MONITOR STRATEGY
| Related DTCs | P0420: Catalyst Deterioration |
| Required Sensors/Components (Main) | Air fuel ratio sensor, heated oxygen sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor, mass air flow meter, crankshaft position sensor and engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | About 30 seconds |
| MIL Operation | 1 driving cycles |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs not stored | P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0037, P0038, P102D (Rear oxygen sensor heater) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0136, P0137, P0138, P0139, P0607 (Rear oxygen sensor) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust camshaft position sensor) P0500 (Vehicle speed sensor) P219A (Air fuel ratio imbalance) |
| Battery voltage | 11 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Idling | OFF |
| Engine speed | Less than 4000 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Engine load | 10 to 80% |
| All of following conditions (a), (b) and (c) met | |
| (a) Mass air flow | 2.5 to 60 gm/s |
| (b) Estimated front catalyst temperature | 570 to 905°C (1058 to 1661°F) [AT] 570 to 850°C (1058 to 1562°F) [MT] |
| (c) Estimated rear catalyst temperature | 360 to 770°C (680 to 1418°F) [AT] 360 to 770°C (680 to 1418°F) [MT] |
| Shift position | 3rd or higher [AT] 3rd or higher [MT] |
The estimated catalyst temperature can be read in the Data List using the Techstream.
TYPICAL MALFUNCTION THRESHOLDS
| Oxygen Storage Capacity (OSC) of Three-way Catalytic Converter (TWC) | Less than 1 |
MONITOR RESULT
Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS [01/2014 - ] .
| Monitor ID | Test ID | Scaling | Unit | Description |
| $21 | $AF | Multiply by 0.001 | No dimension | Oxygen storage capacity of catalyst bank 1 (Normalization) |
P0420: CATALYST EFFICIENCY / O2 STORAGE B1
CONFIRMATION DRIVING PATTERN
- It is necessary that the response of the heated oxygen sensor is normal in order to confirm DTC P0420. Therefore, perform the driving pattern for the heated oxygen sensor monitor before performing the drive pattern for the catalyst efficiency monitor.
- Performing this confirmation driving pattern will activate the catalyst efficiency monitor. This is very useful for verifying the completion of a repair.
Scheme 207
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Monitor / Current Monitor.
- Check that Catalyst Efficiency / Current is Incomplete.
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [A].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible.
- With the shift lever in S, drive the vehicle at 60 km/h (37 mph), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine / Monitor / Current Monitor / O2 Sensor / RL F/C B1S2 [D].
- Check the Test Value for RL F/C B1S2. If Test Value displays a value larger than 0, perform the following procedure, as the O2 sensor monitor is finished. If Test Value displays 0, perform step [C] until it displays a value larger than 0, as the O2 sensor monitor is not finished.
- Turn the ignition switch off and wait for at least 30 seconds [F].
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [G].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the Catalyst Efficiency monitor operates [I].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Check if any DTCs are stored. HINT: If the monitor item does not change to Complete, and no DTCs are stored, perform the following procedure.
- Drive the vehicle at a speed between 75 and 100 km/h (47 and 63 mph) for 10 minutes or more [J]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the Catalyst Efficiency monitor operates [K].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Check if any DTCs are stored. HINT: If the monitor item does not change to Complete, and no DTCs are stored, drive the vehicle again under an increased load.
- If no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
PROCEDURE
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0420 is output A P0420 and other DTCs are output B HINT: If any DTCs other than P0420 are output, troubleshoot those DTCs first. B --> See step 13 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine and run the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor. Perform the Control the Injection Volume operation with the engine idling. Monitor the voltage outputs of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of - 12.5% to +12.5%. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +12.5% Rich Below 3.1 V AFS Voltage B1S1 (Air fuel ratio) -12.5% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen) +12.5% Rich Higher than 0.55 V O2S B1S2 (Heated oxygen) -12.5% Lean Below 0.4 V RESULT Status of AFS Voltage B1S1 Status of O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio and Heated Oxygen Sensor Condition Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal Three-way catalytic converter Gas leaks from exhaust system A Lean Lean/Rich Air fuel ratio sensor malfunction Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction Air fuel ratio sensor B Lean/Rich Lean Heated oxygen sensor malfunction Heated oxygen sensor Gas leaks from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction Heated oxygen sensor Gas leaks from exhaust system C Lean Lean Actual air fuel ratio lean Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system D Rich Rich Actual air fuel ratio rich Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system D Lean: During the Control the Injection Volume Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently below 0.4 V. Rich: During the Control the Injection Volume Active Test, the AFS Voltage is consistently below 3.1 V, and the O2S is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume Active Test, the output voltage of the air fuel ratio sensor and heated oxygen sensor alternate correctly. Refer to "Data List / Active Test" [AFS Voltage B1S1 and O2S B1S2]. Refer to «DATA LIST / ACTIVE TEST [01/2014 - ]»(ref-615234-S30683406662014050900000) . B --> See step 5 C --> See step 6 D --> See step 8 A: Go to next step
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 10 OK: Go to next step
- REPLACE EXHAUST MANIFOLD CONVERTER SUB-ASSEMBLY (TWC: FRONT CATALYST) AND CENTER EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST) NOTE: Replace the exhaust manifold converter sub-assembly (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalyst replacement is necessary. HINT: Confirm the replacement parts, referring to the illustration in the Catalyst Location. Replace the exhaust manifold converter sub-assembly (TWC: Front catalyst). Refer to «REMOVAL [01/2014 - ]»(ref-615249-S10802066922014050900000) . Replace the center exhaust pipe assembly (TWC: Rear catalyst). Refer to «REMOVAL [05/2013 - ]»(ref-615249-S37307435932014050900000) . NEXT --> END
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S10639288742014050900000) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT --> See step 11
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 10 OK: Go to next step
- REPLACE HEATED OXYGEN SENSOR Replace the heated oxygen sensor. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S30534159122014050900000) . HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT --> See step 11
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 10 OK: Go to next step
- CHECK CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO Check the cause of extremely rich or lean actual air fuel ratio, referring to the DTC P0171 Inspection Procedure. Refer to «INSPECTION PROCEDURE»(ref-615236-S23383676962014050900000) . NEXT --> See step 11
- REPAIR OR REPLACE EXHAUST GAS LEAK POINT Repair or replace exhaust gas leak point. Refer to «REMOVAL [05/2013 - ]»(ref-615249-S37307435932014050900000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0420 is output A No DTC is output (No pending DTCs output) B B --> END A: Go to next step
- REPLACE EXHAUST MANIFOLD CONVERTER SUB-ASSEMBLY (TWC: FRONT CATALYST) AND CENTER EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST) NOTE: Replace the exhaust manifold converter sub-assembly (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalyst replacement is necessary. HINT: Confirm the replacement parts, referring to the illustration in the Catalyst Location. Replace the exhaust manifold converter sub-assembly (TWC: Front catalyst). Refer to «REMOVAL [01/2014 - ]»(ref-615249-S10802066922014050900000) . Replace the center exhaust pipe assembly (TWC: Rear catalyst). Refer to «REMOVAL [05/2013 - ]»(ref-615249-S37307435932014050900000) . NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [01/2014 - ]»(ref-615234-S09827197572014050900000)
| Required Sensors/Components | Canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 7 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Atmospheric pressure | 70 to 110 kPa(abs) [525 to 825 mmHg(abs)] |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 4 km/h (2.5 mph) |
| Ignition switch | Off |
| Time after key-off | 5, 7 or 9.5 hours |
| Canister pressure sensor malfunction | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before key-off | Conditions 1 and 2 |
| 1. Duration that vehicle is driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
"Saturated" indicates that the EVAP pressure change is below 0.286 kPa(gauge) [2.14 mmHg(gauge)] in 60 seconds.
| One of following conditions met | |
| EVAP pressure just after reference pressure measurement started | Higher than -0.25 kPa(gauge) [-1.875 mmHg(gauge)] |
| Reference pressure | Below -4.85 kPa(gauge) [-36.384 mmHg(gauge)] |
| Reference pressure | 1.057 kPa(gauge) [-7.93 mmHg(gauge)] or higher |
| Reference pressure | Not saturated within 360 seconds |
| Reference pressure difference between first and second | 0.9 kPa(gauge) [6.76 mmHg(gauge)] or higher |
Refer to EVAP System. Refer to MONITOR RESULT .
Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
- After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All readiness.
- Input the DTC: P043E, P043F, P2401, P2402 or P2419.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Required Sensors/Components | Canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 7 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Atmospheric pressure | 70 to 110 kPa(abs) [525 to 825 mmHg(abs)] |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 4 km/h (2.5 mph) |
| Ignition switch | Off |
| Time after key-off | 5, 7 or 9.5 hours |
| Canister pressure sensor malfunction | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before key-off | Conditions 1 and 2 |
| 1. Duration that vehicle is driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
"Saturated" indicates that the EVAP pressure change is below 0.286 kPa(gauge) [2.14 mmHg(gauge)] in 60 seconds.
| One of following conditions met | |
| EVAP pressure just after reference pressure measurement started | Higher than -0.25 kPa(gauge) [-1.875 mmHg(gauge)] |
| Reference pressure | Below -4.85 kPa(gauge) [-36.384 mmHg(gauge)] |
| Reference pressure | 1.057 kPa(gauge) [-7.93 mmHg(gauge)] or higher |
| Reference pressure | Not saturated within 360 seconds |
| Reference pressure difference between first and second | 0.9 kPa(gauge) [6.76 mmHg(gauge)] or higher |
Refer to EVAP System. Refer to MONITOR RESULT .
Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
- After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All readiness.
- Input the DTC: P043E, P043F, P2401, P2402 or P2419.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Required Sensors/Components | Purge VSV Canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 20 minutes: Purge VSV stuck open/close Within 30 seconds: Purge flow |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Atmospheric pressure | 70 to 110 kPa(abs) [525 to 825 mmHg(abs)] |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | Below 4 km/h (2.5 mph) |
| Ignition switch | Off |
| Time after key-off | 5, 7 or 9.5 hours |
| Canister pressure sensor malfunction | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before key-off | Conditions 1 and 2 |
| 1. Duration that vehicle is driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
| Engine | Running |
| Engine coolant temperature | 4.4°C (40°F) or higher |
| Intake air temperature | 4.4°C (40°F) or higher |
| Canister pressure sensor malfunction | Not detected |
| Purge VSV | Not operated by scan tool |
| EVAP system check | Not operated by scan tool |
| Atmospheric pressure | 76 to 111 kPa (570 to 835 mmHg) |
| Battery voltage | 10 V or higher |
| Purge duty-cycle | 8% or more |
| EVAP pressure when vacuum introduction is complete | Higher than reference pressure x 0.2 |
| EVAP pressure change after purge VSV is open | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] |
| Both of the following conditions are met | Conditions 1 and 2 |
| 1. EVAP pressure change when purge flow is started | Less than 0.1 kPa(gauge) [0.75 mmHg(gauge)] |
| 2. EVAP pressure change during purge operation when vent valve closed | Less than 0.15 kPa(gauge) [1.13 mmHg(gauge)] |
Refer to EVAP System. Refer to MONITOR RESULT .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and wait 15 minutes or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All readiness.
- Input the DTC: P0441.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed You should perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure. NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0441.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Required Sensors/Components | Purge VSV Canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 20 minutes: Purge VSV stuck open/close Within 30 seconds: Purge flow |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Atmospheric pressure | 70 to 110 kPa(abs) [525 to 825 mmHg(abs)] |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | Below 4 km/h (2.5 mph) |
| Ignition switch | Off |
| Time after key-off | 5, 7 or 9.5 hours |
| Canister pressure sensor malfunction | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before key-off | Conditions 1 and 2 |
| 1. Duration that vehicle is driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
| Engine | Running |
| Engine coolant temperature | 4.4°C (40°F) or higher |
| Intake air temperature | 4.4°C (40°F) or higher |
| Canister pressure sensor malfunction | Not detected |
| Purge VSV | Not operated by scan tool |
| EVAP system check | Not operated by scan tool |
| Atmospheric pressure | 76 to 111 kPa (570 to 835 mmHg) |
| Battery voltage | 10 V or higher |
| Purge duty-cycle | 8% or more |
| EVAP pressure when vacuum introduction is complete | Higher than reference pressure x 0.2 |
| EVAP pressure change after purge VSV is open | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] |
| Both of the following conditions are met | Conditions 1 and 2 |
| 1. EVAP pressure change when purge flow is started | Less than 0.1 kPa(gauge) [0.75 mmHg(gauge)] |
| 2. EVAP pressure change during purge operation when vent valve closed | Less than 0.15 kPa(gauge) [1.13 mmHg(gauge)] |
Refer to EVAP System. Refer to MONITOR RESULT .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and wait 15 minutes or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All readiness.
- Input the DTC: P0441.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed You should perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure. NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0441.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Required Sensors/Components | Canister pump module |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds: P0452 and P0453 Within 2 minutes: P0451 (sensor stuck) Less than 15 seconds: P0451 (sensor noise) |
| MIL Operation | Immediate: P0452 and P0453 2 driving cycles: P0451 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Atmospheric pressure (absolute pressure) | 70 to 110 kPa(abs) [525 to 825 mmHg(abs)] |
| Battery voltage | 10.5 V or higher |
| Intake air temperature | 4.4 to 50°C (40 to 122°F) |
| Canister pressure sensor malfunction (P0452, P0453) | Not detected |
| Either of following conditions met | A or B |
| A. Engine condition | Running |
| B. Time after key-off | 5, 7 or 9.5 hours |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Intake air temperature | 4.4 to 50°C (40 to 122°F) |
| Canister pressure sensor malfunction (P0452, P0453) | Not detected |
| Atmospheric pressure (absolute pressure) | 70 to 110 kPa(abs) [525 to 825 mmHg(abs)] |
| Time after key-off | 5, 7 or 9.5 hours |
| Monitor runs whenever following DTCs not stored | None |
| Ignition switch | ON |
| Battery voltage | 8 V or higher |
| Frequency that EVAP pressure change 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher | 10 times or more in 10 seconds |
P0451: CANISTER PRESSURE SENSOR NOISE
| EVAP pressure change during reference pressure measurement | Below 0.65 kPa(gauge) [4.876 mmHg(gauge)] |
P0451: CANISTER PRESSURE SENSOR FIXED/FLAT
| EVAP pressure | Below 42.11 kPa(abs) [315.85 mmHg(abs)] |
P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE
| EVAP pressure | Higher than 123.761 kPa(abs) [928.28 mmHg(abs)] |
P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE
Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / Intake Air.
- Check that the intake air temperature is between 4.4 and 40°C (40 and 104°F).
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All readiness.
