Engine Control System (Diagnostics & Circuit Tests): Diagnosis Scion tC II рестайлинг

INSPECTION PROCEDURE

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure. The Techstream is required to conduct the following diagnostic troubleshooting procedure.

HINT

1. Using the Techstream monitor results enables the EVAP (Evaporative Emission) system to be confirmed.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 111

Scheme 112

1. CONFIRM DTC Turn the ignition switch off and wait for 10 seconds. Turn the ignition switch to ON. Turn the ignition switch off and wait for 10 seconds. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Confirm DTCs and freeze frame data. If any EVAP system DTCs are stored, the malfunctioning area can be determined using the table below. NOTE: If the reference pressure difference between the first and second checks is more than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P2401, P2402 and P2419) are stored. NEXT: Go to next step
2. PERFORM EVAP SYSTEM CHECK (AUTOMATIC MODE) NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the temperature below 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode. After the EVAP SYSTEM CHECK is completed, check for pending DTCs by entering the following menus: Powertrain / Engine / Trouble Codes. HINT: If no pending DTCs are displayed, perform the Confirmation Driving Pattern. After this confirmation, check for pending DTCs. If no DTCs are displayed, the EVAP system is normal. NEXT: Go to next step
3. PERFORM EVAP SYSTEM CHECK (MANUAL MODE) NOTE: In the Evaporative System Check (Manual Mode), the series of 6 Evaporative System Check steps are performed manually using the Techstream. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the temperature below 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Manual Mode. NEXT: Go to next step
4. PERFORM EVAP SYSTEM CHECK (STEP 1/6) Check the EVAP pressure in step 1/6. RESULT DTC *1 Result Suspected Trouble Area Proceed to - Virtually no variation in EVAP pressure Not yet determined A P0451 EVAP pressure fluctuates by +/-0.3 kPa(gauge) [2.25 mmHg(gauge)] or more Canister pressure sensor signal noise B (P0452 or P0453) *2 EVAP pressure is below 42.11 kPa(abs) [315.85 mmHg(abs)] or 123.761 kPa(abs) [928.28 mmHg(abs)] or more EVAP pressure deviates +/-10 kPa [+/-75 mmHg] from actual atmosphere pressure *3 Canister pressure sensor or its circuit has malfunction C *1: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. *2: If the canister pressure sensor circuit has an open or short, DTC P0452 or P0453 is stored 0.5 seconds after the ignition switch is turned to ON. HINT: *3: Canister pressure sensor standard output range is 70 to 110 kPa(abs) [525 to 825 mmHg(abs)]. This varies by weather. B --> See step 38 C --> See step 12 A: Go to next step
5. PERFORM EVAP SYSTEM CHECK (STEP 1/6 TO 2/6) Check the EVAP pressure in steps 1/6 and 2/6. RESULT DTC* Result Suspected Trouble Area Proceed to - Virtually no variation in EVAP pressure during step 1/6. Then decreases to reference pressure Not yet determined A P2402 Small difference between EVAP pressures during steps 1/6 and 2/6 Leak detection pump stuck ON B *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. HINT: The first reference pressure is the value determined in step 2/6. B --> See step 33 A: Go to next step
6. PERFORM EVAP SYSTEM CHECK (STEP 2/6) HINT: Make a note of the pressures checked in inspection items (A) and (B) below. Check the EVAP pressure 4 seconds after the leak detection pump is activated*1 (A). *1: The leak detection pump begins to operate as step 1/6 finishes and step 2/6 starts. Check the EVAP pressure again when it has stabilized. This pressure is the reference pressure (B). RESULT DTC*2 Result Suspected Trouble Area Proceed to - EVAP pressure in inspection item (B) is between -4.85 kPa(gauge) and -1.057 kPa(gauge) [-36.381 mmHg(gauge) and -7.929 mmHg(gauge)] Not yet determined A P043F and P2401 EVAP pressure in inspection item (B) is -1.057 kPa(gauge) [-7.929 mmHg(gauge)] or more Reference orifice high-flow Leak detection pump stuck OFF B P043E EVAP pressure in inspection item (B) is less than -4.85 kPa(gauge) [-36.384 mmHg(gauge)] Reference orifice clogged C P2419 EVAP pressure in inspection item (A) is more than -0.25 kPa(gauge) [-1.875 mmHg(gauge)] Vent valve stuck closed Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) D *2: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. B --> See step 11 C --> See step 38 D --> See step 13 A: Go to next step
