenoid valve SL1. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SL1) Connect the battery positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes operating sound. NG --> See step 5 OK --> See step 6
  4. REPLACE ECM. Refer to «REMOVAL»(ref-511385-S33230492262012102600000)
  5. REPLACE SHIFT SOLENOID VALVE SL1. Refer to «DISASSEMBLY - Step 2»(ref-511376-S20930637052012102600000)
  6. REPAIR OR REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-511376-S36093232142012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

  1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. Follow the instructions on the Techstream and perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART»(ref-511386-S41264955452012102600000) . Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valve and set each shift lever position by yourself Press "-->" button: Shift up Press "<--" button: Shift down Possible to check operation of shift solenoid valves [Vehicle Condition] 50 km/h (31 mph) or less HINT: This test can be conducted when the vehicle speed is 50 km/h (31 mph) or more. This shift position commanded by the ECM is shown in the Data List/Shift display on the Techstream.

Scheme 528

Scheme 528: PROCEDURE
Scheme 528: PROCEDURE
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0766) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0766 is output A P0766 and other DTCs are output B HINT: If any other codes besides P0766 are output, perform troubleshooting for those DTCs first. B --> See step 5 A: Go to next step
  2. INSPECT SHIFT SOLENOID VALVE S4 Remove the shift solenoid valve S4. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - Solenoid body 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve S4) Connect the battery positive (+) lead to the terminal of the solenoid valve connector, and the negative (-) lead to the solenoid body. Then check that the valve moves and makes an operating sound. OK Valve moves and makes operating sound. NG --> See step 6 OK: Go to next step
  3. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. OK There are no foreign objects on each valve. NG --> See step 7 OK: Go to next step
  4. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-511376-S10013809382012102600000) . OK The torque converter clutch operates normally. NG --> See step 8 OK --> See step 9
  5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-511386-S05353409872012102600000)
  6. REPLACE SHIFT SOLENOID VALVE S4. Refer to «DISASSEMBLY - Step 6»(ref-511376-S20930637052012102600000)
  7. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-511376-S29109510052012102600000)
  8. REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY. Refer to «REMOVAL»(ref-511376-S04699610272012102600000)
  9. REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY. Refer to «REMOVAL»(ref-511376-S04699610272012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

  1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. Follow the instructions on the Techstream and perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART»(ref-511386-S41264955452012102600000) . Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valve and set each shift lever position by yourself Press "-->" button: Shift up Press "<--" button: Shift down Possible to check operation of shift solenoid valves [Vehicle Condition] 50 km/h (31 mph) or less HINT: This test can be conducted when the vehicle speed is 50 km/h (31 mph) or more. This shift position commanded by the ECM is shown in the Data List/Shift display on the Techstream.

Scheme 529

Scheme 529: PROCEDURE
Scheme 529: PROCEDURE
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0776) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0776 is output A P0776 and other DTCs are output B HINT: If any other codes besides P0776 are output, perform troubleshooting for those DTCs first. B --> See step 5 A: Go to next step
  2. INSPECT SHIFT SOLENOID VALVE SL2 Remove the shift solenoid valve SL2. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SL2) Connect the battery positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes operating sound. NG --> See step 6 OK: Go to next step
  3. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. OK There are no foreign objects on each valve. NG --> See step 7 OK: Go to next step
  4. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-511376-S10013809382012102600000) . OK The torque converter clutch operates normally. NG --> See step 9 OK --> See step 8
  5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-511386-S05353409872012102600000)
  6. REPLACE SHIFT SOLENOID VALVE SL2. Refer to «DISASSEMBLY - Step 3»(ref-511376-S20930637052012102600000)
  7. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-511376-S29109510052012102600000)
  8. REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY. Refer to «REMOVAL»(ref-511376-S04699610272012102600000)
  9. REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY. Refer to «REMOVAL»(ref-511376-S04699610272012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 530

