INSPECTION PROCEDURE

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data. According to the display on the Techstream, read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note Shift SW Status (R Range) Park/neutral position switch status/ ON or OFF Shift lever in R: ON Shift lever not in R: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the park/neutral position switch or shift cable may be incorrect. Shift SW Status (P Range) Park/neutral position switch status/ ON or OFF Shift lever in P: ON Shift lever not in P: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the park/neutral position switch or shift cable may be incorrect. Shift SW Status (N Range) Park/neutral position switch status/ ON or OFF Shift lever in N: ON Shift lever not in N: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the park/neutral position switch or shift cable may be incorrect. Shift SW Status (D Range) Park/neutral position switch status/ ON or OFF Shift lever in D, M or S: ON Shift lever not in D, M or S: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the park/neutral position switch or shift cable may be incorrect. Sports Mode Selection SW Transmission control switch status/ ON or OFF Shift lever in M (or S), "+" or "-": ON Shift lever not in M (or S), "+" or "-": OFF

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data. According to the display on the Techstream, read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note Shift SW Status (R Range) Park/neutral position switch status/ ON or OFF Shift lever in R: ON Shift lever not in R: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the park/neutral position switch or shift cable may be incorrect. Shift SW Status (P Range) Park/neutral position switch status/ ON or OFF Shift lever in P: ON Shift lever not in P: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the park/neutral position switch or shift cable may be incorrect. Shift SW Status (N Range) Park/neutral position switch status/ ON or OFF Shift lever in N: ON Shift lever not in N: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the park/neutral position switch or shift cable may be incorrect. Shift SW Status (D Range) Park/neutral position switch status/ ON or OFF Shift lever in D, M or S: ON Shift lever not in D, M or S: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the park/neutral position switch or shift cable may be incorrect. Sports Mode Selection SW Transmission control switch status/ ON or OFF Shift lever in M (or S), "+" or "-": ON Shift lever not in M (or S), "+" or "-": OFF

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Using the Techstream, the Data List item "Stop Light Switch" can be read.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Using the Techstream, the Data List item "Stop Light Switch" can be read.

HINT

1. In contrast to normal malfunction diagnosis for components, circuits and systems, DTCs P1603 and P1605 are used to determine the malfunctioning area from the problem symptoms and freeze frame data when the user mentions problems such as engine stall. As these DTCs can be stored as a result of certain user actions, even if these DTCs are output, if the customer makes no mention of problems, clear these DTCs without performing any troubleshooting and return the vehicle to the customer.
2. If any other DTCs are output, perform troubleshooting for those DTCs first.
3. Use any information from the customer problem analysis about the condition of the vehicle at the time when the problem occurred (how the engine stopped, conditions when the engine was restarted, etc.) as a reference. Symptom Suspected Area Engine vibration occurs and engine stops Air-fuel ratio abnormal Engine stops with no engine vibration Ignition system, injection stoppage, high load from external parts Engine can be started with accelerator pedal depressed Insufficient air volume Rough idling after engine started Air-fuel ratio abnormal, abnormal combustion
4. Read freeze frame data using the Techstream. Freeze frame data records engine conditions when a malfunction occurs. This information can be useful when troubleshooting.
5. When confirming the freeze frame data, be sure to check all 5 sets of freeze frame data. Refer to «FREEZE FRAME DATA [05/2013 - 01/2014]»(ref-615120-S31308559972014050900000) .
6. When DTC P1603 (Engine Stall History) is stored, DTC P1605 (Rough Idling) is also stored. When confirming freeze frame data, check DTC P1605. The ECM stores DTC P1605 first. Therefore, 5 sets of freeze frame data can be confirmed through DTC P1605, enabling the technician to obtain more information.
7. When confirming freeze frame data, if there are multiple items related to the cause of the malfunction, perform troubleshooting for all related items.
8. Try to operate the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and the data when the engine is idling (engine warmed up, no load, and shift lever in D or N) and compare these data with the freeze frame data.
9. Inspections take into account the fact that the malfunction may not have reoccurred and place emphasis on checking the vehicle conditions present at the time when the malfunction occurred.
10. When performing inspections, jiggle the relevant wire harnesses and connectors in an attempt to reproduce malfunctions that do not always occur.

Inspection flow

Using freeze frame data, narrow down the parts to be inspected according to the vehicle conditions at the time when the malfunction occurred.

P1603

Scheme 218

1

1. If the engine stalled when the intake air volume was low (during idling or deceleration), there may be a decrease in torque due to an incorrect air-fuel ratio, etc.
2. If the engine stalled when the intake air volume was high (during driving or acceleration), there may be a major malfunction such as continuous misfire due to ignition stoppage, fuel injection stoppage, etc. and the torque drops to zero.

2

1. If the engine speed decreased slowly, there may have been a decrease in torque due to an air-fuel ratio that was incorrect (by approximately 20 to 30%), etc.
2. If the engine speed decreased rapidly, there may have been a malfunction such as when the engine misfires almost continuously due to ignition stoppage, fuel injection stoppage, etc., or when the external load increases due to an external part malfunctioning.

3

1. If the air-fuel ratio is abnormal, there may have been an intake air leak, sensor malfunction, or fuel supply problem.
2. If the vehicle was normal, the air volume may have been insufficient or the ignition timing may have been incorrect.

P1603 inspection flow: Narrow down the parts to be inspected according to the vehicle conditions at the time when the malfunction occurred (freeze frame data).

*: If the engine stalls immediately after the injection method is switched from port injection to direct injection, the injector driver may be malfunctioning.

P1605

Scheme 219

1

1. If the engine speed decreased slowly, there may have been a decrease in torque due to an air-fuel ratio that was incorrect (by approximately 20 to 30%), etc.
2. If the engine speed decreased rapidly, there may have been a malfunction such as when the engine misfires almost continuously due to ignition stoppage, fuel injection stoppage, etc., or when the external load increases due to an external part malfunctioning.

2

1. If the air-fuel ratio is abnormal, there may have been an intake air leak, sensor malfunction, or fuel supply problem.
2. If the vehicle was normal, the air volume may have been insufficient or the ignition timing may have been incorrect.

P1605 inspection flow: Narrow down the parts to be inspected according to the vehicle conditions at the time when the malfunction occurred (freeze frame data).

*: If the engine stalls immediately after the injection method is switched from port injection to direct injection, the injector driver may be malfunctioning.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

1. In contrast to normal malfunction diagnosis for components, circuits and systems, DTCs P1603 and P1605 are used to determine the malfunctioning area from the problem symptoms and freeze frame data when the user mentions problems such as engine stall. As these DTCs can be stored as a result of certain user actions, even if these DTCs are output, if the customer makes no mention of problems, clear these DTCs without performing any troubleshooting and return the vehicle to the customer.
2. If any other DTCs are output, perform troubleshooting for those DTCs first.
3. Use any information from the customer problem analysis about the condition of the vehicle at the time when the problem occurred (how the engine stopped, conditions when the engine was restarted, etc.) as a reference. Symptom Suspected Area Engine vibration occurs and engine stops Air-fuel ratio abnormal Engine stops with no engine vibration Ignition system, injection stoppage, high load from external parts Engine can be started with accelerator pedal depressed Insufficient air volume Rough idling after engine started Air-fuel ratio abnormal, abnormal combustion
4. Read freeze frame data using the Techstream. Freeze frame data records engine conditions when a malfunction occurs. This information can be useful when troubleshooting.
5. When confirming the freeze frame data, be sure to check all 5 sets of freeze frame data. Refer to «FREEZE FRAME DATA [01/2014 - ]»(ref-615120-S38415834072014050900000) .
6. When DTC P1603 (Engine Stall History) is stored, DTC P1605 (Rough Idling) is also stored. When confirming freeze frame data, check DTC P1605. The ECM stores DTC P1605 first. Therefore, 5 sets of freeze frame data can be confirmed through DTC P1605, enabling the technician to obtain more information.
7. When confirming freeze frame data, if there are multiple items related to the cause of the malfunction, perform troubleshooting for all related items.
8. Try to operate the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and the data when the engine is idling (engine warmed up, no load, and shift lever in D or N) and compare these data with the freeze frame data.
9. Inspections take into account the fact that the malfunction may not have reoccurred and place emphasis on checking the vehicle conditions present at the time when the malfunction occurred.
10. When performing inspections, jiggle the relevant wire harnesses and connectors in an attempt to reproduce malfunctions that do not always occur.

Inspection flow

Using freeze frame data, narrow down the parts to be inspected according to the vehicle conditions at the time when the malfunction occurred.

P1603

1

1. If the engine stalled when the intake air volume was low (during idling or deceleration), there may be a decrease in torque due to an incorrect air-fuel ratio, etc.
2. If the engine stalled when the intake air volume was high (during driving or acceleration), there may be a major malfunction such as continuous misfire due to ignition stoppage, fuel injection stoppage, etc. and the torque drops to zero.

2

1. If the engine speed decreased slowly, there may have been a decrease in torque due to an air-fuel ratio that was incorrect (by approximately 20 to 30%), etc.
2. If the engine speed decreased rapidly, there may have been a malfunction such as when the engine misfires almost continuously due to ignition stoppage, fuel injection stoppage, etc., or when the external load increases due to an external part malfunctioning.

3

1. If the air-fuel ratio is abnormal, there may have been an intake air leak, sensor malfunction, or fuel supply problem.
2. If the vehicle was normal, the air volume may have been insufficient or the ignition timing may have been incorrect.

P1603 inspection flow: Narrow down the parts to be inspected according to the vehicle conditions at the time when the malfunction occurred (freeze frame data).