- Input the DTC: P0451, P0452 or P0453.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 208
Scheme 208: WIRING DIAGRAM
| Required Sensors/Components | Canister pump module |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds: P0452 and P0453 Within 2 minutes: P0451 (sensor stuck) Less than 15 seconds: P0451 (sensor noise) |
| MIL Operation | Immediate: P0452 and P0453 2 driving cycles: P0451 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Atmospheric pressure (absolute pressure) | 70 to 110 kPa(abs) [525 to 825 mmHg(abs)] |
| Battery voltage | 10.5 V or higher |
| Intake air temperature | 4.4 to 50°C (40 to 122°F) |
| Canister pressure sensor malfunction (P0452, P0453) | Not detected |
| Either of following conditions met | A or B |
| A. Engine condition | Running |
| B. Time after key-off | 5, 7 or 9.5 hours |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Intake air temperature | 4.4 to 50°C (40 to 122°F) |
| Canister pressure sensor malfunction (P0452, P0453) | Not detected |
| Atmospheric pressure (absolute pressure) | 70 to 110 kPa(abs) [525 to 825 mmHg(abs)] |
| Time after key-off | 5, 7 or 9.5 hours |
| Monitor runs whenever following DTCs not stored | None |
| Ignition switch | ON |
| Battery voltage | 8 V or higher |
| Frequency that EVAP pressure change 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher | 10 times or more in 10 seconds |
P0451: CANISTER PRESSURE SENSOR NOISE
| EVAP pressure change during reference pressure measurement | Below 0.65 kPa(gauge) [4.876 mmHg(gauge)] |
P0451: CANISTER PRESSURE SENSOR FIXED/FLAT
| EVAP pressure | Below 42.11 kPa(abs) [315.85 mmHg(abs)] |
P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE
| EVAP pressure | Higher than 123.761 kPa(abs) [928.28 mmHg(abs)] |
P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE
Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / Intake Air.
- Check that the intake air temperature is between 4.4 and 40°C (40 and 104°F).
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All readiness.
- Input the DTC: P0451, P0452 or P0453.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CONFIRM DTC AND EVAP PRESSURE Connect the Techstream to the DLC3. Turn the ignition switch to ON (do not start the engine). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. Enter the following menus: Powertrain / Engine / Data List / Vapor Pressure Pump. Read the EVAP (Evaporative Emission) pressure displayed on the Techstream. RESULT Display (DTC Output) Test Result Suspected Trouble Area Proceed to P0451 - Canister pressure sensor C P0452 Below 42.11 kPa(abs) [315.85 mmHg(abs)] Wire harness/connector (ECM - Canister pressure sensor) Canister pressure sensor Short in ECM circuit A P0453 Higher than 123.761 kPa(abs) [928.28 mmHg(abs)] Wire harness/connector (ECM - Canister pressure sensor) Canister pressure sensor Open in ECM circuit B B --> See step 4 C --> See step 9 A: Go to next step
- CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Turn the ignition switch off. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to B30-114 (PPMP) - Body ground Always Below 10 ohms Wire harness/connector (ECM - Canister pressure sensor) Short in canister pressure sensor circuit A 10 kohms or higher Wire harness/connector (ECM - Canister pressure sensor) Short in ECM circuit B B --> See step 7 A: Go to next step
- CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to B30-114 (PPMP) - Body ground Always 10 kohms or higher Short in canister pressure sensor circuit A Below 10 ohms Short in wire harness/connector (ECM - Canister pressure sensor) B A --> See step 5 B --> See step 6
- CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition H20-8 (SGND) - Body ground Always 100 ohms or less Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition H20-6 (VCC) - Body ground Ignition switch ON 4.5 to 5.5 V H20-7 (VOUT) - Body ground Ignition switch ON 4.5 to 5.5 V RESULT Test Result Suspected Trouble Area Proceed to Voltage and resistance within standard ranges Open in canister pressure sensor circuit A Voltage and/or resistance outside standard ranges Open in wire harness/connector (ECM - Canister pressure sensor) B TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Canister Pump Module) B --> See step 6 A: Go to next step
- REPLACE CANISTER Replace the canister. Refer to «REMOVAL [05/2013 - ]»(ref-615251-S01365067382014050900000) . NOTE: When replacing the canister, check the canister pump module interior and related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. Check for filter blockage in the canister filter. If the canister filter has blockages, replace the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Vent Hose *3 Air Inlet Port *4 Fuel Tank *5 Canister - - *a Inspection Area (check for disconnection and/or cracks) - - NEXT --> See step 8
- REPAIR OR REPLACE HARNESS OR CONNECTOR (CANISTER - ECM) HINT: If the exhaust tailpipe has been removed, go to the next step before reinstalling it. NEXT --> See step 8
- REPLACE ECM Replace the ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000) . NEXT --> See step 8
- CHECK WHETHER DTC OUTPUT RECURS (AFTER REPAIR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Perform the Evaporative System Check using the Techstream, referring to the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0451, P0452 or P0453. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
- GO TO EVAP SYSTEM. Refer to «EVAP System»(ref-615235-S22502900602014050900000)
| Required Sensors/Components | Purge VSV and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 20 minutes (varies with amount of fuel in tank) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Atmospheric pressure | 70 to 110 kPa(abs) [525 to 825 mmHg(abs)] |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 4 km/h (2.5 mph) |
| Ignition switch | Off |
| Time after key-off | 5, 7 or 9.5 hours |
| Canister pressure sensor malfunction (P0452, P0453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before-key off | Conditions 1 and 2 |
| 1. Duration that vehicle is driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
| EVAP pressure when vacuum introduction complete | Higher than [reference pressure x 0.2] |
| EVAP pressure when vacuum introduction complete | Between reference pressure and [reference pressure x 0.2] |
Refer to EVAP System. Refer to MONITOR RESULT .
Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0455 or P0456.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Required Sensors/Components | Purge VSV and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 20 minutes (varies with amount of fuel in tank) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Atmospheric pressure | 70 to 110 kPa(abs) [525 to 825 mmHg(abs)] |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 4 km/h (2.5 mph) |
| Ignition switch | Off |
| Time after key-off | 5, 7 or 9.5 hours |
| Canister pressure sensor malfunction (P0452, P0453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before-key off | Conditions 1 and 2 |
| 1. Duration that vehicle is driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
| EVAP pressure when vacuum introduction complete | Higher than [reference pressure x 0.2] |
| EVAP pressure when vacuum introduction complete | Between reference pressure and [reference pressure x 0.2] |
Refer to EVAP System. Refer to MONITOR RESULT .
Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0455 or P0456.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0500: Vehicle speed sensor "A" pulse input error |
| Required Sensors/Components (Main) | Wheel speed sensor, Combination meter assembly and Skid control ECU |
| Required Sensors/Components (Related) | Park/neutral position switch assembly, Transmission revolution sensor (Speed sensor NC), Engine coolant temperature sensor, Crankshaft position sensor and Throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: automatic transaxle models 4.1 seconds: manual transaxle models |
| MIL Operation | Immediate: automatic transaxle models 2 driving cycles: manual transaxle models |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | U0101 (Lost Communication with TCM) |
| Time after ignition switch off to ON | 3 seconds or more |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Engine | Running |
| Transmission counter gear speed | 300 rpm or more |
| When either condition below is met | Condition A or B |
| A. When both conditions below are met | |
| Engine coolant temperature | 20°C (68°F) or higher |
| Time after park/neutral position switch turned from ON to off | 2 seconds or more |
| B. When both conditions below are met | |
| Engine coolant temperature | Below 20°C (68°F) |
| Time after park/neutral position switch turned from ON to off | 30 seconds or more |
AUTOMATIC TRANSAXLE MODELS
| Monitor runs whenever following DTCs not stored | None |
| Time after ignition switch off to ON | 3 seconds or more |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Idle | ON |
| Fuel-cut | ON |
| Vehicle speed sensor signal | No pulse input |
Scheme 209
Scheme 209: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- On the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine / Data List / Idle Fuel Cut.
- Drive the vehicle at 24 km/h (15 mph) or more for a total of 30 seconds or more [B].
- Decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C].
- Stop the vehicle.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0500.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 210
Scheme 210: WIRING DIAGRAM
- READ VALUE USING TECHSTREAM (VEHICLE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Vehicle Speed. Drive the vehicle. Read the value displayed on the Techstream. OK Vehicle speeds displayed on Techstream and speedometer display are equal. NG --> See step 2 OK --> See step 5
- CHECK COMBINATION METER SYSTEM Inspect the circuits that send vehicle speed signals to this system in the meter system. Refer to «Speed Signal Circuit»(ref-615252-S38134424382014050900000) . During inspection for the meter section, if there is an instruction that indicates to go back to inspections for each system, proceed to the next step. NEXT: Go to next step
- CHECK HARNESS AND CONNECTOR (ECM - COMBINATION METER) Disconnect the ECM connector. Disconnect the combination meter connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition C50-32 (+S) - A35-15 (SPD) Always Below 1 ohms NG --> See step 4 OK --> See step 6
- CHECK HARNESS AND CONNECTOR (ECM - JUNCTION CONNECTOR) Disconnect the ECM connector. Disconnect the junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition C58-7 - A35-15 (SPD) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - JUNCTION CONNECTOR) OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (JUNCTION CONNECTOR IS DEFECTIVE)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
| Related DTCs | P0500: Vehicle speed sensor "A" pulse input error |
| Required Sensors/Components (Main) | Wheel speed sensor, Combination meter assembly and Skid control ECU |
| Required Sensors/Components (Related) | Park/neutral position switch assembly, Transmission revolution sensor (Speed sensor NC), Engine coolant temperature sensor, Crankshaft position sensor and Throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: automatic transaxle models 4.1 seconds: manual transaxle models |
| MIL Operation | Immediate: automatic transaxle models 2 driving cycles: manual transaxle models |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | U0101 (Lost Communication with TCM) |
| Time after ignition switch off to ON | 3 seconds or more |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Engine | Running |
| Transmission counter gear speed | 300 rpm or more |
| When either condition below is met | Condition A or B |
| A. When both conditions below are met | |
| Engine coolant temperature | 20°C (68°F) or higher |
| Time after park/neutral position switch turned from ON to off | 2 seconds or more |
| B. When both conditions below are met | |
| Engine coolant temperature | Below 20°C (68°F) |
| Time after park/neutral position switch turned from ON to off | 30 seconds or more |
AUTOMATIC TRANSAXLE MODELS
| Monitor runs whenever following DTCs not stored | None |
| Time after ignition switch off to ON | 3 seconds or more |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Idle | ON |
| Fuel-cut | ON |
| Vehicle speed sensor signal | No pulse input |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- On the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine / Data List / Idle Fuel Cut.
- Drive the vehicle at 24 km/h (15 mph) or more for a total of 30 seconds or more [B].
- Decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C].
- Stop the vehicle.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0500.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ VALUE USING TECHSTREAM (VEHICLE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Vehicle Speed. Drive the vehicle. Read the value displayed on the Techstream. OK Vehicle speeds displayed on Techstream and speedometer display are equal. NG --> See step 2 OK --> See step 5
- CHECK COMBINATION METER SYSTEM Inspect the circuits that send vehicle speed signals to this system in the meter system. Refer to «Speed Signal Circuit»(ref-615252-S38134424382014050900000) . During inspection for the meter section, if there is an instruction that indicates to go back to inspections for each system, proceed to the next step. NEXT: Go to next step
- CHECK HARNESS AND CONNECTOR (ECM - COMBINATION METER) Disconnect the ECM connector. Disconnect the combination meter connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition C50-32 (+S) - A35-15 (SPD) Always Below 1 ohms NG --> See step 4 OK --> See step 6
- CHECK HARNESS AND CONNECTOR (ECM - JUNCTION CONNECTOR) Disconnect the ECM connector. Disconnect the junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition C58-7 - A35-15 (SPD) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - JUNCTION CONNECTOR) OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (JUNCTION CONNECTOR IS DEFECTIVE)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
- CHECK STOP LIGHT SWITCH ASSEMBLY (TERMINAL VOLTAGE) Disconnect the stop light switch connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A1-1 (B) - Body ground Always 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Stop Light Switch Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK STOP LIGHT SWITCH ASSEMBLY (TERMINAL VOLTAGE) Disconnect the stop light switch connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A1-5 (B) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Stop Light Switch Assembly) NG --> See step 6 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (STOP LIGHT SWITCH ASSEMBLY - BODY GROUND) Disconnect the stop light switch assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A1-3 (GND) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK ECM (STP AND ST1- VOLTAGE) Disconnect the ECM connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A35-39 (ST1-) - Body ground Brake pedal released 11 to 14 V Brake pedal depressed 0 to 3 V A35-29 (STP) - Body ground Brake pedal released 0 to 3 V Brake pedal depressed 11 to 14 V TEXT IN ILLUSTRATION *a Depressed *b Released *c Front view of wire harness connector (to ECM) NG --> See step 5 OK --> See step 7
- CHECK HARNESS AND CONNECTOR (STOP LIGHT SWITCH ASSEMBLY - ECM) Disconnect the stop light switch assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A1-2 (OUT) - A35-29 (STP) Always Below 1 ohms A1-4 (L) - A35-39 (ST1) Always Below 1 ohms A1-2 (OUT) or A35-29 (STP) - Body ground Always 10 kohms or higher A1-4 (L) or A35-39 (ST1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
- CHECK HARNESS AND CONNECTOR (STOP LIGHT SWITCH ASSEMBLY - INTEGRATION RELAY) Remove the integration relay from the engine room relay block. Disconnect the stop light switch assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A1-5 (B) - 1A-4 Always Below 1 ohms A1-5 (B) or 1A-4 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 9
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
- REPLACE STOP LIGHT SWITCH ASSEMBLY. Refer to «REMOVAL [05/2013 - ]»(ref-615253-S19698628412014050900000)
- GO TO ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit»(ref-615235-S16917092912014050900000)
| Related DTCs | P0505: ISC function |
| Required Sensors/Components (Main) | ETCS |
| Required Sensors/Components (Related) | Crankshaft position sensor, Engine coolant temperature sensor, and Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 5 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust camshaft position sensor) P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) P0748, P0778, P0798 (Pressure control solenoid) P219A (Air fuel ratio imbalance) |
| Engine | Running |
| Either condition is met | 1 or 2 |
| 1. Both of following conditions A and B met | |
| A. Engine speed - Target engine speed | Less than -100 rpm, or more than 150 rpm (A/C off and NSW off) Less than -100 rpm, or more than 200 rpm (A/C on or NSW on) |
| B. IAC flow rate learned value | 0.9 L/sec. or less, or 6 L/sec. or more for 5 seconds or more |
| 2. Both of following conditions C and D met | |
| C. Frequency that both of following conditions (a) and (b) met | 5 times or more |
| (a) Engine speed - Target engine speed | Less than -100 rpm, or more than 150 rpm (A/C off and NSW off) Less than -100 rpm, or more than 200 rpm (A/C on or NSW on) |
| (b) Vehicle condition | Stopped after being driven at 10 km/h (6.25 mph) or more |
| D. Either condition is met | (c) or (d) |
| (c) IAC flow rate learned value | 0.9 L/sec. or less, or 6 L/sec. or more |
| (d) Amount of change of IAC flow rate learned value | +4.91 L/sec. or more, or -4.15 L/sec. or less |
Scheme 211
Scheme 211: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
- Idle the engine for 5 minutes or more [C]. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F].
- Accelerate the vehicle to 10 km/h (6.25 mph) or more, and then idle the engine for 20 seconds or more [E].