7. PERFORM EVAP SYSTEM CHECK (STEP 2/6 TO 3/6) Check the EVAP pressure in step 3/6. RESULT DTC* Result Suspected Trouble Area Proceed to - EVAP pressure increases by 0.3 kPa(gauge) [2.25 mmHg(gauge)] or more within 10 seconds of proceeding from step 2/6 to step 3/6 Not yet determined A P2420 No variation in EVAP pressure even after proceeding from step 2/6 to step 3/6 Vent valve stuck open (vent) Canister (charcoal filter inside canister) clogged B P0451 No variation in EVAP pressure during steps 1/6 through 3/6 Canister pressure sensor output value stuck Vent valve broken (valve split in two) Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) C *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. B --> See step 27 C --> See step 15 A: Go to next step
8. PERFORM EVAP SYSTEM CHECK (STEP 3/6) Wait until the EVAP pressure change is less than 0.12 kPa(gauge) [0.9 mmHg(gauge)] for 30 seconds. Measure the EVAP pressure and record it. HINT: A few minutes are required for the EVAP pressure to become saturated. When there is little fuel in the fuel tank, it takes up to 15 minutes. NEXT: Go to next step
9. PERFORM EVAP SYSTEM CHECK (STEP 4/6) Check the EVAP pressure in step 4/6. RESULT DTC*1 Result Suspected Trouble Area Proceed to - EVAP pressure increases by 0.3 kPa(gauge) [2.25 mmHg(gauge)] or more within 10 seconds of proceeding from step 3/6 to step 4/6 Not yet determined A P0441 *2 EVAP pressure increases by 0.3 kPa(gauge) [2.25 mmHg(gauge)] or more within 10 seconds of proceeding from step 3/6 to step 4/6 Purge VSV Purge VSV circuit Problems in EVAP hose between purge VSV and intake manifold Problems in EVAP hose between canister and purge VSV ECM B P0441 Variation in EVAP pressure is less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] for 10 seconds, after proceeding from step 3/6 to step 4/6 Purge VSV stuck closed Purge VSV circuit Canister (charcoal filter inside canister) clogged Problems in EVAP hose between purge VSV and intake manifold Problems in EVAP hose between canister and purge VSV ECM C *1: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. *2: This result suggests that due to purge line blockage or purge VSV malfunction, the DTC was stored by the purge flow monitor while the engine was running, or that key-off monitor test result were nearly borderline values. B --> See step 22 C --> See step 17 A: Go to next step
10. PERFORM EVAP SYSTEM CHECK (STEP 5/6) Check the EVAP pressure in step 5/6. Compare the EVAP pressure in step 3/6 and the second reference pressure (step 5/6). RESULT DTC* Result Suspected Trouble Area Proceed to - EVAP pressure from step 3/6 less than second reference pressure (step 5/6) Not yet determined (no leakage from EVAP system) A P0441 and P0455 EVAP pressure from step 3/6 higher than [second reference pressure (step 5/6) x 0.2] Purge VSV stuck open EVAP gross leak B P0456 EVAP pressure from step 3/6 higher than second reference pressure (step 5/6) EVAP small leak B *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. A --> See step 43 B --> See step 17
11. PERFORM EVAP SYSTEM CHECK (STEP 3/6) Check the EVAP pressure in step 3/6. RESULT DTC* Result Suspected Trouble Area Proceed to P043F EVAP pressure less than [reference pressure] measured in step 2/6 Reference orifice high-flow A P2401 EVAP pressure almost same as [reference pressure] measured in step 2/6 Leak detection pump stuck off B *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. HINT: The first reference pressure is the value determined in step 2/6. A --> See step 38 B --> See step 31
12. INSPECT CANISTER PUMP MODULE (CANISTER PRESSURE SENSOR CIRCUIT) Check the canister pressure sensor circuit, referring to DTC P0451 canister pressure sensor circuit inspection procedure. Refer to «INSPECTION PROCEDURE»(ref-615239-S07063289612014050900000) . NEXT --> See step 48
13. INSPECT CANISTER PUMP MODULE (VENT VALVE OPERATION) Turn the ignition switch off. Disconnect the canister pump module connector. TEXT IN ILLUSTRATION *1 Component without harness connected (Canister Pump Module) Apply the battery voltage to terminals VLVB and VGND of the pump module. Touch the canister pump module to confirm the vent valve operation. RESULT Condition Tester Result Suspected Trouble Area Proceed to Apply battery voltage to terminals VLVB and VGND Operating Wire harness or connector between vent valve and ECM Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) ECM A Not operating Vent valve B B --> See step 38 A: Go to next step
14. CHECK HARNESS AND CONNECTOR (ECM - CANISTER PUMP MODULE) Turn the ignition switch off. Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A35-42 (VPMP) - H20-1 (VGND) Always Below 1 ohms A35-42 (VPMP) or H20-1 (VGND) - Body ground Always 10 kohms or higher RESULT Result Suspected Trouble Area Proceed to OK Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) ECM A NG Wire harness or connector between ECM and canister pump module B B --> See step 40 A: Go to next step
15. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - BODY GROUND) Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to H20-4 (MGND) - Body ground Always Below 1 ohms Canister pump module Wire harness or connector between canister pump module and ECM ECM A 10 kohms or higher Wire harness or connector between canister pump module and body ground B B --> See step 40 A: Go to next step
16. CHECK HARNESS AND CONNECTOR (ECM - CANISTER PUMP MODULE) Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to A35-34 (MPMP) - H20-3 (MTRB) Always Below 1 ohms Canister pump module ECM A 10 kohms or higher Wire harness or connector between ECM and canister pump module B A --> See step 45 B --> See step 40
17. PERFORM ACTIVE TEST USING TECHSTREAM (PURGE VSV) Enter the following menus: Powertrain / Engine / Active Test / Activate the VSV for EVAP Control. Disconnect the hose (connected to the canister) from the purge VSV. TEXT IN ILLUSTRATION *1 Purge VSV *2 Hose (to Canister) Start the engine. Using the Techstream, turn off the purge VSV (Activate the VSV for Evap Control: OFF). Use your finger to confirm that the purge VSV has no suction. Using the Techstream, turn on the purge VSV (Activate the VSV for Evap Control: ON). Use your finger to confirm that the purge VSV has suction. RESULT Test Result Suspected Trouble Area Proceed to No suction when purge VSV turned off, and suction applied when turned on Blockage in the purge line is considered (based on result of step 9): Problems with EVAP hose between canister and purge VSV Canister (charcoal filter inside canister) clogged ECM A Leakage is considered (based on result of step 10): Fuel cap Leakage from EVAP line, fuel tank, or canister assembly B Suction applied when purge VSV turned off Purge VSV stuck open C No suction when purge VSV turned on Purge VSV stuck closed Problems with EVAP hose between purge VSV and intake manifold D B --> See step 20 C --> See step 21 D --> See step 23 A: Go to next step
18. INSPECT EVAP HOSE (PURGE VSV - CANISTER) Check for blockages in the EVAP purge line between the purge VSV and canister. OK No blockages in the EVAP purge line between the purge VSV and canister. NG --> See step 44 OK: Go to next step
19. INSPECT CANISTER (CHARCOAL FILTER INSIDE CANISTER) Check for filter blockage in the canister. Refer to «INSPECTION [05/2013 - ]»(ref-615251-S10353946292014050900000) . OK No blockages in the canister. OK --> See step 47 NG --> See step 38
20. CHECK FUEL CAP ASSEMBLY Check that the fuel cap is correctly installed and confirm that the fuel cap meets OEM specifications. Tighten the fuel cap firmly (only one click sound could be heard). HINT: If an EVAP tester is available, check the fuel cap using the EVAP tester. Remove the fuel cap and install it onto a fuel cap adapter. Connect an EVAP tester pump hose to the adapter, and pressurize the cap to 3.2 to 3.7 kPa(gauge) [24 to 28 mmHg(gauge)] using an EVAP tester pump. Seal the adapter and wait for 2 minutes. Check the pressure. If the pressure is 2 kPa(gauge) [15 mmHg(gauge)] or more, the fuel cap is normal. RESULT Test Result Suspected Trouble Area Proceed to Fuel cap correctly installed - A Fuel cap loose Fuel cap improperly installed Defective fuel cap Fuel cap does not meet OEM specifications B Defective fuel cap - B No fuel cap - C A --> See step 37 B --> See step 35 C --> See step 36
21. INSPECT PURGE VSV Turn the ignition switch off. Disconnect the purge VSV connector. TEXT IN ILLUSTRATION *1 Purge VSV *2 Hose (to Canister) Disconnect the hose (connected to the canister) from the purge VSV. Start the engine. Use your finger to confirm that the purge VSV has no suction. RESULT Test Result Suspected Trouble Area Proceed to No suction Wire harness or connector between purge VSV and ECM (short to ground) ECM A Suction applied Purge VSV B A --> See step 26 B --> See step 39
22. INSPECT EVAP HOSE (PURGE VSV - CANISTER) Check for blockages in the EVAP purge line between the purge VSV and canister. OK No blockages in the EVAP purge line between the purge VSV and canister. NG --> See step 44 OK: Go to next step
23. CHECK EVAP HOSE (PURGE VSV - INTAKE MANIFOLD) Disconnect the hose (connected to the intake manifold) from the purge VSV. TEXT IN ILLUSTRATION *1 Purge VSV *2 Hose (to Intake Manifold) Start the engine. Use your finger to confirm that the hose has suction. RESULT Test Result Suspected Trouble Area Proceed to Suction applied EVAP hose between purge VSV and intake manifold normal Purge VSV Purge VSV power source Wire harness or connector between purge VSV and ECM A No suction Intake manifold port EVAP hose between purge VSV and intake manifold B B --> See step 34 A: Go to next step
