Engine Control System (Diagnostic Codes (P0010-P0128)): Overview Scion tC II рестайлинг

DESCRIPTION

1. This DTC is designed to detect opens or shorts in the camshaft timing oil control valve circuit. If the camshaft timing oil control valve duty cycle is excessively high or low while the engine is running, the ECM will illuminate the MIL and store the DTC.
2. The VVT (variable valve timing) system adjusts the intake and exhaust valve timing to improve driveability. The engine oil pressure turns the camshaft timing gear to adjust the valve timing. The camshaft timing oil control valve is a solenoid valve and switches the engine oil line. The valve moves when the ECM applies 12 V to the solenoid. The ECM changes the energizing time of the solenoid (duty cycle) in accordance with the camshaft position, crankshaft position, throttle position, etc.

Scheme 160

HINT

This DTC relates to the camshaft timing oil control valve.

MONITOR DESCRIPTION

This DTC is designed to detect opens or shorts in the camshaft timing oil control valve circuit. If the camshaft timing oil control valve duty cycle is excessively high or low while the engine is running, the ECM will illuminate the MIL and store the DTC.

1. This DTC is designed to detect opens or shorts in the camshaft timing oil control valve circuit. If the camshaft timing oil control valve duty cycle is excessively high or low while the engine is running, the ECM will illuminate the MIL and store the DTC.
2. The VVT (variable valve timing) system adjusts the intake and exhaust valve timing to improve driveability. The engine oil pressure turns the camshaft timing gear to adjust the valve timing. The camshaft timing oil control valve is a solenoid valve and switches the engine oil line. The valve moves when the ECM applies 12 V to the solenoid. The ECM changes the energizing time of the solenoid (duty cycle) in accordance with the camshaft position, crankshaft position, throttle position, etc.

HINT

This DTC relates to the camshaft timing oil control valve.

This DTC is designed to detect opens or shorts in the camshaft timing oil control valve circuit. If the camshaft timing oil control valve duty cycle is excessively high or low while the engine is running, the ECM will illuminate the MIL and store the DTC.

The VVT system includes the ECM, camshaft timing oil control valve and VVT controller. The ECM sends a target duty cycle control signal to the camshaft timing oil control valve. This control signal regulates the oil pressure supplied to the VVT controller. Camshaft timing control is performed according to engine operating conditions such as the intake air volume, throttle valve position and engine coolant temperature. The ECM controls the camshaft timing oil control valve based on the signals transmitted by several sensors. The VVT controller regulates the intake camshaft angle using oil pressure through the camshaft timing oil control valve. As a result, the relative positions of the camshaft and crankshaft are optimized, the engine torque and fuel economy improve, and the exhaust emissions decrease under overall driving conditions. The ECM detects the actual intake valve timing using signals from the camshaft and crankshaft position sensors and performs feedback control. This is how the target intake valve timing is verified by the ECM.

1. The ECM optimizes the intake valve timing using the VVT (Variable Valve Timing) system to control the intake camshaft. The VVT system includes the ECM, camshaft timing oil control valve and VVT controller. The ECM sends a target duty cycle control signal to the camshaft timing oil control valve. This control signal regulates the oil pressure supplied to the VVT controller. The VVT controller can advance or retard the intake camshaft.
2. If the difference between the target and actual intake valve timing is large, and changes in the actual intake valve timing are small, the ECM interprets this as a VVT controller being stuck and stores a DTC.

1. Example
2. A DTC is stored when the following conditions 1 and 2 are met: 1. It takes 5 seconds or more to change the valve timing by 5°CA. 2. After condition 1 is met, the camshaft timing oil control valve is forcibly activated for 10 seconds.
3. These DTCs indicate that the VVT controller cannot operate properly due to camshaft timing oil control valve malfunctions or the presence of foreign objects in the camshaft timing oil control valve.