*: If the engine stalls immediately after the injection method is switched from port injection to direct injection, the injector driver may be malfunctioning.

P1605

1

1. If the engine speed decreased slowly, there may have been a decrease in torque due to an air-fuel ratio that was incorrect (by approximately 20 to 30%), etc.
2. If the engine speed decreased rapidly, there may have been a malfunction such as when the engine misfires almost continuously due to ignition stoppage, fuel injection stoppage, etc., or when the external load increases due to an external part malfunctioning.

2

1. If the air-fuel ratio is abnormal, there may have been an intake air leak, sensor malfunction, or fuel supply problem.
2. If the vehicle was normal, the air volume may have been insufficient or the ignition timing may have been incorrect.

P1605 inspection flow: Narrow down the parts to be inspected according to the vehicle conditions at the time when the malfunction occurred (freeze frame data).

*: If the engine stalls immediately after the injection method is switched from port injection to direct injection, the injector driver may be malfunctioning.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

1. In contrast to normal malfunction diagnosis for components, circuits and systems, DTC P1604 is used to determine the malfunctioning area from the problem symptoms and freeze frame data when the user mentions problems such as starting difficulty. As these DTCs can be stored as a result of certain user actions, even if these DTCs are output, if the customer makes no mention of problems, clear these DTCs without performing any troubleshooting and return the vehicle to the customer.
2. If any other DTCs are output, perform troubleshooting for those DTCs first.
3. When the Data List item "Immobilizer Fuel Cut" is ON, the engine cannot be started.
4. Read freeze frame data using the Techstream. Freeze frame data records engine conditions when a malfunction occurs. This information can be useful when troubleshooting.
5. When confirming the freeze frame data, be sure to check all 5 sets of freeze frame data. Refer to «FREEZE FRAME DATA [05/2013 - 01/2014]»(ref-615120-S31308559972014050900000) .
6. When confirming freeze frame data, if there are multiple items related to the cause of the malfunction, perform troubleshooting for all related items.
7. Try to start the vehicle under the conditions recorded in the freeze frame data which were present when the malfunction occurred. Confirm the data at this time and compare it with the freeze frame data.
8. If the malfunction does not reoccur, carefully check the vehicle conditions from when the malfunction occurred using freeze frame data.
9. When performing inspections, jiggle the relevant wire harnesses and connectors in an attempt to reproduce malfunctions that do not always occur.
10. If the same inspection or replacement procedure appears 2 times when performing an inspection procedure, it is not necessary to repeat the procedure the second time.

Scheme 220

Scheme 221

Scheme 222

1. Malfunction Recurrence and Inspection Areas Freeze frame data exists, but the malfunction (starting difficulty) has not reoccurred and the malfunction conditions are unknown. The engine speed recorded in the freeze frame data is 0 rpm (the engine does not crank). HINT: One of the following problems may be present: battery depletion, excess engine friction, a starter malfunction or a crankshaft position sensor malfunction. If the battery voltage is less than 6 V during cranking, there is a high probability that engine friction is abnormal. If the battery voltage drops to 5 V or less when starting the engine, the battery may be malfunctioning. If the battery voltage fluctuates while cranking the engine, it can be concluded that cranking is being performed. When the engine speed is 0 rpm, the crankshaft position sensor and/or ECM may be malfunctioning. All engine speeds recorded in the freeze frame data are between 100 and 250 rpm (the engine cranks but there is no combustion). HINT: If the engine speed is between 100 and 250 rpm (no initial combustion), there may be a wiring problem or a complete failure of an ignition or fuel system part. Due to an engine coolant temperature sensor malfunction, the fuel injection volume is extremely high or low and the engine may not be able to be started. The engine speed recorded in the freeze frame data is 250 rpm or higher (the initial combustion and starter turnoff timing is too late). HINT: If the engine speed is 250 rpm or higher (combustion occurs but the initial combustion and starter turnoff timing is too late), the fuel injection volume is often incorrect (too low or too high) and determining the cause of the malfunction is often difficult. Due to an engine coolant temperature sensor malfunction, the fuel injection volume is extremely high or low and engine starting trouble may occur. If Long FT is incorrect, there may be a fuel supply problem due to the injectors or fuel pump being clogged, etc. If the engine cranking speed is too high, compression loss may have occurred due to carbon interfering with the valve operation. When the malfunction (starting difficulty) can be reproduced, or malfunction conditions are known, perform the following inspections ("Problem Symptoms" and "Systems to Inspect"). Problem Symptoms The engine does not crank. HINT: The starter is normal if a noise that indicates the starter pinion gear is extending is heard. The battery may be fully depleted or there may be excess engine friction. The engine cranking speed is abnormal. HINT: If the engine cranking speed is too high (for example, 300 rpm or higher with no combustion), compression loss may have occurred because carbon interfered with valve operation, etc. There is no initial combustion. HINT: If there is no initial combustion, there is probably a wiring problem or an ignition or fuel system part malfunction. The engine stalls after starter turnoff. HINT: If the engine stalls after starter turnoff, the air-fuel ratio may be incorrect or the VVT may have a problem returning. The initial combustion and starter turnoff occur late. HINT: If the initial combustion and starter turnoff occur late, the fuel injection volume is probably incorrect (too low or too high). HINT: Causes of fuel system malfunctions according to conditions present at the time of the malfunction. When 2 to 3 minutes have elapsed after stopping the engine: Fuel pressure loss due to the pressure regulator failing to maintain the fuel pressure. When 15 to 120 minutes have elapsed after stopping the engine: Problem with injector fuel seal. When a long time has elapsed after stopping the engine: Pressure regulator is stuck open. Systems to Inspect Intake system Ignition system Fuel system
2. INSPECTION FLOW Freeze frame data exists, but the malfunction (starting difficulty) has not reoccurred and the malfunction conditions are unknown. Freeze Frame Data Item Result Suspected Area Procedure Engine Speed 0 rpm (no engine cranking at all) Battery fully depleted Engine assembly (excess friction) Starter assembly Engine immobilizer system Crankshaft position sensor ECM 4 to 9 100 to 250 rpm (engine cranks but no initial combustion*1) Fuel pump control circuit Ignition system Engine coolant temperature sensor Fuel injection system 10 to 14 250 rpm or higher (combustion occurs but initial combustion and starter turnoff*2 occur late) Engine assembly (compression loss) Fuel injection system Fuel pump control circuit 15 to 23 HINT: *1: First combustion after cranking begins. *2: Condition when engine speed increases and starter can be turned off. When the malfunction (starting difficulty) can be reproduced, or when malfunction conditions are known. Problem Symptoms Problem Symptom Suspected Area Suspected Component Procedure The engine does not crank Battery malfunction Battery fully depleted 26 to 31 Starting system Starter assembly (includes pinion gear wear or tooth damage) Starting system Engine immobilizer system Engine immobilizer system Engine assembly Engine assembly (excess friction) Drive plate wear or tooth damage Cranking speed too low Battery malfunction Battery fully depleted 32 to 34 Starting system Starter assembly Engine assembly Engine assembly (excess friction) Cranking speed too high Engine assembly Engine assembly (compression loss) There is no initial combustion Fuel supply problem Cannot maintain pressure due to pressure regulator malfunction Fuel injector leak Fuel leak from fuel line Fuel pump control circuit Fuel pump 35 to 50 Ignition system malfunction Spark plug Crankshaft position sensor Ignition coil assembly Engine stalls after starter turnoff Air suction Intake system connections 51 to 57 Deposits in throttle body Throttle with motor body assembly VVT valve does not return properly Camshaft timing oil control valve assembly Mass air flow meter malfunction Mass air flow meter The initial combustion and starter turnoff occur late Engine coolant temperature sensor malfunction Engine coolant temperature sensor 58 to 71 Mass air flow meter malfunction Mass air flow meter Abnormal A/F learned value Air fuel ratio sensor Deviation from fuel injection characteristics Fuel injector assembly Wet-fouled or dry-fouled spark plug Spark plug Lack of fuel pressure Pressure regulator Fuel pump Fuel pump control circuit Systems to Inspect Troubleshooting by System Suspected Area Suspected Component Procedure Fuel system troubleshooting A Abnormal A/F learned value Fuel injector assembly 87 to 94 95 to 102 Rough idling Crankshaft position sensor Abnormal fuel pressure Fuel Fuel leak from fuel line Fuel pump Pressure regulator Fuel system troubleshooting B Abnormal concentration of HC in surge tank Purge VSV system Fuel injector assembly Intake valve 103 to 105 Fuel system troubleshooting C Injection signal system malfunction Fuel injector assembly Crankshaft position sensor Camshaft position sensor ECM 73 to 77 Intake system troubleshooting Difference between ISC target value and opening angle when idling Engine assembly (compression loss) Valve timing Engine coolant temperature sensor ECM 84 to 86 106 to 108 Ignition system troubleshooting Camshaft and/or crankshaft position sensor signal malfunction Crankshaft position sensor system (including sensor installation) Camshaft position sensor system (including sensor installation) ECM 78 to 83 109 to 114