24. INSPECT PURGE VSV Remove the purge VSV. Apply battery voltage to the terminals of the purge VSV. TEXT IN ILLUSTRATION *1 Purge VSV Confirm that air flows from port E to port F. RESULT Test Result Condition Suspected Trouble Area Proceed to Air flows Battery voltage is applied to purge VSV terminals Purge VSV normal Purge VSV power source Wire harness or connector between purge VSV and ECM A No air flow Battery voltage is applied to purge VSV terminals Purge VSV B B --> See step 39 A: Go to next step
25. CHECK TERMINAL VOLTAGE (POWER SOURCE OF PURGE VSV) Disconnect the purge VSV connector. Turn the ignition switch to ON. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Purge VSV) Measure the voltage according to the value(s) in the table below. RESULT Tester Connection Switch Condition Specified Condition Suspected Trouble Area Proceed to B18-1 - Body ground Ignition switch ON 11 to 14 V Purge VSV power source normal Wire harness or connector between purge VSV and ECM A Other than result above Wire harness or connectors between purge VSV and battery B B --> See step 40 A: Go to next step
26. CHECK HARNESS AND CONNECTOR (PURGE VSV - ECM) Disconnect the ECM connector. Disconnect the purge VSV connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B18-2 - B30-28 (PRG) Always Below 1 ohms B18-2 or B30-28 (PRG) - Body ground Always 10 kohms or higher OK --> See step 47 NG --> See step 40
27. INSPECT CANISTER PUMP MODULE (POWER SOURCE FOR VENT VALVE) Turn the ignition switch off. Disconnect the canister pump module connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. RESULT Tester Connection Switch Condition Specified Condition Suspected Trouble Area Proceed to H20-5 (VLVB) - Body ground Ignition switch ON 11 to 14 V Wire harness or connector between vent valve and ECM Vent valve Canister (charcoal filter inside canister) clogged ECM A Below 3 V Power source wire harness of vent valve B TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Canister Pump Module) B --> See step 40 A: Go to next step
28. INSPECT CANISTER PUMP MODULE (VENT VALVE OPERATION) Turn the ignition switch off. Disconnect the canister pump module connector. TEXT IN ILLUSTRATION *1 Component without harness connected (Canister Pump Module) Apply the battery voltage to terminals VLVB and VGND of the pump module. Touch the canister pump module to confirm the vent valve operation. RESULT Condition Tester Result Suspected Trouble Area Proceed to Apply battery voltage to terminals VLVB and VGND Operating Wire harness or connector between vent valve and ECM Canister (charcoal filter inside canister) clogged ECM A Not operating Vent valve B B --> See step 38 A: Go to next step
29. CHECK HARNESS AND CONNECTOR (ECM - CANISTER PUMP MODULE) Turn the ignition switch off. Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Test Result Suspected Trouble Area Proceed to A35-42 (VPMP) - H20-1 (VGND) Always Below 1 ohms Canister (charcoal filter inside canister) clogged ECM A 10 kohms or higher Wire harness or connector between ECM and canister pump module B B --> See step 40 A: Go to next step
30. INSPECT CANISTER (CHARCOAL FILTER INSIDE CANISTER) Check for filter blockage in the canister. Refer to «INSPECTION [05/2013 - ]»(ref-615251-S10353946292014050900000) . OK No blockages in the canister. OK --> See step 47 NG --> See step 38
31. CHECK TERMINAL VOLTAGE (CANISTER PUMP MODULE) Turn the ignition switch off. Disconnect the canister pump module connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. RESULT Tester Connection Condition Test Result Suspected Trouble Area Proceed to H20-3 (MTRB) - Body ground Ignition switch ON 9 to 14 V Wire harness or connector between leak detection pump and body ground Leak detection pump A Below 3 V Wire harness or connector between leak detection pump and ECM ECM B TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Canister Pump Module) B --> See step 33 A: Go to next step
32. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - BODY GROUND) Turn the ignition switch off. Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to H20-4 (MGND) - Body ground Always Below 1 ohms Leak detection pump A 10 kohms or higher Wire harness or connector between canister pump module and body ground B A --> See step 38 B --> See step 40
33. CHECK HARNESS AND CONNECTOR (ECM - CANISTER PUMP MODULE) Turn the ignition switch off. Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A35-34 (MPMP) - H20-3 (MTRB) Always Below 1 ohms A35-34 (MPMP) or H20-3 (MTRB) - Body ground Always 10 kohms or higher RESULT Result Suspected Trouble Area Proceed to OK ECM A NG Wire harness or connector between ECM and canister pump module B A --> See step 47 B --> See step 40