The VVT system includes the ECM, camshaft timing oil control valve and VVT controller. The ECM sends a target duty cycle control signal to the camshaft timing oil control valve. This control signal regulates the oil pressure supplied to the VVT controller. Camshaft timing control is performed according to engine operating conditions such as the intake air volume, throttle valve position and engine coolant temperature. The ECM controls the camshaft timing oil control valve based on the signals transmitted by several sensors. The VVT controller regulates the intake camshaft angle using oil pressure through the camshaft timing oil control valve. As a result, the relative positions of the camshaft and crankshaft are optimized, the engine torque and fuel economy improve, and the exhaust emissions decrease under overall driving conditions. The ECM detects the actual intake valve timing using signals from the camshaft and crankshaft position sensors and performs feedback control. This is how the target intake valve timing is verified by the ECM.

1. The ECM optimizes the intake valve timing using the VVT (Variable Valve Timing) system to control the intake camshaft. The VVT system includes the ECM, camshaft timing oil control valve and VVT controller. The ECM sends a target duty cycle control signal to the camshaft timing oil control valve. This control signal regulates the oil pressure supplied to the VVT controller. The VVT controller can advance or retard the intake camshaft.
2. If the difference between the target and actual intake valve timing is large, and changes in the actual intake valve timing are small, the ECM interprets this as a VVT controller being stuck and stores a DTC.

1. Example
2. A DTC is stored when the following conditions 1 and 2 are met: 1. It takes 5 seconds or more to change the valve timing by 5°CA. 2. After condition 1 is met, the camshaft timing oil control valve is forcibly activated for 10 seconds.
3. These DTCs indicate that the VVT controller cannot operate properly due to camshaft timing oil control valve malfunctions or the presence of foreign objects in the camshaft timing oil control valve.

1. This DTC is designed to detect opens or shorts in the camshaft timing oil control valve circuit. If the camshaft timing oil control valve duty cycle is excessively high or low while the engine is running, the ECM will illuminate the MIL and store the DTC.
2. The VVT (Variable Valve Timing) system adjusts the intake and exhaust valve timing to improve driveability. The engine oil pressure turns the camshaft timing gear to adjust the valve timing. The camshaft timing oil control valve is a solenoid valve and switches the engine oil line. The valve moves when the ECM applies 12 volts to the solenoid. The ECM changes the energizing time of the solenoid (duty cycle) in accordance with the camshaft position, crankshaft position, throttle position, etc.

Scheme 161

This DTC is designed to detect opens or shorts in the camshaft timing oil control valve circuit. If the camshaft timing oil control valve duty cycle is excessively high or low while the engine is running, the ECM will illuminate the MIL and store the DTC.

1. This DTC is designed to detect opens or shorts in the camshaft timing oil control valve circuit. If the camshaft timing oil control valve duty cycle is excessively high or low while the engine is running, the ECM will illuminate the MIL and store the DTC.
2. The VVT (Variable Valve Timing) system adjusts the intake and exhaust valve timing to improve driveability. The engine oil pressure turns the camshaft timing gear to adjust the valve timing. The camshaft timing oil control valve is a solenoid valve and switches the engine oil line. The valve moves when the ECM applies 12 volts to the solenoid. The ECM changes the energizing time of the solenoid (duty cycle) in accordance with the camshaft position, crankshaft position, throttle position, etc.

This DTC is designed to detect opens or shorts in the camshaft timing oil control valve circuit. If the camshaft timing oil control valve duty cycle is excessively high or low while the engine is running, the ECM will illuminate the MIL and store the DTC.

HINT

If DTC P0014 or P0015 is output, check the VVT (Variable Valve Timing) system.

The Variable Valve Timing (VVT) system includes the ECM, camshaft timing oil control valve and VVT controller. The ECM sends a target duty cycle control signal to the camshaft timing oil control valve. This control signal regulates the oil pressure supplied to the VVT controller. Camshaft timing control is performed according to engine operating conditions such as the intake air volume, throttle valve position and engine coolant temperature. The ECM controls the camshaft timing oil control valve based on the signals transmitted by several sensors. The VVT controller regulates the exhaust camshaft angle using oil pressure through the camshaft timing oil control valve. As a result, the relative positions of the camshaft and crankshaft are optimized, the engine torque and fuel economy improve, and the exhaust emissions decrease under overall driving conditions. The ECM detects the actual exhaust valve timing using signals from the camshaft and crankshaft position sensors and performs feedback control. This is how the target exhaust valve timing is verified by the ECM.