- Repeat step [E] 5 times.
- Enter the following menus: Powertrain / Engine / Trouble Codes [F].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0505 is output A P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 2»(ref-615246-S35610607062014050900000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 7 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615245-S05242304412014050900000) . OK No leaks in air induction system. HINT: Perform "Inspection After Repair" after repairing or replacing the air induction system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 8 OK: Go to next step
- INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for contamination between the throttle valve and housing, and check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 9 OK: Go to next step
- CONFIRM WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the DTCs. RESULT Result Proceed to P0505 is output A No DTC is output B B --> END A --> See step 10
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [05/2013 - 01/2014]»(ref-615234-S41552064272014050900000)
- REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615251-S07057139652014050900000)
- REPAIR OR REPLACE AIR INDUCTION SYSTEM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615249-S35888103472014050900000)
- REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S19667413492014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
| Related DTCs | P0505: ISC function |
| Required Sensors/Components (Main) | ETCS |
| Required Sensors/Components (Related) | Crankshaft position sensor, Engine coolant temperature sensor, and Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 5 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust camshaft position sensor) P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) P0748, P0778, P0798 (Pressure control solenoid) P219A (Air fuel ratio imbalance) |
| Engine | Running |
| Either condition is met | 1 or 2 |
| 1. Both of following conditions A and B met | |
| A. Engine speed - Target engine speed | Less than -100 rpm, or more than 150 rpm (A/C off and NSW off) Less than -100 rpm, or more than 200 rpm (A/C on or NSW on) |
| B. IAC flow rate learned value | 0.9 L/sec. or less, or 6 L/sec. or more for 5 seconds or more |
| 2. Both of following conditions C and D met | |
| C. Frequency that both of following conditions (a) and (b) met | 5 times or more |
| (a) Engine speed - Target engine speed | Less than -100 rpm, or more than 150 rpm (A/C off and NSW off) Less than -100 rpm, or more than 200 rpm (A/C on or NSW on) |
| (b) Vehicle condition | Stopped after being driven at 10 km/h (6.25 mph) or more |
| D. Either condition is met | (c) or (d) |
| (c) IAC flow rate learned value | 0.9 L/sec. or less, or 6 L/sec. or more |
| (d) Amount of change of IAC flow rate learned value | +4.91 L/sec. or more, or -4.15 L/sec. or less |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
- Idle the engine for 5 minutes or more [C]. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F].
- Accelerate the vehicle to 10 km/h (6.25 mph) or more, and then idle the engine for 20 seconds or more [E].
- Repeat step [E] 5 times.
- Enter the following menus: Powertrain / Engine / Trouble Codes [F].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0505 is output A P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 2»(ref-615246-S35610607062014050900000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 7 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615245-S05242304412014050900000) . OK No leaks in air induction system. HINT: Perform "Inspection After Repair" after repairing or replacing the air induction system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 8 OK: Go to next step
- INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for contamination between the throttle valve and housing, and check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 9 OK: Go to next step
- CONFIRM WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the DTCs. RESULT Result Proceed to P0505 is output A No DTC is output B B --> END A --> See step 10
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [01/2014 - ]»(ref-615234-S09827197572014050900000)
- REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL [01/2014 - ]»(ref-615251-S04399339742014050900000)
- REPAIR OR REPLACE AIR INDUCTION SYSTEM. Refer to «REMOVAL [01/2014 - ]»(ref-615249-S07640147832014050900000)
- REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S19667413492014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
| Related DTCs | P050A: Cold start idle air speed control system |
| Required sensors/Components (Main) | Throttle with motor body assembly |
| Required sensors/Components (Related) | Mass air flow meter assembly Engine coolant temperature sensor |
| Frequency of operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust camshaft position sensor) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) P219A (Air fuel ratio imbalance) |
| Battery voltage | 8 V or higher |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| Engine coolant temperature at engine start | 10°C (14°F) or higher |
| Engine coolant temperature | 10 to 50°C (14 to 122°F) |
| Engine idling | 3 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 3 km/h (1.875 mph) |
| Time after shift position changed | 1 second or more [AT] |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Accumulated mass air flow | Less than 25.625 g (varies with ECT) [AT] Less than 29.375 g (varies with ECT) [MT] |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P050A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following the menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 21 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Short FT #1 and Long FT #1. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. Result Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
- INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. OK --> See step 14 NG --> See step 4
- REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S19667413492014050900000) . HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT --> See step 14
- CHECK PCV SYSTEM Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 2»(ref-615246-S35610607062014050900000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 10 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615245-S05242304412014050900000) . OK No leaks in air induction system. NG --> See step 11 OK: Go to next step
- INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK Air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1 and VVT Change Angle #1]. Refer to «DATA LIST / ACTIVE TEST [05/2013 - 01/2014]»(ref-615234-S35938653532014050900000) . NG --> See step 13 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 8 gm/sec and 22 gm/sec (shift lever: N; A/C: Off). OK --> See step 14 NG --> See step 15
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 14
- REPAIR OR REPLACE AIR INDUCTION SYSTEM Repair or replace the air induction system. HINT: Perform "Inspection After Repair" after repairing or replacing the air induction system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT --> See step 14
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
- CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 15 A --> See step 22
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [05/2013 - ]»(ref-615109-S05659225472014050900000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050A is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-5 (VG) - B30-94 (VG) Always Below 1 ohms B2-4 (E2G) - B30-117 (E2G) Always Below 1 ohms B2-5 (VG) or B30-94 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S10339709762014050900000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. Perform "Inspection After Repair" after replacing the mass air flow meter. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 20 A --> END
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [05/2013 - 01/2014]»(ref-615234-S41552064272014050900000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
| Related DTCs | P050A: Cold start idle air speed control system |
| Required sensors/Components (Main) | Throttle with motor body assembly |
| Required sensors/Components (Related) | Mass air flow meter assembly Engine coolant temperature sensor |
| Frequency of operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust camshaft position sensor) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) P219A (Air fuel ratio imbalance) |
| Battery voltage | 8 V or higher |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| Engine coolant temperature at engine start | 10°C (14°F) or higher |
| Engine coolant temperature | 10 to 50°C (14 to 122°F) |
| Engine idling | 3 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 3 km/h (1.875 mph) |
| Time after shift position changed | 1 second or more [AT] |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Accumulated mass air flow | Less than 25.625 g (varies with ECT) [AT] Less than 29.375 g (varies with ECT) [MT] |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P050A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following the menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 21 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Short FT #1 and Long FT #1. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. Result Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
- INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. OK --> See step 14 NG --> See step 4
- REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S19667413492014050900000) . HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT --> See step 14
- CHECK PCV SYSTEM Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 2»(ref-615246-S35610607062014050900000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 10 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615245-S05242304412014050900000) . OK No leaks in air induction system. NG --> See step 11 OK: Go to next step
- INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK Air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1 and VVT Change Angle #1]. Refer to «DATA LIST / ACTIVE TEST [01/2014 - ]»(ref-615234-S30683406662014050900000) . NG --> See step 13 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 8 gm/sec and 22 gm/sec (shift lever: N; A/C: Off). OK --> See step 14 NG --> See step 15
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 14
- REPAIR OR REPLACE AIR INDUCTION SYSTEM Repair or replace the air induction system. HINT: Perform "Inspection After Repair" after repairing or replacing the air induction system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT --> See step 14
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
- CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 15 A --> See step 22
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [05/2013 - ]»(ref-615109-S05659225472014050900000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050A is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-5 (VG) - B30-94 (VG) Always Below 1 ohms B2-4 (E2G) - B30-117 (E2G) Always Below 1 ohms B2-5 (VG) or B30-94 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S10339709762014050900000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. Perform "Inspection After Repair" after replacing the mass air flow meter. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 20 A --> END
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [01/2014 - ]»(ref-615234-S09827197572014050900000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
| Related DTCs | P050B: Cold start ignition timing performance |
| Required Sensors/Components (Main) | Throttle with motor body assembly |