34. INSPECT INTAKE MANIFOLD (EVAP PURGE PORT) Stop the engine. Disconnect the EVAP hose from the intake manifold. Start the engine. Use your finger to confirm that the port of the intake manifold has suction. RESULT Tester Connection Suspected Trouble Area Proceed to Suction applied EVAP hose between intake manifold and purge VSV A No suction Intake manifold B A --> See step 41 B --> See step 42
35. CORRECTLY REINSTALL OR REPLACE FUEL TANK CAP ASSEMBLY HINT: When reinstalling the fuel cap, tighten it firmly (only one click sound could be heard). When replacing the fuel cap, use a fuel cap that meets OEM specifications, and install it firmly. NEXT --> See step 48
36. REPLACE FUEL TANK CAP ASSEMBLY HINT: When installing the fuel cap, tighten it firmly (only one click sound could be heard). NEXT --> See step 48
37. LOCATE EVAP LEAK PART Disconnect the vent hose. TEXT IN ILLUSTRATION *1 Vent Hose (to Canister Filter) *2 Canister Pump Module *3 EVAP Tester *4 Adapter *a Disconnect the Vent Hose - - Connect the EVAP pressure tester tool to the canister pump module with the adapter. Pressurize the EVAP system to 3.2 to 3.7 kPa(gauge) [24 to 28 mmHg(gauge)]. Apply soapy water to the piping and connecting parts of the EVAP system. Look for areas where bubbles appear. This indicates the leak point. Repair or replace the leak point. HINT: Disconnect the hose between the canister and fuel tank from the canister. Block the canister side and conduct an inspection. In this way, the fuel tank can be excluded as an area suspected of causing fuel leaks. NEXT --> See step 48
38. REPLACE CANISTER Replace the canister. Refer to «REMOVAL [05/2013 - ]»(ref-615251-S01365067382014050900000) . NOTE: When replacing the canister, check the canister pump module interior and related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. Check for filter blockage in the canister filter. if the canister filter has blockages, replace the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Vent Hose *3 Air Inlet Port *4 Fuel Tank *5 Canister - - *a Inspection Area (check for disconnection and/or cracks) - - NEXT --> See step 48
39. REPLACE PURGE VSV Replace the purge VSV. Refer to «REMOVAL [05/2013 - ]»(ref-615251-S15991977022014050900000) . NEXT --> See step 48
40. REPAIR OR REPLACE HARNESS OR CONNECTOR NEXT --> See step 48
41. REPAIR OR REPLACE EVAP PURGE LINE (INTAKE MANIFOLD - PURGE VSV) NEXT --> See step 48
42. INSPECT INTAKE MANIFOLD (EVAP PURGE PORT) Check that the EVAP purge port of the intake manifold is not clogged. If necessary, replace the intake manifold. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615249-S35888103472014050900000) . NEXT --> See step 48
43. REPAIR OR REPLACE PARTS AND COMPONENTS INDICATED BY OUTPUT DTCS Repair the malfunctioning areas indicated by the DTCs that had been confirmed when the vehicle was brought in. NEXT --> See step 48
44. REPAIR OR REPLACE EVAP PURGE LINE (PURGE VSV - CANISTER) NEXT --> See step 48
45. REPLACE CANISTER Replace the canister. Refer to «REMOVAL [05/2013 - ]»(ref-615251-S01365067382014050900000) . NOTE: When replacing the canister, check the canister pump module interior and related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. Check for filter blockage in the canister filter. if the canister filter has blockages, replace the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Vent Hose *3 Air Inlet Port *4 Fuel Tank *5 Canister - - *a Inspection Area (check for disconnection and/or cracks) - - NEXT: Go to next step
46. PERFORM EVAP SYSTEM CHECK (AUTOMATIC MODE) NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine in this step. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing an Evaporative System Check, keep the fuel temperature below 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode. After the Evaporative System Check is completed, check for pending DTCs by entering the following menus: Powertrain / Engine / Trouble Codes. RESULT Result Proceed to EVAP system DTCs are output A No DTCs output (No pending DTCs output) B B --> END A: Go to next step
47. REPLACE ECM Replace the ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000) . NEXT: Go to next step
48. PERFORM EVAP SYSTEM CHECK (AUTOMATIC MODE) NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine in this step. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing an Evaporative System Check, keep the fuel temperature below 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode. After the Evaporative System Check is completed, check for pending DTCs by entering the following menus: Powertrain / Engine / Trouble Codes. HINT: If no pending DTCs are found, the repair has been successfully completed. NEXT --> END