Scheme 223

1. CHECK FOR ANY OTHER DTCS OUTPUT AND RECORD FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs and record the freeze frame data. HINT: This freeze frame data shows the actual engine conditions when engine starting trouble occurred. When confirming the freeze frame data, be sure to check all 5 data sets of freeze frame data. The fourth set of freeze frame data is the data recorded when the DTC is stored. RESULT Result Proceed to Only DTC P1604 is output A DTCs other than P1604 are output B B --> See step 115 A: Go to next step
2. CHECK ENGINE IMMOBILIZER SYSTEM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Immobilizer Fuel Cut. Read the value displayed on the Techstream. OK Immobilizer Fuel Cut is OFF. HINT: After reconnecting the battery cable, if the engine is started immediately (without waiting 1.8 seconds after turning the ignition switch to ON), the engine will stop (due to the key verification process). The engine can be started after that. RESULT Result Result OK A NG (w/ Smart Key System) B NG (w/o Smart Key System) C B --> See step 116 C --> See step 184 A: Go to next step
3. CHECK MALFUNCTION CONDITION Confirm the problem symptoms. RESULT Result Proceed to Freeze frame data exists, but the starting difficulty cannot be reproduced and it is unknown what kind of starting difficulty occurred A The problem symptoms can be reproduced, or the malfunction conditions are known B B --> See step 25 A: Go to next step
4. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [05/2013 - 01/2014]»(ref-615120-S31308559972014050900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to Engine Speed Battery Voltage All 5 sets of freeze frame data are 0 rpm (no engine cranking at all) Minimum voltage is below 5 V Battery fully depleted A Minimum voltage is 5 V or higher Starter malfunction Crankshaft position sensor system Excess engine friction Engine immobilizer system ECM B 60 to 250 rpm (engine cranks but no initial combustion) - Fuel pump control circuit Ignition system Engine coolant temperature sensor Engine immobilizer system Fuel injection system C 250 rpm or higher (combustion occurs but initial combustion and starter turnoff occur late) - Engine assembly Fuel injection system Fuel pump control circuit D HINT: When DTC P1604 is stored, either "Engine Start Hesitation"*1 or "Low Rev for Eng Start"*2 in the freeze frame data will be ON. If "Low Rev for Eng Start" is ON, proceed to E. *1: This value turns ON when the engine speed does not reach a certain value for a certain period of time when starting the engine. *2: This value turns ON when the engine stalls immediately after starting the engine. If "Low Rev for Eng Start" is ON, as there is a possibility that the low engine speed or engine stall was caused by the user, confirm the following freeze frame data items. Immobilizer Fuel Cut Engine Speed (Starter Off) Shift SW Status (R, D Range) B --> See step 5 C --> See step 10 D --> See step 15 E --> See step 51 A --> CHARGE OR REPLACE BATTERY
5. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [05/2013 - 01/2014]»(ref-615120-S31308559972014050900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Battery Voltage Minimum voltage is 6 V or higher and voltage does not fluctuate*1 Starter system A Minimum voltage is 6 V or higher and voltage fluctuates*2, *3 Crankshaft position sensor system ECM B Minimum voltage is 5 to 6 V*4 Excess engine friction Battery fully depleted C HINT: *1: The 5 sets of freeze frame data show approximately the same battery voltage. *2: The 5 sets of freeze frame data show different battery voltages. *3: If the voltage fluctuates, it can be determined that cranking is being performed. When the engine speed is 0 rpm, the crankshaft position sensor system and/or the ECM may be malfunctioning. *4: There may be excess engine friction. Make sure that the crankshaft rotates smoothly when turning it by hand. Excess engine friction may have occurred temporarily. Remove the cylinder head cover and oil pan, and check for foreign matter such as iron fragments. If there is a malfunction or signs of a malfunction present, perform a detailed inspection by disassembling all the parts. Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 6 C --> CHECK AND REPAIR ENGINE OR BATTERY A --> See step 117
6. CHECK CRANKSHAFT POSITION SENSOR (SENSOR INSTALLATION) Check the tightening and installation condition of the crankshaft position sensor bolt. Check the connection of the crankshaft position sensor connector. RESULT Result Proceed to Normal A Abnormal B B --> See step 118 A: Go to next step
7. CHECK CRANKSHAFT POSITION SENSOR Disconnect the crankshaft position sensor connector. Check for oil on the connector terminals. OK No oil on the terminals. NG --> See step 119 OK: Go to next step
8. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Disconnect the crankshaft position sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B15-1 - B30-74 (NE+) Always Below 1 ohms B15-2 - B30-120 (NE-) Always Below 1 ohms B15-1 or B30-74 (NE+) - Body ground Always 10 kohms or higher B15-2 or B30-120 (NE-) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
9. CHECK CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S03430781602014050900000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 120 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
10. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [05/2013 - 01/2014]»(ref-615120-S31308559972014050900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to Coolant Temp, Ambient Temp for A/C, Intake Air Coolant Temp, Ambient Temp for A/C Fuel Pump Duty Difference between Coolant Temp, Ambient Temp for A/C and Intake Air is 10°C or more*1 Coolant Temp is 125°C or higher, or below Ambient Temp for A/C by 15°C or more - Engine coolant temperature sensor A Other than above No sets of freeze frame data are 0% - B At least 1 of the 5 sets of freeze frame data is 0% Fuel pump control circuit C Difference between Coolant Temp, Ambient Temp for A/C and Intake Air is less than 10°C*2 - At least 1 of the 5 sets of freeze frame data is 0% Fuel pump control circuit C No sets of freeze frame data are 0% - B HINT: *1: A long time had not elapsed after stopping the engine. *2: A long time had elapsed after stopping the engine. B --> See step 11 C --> See step 122 A --> See step 121
11. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for an operating sound from the fuel pump. OK Control the Fuel Pump / Speed Specified Condition ON Operating sound heard OFF Operating sound not heard HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. NG --> See step 123 OK: Go to next step
12. CHECK TERMINAL VOLTAGE (FUEL INJECTOR POWER SOURCE) Disconnect the fuel injector assembly connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Cylinder Tester Connection Switch Condition Specified Condition No. 1 B10-1 - Body ground Ignition switch ON 11 to 14 V No. 2 B11-1 - Body ground Ignition switch ON 11 to 14 V No. 3 B12-1 - Body ground Ignition switch ON 11 to 14 V No. 4 B13-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 179 OK: Go to next step
13. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for fuel leakage from the fuel pipes. RESULT Result Proceed to Fuel leakage or signs of fuel leakage are present A No fuel leakage or signs of fuel leakage B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When performing the Active Test, if there is no operating noise from the fuel pump, the fuel pump system may be malfunctioning. Check if the vehicle ran out of fuel, as engine starting trouble due to running out of fuel is also detected. B --> See step 14 A --> REPAIR OR REPLACE FUEL LINE
14. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump (fuel pump, fuel pump filter, and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is foreign matter or signs that fuel pump was stuck A There is no foreign matter and no signs that fuel pump was stuck B B --> See step 24 A --> REPAIR OR REPLACE FUEL SYSTEM
15. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [05/2013 - 01/2014]»(ref-615120-S31308559972014050900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to Coolant Temp, Ambient Temp for A/C, Intake Air Coolant Temp, Ambient Temp for A/C Long FT Engine Speed Difference between Coolant Temp, Ambient Temp for A/C and Intake Air is 10°C or more Coolant Temp is 125°C or higher, or below Ambient Temp for A/C by 15°C or more - - Engine coolant temperature sensor A Other than above -15% or less, or +15% or more - Fuel pump control circuit Fuel injector assembly B -15 to +15% Minimum speed is 300 rpm or more*1 Engine assembly C Minimum speed is less than 300 rpm Fuel system Intake air system D Difference between Coolant Temp, Ambient Temp for A/C and Intake Air is less than 10°C - -15% or less, or +15% or more - Fuel pump control circuit Fuel injector assembly B -15 to +15% Minimum speed is 300 rpm or more*1 Engine assembly C Minimum speed is less than 300 rpm Fuel system Intake air system D HINT: *1: Compression loss may have occurred in the engine assembly. Perform "Inspection After Repair" after replacing the engine coolant temperature sensor or engine assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 16 C --> CHECK AND REPAIR ENGINE D --> See step 18 A --> See step 124
16. INSPECT FUEL INJECTOR ASSEMBLY Check that no carbon is stuck to the fuel injector assembly. OK No carbon present. HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 125 OK: Go to next step
17. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump (fuel pump, fuel pump filter, and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is foreign matter or signs that fuel pump was stuck A There is no foreign matter and no signs that fuel pump was stuck B B --> See step 24 A --> REPAIR OR REPLACE FUEL SYSTEM
18. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [05/2013 - 01/2014]»(ref-615120-S31308559972014050900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Coolant Temp Engine coolant temperature is 40°C or less*1 Pressure regulator A Engine coolant temperature is 40 to 90°C*2 Fuel injector B Engine coolant temperature is 90°C or higher*3 Pressure regulator A HINT: *1: If the engine coolant temperature is 40°C or less (after stopping the engine and the vehicle has not been driven for a long period of time), the pressure regulator may be stuck open. Attach a fuel pressure gauge and check the ability of the system to maintain fuel pressure after stopping the engine. *2: If the engine coolant temperature is 40 to 90°C (15 to 120 minutes have passed after stopping the engine), there may be fuel leaking from a fuel injector. *3: If the engine coolant temperature is 90°C or more (2 to 5 minutes have passed after stopping the engine), there may be a problem with the pressure regulator failing to maintain the fuel pressure. Attach a fuel pressure gauge and check the ability of the pressure regulator to maintain fuel pressure after stopping the engine. B --> See step 20 A: Go to next step