1. The ECM optimizes the exhaust valve timing using the VVT (Variable Valve Timing) system to control the exhaust camshaft. The VVT system includes the ECM, camshaft timing oil control valve and VVT controller. The ECM sends a target duty cycle control signal to the camshaft timing oil control valve. This control signal regulates the oil pressure supplied to the VVT controller. The VVT controller can advance or retard the exhaust camshaft.
2. If the difference between the target and actual exhaust valve timing is large, and changes in actual exhaust valve timing are small, the ECM interprets this as a VVT controller being stuck and stores a DTC.

1. Example
2. A DTC is stored when the following conditions 1 and 2 are met: 1. It takes 5 seconds or more to change the valve timing by 5°CA. 2. After condition 1 is met, the camshaft timing oil control valve is forcibly activated for 10 seconds.
3. These DTCs indicate that the VVT controller cannot operate properly due to camshaft timing oil control valve malfunctions or the presence of foreign objects in the camshaft timing oil control valve.

HINT

If DTC P0014 or P0015 is output, check the VVT (Variable Valve Timing) system.

The Variable Valve Timing (VVT) system includes the ECM, camshaft timing oil control valve and VVT controller. The ECM sends a target duty cycle control signal to the camshaft timing oil control valve. This control signal regulates the oil pressure supplied to the VVT controller. Camshaft timing control is performed according to engine operating conditions such as the intake air volume, throttle valve position and engine coolant temperature. The ECM controls the camshaft timing oil control valve based on the signals transmitted by several sensors. The VVT controller regulates the exhaust camshaft angle using oil pressure through the camshaft timing oil control valve. As a result, the relative positions of the camshaft and crankshaft are optimized, the engine torque and fuel economy improve, and the exhaust emissions decrease under overall driving conditions. The ECM detects the actual exhaust valve timing using signals from the camshaft and crankshaft position sensors and performs feedback control. This is how the target exhaust valve timing is verified by the ECM.

1. The ECM optimizes the exhaust valve timing using the VVT (Variable Valve Timing) system to control the exhaust camshaft. The VVT system includes the ECM, camshaft timing oil control valve and VVT controller. The ECM sends a target duty cycle control signal to the camshaft timing oil control valve. This control signal regulates the oil pressure supplied to the VVT controller. The VVT controller can advance or retard the exhaust camshaft.
2. If the difference between the target and actual exhaust valve timing is large, and changes in actual exhaust valve timing are small, the ECM interprets this as a VVT controller being stuck and stores a DTC.

1. Example
2. A DTC is stored when the following conditions 1 and 2 are met: 1. It takes 5 seconds or more to change the valve timing by 5°CA. 2. After condition 1 is met, the camshaft timing oil control valve is forcibly activated for 10 seconds.
3. These DTCs indicate that the VVT controller cannot operate properly due to camshaft timing oil control valve malfunctions or the presence of foreign objects in the camshaft timing oil control valve.

In the VVT (Variable Valve Timing) system, the appropriate intake and exhaust valve open and close timing is controlled by the ECM. The ECM performs intake and exhaust valve control by performing the following: 1) controlling the camshaft and camshaft timing oil control valve, and operating the camshaft timing gear; and 2) changing the relative positions of the camshaft and crankshaft.

To monitor the correlation of the intake camshaft position and crankshaft position, the ECM checks the VVT learned value while the engine is idling. The VVT learned value is calibrated based on the camshaft position and crankshaft position. The intake valve timing is set to the most retarded angle while the engine is idling. If the VVT learned value is out of the specified range in consecutive driving cycles, the ECM illuminates the MIL and stores DTC P0016.

To monitor the correlation of the exhaust camshaft position and crankshaft position, the ECM checks the VVT learned value while the engine is idling. The VVT learned value is calibrated based on the camshaft position and crankshaft position. The exhaust valve timing is set to the most advanced angle while the engine is idling. If the VVT learned value is out of the specified range in consecutive driving cycles, the ECM illuminates the MIL and stores DTC P0017.

In the VVT (Variable Valve Timing) system, the appropriate intake and exhaust valve open and close timing is controlled by the ECM. The ECM performs intake and exhaust valve control by performing the following: 1) controlling the camshaft and camshaft timing oil control valve, and operating the camshaft timing gear; and 2) changing the relative positions of the camshaft and crankshaft.