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure. The Techstream is required to conduct the following diagnostic troubleshooting procedure.

HINT

1. Using the Techstream monitor results enables the EVAP (Evaporative Emission) system to be confirmed.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 113

Scheme 114

1. CHECK INTEGRATION RELAY (POWER SOURCE) Remove the integration relay from the engine room relay block. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition 1C-1 - Body ground Always 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Integration Relay) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (INTEGRATION RELAY - BATTERY) OK: Go to next step
2. INSPECT INTEGRATION RELAY (EFI NO. 1) Inspect the integration relay (EFI NO. 1). Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 2»(ref-615228-S19103065862014050900000) . NG --> REPLACE INTEGRATION RELAY OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (INTEGRATION RELAY - ECM, BODY GROUND) Check the harness and connectors between the integration relay and ECM. Remove the integration relay from the engine room relay block. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A35-6 (MREL) - 1B-2 Always Below 1 ohms A35-2 (+B) - 1B-4 Always Below 1 ohms A35-1 (+B2) - 1B-4 Always Below 1 ohms A35-6 (MREL) or 1B-2 - Body ground Always 10 kohms or higher A35-2 (+B) or 1B-4 - Body ground Always 10 kohms or higher A35-1 (+B2) or 1B-4 - Body ground Always 10 kohms or higher Check the harness and connectors between the integration relay and body ground. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1B-3 - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (ECM - BODY GROUND) Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B30-104 (E1) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. INSPECT ECM (IGSW VOLTAGE) Disconnect the ECM connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition A35-28 (IGSW) - B30-104 (E1) Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> See step 6 OK --> See step 12
6. INSPECT INTEGRATION RELAY (IG2) Inspect the integration relay (IG2). Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615228-S19103065862014050900000) . NG --> REPLACE INTEGRATION RELAY OK: Go to next step
7. CHECK HARNESS AND CONNECTOR (INTEGRATION RELAY - ECM) Remove the integration relay from the engine room relay block. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1A-4 - A35-28 (IGSW) Always Below 1 ohms 1A-4 or A35-28 (IGSW) - Body ground Always 10 kohms or higher RESULT Result Proceed to Out of normal range A Within normal range B B --> See step 8 A --> REPAIR OR REPLACE HARNESS OR CONNECTOR
8. CHECK IF VEHICLE IS EQUIPPED WITH SMART KEY SYSTEM Confirm the vehicle specifications. RESULT Result Proceed to w/ Smart Key System A w/o Smart Key System B B --> See step 10 A: Go to next step
9. CHECK HARNESS AND CONNECTOR (INTEGRATION RELAY - POWER SOURCE CONTROL ECU) Remove the integration relay from the engine room relay block. Disconnect the power source control ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1A-2 - C42-8 (IG2D) Always Below 1 ohms 1A-3 - Body ground Always Below 1 ohms 1A-2 or C42-8 (IG2D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 13
10. CHECK HARNESS AND CONNECTOR (INTEGRATION RELAY - IGNITION SWITCH ASSEMBLY) Remove the integration relay from the engine room relay block. Disconnect the ignition switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1A-2 - C5-6 (IG2) Always Below 1 ohms 1A-3 - Body ground Always Below 1 ohms 1A-2 or C5-6 (IG2) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
11. INSPECT IGNITION SWITCH ASSEMBLY Inspect the ignition switch assembly. Refer to «INSPECTION [05/2013 - ]»(ref-615241-S12172629802014050900000) . NG --> See step 14 OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IGNITION SWITCH - BATTERY)
12. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
13. CHECK SMART KEY SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [05/2013 - 01/2014]»(ref-615115-S30223459362014050900000)
14. REPLACE IGNITION SWITCH ASSEMBLY. Refer to «REMOVAL [05/2013 - ]»(ref-615241-S37701422032014050900000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Note. Inspect the fuses of circuits related to this system before performing the following inspection procedure.