19. CHECK FUEL PRESSURE HINT: For the fuel pressure inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [05/2013 - 01/2014] - Step 2»(ref-615250-S34834712852014050900000) . Attach a fuel pressure gauge and check the fuel pressure after stopping the engine. Standard 147 kPa (1.5 kgf/cm 2 ) or higher (5 minutes after stopping the engine) HINT: If the engine cannot be started, read the values after cranking the engine. RESULT Result Proceed to Normal A Abnormal B A --> See step 24 B --> See step 175
20. CHECK FUEL INJECTOR ASSEMBLY Clean the inside of the surge tank with compressed air. After stopping the engine, measure the HC concentration inside the surge tank for 15 minutes. RESULT Result Proceed to 4000 ppm or more A Less than 4000 ppm B HINT: If the concentration is 4000 ppm or more, a fuel injector assembly may have a sealing problem. B --> See step 22 A: Go to next step
21. CHECK FUEL INJECTOR ASSEMBLY Inspect the fuel injector assemblies. Refer to «INSPECTION [05/2013 - ]»(ref-615244-S28235590902014050900000) . RESULT Result Proceed to Abnormal A Normal B HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 22 A --> See step 176
22. CHECK THROTTLE WITH MOTOR BODY ASSEMBLY Check if carbon is in the airflow passage. RESULT Result Proceed to Carbon in passage A No carbon present B HINT: Perform "Inspection After Repair" after cleaning or replacing the throttle with motor body assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 23 A --> See step 126
23. CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615245-S05242304412014050900000) . OK No leaks in intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the c system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
24. PERFORM SIMULATION TEST Check if the engine can be started. RESULT Result Proceed to Engine can be started A Engine cannot be started B B --> See step 25 A --> END
25. CONFIRM PROBLEM SYMPTOM Confirm the problem symptoms. HINT: The problem symptoms below can be determined by reading the freeze frame data. RESULT Problem Symptom Suspected Area Proceed to The engine does not crank Battery fully depleted Starter assembly (includes pinion gear wear or tooth damage) Starter system Engine assembly (excess friction) Drive plate wear or tooth damage A Abnormal cranking speed Battery fully depleted Starter assembly Engine assembly (excess friction, compression loss) B There is no initial combustion (combustion does not occur even once)*1 Pressure regulator fuel pressure maintenance Fuel injector leak Fuel leak from fuel line Fuel pump control circuit Fuel pump Spark plug Crankshaft position sensor system Ignition coil system C The engine stalls after starter turnoff (engine stalls immediately after the first time the engine speed increases)*2 Intake system connections throttle with motor body assembly Camshaft timing oil control valve assembly Mass air flow meter system D The initial combustion and starter turnoff occur late*3 Engine coolant temperature sensor Mass air flow meter Air fuel ratio sensor Heated oxygen sensor Fuel injector assembly Spark plug Pressure regulator Fuel pump Fuel pump control circuit E HINT: If there is hesitation (cranking speed is slow and combustion occurs before passing TDC) during the initial cranking period, the battery charge may be insufficient or the starter may be malfunctioning. *1: If there is no initial combustion, a wire harness may be malfunctioning, or the ignition or fuel system may be malfunctioning. *2: If the engine stalls after starter turnoff, the air-fuel ratio may be incorrect or the camshaft timing oil control valve assembly may have a problem returning. *3: If the initial combustion and starter turnoff occur late, the fuel injection volume may be incorrect (too low or too high). B --> See step 32 C --> See step 35 D --> See step 51 E --> See step 58 A: Go to next step
26. PERFORM SIMULATION TEST When cranking the engine, check for a noise indicating that the starter pinion gear is extending, and check that the starter pinion gear is not spinning freely. RESULT Problem Symptom Suspected Area Proceed to A noise indicating that the starter pinion gear is extending is heard and the starter pinion gear is not spinning freely*1 Battery Excess engine friction Starter assembly A A noise indicating that the starter pinion gear is extending is heard but the starter pinion gear is spinning freely Drive plate Starter assembly B A noise indicating that the starter pinion gear is extending is not heard Battery Starter assembly Starter system C HINT: *1: The battery may be fully depleted or there may be excess engine friction. B --> See step 29 C --> See step 30 A: Go to next step
27. INSPECT BATTERY Check the electrolyte quantity. OK Electrolyte quantity is within the specified range. Inspect the specific gravity. Inspect the specific gravity of each cell. Standard specific gravity 1.25 to 1.29 (electrolyte is at 20°C (68°F)) HINT: If the result is not as specified, recharge or replace the battery. It is not necessary to inspect a maintenance-free battery. Inspect the battery voltage. Turn the ignition switch off and turn on the headlights for 20 to 30 seconds. This will remove the surface charge from the battery. Measure the battery voltage. Standard voltage 12.5 to 12.9 V (electrolyte is at 20°C (68°F)) HINT: If the result is not as specified, recharge or replace the battery. Measure the battery voltage when cranking the engine. Standard Approximately 6 V or higher (0°C (32°F) or higher) HINT: When the battery is depleted, the horn becomes quieter. NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
28. CHECK ENGINE ASSEMBLY Check that the crankshaft rotates smoothly when rotating it by hand. OK Crankshaft rotates smoothly. HINT: Excess engine friction may have occurred temporarily. Remove the cylinder head cover and oil pan, and check for foreign matter such as iron fragments. If there is a malfunction or signs of a malfunction present, perform a detailed inspection by disassembling all the parts. Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> REPAIR OR REPLACE ENGINE ASSEMBLY OK --> See step 127
29. CHECK STARTER ASSEMBLY Remove the starter. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615241-S20808113982014050900000) . Check for starter pinion gear wear and damage. OK There is no wear or damage. NG --> See step 129 OK --> See step 128
30. INSPECT BATTERY Check the electrolyte quantity. OK Electrolyte quantity is within the specified range. Inspect the specific gravity. Inspect the specific gravity of each cell. Standard specific gravity 1.25 to 1.29 (electrolyte is at 20°C (68°F)) HINT: If the result is not as specified, recharge or replace the battery. It is not necessary to inspect a maintenance-free battery. Inspect the battery voltage. Turn the ignition switch off and turn on the headlights for 20 to 30 seconds. This will remove the surface charge from the battery. Measure the battery voltage. Standard voltage 12.5 to 12.9 V (electrolyte is at 20°C (68°F)) HINT: If the result is not as specified, recharge or replace the battery. Measure the battery voltage when cranking the engine. Standard Approximately 6 V or higher (0°C (32°F) or higher) HINT: When the battery is depleted, the horn becomes quieter. NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
31. INSPECT STARTER ASSEMBLY Inspect the starter. Refer to «INSPECTION [05/2013 - 01/2014]»(ref-615241-S39340577512014050900000) . NG --> See step 131 OK --> See step 130
32. PERFORM SIMULATION TEST Check the cranking speed. RESULT Problem Symptom Suspected Area Proceed to Cranking speed is slow (100 rpm or less) Battery Starter assembly Excess engine friction A Cranking speed is fast (300 rpm or more)* Engine compression loss B HINT: *: If the cranking speed is fast, there may be compression loss. Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> CHECK AND REPAIR ENGINE ASSEMBLY A: Go to next step
33. INSPECT BATTERY Check the electrolyte quantity. OK Electrolyte quantity is within the specified range. Inspect the specific gravity. Inspect the specific gravity of each cell. Standard specific gravity 1.25 to 1.29 (electrolyte is at 20°C (68°F)) HINT: If the result is not as specified, recharge or replace the battery. It is not necessary to inspect a maintenance-free battery. Inspect the battery voltage. Turn the ignition switch off and turn on the headlights for 20 to 30 seconds. This will remove the surface charge from the battery. Measure the battery voltage. Standard voltage 12.5 to 12.9 V (electrolyte is at 20°C (68°F)) HINT: If the result is not as specified, recharge or replace the battery. Measure the battery voltage when cranking the engine. Standard Approximately 6 V or higher (0°C (32°F) or higher) HINT: When the battery is depleted, the horn becomes quieter. NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
34. CHECK ENGINE ASSEMBLY Check that the crankshaft rotates smoothly when rotating it by hand. OK Crankshaft rotates smoothly. HINT: Excess engine friction may have occurred temporarily. Remove the cylinder head cover and oil pan, and check for foreign matter such as iron fragments. If there is a malfunction or signs of a malfunction present, perform a detailed inspection by disassembling all the parts. Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> REPAIR OR REPLACE ENGINE ASSEMBLY OK --> See step 132
35. CHECK FUEL INJECTOR ASSEMBLY Using a sound scope or screwdriver, check for fuel injector operating noise while cranking the engine. OK Fuel injector operating noise is heard. NG --> See step 48 OK: Go to next step
36. CHECK FUEL PRESSURE Inspect the fuel pressure. Refer to «ON-VEHICLE INSPECTION [05/2013 - 01/2014] - Step 2»(ref-615250-S34834712852014050900000) . NG --> See step 46 OK: Go to next step
37. CHECK SPARK PLUG AND SPARK Check for sparks. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615243-S15300027832014050900000) . NG --> See step 41 OK: Go to next step
38. CONFIRM VEHICLE CONDITION Confirm the conditions present when the malfunction occurred based on the customer problem analysis. RESULT Problem Symptom Suspected Area Proceed to When the engine is stopped and a long time has passed, engine starting trouble occurs*1 Pressure regulator is stuck open A When the engine is stopped and approximately 15 to 120 minutes have passed, engine starting trouble occurs*2 Fuel injector leak B When the engine is stopped and approximately 2 to 3 minutes have passed, engine starting trouble occurs*3 Failure to maintain fuel pressure by pressure regulator A Condition other than above, or there is an inconsistency in the conditions present when engine starting trouble occurs - C*4 HINT: *1: The pressure regulator may be stuck open. Attach a fuel pressure gauge and check the ability of the system to maintain fuel pressure after stopping the engine. *2: Fuel may be leaking from a fuel injector assembly. *3: The pressure regulator may not be able to maintain the fuel pressure. Attach a fuel pressure gauge and check the ability of the pressure regulator to maintain fuel pressure after stopping the engine. *4: From step 72, perform fuel system troubleshooting C (steps 73 to 77). B --> See step 40 C --> See step 72 A: Go to next step