To monitor the correlation of the intake camshaft position and crankshaft position, the ECM checks the VVT learned value while the engine is idling. The VVT learned value is calibrated based on the camshaft position and crankshaft position. The intake valve timing is set to the most retarded angle while the engine is idling. If the VVT learned value is out of the specified range in consecutive driving cycles, the ECM illuminates the MIL and stores DTC P0016.

To monitor the correlation of the exhaust camshaft position and crankshaft position, the ECM checks the VVT learned value while the engine is idling. The VVT learned value is calibrated based on the camshaft position and crankshaft position. The exhaust valve timing is set to the most advanced angle while the engine is idling. If the VVT learned value is out of the specified range in consecutive driving cycles, the ECM illuminates the MIL and stores DTC P0017.

Refer to DTC P2195. Refer to DESCRIPTION .

HINT

Scheme 162

1. Although the DTC titles say oxygen sensor, these DTCs relate to the air fuel ratio sensor.
2. Sensor 1 refers to the sensor mounted in front of the Three-way Catalytic Converter (TWC) and located near the engine assembly.
3. When one of these DTCs is stored, the ECM enters fail-safe mode. The ECM turns off the air fuel ratio sensor heater in fail-safe mode. The ECM continues operating in fail-safe mode until the ignition switch is turned off.
4. The ECM provides a pulse-width modulated control circuit to adjust the current through the heater. The air fuel ratio sensor heater circuit uses a relay on the +B side of the circuit.

The ECM uses information from the air fuel ratio sensor to regulate the air-fuel ratio and keep it close to the stoichiometric level. This maximizes the ability of the Three-way Catalytic Converter (TWC) to purify the exhaust gases.

The air fuel ratio sensor detects oxygen levels in the exhaust gas and transmits the information to the ECM. The inner surface of the sensor element is exposed to the outside air. The outer surface of the sensor element is exposed to the exhaust gas. The sensor element is made of platinum coated zirconia and includes an integrated heating element.

The zirconia element generates a small voltage when there is a large difference in the oxygen concentrations between the exhaust gas and outside air. The platinum coating amplifies this voltage generation.

The air fuel ratio sensor is more efficient when heated. When the exhaust gas temperature is low, the sensor cannot generate useful voltage signals without supplementary heating. The ECM regulates the supplementary heating using a duty cycle approach to adjust the average current in the sensor heater element. If the heater current is outside the normal range, the signal transmitted by the air fuel ratio sensor becomes inaccurate. As a result, the ECM is unable to regulate the air-fuel ratio properly.

When the current in the air fuel ratio sensor heater is outside the normal operating range, the ECM interprets this as a malfunction in the sensor heater and stores a DTC.

Refer to DTC P2195. Refer to DESCRIPTION .

HINT

1. Although the DTC titles say oxygen sensor, these DTCs relate to the air fuel ratio sensor.
2. Sensor 1 refers to the sensor mounted in front of the Three-way Catalytic Converter (TWC) and located near the engine assembly.
3. When one of these DTCs is stored, the ECM enters fail-safe mode. The ECM turns off the air fuel ratio sensor heater in fail-safe mode. The ECM continues operating in fail-safe mode until the ignition switch is turned off.
4. The ECM provides a pulse-width modulated control circuit to adjust the current through the heater. The air fuel ratio sensor heater circuit uses a relay on the +B side of the circuit.

The ECM uses information from the air fuel ratio sensor to regulate the air-fuel ratio and keep it close to the stoichiometric level. This maximizes the ability of the Three-way Catalytic Converter (TWC) to purify the exhaust gases.

The air fuel ratio sensor detects oxygen levels in the exhaust gas and transmits the information to the ECM. The inner surface of the sensor element is exposed to the outside air. The outer surface of the sensor element is exposed to the exhaust gas. The sensor element is made of platinum coated zirconia and includes an integrated heating element.

The zirconia element generates a small voltage when there is a large difference in the oxygen concentrations between the exhaust gas and outside air. The platinum coating amplifies this voltage generation.