Scheme 115

1. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. Check whether the fuel pump operating sound occurs when performing the Active Test on the Techstream. OK Fuel pump operating sound occurs. NG --> See step 4 OK: Go to next step
2. READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Starter Signal. Check the result when the ignition switch is turned to ON and START. OK Ignition Switch Position Starter Signal ON Close (Starter signal OFF) START Open (Starter signal ON) NG --> REPAIR OR REPLACE STARTING SYSTEM OK: Go to next step
3. READ VALUE USING TECHSTREAM (ENGINE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Engine Speed. Read the values displayed on the Techstream while cranking the engine. OK Values are displayed continuously. NG --> REPAIR OR REPLACE CRANKSHAFT POSITION SENSOR CIRCUIT OK --> See step 12
4. CHECK INSTRUMENT PANEL JUNCTION BLOCK (C/OPN RELAY INPUT VOLTAGE) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition 2B-2 - Body ground Ignition switch off Below 1 V 2B-5 - Body ground 2B-2 - Body ground Ignition switch ON 11 to 14 V 2B-5 - Body ground TEXT IN ILLUSTRATION *a Component with harness connected (Instrument Panel Junction Block) NG --> See step 9 OK: Go to next step
5. INSPECT INSTRUMENT PANEL JUNCTION BLOCK (C/OPN RELAY) Inspect the instrument panel junction block (C/OPN relay). Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 4»(ref-615228-S19103065862014050900000) . NG --> REPLACE INSTRUMENT PANEL JUNCTION BLOCK OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (INSTRUMENT PANEL JUNCTION BLOCK - ECM) Disconnect the ECM connector. Disconnect the instrument panel junction block connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2B-12 - A35-8 (FC) Always Below 1 ohms 2B-12 or A35-8 (FC) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. CHECK HARNESS AND CONNECTOR (C/OPN RELAY - FUEL PUMP - BODY GROUND) Check the harness and connectors between the instrument panel junction block and fuel pump. Disconnect the instrument panel junction block connector. Disconnect the fuel pump connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2A-13 - H12-4 Always Below 1 ohms 2A-13 or H12-4 - Body ground Always 10 kohms or higher Check the harness and connectors between the fuel pump and body ground. Disconnect the fuel pump connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition H12-5 - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
8. INSPECT FUEL PUMP Inspect the fuel pump. Refer to «INSPECTION [05/2013 - ]»(ref-615244-S33268116522014050900000) . HINT: Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 14 OK --> See step 13
9. INSPECT INTEGRATION RELAY (EFI NO. 2) Inspect the integration relay (EFI NO. 2). Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 3»(ref-615228-S19103065862014050900000) . NG --> REPLACE INTEGRATION RELAY OK: Go to next step
10. CHECK HARNESS AND CONNECTOR (INSTRUMENT PANEL JUNCTION BLOCK - INTEGRATION RELAY) Remove the integration relay from the engine room relay block. Disconnect the instrument panel junction block connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1A-4 - 2B-5 Always Below 1 ohms 2B-2 - 1B-8 Always Below 1 ohms 1B-6 - 1B-4 Always Below 1 ohms 1B-7 - Body ground Always Below 1 ohms 1A-4 or 2B-5 - Body ground Always 10 kohms or higher 2B-2 or 1B-8 - Body ground Always 10 kohms or higher 1B-6 or 1B-4 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 11
11. GO TO ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit»(ref-615235-S16917092912014050900000)
12. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
13. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
14. REPLACE FUEL PUMP. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S34315231702014050900000)

Note. Inspect the fuses of circuits related to this system before performing the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 116

1. INSPECT FUEL INJECTOR ASSEMBLY (POWER SOURCE) Disconnect the fuel injector connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Cylinder Tester Connection Switch Condition Specified Condition No. 1 B10-1 - Ground Ignition switch ON 11 to 14 V No. 2 B11-1 - Ground Ignition switch ON 11 to 14 V No. 3 B12-1 - Ground Ignition switch ON 11 to 14 V No. 4 B13-1 - Ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly) NG --> See step 4 OK: Go to next step
2. INSPECT FUEL INJECTOR ASSEMBLY Inspect the fuel injector assembly. Refer to «INSPECTION [05/2013 - ]»(ref-615244-S28235590902014050900000) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 5 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (FUEL INJECTOR - ECM) Disconnect the fuel injector connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Cylinder Tester Connection Condition Specified Condition No. 1 B10-2 - Body ground Always 10 kohms or higher B10-2 - B30-85 (#10) Always Below 1 ohms No. 2 B11-2 - Ground Always 10 kohms or higher B11-2 - B30-84 (#20) Always Below 1 ohms No. 3 B12-2 - Ground Always 10 kohms or higher B12-2 - B30-83 (#30) Always Below 1 ohms No. 4 B13-2 - Ground Always 10 kohms or higher B13-2 - B30-82 (#40) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
4. INSPECT INTEGRATION RELAY (IG2) Inspect the integration relay (IG2). Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615228-S19103065862014050900000) . NG --> REPLACE INTEGRATION RELAY OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (INTEGRATION RELAY - FUEL INJECTOR)
5. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S17953342372014050900000)
6. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

This inspection procedure is based on the premise that the engine can crank normally. If the engine cannot crank normally, proceed to the problem symptoms table. Refer to PROBLEM SYMPTOMS TABLE [05/2013 - 01/2014] .

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

This inspection procedure is based on the premise that the engine can crank normally. If the engine cannot crank normally, proceed to the problem symptoms table. Refer to PROBLEM SYMPTOMS TABLE [01/2014 - ] .