Scheme 530: PROCEDURE
Scheme 530: PROCEDURE

Scheme 531

Scheme 531
Scheme 531

Scheme 532

Scheme 532
Scheme 532
  1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL2) Disconnect the transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 4 (SL2+) - 9 (SL2-) 20°C (68°F) 5.0 to 5.6 ohms 4 (SL2+) - Body ground Always 10 kohms or higher 9 (SL2-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Wire) NG --> See step 3 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Reconnect the transmission wire connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-58 (SL2+) - B33-59 (SL2-) 20°C (68°F) 5.0 to 5.6 ohms B33-58 (SL2+) - Body ground Always 10 kohms or higher B33-59 (SL2-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
  3. INSPECT SHIFT SOLENOID VALVE SL2 Remove the shift solenoid valve SL2. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SL2) Connect the battery positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes operating sound. NG --> See step 6 OK --> See step 4
  4. REPAIR OR REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-511376-S36093232142012102600000)
  5. REPLACE ECM. Refer to «REMOVAL»(ref-511385-S33230492262012102600000)
  6. REPLACE SHIFT SOLENOID VALVE SL2. Refer to «DISASSEMBLY - Step 3»(ref-511376-S20930637052012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

  1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data. Follow the instructions on the Techstream and read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note SPD (NC) Input turbine speed/ Min.: 0 RPM Max.: 12750 RPM 4th when shift lever is in D (after warming up the engine): Intermediate shaft speed (NC) becomes close to the engine speed Data is displayed in increments of 50 RPM HINT: SPD (NC) is always 0 RPM while driving: Open or short in the sensor or circuit. SPD (NC) is always more than 0 RPM and less than 300 RPM while driving the vehicle at 50 km/h (31 mph) or more: Sensor trouble, improper installation, or intermittent connection trouble of the circuit.

Scheme 533

Scheme 533
Scheme 533
  1. INSPECT SPEED SENSOR NC (INSTALLATION) Check the speed sensor NC installation. OK Installation bolt is tightened properly and there is no clearance between the sensor and transaxle case. TEXT IN ILLUSTRATION *a Correct *b Incorrect *c Clearance NG --> SECURELY INSTALL SENSOR OR REPLACE SPEED SENSOR NC OK: Go to next step
  2. INSPECT SPEED SENSOR NC Disconnect the speed sensor NC connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 560 to 680 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Speed Sensor NC) NG --> See step 4 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (SPEED SENSOR NC - ECM) Reconnect the speed sensor NC connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-101 (NC+) - B33-102 (NC-) 20°C (68°F) 560 to 680 ohms B33-101 (NC+) - Body ground Always 10 kohms or higher B33-102 (NC-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
  4. REPLACE SPEED SENSOR NC. Refer to «REMOVAL»(ref-511376-S21763030762012102600000)
  5. REPLACE ECM. Refer to «REMOVAL»(ref-511385-S33230492262012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 534

Scheme 534: PROCEDURE
Scheme 534: PROCEDURE

Scheme 535

Scheme 535
Scheme 535
  1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE S4) Disconnect the transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 8 (S4) - Body ground 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Wire) NG --> See step 3 OK: Go to next step
  2. CHECK WIRE HARNESS (TRANSMISSION WIRE - ECM) Reconnect the transmission wire connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-78 (S4) - Body ground 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
  3. INSPECT SHIFT SOLENOID VALVE S4 Remove the shift solenoid valve S4. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - Solenoid body 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve S4) Connect the battery positive (+) lead to the terminal of the solenoid valve connector, and the negative (-) lead to the solenoid body. Then check that the valve moves and makes an operating sound. OK Valve moves and makes operating sound. NG --> See step 6 OK --> See step 4
  4. REPAIR OR REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-511376-S36093232142012102600000)
  5. REPLACE ECM. Refer to «REMOVAL»(ref-511385-S33230492262012102600000)
  6. REPLACE SHIFT SOLENOID VALVE S4. Refer to «DISASSEMBLY - Step 6»(ref-511376-S20930637052012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