The air fuel ratio sensor is more efficient when heated. When the exhaust gas temperature is low, the sensor cannot generate useful voltage signals without supplementary heating. The ECM regulates the supplementary heating using a duty cycle approach to adjust the average current in the sensor heater element. If the heater current is outside the normal range, the signal transmitted by the air fuel ratio sensor becomes inaccurate. As a result, the ECM is unable to regulate the air-fuel ratio properly.

When the current in the air fuel ratio sensor heater is outside the normal operating range, the ECM interprets this as a malfunction in the sensor heater and stores a DTC.

Refer to DTC P0136. Refer to DESCRIPTION.

HINT

Scheme 163

1. When any of these DTCs is stored, the ECM enters fail-safe mode. The ECM turns off the heated oxygen sensor heater in fail-safe mode. The ECM continues operating in fail-safe mode until the ignition switch is turned off.
2. The ECM provides a pulse-width modulated control circuit to adjust the current through the heater. The heated oxygen sensor heater circuit uses a relay on the +B side of the circuit.

The sensing portion of the heated oxygen sensor has a zirconia element which is used to detect the oxygen concentration in the exhaust gas. If the zirconia element is at the appropriate temperature and the difference between the oxygen concentrations surrounding the inside and outside surfaces of the sensor is large, the zirconia element generates voltage signals. In order to increase the oxygen concentration detecting capacity of the zirconia element, the ECM supplements the heat from the exhaust with heat from a heating element inside the sensor.

Heated oxygen sensor heater range check (P0037, P0038 and P102D)

The ECM monitors the current applied to the heated oxygen sensor heater to check the heater for malfunctions.

If the heater current is outside the normal range, the signal transmitted by the heated oxygen sensor becomes inaccurate. When the current in the heated oxygen sensor heater is outside the normal operating range, the ECM interprets this as a malfunction in the sensor heater and stores a DTC.

Heated oxygen sensor heater performance (P0141)

After the accumulated heater ON time exceeds 100 seconds, the ECM calculates the heater resistance using the battery voltage and the current applied to the heater.

If the resistance is above the threshold value, the ECM determines that there is a malfunction in the heated oxygen sensor heater and stores DTC P0141.

HINT

Normally, the heated oxygen sensor current is 0.4 to 1 A (when the engine is idling, the heated oxygen sensor is warmed up and battery voltage is 11 to 14 V).

Refer to DTC P0136. Refer to DESCRIPTION.

HINT

1. When any of these DTCs is stored, the ECM enters fail-safe mode. The ECM turns off the heated oxygen sensor heater in fail-safe mode. The ECM continues operating in fail-safe mode until the ignition switch is turned off.
2. The ECM provides a pulse-width modulated control circuit to adjust the current through the heater. The heated oxygen sensor heater circuit uses a relay on the +B side of the circuit.

The sensing portion of the heated oxygen sensor has a zirconia element which is used to detect the oxygen concentration in the exhaust gas. If the zirconia element is at the appropriate temperature and the difference between the oxygen concentrations surrounding the inside and outside surfaces of the sensor is large, the zirconia element generates voltage signals. In order to increase the oxygen concentration detecting capacity of the zirconia element, the ECM supplements the heat from the exhaust with heat from a heating element inside the sensor.

Heated oxygen sensor heater range check (P0037, P0038 and P102D)

The ECM monitors the current applied to the heated oxygen sensor heater to check the heater for malfunctions.

If the heater current is outside the normal range, the signal transmitted by the heated oxygen sensor becomes inaccurate. When the current in the heated oxygen sensor heater is outside the normal operating range, the ECM interprets this as a malfunction in the sensor heater and stores a DTC.

Heated oxygen sensor heater performance (P0141)

After the accumulated heater ON time exceeds 100 seconds, the ECM calculates the heater resistance using the battery voltage and the current applied to the heater.

If the resistance is above the threshold value, the ECM determines that there is a malfunction in the heated oxygen sensor heater and stores DTC P0141.

HINT

Normally, the heated oxygen sensor current is 0.4 to 1 A (when the engine is idling, the heated oxygen sensor is warmed up and battery voltage is 11 to 14 V).

Refer to DTC P0102. Refer to DESCRIPTION.