| Required Sensors/Components (Related) | Mass air flow meter assembly Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust camshaft position sensor) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) P219A (Air fuel ratio imbalance) |
| Battery voltage | 8 V or higher |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| Engine coolant temperature at engine start | 10°C (14°F) or higher |
| Engine coolant temperature | 10 to 50°C (14 to 122°F) |
| Engine idling time | 3 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 3 km/h (1.875 mph) |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Accumulated time when ignition timing retard is cut off | 10 seconds or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P050B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P050B is output A P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 21 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Short FT #1 and Long FT #1. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
- INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. OK --> See step 14 NG --> See step 4
- REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S19667413492014050900000) . HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT --> See step 14
- CHECK PCV HOSE Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 2»(ref-615246-S35610607062014050900000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 10 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615245-S05242304412014050900000) . OK No leak in the air induction system. HINT: Perform "Inspection After Repair" after repairing or replacing the air induction system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 11 OK: Go to next step
- INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK The air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1 and VVT Change Angle #1]. Refer to «DATA LIST / ACTIVE TEST [05/2013 - 01/2014]»(ref-615234-S35938653532014050900000) . NG --> See step 13 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 8 gm/sec and 22 gm/sec (shift lever: N; A/C: Off). OK --> See step 14 NG --> See step 15
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 14
- REPAIR OR REPLACE AIR INDUCTION SYSTEM Repair or replace the air induction system. HINT: Perform "Inspection After Repair" after repairing or replacing the air induction system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT --> See step 14
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
- CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 15 A --> See step 22
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [05/2013 - ]»(ref-615109-S05659225472014050900000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-5 (VG) - B30-94 (VG) Always Below 1 ohms B2-4 (E2G) - B30-117 (E2G) Always Below 1 ohms B2-5 (VG) or B30-94 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S10339709762014050900000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. Perform "Inspection After Repair" after replacing the mass air flow meter. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 20 A --> END
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [05/2013 - 01/2014]»(ref-615234-S41552064272014050900000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
| Related DTCs | P050B: Cold start ignition timing performance |
| Required Sensors/Components (Main) | Throttle with motor body assembly |
| Required Sensors/Components (Related) | Mass air flow meter assembly Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust camshaft position sensor) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) P219A (Air fuel ratio imbalance) |
| Battery voltage | 8 V or higher |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| Engine coolant temperature at engine start | 10°C (14°F) or higher |
| Engine coolant temperature | 10 to 50°C (14 to 122°F) |
| Engine idling time | 3 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 3 km/h (1.875 mph) |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Accumulated time when ignition timing retard is cut off | 10 seconds or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P050B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P050B is output A P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 21 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Short FT #1 and Long FT #1. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
- INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. OK --> See step 14 NG --> See step 4
- REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S19667413492014050900000) . HINT: Perform "Inspection After Repair" after replacing the throttle with motor body assembly. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT --> See step 14
- CHECK PCV HOSE Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 2»(ref-615246-S35610607062014050900000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 10 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615245-S05242304412014050900000) . OK No leak in the air induction system. HINT: Perform "Inspection After Repair" after repairing or replacing the air induction system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NG --> See step 11 OK: Go to next step
- INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK The air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1 and VVT Change Angle #1]. Refer to «DATA LIST / ACTIVE TEST [01/2014 - ]»(ref-615234-S30683406662014050900000) . NG --> See step 13 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 8 gm/sec and 22 gm/sec (shift lever: N; A/C: Off). OK --> See step 14 NG --> See step 15
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 14
- REPAIR OR REPLACE AIR INDUCTION SYSTEM Repair or replace the air induction system. HINT: Perform "Inspection After Repair" after repairing or replacing the air induction system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT --> See step 14
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
- CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 15 A --> See step 22
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [05/2013 - ]»(ref-615109-S05659225472014050900000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-5 (VG) - B30-94 (VG) Always Below 1 ohms B2-4 (E2G) - B30-117 (E2G) Always Below 1 ohms B2-5 (VG) or B30-94 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [05/2013 - ]»(ref-615228-S10339709762014050900000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. Perform "Inspection After Repair" after replacing the mass air flow meter. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 20 A --> END
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [01/2014 - ]»(ref-615234-S09827197572014050900000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
| Related DTCs | P0560: ECM system voltage |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate (MIL illuminated after next engine start) |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Stand-by RAM | Initialized |
| ECM power source | Below 3.5 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0560.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 212
Scheme 212: WIRING DIAGRAM
- CHECK HARNESS AND CONNECTOR (ECM - BATTERY) Disconnect the ECM connector. Disconnect the cable from the positive (+) battery terminal. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A35-20 (BATT) - Battery positive (+) terminal Always Below 1 ohms A35-20 (BATT) or Battery positive (+) terminal - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT BATTERY Check that the battery is not depleted. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615240-S02525013702014050900000) . OK Battery is not depleted. NG --> REPLACE BATTERY OK: Go to next step
- CHECK BATTERY TERMINAL Check that the battery terminals are not loose or corroded. OK Battery terminals are not loose or corroded. NG --> REPAIR BATTERY TERMINAL OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0560 is output A No DTC is output B B --> See step 6 A --> See step 5
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
| Related DTCs | P0560: ECM system voltage |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate (MIL illuminated after next engine start) |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Stand-by RAM | Initialized |
| ECM power source | Below 3.5 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0560.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK HARNESS AND CONNECTOR (ECM - BATTERY) Disconnect the ECM connector. Disconnect the cable from the positive (+) battery terminal. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A35-20 (BATT) - Battery positive (+) terminal Always Below 1 ohms A35-20 (BATT) or Battery positive (+) terminal - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT BATTERY Check that the battery is not depleted. Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615240-S02525013702014050900000) . OK Battery is not depleted. NG --> REPLACE BATTERY OK: Go to next step
- CHECK BATTERY TERMINAL Check that the battery terminals are not loose or corroded. OK Battery terminals are not loose or corroded. NG --> REPAIR BATTERY TERMINAL OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0560 is output A No DTC is output B B --> See step 6 A --> See step 5
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | None |
| Frequency of operation | Continuous |
| Duration | 6 times |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Main CPU and sub CPU mirroring | Fail |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0604.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P0604 is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | None |
| Frequency of operation | Continuous |
| Duration | 6 times |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Main CPU and sub CPU mirroring | Fail |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0604.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P0604 is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
| Related DTC | P0606: ECM range check |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Within 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Time after ignition switch off to ON | More than 0.5 seconds |
| Starter | Off |
| Either condition A or B is met | |
| A. DMA communication | No response |
| B. Watchdog from monitoring processor | Not toggle |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 1 second or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0606.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 1 second or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P0606 is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
| Related DTC | P0606: ECM range check |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Within 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Time after ignition switch off to ON | More than 0.5 seconds |
| Starter | Off |
| Either condition A or B is met | |
| A. DMA communication | No response |
| B. Watchdog from monitoring processor | Not toggle |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 1 second or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0606.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 1 second or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P0606 is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
| Related DTCs | P0607: Control module performance |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | Heated oxygen sensor |
| Frequency of operation | Continuous |
| Duration | 60 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Engine | Running |
| Estimated heated oxygen sensor temperature | 450 to 750°C (842 to 1382°F) |
| Heated oxygen sensor transistors | Fail |
Scheme 213
Scheme 213: CONFIRMATION DRIVING PATTERN
- Stop the engine for 30 minutes or more [A].