39. CHECK FUEL PRESSURE HINT: For the fuel pressure inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [05/2013 - 01/2014] - Step 2»(ref-615250-S34834712852014050900000) . Attach a fuel pressure gauge and check the fuel pressure after stopping the engine. RESULT Result Proceed to 147 kPa (1.5 kgf/cm 2 ) or higher (5 minutes after stopping the engine) A*1 Below 147 kPa (1.5 kgf/cm 2 ) (5 minutes after stopping the engine) B HINT: If the engine cannot be started, check the fuel pressure after cranking the engine. *1: From step 72, perform fuel system troubleshooting C (steps 73 to 77). A --> See step 72 B --> See step 133
40. CHECK FUEL INJECTOR ASSEMBLY After stopping the engine, measure the HC concentration inside the surge tank for 15 minutes. RESULT Result Proceed to 4000 ppm or more A Less than 4000 ppm B*1 HINT: If the concentration is 4000 ppm or more, a fuel injector assembly may have a sealing problem. *1: From step 72, perform fuel system troubleshooting C (steps 73 to 77). Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 72 A --> See step 134
41. CHECK SPARK PLUG Inspect the spark plugs. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 3»(ref-615243-S15300027832014050900000) . HINT: Even if the spark plug of only one cylinder is malfunctioning, replace the spark plugs of all cylinders. Perform "Inspection After Repair" after replacing the spark plug. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 135 OK: Go to next step
42. READ VALUE USING TECHSTREAM (ENGINE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / Engine Speed. Start the engine. While running the engine, read the value of Engine Speed. OK A value that matches the actual engine speed is constantly output. HINT: Check the engine speed using a line graph. If the engine cannot be started, check the engine speed while cranking the engine. If the engine speed is 0 rpm, the crankshaft position sensor may have an open or short circuit. NG --> See step 136 OK: Go to next step
43. CHECK TERMINAL VOLTAGE (IGNITION COIL POWER SOURCE) Disconnect the ignition coil assembly connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B26-1 (+B) - B26-4 (GND) Ignition switch ON 11 to 14 V B27-1 (+B) - B27-4 (GND) Ignition switch ON 11 to 14 V B28-1 (+B) - B28-4 (GND) Ignition switch ON 11 to 14 V B29-1 (+B) - B29-4 (GND) Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Ignition Coil Assembly) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 137 OK: Go to next step
44. CHECK HARNESS AND CONNECTOR (IGNITION COIL ASSEMBLY - ECM) Disconnect the ignition coil assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B26-2 (IGF) - B30-23 (IGF1) Always Below 1 ohms B27-2 (IGF) - B30-23 (IGF1) Always Below 1 ohms B28-2 (IGF) - B30-23 (IGF1) Always Below 1 ohms B29-2 (IGF) - B30-23 (IGF1) Always Below 1 ohms B26-2 (IGF) or B30-23 (IGF1) - Body ground Always 10 kohms or higher B27-2 (IGF) or B30-23 (IGF1) - Body ground Always 10 kohms or higher B28-2 (IGF) or B30-23 (IGF1) - Body ground Always 10 kohms or higher B29-2 (IGF) or B30-23 (IGF1) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
45. CHECK HARNESS AND CONNECTOR (IGNITION COIL ASSEMBLY - ECM) Disconnect the ignition coil assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B26-3 (IGT1) - B30-108 (IGT1) Always Below 1 ohms B27-3 (IGT2) - B30-107 (IGT2) Always Below 1 ohms B28-3 (IGT3) - B30-106 (IGT3) Always Below 1 ohms B29-3 (IGT4) - B30-105 (IGT4) Always Below 1 ohms B26-3 (IGT1) or B30-108 (IGT1) - Body ground Always 10 kohms or higher B27-3 (IGT2) or B30-107 (IGT2) - Body ground Always 10 kohms or higher B28-3 (IGT3) or B30-106 (IGT3) - Body ground Always 10 kohms or higher B29-3 (IGT4) or B30-105 (IGT4) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. If the wire harness is normal, after replacing the ignition coil assembly, check if engine starting trouble occurs again. If engine starting trouble occurs again, proceed to step 72 and perform troubleshooting for the ignition system (steps 78 to 83). Perform "Inspection After Repair" after replacing the ignition coil assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 138
46. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for an operating sound from the fuel pump. OK Control the Fuel Pump / Speed Specified Condition ON Operating sound heard OFF Operating sound not heard HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. NG --> See step 139 OK: Go to next step
47. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for fuel leakage from the fuel pipes. RESULT Result Proceed to Fuel leakage or signs of fuel leakage are present A No fuel leakage or signs of fuel leakage B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Check if the vehicle ran out of fuel, as engine starting trouble due to running out of fuel is also detected. If there are no fuel leaks, after inspecting the fuel pump control circuit, check if engine starting trouble occurs again. If engine starting trouble occurs again, proceed to step 72 and perform fuel system troubleshooting C (steps 73 to 77). B --> See step 140 A --> REPAIR OR REPLACE FUEL LINE
48. READ VALUE USING TECHSTREAM (ENGINE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / Engine Speed. Start the engine. While running the engine, read the value of Engine Speed. OK A value that matches the actual engine speed is constantly output. HINT: Check the engine speed using a line graph. If the engine cannot be started, check the engine speed while cranking the engine. If the engine speed is 0 rpm, the crankshaft position sensor may have an open or short circuit. NG --> See step 141 OK: Go to next step
49. CHECK TERMINAL VOLTAGE (FUEL INJECTOR POWER SOURCE) Disconnect the fuel injector assembly connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Cylinder Tester Connection Switch Condition Specified Condition No. 1 B10-1 - Body ground Ignition switch ON 11 to 14 V No. 2 B11-1 - Body ground Ignition switch ON 11 to 14 V No. 3 B12-1 - Body ground Ignition switch ON 11 to 14 V No. 4 B13-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 180 OK: Go to next step
50. CHECK HARNESS AND CONNECTOR (FUEL INJECTOR ASSEMBLY - ECM) Disconnect the fuel injector assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Cylinder Tester Connection Condition Specified Condition No. 1 B10-2 - Body ground Always 10 kohms or higher B10-2 - B30-85 (#10) Always Below 1 ohms No. 2 B11-2 - Body ground Always 10 kohms or higher B11-2 - B30-84 (#20) Always Below 1 ohms No. 3 B12-2 - Body ground Always 10 kohms or higher B12-2 - B30-83 (#30) Always Below 1 ohms No. 4 B13-2 - Body ground Always 10 kohms or higher B13-2 - B30-82 (#40) Always Below 1 ohms HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 158
51. CHECK MASS AIR FLOW METER Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off, and the shift lever should be in N or P. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / MAF. Check MAF in the Data List during idling. Standard 2.1 to 3.1 gm/sec NG --> See step 57 OK: Go to next step
52. CHECK AIR INDUCTION SYSTEM Check for air leakage in the intake system [vacuum hose disconnection, cracks, damaged gaskets, etc.]. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615245-S05242304412014050900000) . HINT: If the accelerator pedal is released after racing the engine, the inspection is easier to perform because the vacuum inside the intake manifold increases and the air suction noise becomes louder. If Short FT and Long FT are largely different from the normal values (differ by more than 15%) when idling (intake air volume is small) and almost the same as the normal values when racing the engine (for example, when maintaining a speed of 3000 rpm) (intake air volume is high), air leakage may be present. Perform "Inspection After Repair" after repairing or replacing the c system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . OK There is no air leakage. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
53. CHECK THROTTLE WITH MOTOR BODY ASSEMBLY Disconnect the throttle with motor body assembly connector. HINT: When the connector is disconnected, the vehicle enters fail-safe mode and the throttle valve opening angle is 4 to 7°. Crank the engine and check that it starts. RESULT Result Proceed to Engine starts A Engine does not start B Connect the throttle with motor body assembly connector. HINT: When this inspection is performed, the MIL may illuminate. After finishing the inspection, check and clear DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . B --> See step 55 A: Go to next step
54. CHECK THROTTLE WITH MOTOR BODY ASSEMBLY Check if carbon is in the airflow passage. OK No carbon present. HINT: Perform "Inspection After Repair" after cleaning the throttle with motor body assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> REMOVE FOREIGN OBJECT AND CLEAN THROTTLE WITH MOTOR BODY ASSEMBLY OK: Go to next step
55. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank1). HINT: When performing the Active Test, make sure the A/C is on and the shift lever is in P or N. Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK*1 Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls RESULT Result Proceed to NG A OK B HINT: *1: From step 72, perform intake system troubleshooting (steps 84 to 86). If engine starting trouble still occurs, perform fuel system troubleshooting A (steps 87 to 94). Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. If the camshaft timing oil control valve assembly is stuck on, the valve overlap increases and combustion worsens due to the internal EGR which may cause the engine to stall. B --> See step 56 A --> See step 143
56. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR) Connect the Techstream to the DLC3. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank1). HINT: When performing the Active Test, make sure the A/C is on and the shift lever is in P or N. Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK*1 Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: *1: From step 72, perform intake system troubleshooting (steps 84 to 86). If engine starting trouble still occurs, perform fuel system troubleshooting A (steps 87 to 94). Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. If the camshaft timing oil control valve assembly is stuck on, the valve overlap increases and combustion worsens due to the internal EGR which may cause the engine to stall. OK --> See step 72 NG --> See step 183
57. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-5 (VG) - B30-94 (VG) Always Below 1 ohms B2-4 (E2G) - B30-117 (E2G) Always Below 1 ohms B2-5 (VG) or B30-94 (VG) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. If the wire harness is normal, after replacing the mass air flow meter, check if engine starting trouble occurs again. If engine starting trouble occurs again, proceed to step 72 and perform intake system troubleshooting (steps 84 to 86). If engine starting trouble still occurs, perform fuel system troubleshooting A (steps 87 to 94). Perform "Inspection After Repair" after replacing the mass air flow meter. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 144
58. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION [05/2013 - ]»(ref-615228-S41970993802014050900000) . HINT: If the engine coolant temperature sensor is malfunctioning, after replacing it, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 72 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. NG --> See step 145 OK: Go to next step
59. CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) Disconnect the engine coolant temperature sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B3-2 - B30-64 (THW) Always Below 1 ohms B3-1 - B30-65 (ETHW) Always Below 1 ohms B3-2 or B30-64 (THW) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. If the wire harness or connector is malfunctioning, after replacing or repairing it, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 72 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
60. CHECK MASS AIR FLOW METER Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off, and the shift lever should be in N or P. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / MAF. Check MAF in the Data List during idling. Standard 2.1 to 3.1 gm/sec HINT: If the mass air flow meter is malfunctioning, after replacing it, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 72 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. Perform "Inspection After Repair" after replacing the mass air flow meter. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 146 OK: Go to next step
61. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-5 (VG) - B30-94 (VG) Always Below 1 ohms B2-4 (E2G) - B30-117 (E2G) Always Below 1 ohms B2-5 (VG) or B30-94 (VG) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. If the wire harness or connector is malfunctioning, after replacing or repairing it, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 72 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
62. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / Atmospheric Pressure and Long FT. RESULT Data List Item Result Suspected Area Proceed to Long FT +25% or more or less than -25% Air fuel ratio sensor Heated oxygen sensor Mass air flow meter Fuel injector assembly ECM A Atmosphere Pressure 80 kPa or less (when elevation is 0 m) Both Data List items listed above Values are other than above - B B --> See step 66 A: Go to next step
63. PERFORM SIMULATION TEST Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / Learning Value Reset. Confirm the following conditions as instructed on the screen. Ignition switch ON Engine stopped Battery voltage 9 V or higher After confirming, select "Next" and initialize the learn value. After the Techstream display indicates that the learning value reset is complete, turn the ignition switch off and wait for 5 seconds or more. NOTE: If a message indicating learned value initialization failure is displayed on the screen, confirm the execution conditions, and perform learned value initialization again. Check if the engine can be started. RESULT Result Proceed to Engine can be started A Engine cannot be started B B --> See step 66 A: Go to next step
64. INSPECT AIR FUEL RATIO SENSOR Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Fuel System Status #1. Confirm that Fuel System Status #1 is CL. Enter the following menus: Powertrain / Engine / Data List / AF Lambda B1S1. Confirm that AF Lambda B1S1 is within the range of 0.95 to 1.05 when idling. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F sensor. Read the output voltage from the air fuel ratio sensor when increasing and decreasing the fuel injection volume. Standard Techstream Display Injection Volume Specified Condition AFS Voltage B1S1 +12.5% Air fuel ratio sensor output voltage is below 3.1 V -12.5% Air fuel ratio sensor output voltage is higher than 3.4 V RESULT Result Proceed to Normal A Abnormal B HINT: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the air fuel ratio sensor is malfunctioning, after replacing it, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 72 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 147 A: Go to next step
65. PERFORM SIMULATION TEST Check if the idling speed is stable after starting the engine. OK Speed is stable. HINT: After replacing the fuel injector assembly or mass air flow meter, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 72 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. Perform "Inspection After Repair" after replacing the mass air flow meter or fuel injector assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 149 OK --> See step 148
66. CHECK FUEL PRESSURE Inspect the fuel pressure. Refer to «ON-VEHICLE INSPECTION [05/2013 - 01/2014] - Step 2»(ref-615250-S34834712852014050900000) . NG --> See step 71 OK: Go to next step
67. CHECK SPARK PLUG Inspect the spark plugs. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 3»(ref-615243-S15300027832014050900000) . RESULT Result Proceed to All cylinders are normal A One cylinder is abnormal*1 B All cylinders are abnormal*2, *3 C HINT: *1: If one cylinder is abnormal, replace the spark plug of that cylinder and inspect the ignition and fuel system for that cylinder. After performing repairs, check if engine starting trouble occurs again. If engine starting trouble still occurs, proceed to step 72 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. *2: If all cylinders are abnormal, replace the spark plugs of all cylinders and check if engine starting trouble occurs again. If engine starting trouble still occurs, proceed to step 72 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. *3: Engine starting trouble may occur if the vehicle is driven extremely short distances repeatedly. Perform "Inspection After Repair" after replacing the spark plug. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 150 C --> See step 151 A: Go to next step
68. CONFIRM VEHICLE CONDITION Confirm the conditions present when the malfunction occurred based on the customer problem analysis. RESULT Problem Symptom Suspected Area Proceed to When the engine is stopped and a long time has passed, engine starting trouble occurs*1 Pressure regulator is stuck open A When the engine is stopped and approximately 15 to 120 minutes have passed, engine starting trouble occurs*2 Fuel injector leak B When the engine is stopped and approximately 2 to 3 minutes have passed, engine starting trouble occurs*3 Failure to maintain fuel pressure by pressure regulator A Condition other than above, or there is an inconsistency in the conditions present when engine starting trouble occurs - C*4 HINT: *1: The pressure regulator may be stuck open. Attach a fuel pressure gauge and check the ability of the system to maintain fuel pressure after stopping the engine. *2: Fuel may be leaking from a fuel injector assembly. *3: The pressure regulator may not be able to maintain the fuel pressure. Attach a fuel pressure gauge and check the ability of the pressure regulator to maintain fuel pressure after stopping the engine. *4: From step 72, perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. B --> See step 70 C --> See step 72 A: Go to next step
69. CHECK FUEL PRESSURE HINT: For the fuel pressure inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [05/2013 - 01/2014] - Step 2»(ref-615250-S34834712852014050900000) . Attach a fuel pressure gauge and check the fuel pressure after stopping the engine. RESULT Result Proceed to 147 kPa (1.5 kgf/cm 2 ) or higher (5 minutes after stopping the engine) A*1 Below 147 kPa (1.5 kgf/cm 2 ) (5 minutes after stopping the engine) B HINT: If the engine cannot be started, check the fuel pressure after cranking the engine. *1: From step 72, perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. A --> See step 72 B --> See step 152
70. CHECK FUEL INJECTOR ASSEMBLY Clean the inside of the surge tank with compressed air. After stopping the engine, measure the HC concentration inside the surge tank for 15 minutes. RESULT Result Proceed to 4000 ppm or more A Less than 4000 ppm B*1 HINT: If the concentration is 4000 ppm or more, a fuel injector assembly may have a sealing problem. *1: From step 72, perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 72 A --> See step 153
71. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for fuel leakage from the fuel pipes. RESULT Result Proceed to Fuel leakage or signs of fuel leakage are present A No fuel leakage or signs of fuel leakage B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Check if the vehicle ran out of fuel, as engine starting trouble due to running out of fuel is also detected. If there are no fuel leaks, after inspecting the fuel pump control circuit, check if engine starting trouble occurs again. If engine starting trouble still occurs, proceed to step 72 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. B --> See step 154 A --> REPAIR OR REPLACE FUEL LINE
72. CHECK MALFUNCTION CONDITION If the malfunction could not be identified during the inspections in steps 38, 39, 40 and 47, perform fuel system troubleshooting C (steps 73 to 77). RESULT Performed Step Troubleshooting by System Procedure Proceed to Steps 38, 39, 40 and 47 Fuel system troubleshooting C 73 to 77 A If the malfunction could not be identified during the inspection in step 45, perform ignition system troubleshooting (steps 78 to 83). RESULT Performed Step Troubleshooting by System Procedure Proceed to Step 45 Ignition system troubleshooting 78 to 83 B If the malfunction could not be identified during the inspections in steps 55, 56 and 57, perform intake air system troubleshooting (steps 84 to 86). If engine starting trouble still occurs, perform fuel system troubleshooting A (steps 87 to 94). RESULT Performed Step Troubleshooting by System Procedure Proceed to Step 55, 56, 57 Intake air system troubleshooting 84 to 86 C Fuel system troubleshooting A 87 to 94 If the malfunction could not be identified during the inspections in steps 58, 59, 60, 61, 64, 65, 67, 68, 69, 70 and 71, perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake air system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 114), in that order. RESULT Performed Step Troubleshooting by System Procedure Proceed to Steps 58, 59, 60, 61, 64, 65, 67, 68, 69, 70 and 71 Fuel system troubleshooting A 95 to 102 D Fuel system troubleshooting B 103 to 105 Intake air system troubleshooting 106 to 108 Ignition system troubleshooting 109 to 114 B --> See step 78 C --> See step 84 D --> See step 95 A: Go to next step
73. INSPECT FUEL INJECTOR ASSEMBLY Inspect the fuel injector assemblies. Refer to «INSPECTION [05/2013 - ]»(ref-615244-S28235590902014050900000) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 181 OK: Go to next step