The mass air flow meter is a sensor that measures the amount of air flowing through the throttle valve. The ECM uses this information to determine the fuel injection time and to provide an appropriate air-fuel ratio. Inside the mass air flow meter, there is a heated platinum wire which is exposed to the flow of intake air. By applying a specific electrical current to the wire, the ECM heats it to a specific temperature. The flow of incoming air cools both the wire and an internal thermistor, affecting their resistance. To maintain a constant current value, the ECM varies the voltage applied to the wire and internal thermistor. The voltage level is proportional to the airflow through the sensor and the ECM uses it to calculate the intake air volume.

The ECM monitors the average engine load ratio to check the mass air flow meter for malfunctions. The average engine load ratio is obtained by comparing the average engine load calculated from the mass air flow meter output to the average engine load estimated from the driving conditions, such as the engine speed and throttle valve opening angle. If the average engine load ratio is below the threshold value, the ECM determines that the intake air volume is low, and if the average engine load ratio is above the threshold value, the ECM determines that the intake air volume is high.

If this is detected in 2 consecutive driving cycles, the MIL is illuminated and a DTC is stored.

Refer to DTC P0102. Refer to DESCRIPTION.

The mass air flow meter is a sensor that measures the amount of air flowing through the throttle valve. The ECM uses this information to determine the fuel injection time and to provide an appropriate air-fuel ratio. Inside the mass air flow meter, there is a heated platinum wire which is exposed to the flow of intake air. By applying a specific electrical current to the wire, the ECM heats it to a specific temperature. The flow of incoming air cools both the wire and an internal thermistor, affecting their resistance. To maintain a constant current value, the ECM varies the voltage applied to the wire and internal thermistor. The voltage level is proportional to the airflow through the sensor and the ECM uses it to calculate the intake air volume.

The ECM monitors the average engine load ratio to check the mass air flow meter for malfunctions. The average engine load ratio is obtained by comparing the average engine load calculated from the mass air flow meter output to the average engine load estimated from the driving conditions, such as the engine speed and throttle valve opening angle. If the average engine load ratio is below the threshold value, the ECM determines that the intake air volume is low, and if the average engine load ratio is above the threshold value, the ECM determines that the intake air volume is high.

If this is detected in 2 consecutive driving cycles, the MIL is illuminated and a DTC is stored.

The mass air flow meter is a sensor that measures the amount of air flowing through the throttle valve.

The ECM uses this information to determine the fuel injection time and to provide the appropriate air-fuel ratio.

Inside the mass air flow meter, there is a heated platinum wire which is exposed to the flow of intake air.

By applying a specific electrical current to the wire, the ECM heats it to a given temperature. The flow of incoming air cools both the wire and an internal thermistor, affecting their resistance. To maintain a constant current value, the ECM varies the voltage applied to the wire and internal thermistor. The voltage level is proportional to the airflow through the sensor, and the ECM uses it to calculate the intake air volume.

The circuit is constructed so that the platinum hot wire and temperature sensor create a bridge circuit, and the power transistor is controlled so that the potentials of A and B remain equal to maintain the predetermined temperature.

HINT

When either of these DTCs is stored, the ECM enters fail-safe mode. During fail-safe mode, the ignition timing is calculated by the ECM according to the engine speed and throttle valve position. The ECM continues operating in fail-safe mode until a pass condition is detected.

Scheme 164

HINT

When either of these DTCs is stored, check the air flow rate by entering the following menus: Powertrain / Engine / Data List / All Data / MAF.

If there is a defect in the mass air flow meter or an open or short circuit, the voltage level deviates from the normal operating range. The ECM interprets this deviation as a malfunction in the mass air flow meter and stores a DTC.

Example

When the sensor output voltage remains below 0.2 V, or higher than 4.9 V for more than 3 seconds, the ECM stores a DTC.

If the malfunction is not repaired successfully, a DTC is stored 3 seconds after the engine is next started.

The mass air flow meter is a sensor that measures the amount of air flowing through the throttle valve.

The ECM uses this information to determine the fuel injection time and to provide the appropriate air-fuel ratio.

Inside the mass air flow meter, there is a heated platinum wire which is exposed to the flow of intake air.