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 117

1. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE VACUUM SWITCHING VALVE FOR ACIS) Disconnect the vacuum hose from port F of the vacuum switching valve (for ACIS). Connect the Techstream to the DLC3. Start the engine. Enter the following menus: Powertrain / Engine / Active Test / Active the VSV for Intake Control. Operate the vacuum switching valve for ACIS. Check the vacuum switching valve air flow when switching the vacuum switching valve. OK Test Condition Specified Condition Vacuum switching valve is ON Air from port E flows out through port F Vacuum switching valve is OFF Air from port E flows out through air filter TEXT IN ILLUSTRATION *1 Air *2 Port F *3 Port E *4 Air Filter *a Vacuum Switching Valve is ON *b Vacuum Switching Valve is OFF NG --> See step 4 OK: Go to next step
2. CHECK VACUUM HOSES (VACUUM SWITCHING VALVE (FOR ACIS) - INTAKE AIR CONTROL VALVE, INTAKE MANIFOLD) Check the vacuum hoses. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615245-S05242304412014050900000) . NG --> REPAIR OR REPLACE VACUUM HOSES OK: Go to next step
3. INSPECT INTAKE MANIFOLD (INTAKE AIR CONTROL VALVE) Inspect the intake air control valve. Refer to «INSPECTION [05/2013 - ]»(ref-615249-S38367223342014050900000) . NG --> See step 9 OK --> See step 7
4. INSPECT VACUUM SWITCHING VALVE ASSEMBLY (FOR ACIS) Inspect the vacuum switching valve assembly (for ACIS). Refer to «ON-VEHICLE INSPECTION [05/2013 - ]»(ref-615249-S25249650892014050900000) . NG --> See step 8 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (VACUUM SWITCHING VALVE (FOR ACIS) - ECM AND INTEGRATION RELAY) Disconnect the vacuum switching valve (for ACIS) connector. Disconnect the ECM connector. Remove the integration relay from the engine room relay block. Disconnect the integration relay connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B19-1 - B30-27 (ACIS) Always Below 1 ohms B19-2 - 1B-4 Always Below 1 ohms B19-1 or B30-27 (ACIS) - Body ground Always 10 kohms or higher B19-2 or 1B-4 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
6. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
7. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [05/2013 - 01/2014]»(ref-615120-S16624443392014050900000)
8. REPLACE VACUUM SWITCHING VALVE ASSEMBLY (FOR ACIS). Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615249-S35888103472014050900000)
9. REPLACE INTAKE MANIFOLD. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615249-S35888103472014050900000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Inspection Method

Example

Drive at 10 km/h (6.25 mph), depress the accelerator pedal by 1/2 to 3/4 and keep it in that position. Under these conditions, if the engine speed decreases to 1000 rpm when the brake pedal is depressed, the brake override system has been activated.

HINT

1. Under normal conditions, the Accelerator Position value changes in response to the Accel Sens. No. 1 Volt % value. For more information on the numerical values, refer to the Data List. Refer to «DATA LIST / ACTIVE TEST [05/2013 - 01/2014]»(ref-615234-S35938653532014050900000) .
2. If the Accelerator Position and Accel Sens.No. 1 Volt% values in the Data List diverge and the Accelerator Position value in the Data List is fixed even though Accel Sens.No. 1 Volt% is changing, check that this control is activated (use the GTS data saving function to record data while driving the vehicle, and then confirm it after driving is completed).

Note. The brake override system restricts driving torque if the brake pedal is depressed when driving with the accelerator pedal depressed. If a customer reports experiencing loss of torque after the accelerator and brake pedals have both been intentionally depressed, explain to the customer that this is not a malfunction, and that the customer should avoid depressing both the accelerator and brake pedals at the same time. Example: While operating the accelerator pedal, the customer uses their left foot to operate the brake pedal.

Inspection Method

Example

Drive at 10 km/h (6.25 mph), depress the accelerator pedal by 1/2 to 3/4 and keep it in that position. Under these conditions, if the engine speed decreases to 1000 rpm when the brake pedal is depressed, the brake override system has been activated.

HINT

1. Under normal conditions, the Accelerator Position value changes in response to the Accel Sens. No. 1 Volt % value. For more information on the numerical values, refer to the Data List. Refer to «DATA LIST / ACTIVE TEST [01/2014 - ]»(ref-615234-S30683406662014050900000) .
2. If the Accelerator Position and Accel Sens.No. 1 Volt% values in the Data List diverge and the Accelerator Position value in the Data List is fixed even though Accel Sens.No. 1 Volt% is changing, check that this control is activated (use the GTS data saving function to record data while driving the vehicle, and then confirm it after driving is completed).

Note. The brake override system restricts driving torque if the brake pedal is depressed when driving with the accelerator pedal depressed. If a customer reports experiencing loss of torque after the accelerator and brake pedals have both been intentionally depressed, explain to the customer that this is not a malfunction, and that the customer should avoid depressing both the accelerator and brake pedals at the same time. Example: While operating the accelerator pedal, the customer uses their left foot to operate the brake pedal.