74. CHECK TERMINAL VOLTAGE (FUEL INJECTOR POWER SOURCE) Disconnect the fuel injector assembly connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Cylinder Tester Connection Switch Condition Specified Condition No. 1 B10-1 - Body ground Ignition switch ON 11 to 14 V No. 2 B11-1 - Body ground Ignition switch ON 11 to 14 V No. 3 B12-1 - Body ground Ignition switch ON 11 to 14 V No. 4 B13-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 182 OK: Go to next step
75. CHECK HARNESS AND CONNECTOR (FUEL INJECTOR ASSEMBLY - ECM) Disconnect the fuel injector assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Cylinder Tester Connection Condition Specified Condition No. 1 B10-2 - Body ground Always 10 kohms or higher B10-2 - B30-85 (#10) Always Below 1 ohms No. 2 B11-2 - Body ground Always 10 kohms or higher B11-2 - B30-84 (#20) Always Below 1 ohms No. 3 B12-2 - Body ground Always 10 kohms or higher B12-2 - B30-83 (#30) Always Below 1 ohms No. 4 B13-2 - Body ground Always 10 kohms or higher B13-2 - B30-82 (#40) Always Below 1 ohms HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
76. CHECK CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S03430781602014050900000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 77 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
77. CHECK CAMSHAFT POSITION SENSOR Replace the camshaft position sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S31093354652014050900000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 163 OK --> END (CAMSHAFT POSITION SENSOR IS DEFECTIVE)
78. CHECK CRANKSHAFT POSITION SENSOR Check the tightening and installation condition of the crankshaft position sensor bolt. Check the connection of the crankshaft position sensor connector. OK Sensor is installed correctly. NG --> See step 156 OK: Go to next step
79. CHECK CAMSHAFT POSITION SENSOR Check the tightening and installation condition of the camshaft position sensor bolt. Check the connection of the camshaft position sensor connector. OK Sensor is installed correctly. NG --> See step 157 OK: Go to next step
80. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Disconnect the crankshaft position sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B15-1 - B30-74 (NE+) Always Below 1 ohms B15-2 - B30-120 (NE-) Always Below 1 ohms B15-1 or B30-74 (NE+) - Body ground Always 10 kohms or higher B15-2 or B30-120 (NE-) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
81. CHECK HARNESS AND CONNECTOR (CAMSHAFT POSITION SENSOR - ECM) Disconnect the camshaft position sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B25-1 (VV1+) - B30-76 (G2+) Always Below 1 ohms B25-2 (VV1-) - B30-122 (G2-) Always Below 1 ohms B25-3 (VC) - B30-99 (VCV1) Always Below 1 ohms B25-1 (VV1+) or B30-76 (G2+) - Body ground Always 10 kohms or higher B25-2 (VV1-) or B30-122 (G2-) - Body ground Always 10 kohms or higher B25-3 (VC) or B30-99 (VCV1) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
82. CHECK CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S03430781602014050900000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 83 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
83. CHECK CAMSHAFT POSITION SENSOR Replace the camshaft position sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S31093354652014050900000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 142 OK --> END (CAMSHAFT POSITION SENSOR IS DEFECTIVE)
84. READ VALUE USING TECHSTREAM (ISC LEARNING VALUE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine and warm it up until the engine coolant temperature stabilizes with the A/C switch and all the accessory switches off. Enter the following menus: Powertrain / Engine / Data List / ISC Learning Value. RESULT Data List Item Result Suspected Area Proceed to ISC Learning Value (engine displacement (liters) x 0.9) or more Valve timing Compression A Less than (engine displacement (liters) x 0.9) - B B --> See step 86 A: Go to next step
85. CHECK CYLINDER COMPRESSION PRESSURE Inspect the compression. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 4»(ref-615223-S04319462632014050900000) . HINT: Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> REPAIR OR REPLACE ENGINE ASSEMBLY OK --> See step 159
86. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S06137183572014050900000) . HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 160 OK: Go to next step
87. CHECK FUEL PRESSURE HINT: For the fuel pressure inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [05/2013 - 01/2014] - Step 2»(ref-615250-S34834712852014050900000) . Attach a fuel pressure gauge and check the fuel pressure when cranking the engine and after stopping the engine. RESULT Vehicle State Specified Condition Cranking engine 304 to 343 kPa (3.1 to 3.5 kgf/cm 2 ) 5 minutes after stopping engine 147 kPa (1.5 kgf/cm 2 ) or higher NG --> See step 93 OK: Go to next step
88. READ VALUE USING TECHSTREAM (LONG FT) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / Long FT. RESULT Data List Item Result Suspected Area Proceed to Long FT -15 to +15% Wire harness or connector Fuel A +15% or more, or less than -15% Fuel injector assembly B HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 161 A: Go to next step
89. PERFORM SIMULATION TEST Check if the idling speed is stable after starting the engine and if an unstable idling speed has ever occurred in the past. RESULT Problem Symptom Suspected Area Proceed to Current unstable idling speed or history of unstable idling speed Crankshaft position sensor system A All current and past idling speeds are stable Fuel B HINT: Through the customer problem analysis, confirm the fuel being used and the location at which the fuel was added to check if the malfunction is caused by the fuel in the vehicle. B --> REPLACE FUEL A: Go to next step
90. CHECK CRANKSHAFT POSITION SENSOR Check the tightening and installation condition of the crankshaft position sensor bolt. Check the connection of the crankshaft position sensor connector. OK Sensor is installed correctly. NG --> See step 162 OK: Go to next step
91. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Disconnect the crankshaft position sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B15-1 - B30-74 (NE+) Always Below 1 ohms B15-2 - B30-120 (NE-) Always Below 1 ohms B15-1 or B30-74 (NE+) - Body ground Always 10 kohms or higher B15-2 or B30-120 (NE-) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
92. CHECK CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S03430781602014050900000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 166 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
93. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for fuel leakage from the fuel pipes. RESULT Result Proceed to Fuel leakage or signs of fuel leakage are present A No fuel leakage or signs of fuel leakage B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When performing the Active Test, if there is no operating noise from the fuel pump, the fuel pump system may be malfunctioning. Check if the vehicle ran out of fuel, as engine starting trouble due to running out of fuel is also detected. B --> See step 94 A --> REPAIR OR REPLACE FUEL LINE
94. INSPECT FUEL PUMP Inspect the fuel pump. Refer to «INSPECTION [05/2013 - ]»(ref-615244-S33268116522014050900000) . HINT: Make sure there is no foreign matter such as iron particles on the fuel pump and no signs that the fuel pump was stuck. Make sure the internal connector is securely connected. Make sure the fuel pump filter is not clogged. Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 167 OK --> See step 164
95. CHECK FUEL PRESSURE HINT: For the fuel pressure inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [05/2013 - 01/2014] - Step 2»(ref-615250-S34834712852014050900000) . Attach a fuel pressure gauge and check the fuel pressure after stopping the engine. RESULT Result Proceed to 147 kPa (1.5 kgf/cm 2 ) or higher (5 minutes after stopping the engine) A Below 147 kPa (1.5 kgf/cm 2 ) (5 minutes after stopping the engine) B B --> See step 101 A: Go to next step
96. READ VALUE USING TECHSTREAM (LONG FT) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / Long FT. RESULT Data List Item Result Suspected Area Proceed to Long FT -15 to +15% Wire harness or connector Fuel A +15% or more, or less than -15% Fuel injector assembly B HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 174 A: Go to next step
97. PERFORM SIMULATION TEST Check if the idling speed is stable after starting the engine and if an unstable idling speed has ever occurred in the past. RESULT Problem Symptom Suspected Area Proceed to Current unstable idling speed or history of unstable idling speed Crankshaft position sensor system A All current and past idling speeds are stable Fuel B HINT: Through the customer problem analysis, confirm the fuel being used and the location at which the fuel was added to check if the malfunction is caused by the fuel in the vehicle. B --> REPLACE FUEL A: Go to next step
98. CHECK CRANKSHAFT POSITION SENSOR Check the tightening and installation condition of the crankshaft position sensor bolt. Check the connection of the crankshaft position sensor connector. OK Sensor is installed correctly. NG --> See step 165 OK: Go to next step
99. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Disconnect the crankshaft position sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B15-1 - B30-74 (NE+) Always Below 1 ohms B15-2 - B30-120 (NE-) Always Below 1 ohms B15-1 or B30-74 (NE+) - Body ground Always 10 kohms or higher B15-2 or B30-120 (NE-) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
100. CHECK CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S03430781602014050900000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 155 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
101. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for fuel leakage from the fuel pipes. RESULT Result Proceed to Fuel leakage or signs of fuel leakage are present A No fuel leakage or signs of fuel leakage B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When performing the Active Test, if there is no operating noise from the fuel pump, the fuel pump system may be malfunctioning. Check if the vehicle ran out of fuel, as engine starting trouble due to running out of fuel is also detected. B --> See step 102 A --> REPAIR OR REPLACE FUEL LINE
102. INSPECT FUEL PUMP Inspect the fuel pump. Refer to «INSPECTION [05/2013 - ]»(ref-615244-S33268116522014050900000) . HINT: Make sure there is no foreign matter such as iron particles on the fuel pump and no signs that the fuel pump was stuck. Make sure the internal connector is securely connected. Make sure the fuel pump filter is not clogged. Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 177 OK: Go to next step