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on [B].
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [C].
- Start the engine and wait 2 minutes [D].
- Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [E].
- Idle the engine for 1 minute [F].
- Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Drive the vehicle at a speed between 56 and 80 km/h (35 and 50 mph) for 5 minutes or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine / Trouble Codes [I].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0607, P0136, P0137 or P0138.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [I] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . RESULT Result Proceed to P0607 and P0136, P0137 or P0138 are output A Only P0607 is output B B --> See step 3 A: Go to next step
- INSPECT DTC (P0136, P0137 OR P0138) Refer to the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S38570565592014050900000) . Then proceed to "Inspect ECM". If P0137 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S38570565592014050900000) . Then proceed to "Inspect ECM". If P0138 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S38570565592014050900000) . Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT --> See step 6
- CHECK FOR EXHAUST GAS LEAK Allow the engine to idle, and then rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair them and proceed to "Perform Confirmation Driving Pattern". If no exhaust gas leaks are present, proceed to "Perform Confirmation Driving Pattern". HINT: If no exhaust gas leaks are present, there may be a malfunction in the heated oxygen sensor circuit. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Connect the Techstream to the DLC3. Start the engine. Warm up the engine until the engine coolant temperature becomes 75°C (167°F) or higher. Perform the driving pattern. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle. Drive the vehicle at a speed between 56 and 80 km/h (35 and 50 mph) for 5 minutes. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0607 and P0136, P0137 or P0138 are output A Only P0607 is output B No DTC is output C B --> See step 7 C --> See step 6 A: Go to next step
- INSPECT DTC (P0136, P0137 OR P0138) Refer to the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S38570565592014050900000) . Then proceed to "Inspect ECM". If P0137 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S38570565592014050900000) . Then proceed to "Inspect ECM". If P0138 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S38570565592014050900000) . Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT: Go to next step
- INSPECT ECM Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Stop the engine and wait for 30 minutes. Connect the Techstream to the DLC3. Start the engine and allow it to idle for 2 minutes. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Check the DTCs. RESULT Result Proceed to DTC is not output A P0607 is output B B --> See step 7 A --> END
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
| Related DTCs | P0607: Control module performance |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | Heated oxygen sensor |
| Frequency of operation | Continuous |
| Duration | 60 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Engine | Running |
| Estimated heated oxygen sensor temperature | 450 to 750°C (842 to 1382°F) |
| Heated oxygen sensor transistors | Fail |
- Stop the engine for 30 minutes or more [A].
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on [B].
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [C].
- Start the engine and wait 2 minutes [D].
- Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [E].
- Idle the engine for 1 minute [F].
- Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Drive the vehicle at a speed between 56 and 80 km/h (35 and 50 mph) for 5 minutes or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine / Trouble Codes [I].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0607, P0136, P0137 or P0138.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [I] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . RESULT Result Proceed to P0607 and P0136, P0137 or P0138 are output A Only P0607 is output B B --> See step 3 A: Go to next step
- INSPECT DTC (P0136, P0137 OR P0138) Refer to the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S06969229792014050900000) . Then proceed to "Inspect ECM". If P0137 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S06969229792014050900000) . Then proceed to "Inspect ECM". If P0138 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S06969229792014050900000) . Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT --> See step 6
- CHECK FOR EXHAUST GAS LEAK Allow the engine to idle, and then rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair them and proceed to "Perform Confirmation Driving Pattern". If no exhaust gas leaks are present, proceed to "Perform Confirmation Driving Pattern". HINT: If no exhaust gas leaks are present, there may be a malfunction in the heated oxygen sensor circuit. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [05/2013 - ]»(ref-615120-S07565023022014050900000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Connect the Techstream to the DLC3. Start the engine. Warm up the engine until the engine coolant temperature becomes 75°C (167°F) or higher. Perform the driving pattern. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle. Drive the vehicle at a speed between 56 and 80 km/h (35 and 50 mph) for 5 minutes. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0607 and P0136, P0137 or P0138 are output A Only P0607 is output B No DTC is output C B --> See step 7 C --> See step 6 A: Go to next step
- INSPECT DTC (P0136, P0137 OR P0138) Refer to the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S06969229792014050900000) . Then proceed to "Inspect ECM". If P0137 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S06969229792014050900000) . Then proceed to "Inspect ECM". If P0138 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2»(ref-615236-S06969229792014050900000) . Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT: Go to next step
- INSPECT ECM Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Stop the engine and wait for 30 minutes. Connect the Techstream to the DLC3. Start the engine and allow it to idle for 2 minutes. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Check the DTCs. RESULT Result Proceed to DTC is not output A P0607 is output B B --> See step 7 A --> END
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | |
| MIL operation | Immediate |
| Sequence of operation | None |
| When either condition below is met | Condition 1 or 2 |
| 1. When all conditions below are met | |
| CPU reset | 1 time or more |
| Learned throttle position - Learned accelerator pedal position | 0.4 V or higher |
| Electronic throttle actuator | OFF |
| 2. CPU reset | 2 times or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P060A is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | |
| MIL operation | Immediate |
| Sequence of operation | None |
| When either condition below is met | Condition 1 or 2 |
| 1. When all conditions below are met | |
| CPU reset | 1 time or more |
| Learned throttle position - Learned accelerator pedal position | 0.4 V or higher |
| Electronic throttle actuator | OFF |
| 2. CPU reset | 2 times or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P060A is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 2 times: Case 1 30 times: Case 2 and 3 |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
ECM MAIN CPU COMMUNICATION ERROR: CASE 1 AND CASE 2
| Monitor runs whenever following DTCs not stored | None |
| Both of the following conditions are met | |
| Battery voltage | 8 V or higher |
| Starter | Off |
ECM MAIN CPU COMMUNICATION ERROR: CASE 3
| Knock control sensor circuit | Fail |
| Knock control sensor serial communication | Fail |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. RESULT Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327 or P0328 are output C B --> See step 3 C --> See step 4 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
- GO TO DTC P0327 OR P0328. Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor)»(ref-615236-S36537401702014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 2 times: Case 1 30 times: Case 2 and 3 |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
ECM MAIN CPU COMMUNICATION ERROR: CASE 1 AND CASE 2
| Monitor runs whenever following DTCs not stored | None |
| Both of the following conditions are met | |
| Battery voltage | 8 V or higher |
| Starter | Off |
ECM MAIN CPU COMMUNICATION ERROR: CASE 3
| Knock control sensor circuit | Fail |
| Knock control sensor serial communication | Fail |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. RESULT Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327 or P0328 are output C B --> See step 3 C --> See step 4 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
- GO TO DTC P0327 OR P0328. Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor)»(ref-615236-S34003911702014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 1 second |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Difference of main accelerator pedal position and sub accelerator pedal position | 0.3 V or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P060D is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 1 second |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Difference of main accelerator pedal position and sub accelerator pedal position | 0.3 V or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P060D is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 1 second: Throttle sensor fail 13 times: Brake switch signal fail |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
| DMA communication error | Not detected |
| When one of following conditions is met | Condition 1 or 2 |
| 1. Difference of main throttle position and sub throttle position | 0.3 V or more |
| 2. Stop light switch signal (CPU) and stop light switch signal (Monitor IC) | Different |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060E.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P060E is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 1 second: Throttle sensor fail 13 times: Brake switch signal fail |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
| DMA communication error | Not detected |
| When one of following conditions is met | Condition 1 or 2 |
| 1. Difference of main throttle position and sub throttle position | 0.3 V or more |
| 2. Stop light switch signal (CPU) and stop light switch signal (Monitor IC) | Different |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060E.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P060E is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
| Related DTCs | P0617: Starter signal |
| Required Sensors/Components (Main) | Starter relay (ST), Park/neutral position switch assembly, Clutch pedal switch assembly (for clutch start system), Ignition switch assembly, Power source control ECU |
| Required Sensors/Components (Related) | Speed sensor, Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 20 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | 20 km/h (12.43 mph) or more |
| Engine speed | 1000 rpm or more |
Scheme 214
Scheme 214: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Idle the engine for 5 seconds or more [B].