By applying a specific electrical current to the wire, the ECM heats it to a given temperature. The flow of incoming air cools both the wire and an internal thermistor, affecting their resistance. To maintain a constant current value, the ECM varies the voltage applied to the wire and internal thermistor. The voltage level is proportional to the airflow through the sensor, and the ECM uses it to calculate the intake air volume.

The circuit is constructed so that the platinum hot wire and temperature sensor create a bridge circuit, and the power transistor is controlled so that the potentials of A and B remain equal to maintain the predetermined temperature.

HINT

When either of these DTCs is stored, the ECM enters fail-safe mode. During fail-safe mode, the ignition timing is calculated by the ECM according to the engine speed and throttle valve position. The ECM continues operating in fail-safe mode until a pass condition is detected.

HINT

When either of these DTCs is stored, check the air flow rate by entering the following menus: Powertrain / Engine / Data List / All Data / MAF.

If there is a defect in the mass air flow meter or an open or short circuit, the voltage level deviates from the normal operating range. The ECM interprets this deviation as a malfunction in the mass air flow meter and stores a DTC.

Example

When the sensor output voltage remains below 0.2 V, or higher than 4.9 V for more than 3 seconds, the ECM stores a DTC.

If the malfunction is not repaired successfully, a DTC is stored 3 seconds after the engine is next started.

The ECM performs OBD II monitoring based on the values from the intake air temperature sensor. If there is no change of the sensor value within the normal range, the ECM will not be able to perform OBD II monitoring or will misdiagnose that there is a malfunction in the sensor. The ECM detects when the intake air temperature sensor value is stuck by performing monitoring after the ignition switch is turned off or the engine is started (short soak or long soak).

1. The intake air temperature sensor, mounted on the mass air flow meter, monitors the intake air temperature. The intake air temperature sensor has a built-in thermistor with a resistance that varies according to the temperature of the intake air. When the intake air temperature is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes (Scheme 160)
2. The intake air temperature sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R.
3. Resistor R and the intake air temperature sensor are connected in series. When the resistance value of the intake air temperature sensor changes according to changes in the intake air temperature, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve driveability.

The ECM performs OBD II monitoring based on the values from the intake air temperature sensor. If there is no change of the sensor value within the normal range, the ECM will not be able to perform OBD II monitoring or will misdiagnose that there is a malfunction in the sensor. The ECM detects when the intake air temperature sensor value is stuck by performing monitoring after the ignition switch is turned off or the engine is started (short soak or long soak).

The ECM monitors the sensor voltage and uses this value to calculate the intake air temperature. When the sensor output voltage deviates from the normal operating range, the ECM interprets this as a malfunction in the intake air temperature sensor and stores a DTC.

Example

If the sensor output voltage is higher than 4.91 V for 0.5 seconds or more, the ECM determines that there is an open in the intake air temperature sensor circuit and stores DTC P0113. Conversely, if the output voltage is below 0.18 V for 0.5 seconds or more, the ECM determines that there is a short in the sensor circuit and stores DTC P0112.

If the malfunction is not repaired successfully, a DTC is stored 0.5 seconds after the engine is next started.

1. The intake air temperature sensor, mounted on the mass air flow meter, monitors the intake air temperature. The intake air temperature sensor has a built-in thermistor with a resistance that varies according to the temperature of the intake air. When the intake air temperature is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes (Scheme 160)
2. The intake air temperature sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R.
3. Resistor R and the intake air temperature sensor are connected in series. When the resistance value of the intake air temperature sensor changes according to changes in the intake air temperature, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve driveability. HINT: When DTC P0112 or P0113 is stored, the ECM enters fail-safe mode. During fail-safe mode, the intake air temperature is estimated to be 20°C (68°F) by the ECM. The ECM continues operating in fail-safe mode until a pass condition is detected.

HINT

When either of these DTCs is stored, check the intake air temperature by entering the following menus: Powertrain / Engine / All Data / Intake Air.

The ECM monitors the sensor voltage and uses this value to calculate the intake air temperature. When the sensor output voltage deviates from the normal operating range, the ECM interprets this as a malfunction in the intake air temperature sensor and stores a DTC.