103. CHECK PURGE VSV Disconnect the vacuum hose (on the canister side) of the purge VSV. Start the engine. Idle the engine. Disconnect the connector of the purge VSV. Check if air flows through the purge VSV. OK Air does not flow Connect the connector of the purge VSV. Connect the vacuum hose of the purge VSV. HINT: When this inspection is performed, the MIL may illuminate. After finishing the inspection, check and clear DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . NG --> See step 168 OK: Go to next step
104. CHECK FUEL INJECTOR ASSEMBLY Clean the inside of the surge tank with compressed air. After stopping the engine, measure the HC concentration inside the surge tank for 15 minutes. RESULT Result Proceed to 4000 ppm or more A Less than 4000 ppm B HINT: If the concentration is 4000 ppm or more, a fuel injector assembly may have a sealing problem. Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . B --> See step 105 A --> See step 169
105. CHECK INTAKE VALVE Check if carbon is on the intake valves. RESULT Result Proceed to Carbon present A No carbon present B B --> See step 106 A --> CLEAN INTAKE VALVE
106. READ VALUE USING TECHSTREAM (ISC LEARNING VALUE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine, turn off all accessory switches and warm up the engine until the engine coolant temperature stabilizes. Enter the following menus: Powertrain / Engine / Data List / ISC Learning Value. RESULT Data List Item Result Suspected Area Proceed to ISC Learning Value (engine displacement (liters) x 0.9) or more Valve timing Compression A Less than (engine displacement (liters) x 0.9) - B B --> See step 108 A: Go to next step
107. CHECK CYLINDER COMPRESSION PRESSURE Inspect the compression. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 4»(ref-615223-S04319462632014050900000) . HINT: Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> REPAIR OR REPLACE ENGINE ASSEMBLY OK --> See step 170
108. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION [05/2013 - ]»(ref-615228-S41970993802014050900000) . HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 171 OK: Go to next step
109. CHECK CRANKSHAFT POSITION SENSOR Check the tightening and installation condition of the crankshaft position sensor bolt. Check the connection of the crankshaft position sensor connector. OK Sensor is installed correctly. NG --> See step 172 OK: Go to next step
110. CHECK CAMSHAFT POSITION SENSOR Check the tightening and installation condition of the camshaft position sensor bolt. Check the connection of the camshaft position sensor connector. OK Sensor is installed correctly. NG --> See step 173 OK: Go to next step
111. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Disconnect the crankshaft position sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B15-1 - B30-74 (NE+) Always Below 1 ohms B15-2 - B30-120 (NE-) Always Below 1 ohms B15-1 or B30-74 (NE+) - Body ground Always 10 kohms or higher B15-2 or B30-120 (NE-) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
112. CHECK HARNESS AND CONNECTOR (CAMSHAFT POSITION SENSOR - ECM) Disconnect the camshaft position sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B25-1 (VV1+) - B30-76 (G2+) Always Below 1 ohms B25-2 (VV1-) - B30-122 (G2-) Always Below 1 ohms B25-3 (VC) - B30-99 (VCV1) Always Below 1 ohms B25-1 (VV1+) or B30-76 (G2+) - Body ground Always 10 kohms or higher B25-2 (VV1-) or B30-122 (G2-) - Body ground Always 10 kohms or higher B25-3 (VC) or B30-99 (VCV1) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
113. CHECK CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S03430781602014050900000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 114 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
114. CHECK CAMSHAFT POSITION SENSOR Replace the camshaft position sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S31093354652014050900000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 178 OK --> END (CAMSHAFT POSITION SENSOR IS DEFECTIVE)
115. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [05/2013 - 01/2014]»(ref-615234-S41552064272014050900000)
116. REPAIR ENGINE IMMOBILIZER SYSTEM (W/ SMART KEY SYSTEM). Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [05/2013 - 01/2014]»(ref-615123-S13172150892014050900000)
117. CHECK STARTER SIGNAL CIRCUIT. Refer to «Starter Signal Circuit»(ref-615235-S40084649782014050900000)
118. SECURELY REINSTALL SENSOR. Refer to «INSTALLATION [05/2013 - ]»(ref-615228-S22193595252014050900000)
119. REPLACE CRANKSHAFT POSITION SENSOR. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S03430781602014050900000)
120. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
121. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S06137183572014050900000)
122. CHECK FUEL PUMP CONTROL CIRCUIT. Refer to «Fuel Pump Control Circuit»(ref-615235-S31281831432014050900000)
123. REPAIR FUEL PUMP CONTROL CIRCUIT. Refer to «Fuel Pump Control Circuit»(ref-615235-S31281831432014050900000)
124. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S06137183572014050900000)
125. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S17953342372014050900000)
126. CLEAN OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S19667413492014050900000)
127. INSPECT STARTER ASSEMBLY. Refer to «INSPECTION [05/2013 - 01/2014]»(ref-615241-S39340577512014050900000)
128. REPLACE DRIVE PLATE AND RING GEAR OR FLYWHEEL. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615223-S21814213422014050900000)
129. REPLACE STARTER ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615241-S20808113982014050900000)
130. CHECK STARTER SIGNAL CIRCUIT. Refer to «Starter Signal Circuit»(ref-615235-S40084649782014050900000)
131. REPLACE STARTER ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615241-S20808113982014050900000)
132. INSPECT STARTER ASSEMBLY. Refer to «INSPECTION [05/2013 - 01/2014]»(ref-615241-S39340577512014050900000)
133. REPLACE FUEL PRESSURE REGULATOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S15778762162014050900000)
134. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S17953342372014050900000)
135. REPLACE SPARK PLUG. Refer to «REMOVAL [05/2013 - ] - Step 2»(ref-615228-S28016964092014050900000)
136. CHECK CRANKSHAFT POSITION SENSOR CIRCUIT. Refer to «DTC P0335: Crankshaft Position Sensor "A" Circuit; DTC P0339: Crankshaft Position Sensor "A" Circuit Intermittent»(ref-615236-S30576698662014050900000)
137. CHECK IGNITION COIL POWER SOURCE CIRCUIT. Refer to «DTC P0351: Ignition Coil "A" Primary / Secondary Circuit; DTC P0352: Ignition Coil "B" Primary / Secondary Circuit; DTC P0353: Ignition Coil "C" Primary / Secondary Circuit; DTC P0354: Ignition Coil "D" Primary / Secondary Circuit»(ref-615236-S14259472362014050900000)
138. REPLACE IGNITION COIL ASSEMBLY. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S33820474432014050900000)
139. CHECK FUEL PUMP CONTROL CIRCUIT. Refer to «Fuel Pump Control Circuit»(ref-615235-S31281831432014050900000)
140. CHECK FUEL PUMP CONTROL CIRCUIT. Refer to «Fuel Pump Control Circuit»(ref-615235-S31281831432014050900000)
141. REPLACE CRANKSHAFT POSITION SENSOR. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S03430781602014050900000)
142. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
143. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S42887372192014050900000)
144. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S10339709762014050900000)
145. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S06137183572014050900000)
146. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S10339709762014050900000)
147. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S10639288742014050900000)
148. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S10339709762014050900000)
149. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S17953342372014050900000)
150. REPLACE SPARK PLUG (ABNORMAL CYLINDER). Refer to «REMOVAL [05/2013 - ] - Step 2»(ref-615228-S28016964092014050900000)
151. REPLACE SPARK PLUG (ALL). Refer to «REMOVAL [05/2013 - ] - Step 2»(ref-615228-S28016964092014050900000)
152. REPLACE FUEL PRESSURE REGULATOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S15778762162014050900000)
153. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S17953342372014050900000)
154. CHECK FUEL PUMP CONTROL CIRCUIT. Refer to «Fuel Pump Control Circuit»(ref-615235-S31281831432014050900000)
155. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
156. SECURELY REINSTALL SENSOR. Refer to «INSTALLATION [05/2013 - ]»(ref-615228-S22193595252014050900000)
157. SECURELY REINSTALL SENSOR. Refer to «INSTALLATION [05/2013 - ]»(ref-615228-S22193595252014050900000)
158. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
159. ADJUST VALVE TIMING. Refer to «REASSEMBLY [05/2013 - 01/2014]»(ref-615223-S16190509832014050900000)
160. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S06137183572014050900000)
161. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S17953342372014050900000)
162. SECURELY REINSTALL SENSOR. Refer to «INSTALLATION [05/2013 - ]»(ref-615228-S22193595252014050900000)
163. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
164. REPLACE FUEL PRESSURE REGULATOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S15778762162014050900000)
165. SECURELY REINSTALL SENSOR. Refer to «INSTALLATION [05/2013 - ]»(ref-615228-S22193595252014050900000)
166. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
167. REPLACE FUEL PUMP. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S34315231702014050900000)
168. INSPECT PURGE VSV. Refer to «INSPECTION [05/2013 - ]»(ref-615251-S19847435922014050900000)
169. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S17953342372014050900000)
170. ADJUST VALVE TIMING. Refer to «REASSEMBLY [05/2013 - 01/2014]»(ref-615223-S16190509832014050900000)
171. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S06137183572014050900000)
172. SECURELY REINSTALL SENSOR. Refer to «INSTALLATION [05/2013 - ]»(ref-615228-S22193595252014050900000)
173. SECURELY REINSTALL SENSOR. Refer to «INSTALLATION [05/2013 - ]»(ref-615228-S22193595252014050900000)
174. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S17953342372014050900000)
175. REPLACE FUEL PRESSURE REGULATOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S15778762162014050900000)
176. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S17953342372014050900000)
177. REPLACE FUEL PUMP. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S34315231702014050900000)
178. REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
179. REPAIR FUEL INJECTOR POWER SOURCE CIRCUIT. Refer to «Fuel Injector Circuit»(ref-615235-S16561013462014050900000)
180. REPAIR FUEL INJECTOR POWER SOURCE CIRCUIT. Refer to «Fuel Injector Circuit»(ref-615235-S16561013462014050900000)
181. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615244-S17953342372014050900000)
182. REPAIR FUEL INJECTOR POWER SOURCE CIRCUIT. Refer to «Fuel Injector Circuit»(ref-615235-S16561013462014050900000)
183. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S42887372192014050900000)
184. REPAIR OR REPLACE ENGINE IMMOBILIZER SYSTEM (W/O SMART KEY SYSTEM). Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [05/2013 - 01/2014]»(ref-615124-S10382631032014050900000)