  1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. Follow the instructions on the Techstream and perform the Active Test. Tester Display Test Part Control Range Diagnostic Note Activate the Solenoid (SLT)* Operate the shift solenoid SLT and raise line pressure ON/OFF HINT: OFF: Line pressure up (when Active Test "Solenoid (SLT)" is performed, ECM commands SLT solenoid to turn OFF) ON: No action (normal operation) [Vehicle Condition] Vehicle stopped Engine idling HINT: *: "Solenoid (SLT)" in the Active Test is performed to check the line pressure changes by connecting SST to the automatic transaxle, which is used in the Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-511386-S15693943782012102600000) as well. Please note that the pressure values in the Active Test and Hydraulic Test are different.

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 536

Scheme 536: PROCEDURE
Scheme 536: PROCEDURE

Scheme 537

Scheme 537
Scheme 537
  1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SLT) Disconnect the transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2 (SLT+) - 7 (SLT-) 20°C (68°F) 5.0 to 5.6 ohms 2 (SLT+) - Body ground Always 10 kohms or higher 7 (SLT-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Wire) NG --> See step 3 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Reconnect the transmission wire connector. Disconnect the B33 ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-76 (SLT+) - B33-75 (SLT-) 20°C (68°F) 5.0 to 5.6 ohms B33-76 (SLT+) - Body ground Always 10 kohms or higher B33-75 (SLT-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
  3. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Shift Solenoid Valve SLT) Connect the battery positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes operating sound. NG --> See step 5 OK --> See step 6
  4. REPLACE ECM. Refer to «REMOVAL»(ref-511385-S33230492262012102600000)
  5. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «DISASSEMBLY - Step 4»(ref-511376-S20930637052012102600000)
  6. REPAIR OR REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-511376-S36093232142012102600000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 538

Scheme 538: PROCEDURE
Scheme 538: PROCEDURE

Scheme 539

Scheme 539
Scheme 539

Scheme 540

Scheme 540
Scheme 540
  1. INSPECT TRANSMISSION CONTROL SWITCH Disconnect the transmission control switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 6 (IG) - 13 (S) Shift lever in S, "+" or "-" Below 1 ohms Shift lever not in S, "+" and "-" 10 kohms or higher 5 (SFTU) - 11 (E) Shift lever continuously shifted to "+" (Up-shift) Below 1 ohms Shift lever in S 10 kohms or higher 4 (SFTD) - 11(E) Shift lever continuously shifted to "-" (Down-shift) Below 1 ohms Shift lever in S 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Control Switch) NG --> See step 5 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (TRANSMISSION CONTROL SWITCH - BATTERY, BODY GROUND) Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition C33-6 (IG) - Body ground Ignition switch ON 11 to 14 V C33-6 (IG) - Body ground Ignition switch off Below 1 V Turn the ignition switch off. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C33-11 (E) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Transmission Control Switch) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (TRANSMISSION CONTROL SWITCH - ECM) Reconnect the transmission control switch connector. Disconnect the ECM connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B33-74 (S) - Body ground Ignition switch ON Shift lever in S, "+" or "-" 11 to 14 V Ignition switch ON Shift lever not in S, "+" and "-" Below 1 V Turn the ignition switch off. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A36-16 (SFTU) - Body ground Shift lever continuously shifted to "+" (Up-shift) Below 1 ohms Shift lever in S 10 kohms or higher A36-51 (SFTD) - Body ground Shift lever continuously shifted to "-" (Down-shift) Below 1 ohms Shift lever in S 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
  4. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-511386-S09199791672012102600000)
  5. REPLACE SHIFT LOCK CONTROL UNIT ASSEMBLY (TRANSMISSION CONTROL SWITCH). Refer to «REMOVAL»(ref-511376-S25985831472012102600000)