- Drive the vehicle at 24 km/h (15 mph) or more for 20 seconds or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0617.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 215
Scheme 215: WIRING DIAGRAM
Scheme 216
- READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Starter Signal. Check the value displayed on the Techstream when the ignition switch is turned to ON and when the engine is started. OK Condition Starter Signal Ignition switch turned to ON Close Engine started Open RESULT Result Proceed to OK A NG (for Automatic Transaxle) B NG (for Manual Transaxle) C B --> See step 2 C --> See step 5 A --> See step 8
- INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the park/neutral position switch assembly. Refer to «INSPECTION [05/2013 - ]»(ref-615232-S12101033632014050900000) . NG --> See step 9 OK: Go to next step
- REPAIR OR REPLACE HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Drive the vehicle at more than 24 km/h (15 mph) for more than 20 seconds. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0617 is output A No DTC is output B B --> END A --> See step 10
- INSPECT CLUTCH PEDAL SWITCH ASSEMBLY (FOR CLUTCH START SYSTEM) Inspect the clutch pedal switch assembly (for clutch start system). Refer to «INSPECTION [05/2013 - ]»(ref-615242-S20780142122014050900000) . NG --> See step 11 OK: Go to next step
- REPAIR OR REPLACE HARNESS AND CONNECTOR (CLUTCH PEDAL SWITCH - ECM) NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Drive the vehicle at more than 24 km/h (15 mph) for more than 20 seconds. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0617 is output A No DTC is output B B --> END A --> See step 12
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
- REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615232-S41430119042014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
- REPLACE CLUTCH PEDAL SWITCH ASSEMBLY (FOR CLUTCH START SYSTEM). Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615242-S03674012242014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
| Related DTCs | P0617: Starter signal |
| Required Sensors/Components (Main) | Starter relay (ST), Park/neutral position switch assembly, Clutch pedal switch assembly (for clutch start system), Ignition switch assembly, Power source control ECU |
| Required Sensors/Components (Related) | Speed sensor, Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 20 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | 20 km/h (12.43 mph) or more |
| Engine speed | 1000 rpm or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Idle the engine for 5 seconds or more [B].
- Drive the vehicle at 24 km/h (15 mph) or more for 20 seconds or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0617.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Starter Signal. Check the value displayed on the Techstream when the ignition switch is turned to ON and when the engine is started. OK Condition Starter Signal Ignition switch turned to ON Close Engine started Open RESULT Result Proceed to OK A NG (for Automatic Transaxle) B NG (for Manual Transaxle) C B --> See step 2 C --> See step 5 A --> See step 8
- INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the park/neutral position switch assembly. Refer to «INSPECTION [05/2013 - ]»(ref-615232-S12101033632014050900000) . NG --> See step 9 OK: Go to next step
- REPAIR OR REPLACE HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Drive the vehicle at more than 24 km/h (15 mph) for more than 20 seconds. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0617 is output A No DTC is output B B --> END A --> See step 10
- INSPECT CLUTCH PEDAL SWITCH ASSEMBLY (FOR CLUTCH START SYSTEM) Inspect the clutch pedal switch assembly (for clutch start system). Refer to «INSPECTION [05/2013 - ]»(ref-615242-S20780142122014050900000) . NG --> See step 11 OK: Go to next step
- REPAIR OR REPLACE HARNESS AND CONNECTOR (CLUTCH PEDAL SWITCH - ECM) NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Drive the vehicle at more than 24 km/h (15 mph) for more than 20 seconds. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0617 is output A No DTC is output B B --> END A --> See step 12
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
- REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615232-S41430119042014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
- REPLACE CLUTCH PEDAL SWITCH ASSEMBLY (FOR CLUTCH START SYSTEM). Refer to «REMOVAL [01/2014 - ]»(ref-615242-S11405931282014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
| Related DTCs | P062F: Internal control module EEPROM error |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 3 times |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Permanent fault code data | Mismatch (3 times or more) |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 30 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P062F.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 30 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to No DTC is output A DTC P062F is output B B --> See step 2 A --> See step 3
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
| Related DTCs | P062F: Internal control module EEPROM error |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 3 times |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Permanent fault code data | Mismatch (3 times or more) |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 30 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P062F.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 30 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to No DTC is output A DTC P062F is output B B --> See step 2 A --> See step 3
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
| Related DTCs | P0630: VIN not programmed |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.325 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
COMPONENT OPERATING RANGE
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0630.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ CURRENT DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0630 is output A P0630 and other DTCs are output B HINT: If any DTCs other than P0630 are output, troubleshoot those DTCs first. NOTE: If P0630 is stored, the VIN must be input to the ECM using the Techstream. However, all DTCs are cleared automatically by the Techstream when the VIN is input. If DTCs other than P0630 are output, troubleshoot them first. B --> See step 3 A: Go to next step
- INPUT VIN WITH TECHSTREAM Refer to Registration. Refer to «REGISTRATION [05/2013 - ]»(ref-615120-S10374678432014050900000) . NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [05/2013 - 01/2014]»(ref-615234-S41552064272014050900000)
| Related DTCs | P0630: VIN not programmed |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.325 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0630.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ CURRENT DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0630 is output A P0630 and other DTCs are output B HINT: If any DTCs other than P0630 are output, troubleshoot those DTCs first. NOTE: If P0630 is stored, the VIN must be input to the ECM using the Techstream. However, all DTCs are cleared automatically by the Techstream when the VIN is input. If DTCs other than P0630 are output, troubleshoot them first. B --> See step 3 A: Go to next step
- INPUT VIN WITH TECHSTREAM Refer to Registration. Refer to «REGISTRATION [05/2013 - ]»(ref-615120-S10374678432014050900000) . NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [01/2014 - ]»(ref-615234-S09827197572014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | |
| MIL operation | Immediate |
| Sequence of operation | None |
| Throttle actuator power supply voltage | 7 V or higher |
| Ignition switch | From ON to off (Temporary Fail ON) |
| Throttle actuator power supply | ON |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Turn the ignition switch to ON.
- Wait 10 seconds or more.
- Turn the ignition switch off.
- Wait 15 seconds or more.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0657.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [05/2013 - 01/2014]»(ref-615120-S02653872462014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Wait 10 seconds or more. Turn the ignition switch off. Wait 15 seconds or more. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P0657 is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [05/2013 - 01/2014]»(ref-615120-S09573425712014050900000)
- REPLACE ECM. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615228-S17169059992014050900000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | |
| MIL operation | Immediate |
| Sequence of operation | None |
| Throttle actuator power supply voltage | 7 V or higher |
| Ignition switch | From ON to off (Temporary Fail ON) |
| Throttle actuator power supply | ON |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Turn the ignition switch to ON.
- Wait 10 seconds or more.
- Turn the ignition switch off.
- Wait 15 seconds or more.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0657.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [01/2014 - ]»(ref-615120-S08989089142014050900000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Wait 10 seconds or more. Turn the ignition switch off. Wait 15 seconds or more. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P0657 is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [01/2014 - ]»(ref-615120-S17089150332014050900000)
- REPLACE ECM. Refer to «REMOVAL [01/2014 - ]»(ref-615228-S24796868852014050900000)