Example

If the sensor output voltage is higher than 4.91 V for 0.5 seconds or more, the ECM determines that there is an open in the intake air temperature sensor circuit and stores DTC P0113. Conversely, if the output voltage is below 0.18 V for 0.5 seconds or more, the ECM determines that there is a short in the sensor circuit and stores DTC P0112.

If the malfunction is not repaired successfully, a DTC is stored 0.5 seconds after the engine is next started.

A thermistor, whose resistance value varies according to the engine coolant temperature, is built into the engine coolant temperature sensor.

The structure of the sensor and its connection to the ECM are the same as those of the intake air temperature sensor.

HINT

When DTC P0115, P0117 or P0118 is stored, the ECM enters fail-safe mode. During fail-safe mode, the engine coolant temperature is estimated to be 80°C (176°F) by the ECM. The ECM continues operating in fail-safe mode until a pass condition is detected.

HINT

When any of these DTCs is stored, check the engine coolant temperature by entering the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.

The engine coolant temperature sensor is used to monitor the engine coolant temperature. The engine coolant temperature sensor has a thermistor with a resistance that varies according to the temperature of the engine coolant. When the coolant temperature is low, the resistance in the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are reflected in the output voltage from the sensor. The ECM monitors the sensor voltage and uses this value to calculate the engine coolant temperature. When the sensor output voltage deviates from the normal operating range, the ECM interprets this as a fault in the engine coolant temperature sensor and stores a DTC.

Example

If the sensor output voltage is higher than 4.91 V for 0.5 seconds or more, the ECM determines that there is an open in the engine coolant temperature sensor circuit and stores DTC P0118. Conversely, if the voltage output is below 0.14 V for 0.5 seconds or more, the ECM determines that there is a short in the sensor circuit and stores DTC P0117.

If the malfunction is not repaired successfully, a DTC is stored 0.5 seconds after the engine is next started.

A thermistor, whose resistance value varies according to the engine coolant temperature, is built into the engine coolant temperature sensor.

The structure of the sensor and its connection to the ECM are the same as those of the intake air temperature sensor.

HINT

When DTC P0115, P0117 or P0118 is stored, the ECM enters fail-safe mode. During fail-safe mode, the engine coolant temperature is estimated to be 80°C (176°F) by the ECM. The ECM continues operating in fail-safe mode until a pass condition is detected.

HINT

When any of these DTCs is stored, check the engine coolant temperature by entering the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.

The engine coolant temperature sensor is used to monitor the engine coolant temperature. The engine coolant temperature sensor has a thermistor with a resistance that varies according to the temperature of the engine coolant. When the coolant temperature is low, the resistance in the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are reflected in the output voltage from the sensor. The ECM monitors the sensor voltage and uses this value to calculate the engine coolant temperature. When the sensor output voltage deviates from the normal operating range, the ECM interprets this as a fault in the engine coolant temperature sensor and stores a DTC.

Example

If the sensor output voltage is higher than 4.91 V for 0.5 seconds or more, the ECM determines that there is an open in the engine coolant temperature sensor circuit and stores DTC P0118. Conversely, if the voltage output is below 0.14 V for 0.5 seconds or more, the ECM determines that there is a short in the sensor circuit and stores DTC P0117.

If the malfunction is not repaired successfully, a DTC is stored 0.5 seconds after the engine is next started.

Refer to DTC P0115. Refer to DESCRIPTION.

Engine coolant temperature sensor cold start monitor

When a cold engine start is performed and then the engine is warmed up, if the engine coolant temperature sensor value does not change, it is determined that a malfunction has occurred. If this is detected in 2 consecutive driving cycles, the MIL is illuminated and a DTC is stored.

Engine coolant temperature sensor soak monitor

If the engine coolant temperature sensor value does not change after the warmed up engine is stopped and then the next cold engine start is performed, it is determined that a malfunction has occurred. If this is detected in 2 consecutive driving cycles, the MIL is illuminated and a DTC is stored.

Refer to DTC P0115. Refer to DESCRIPTION.

Engine coolant temperature sensor cold start monitor

When a cold engine start is performed and then the engine is warmed up, if the engine coolant temperature sensor value does not change, it is determined that a malfunction has occurred. If this is detected in 2 consecutive driving cycles, the MIL is illuminated and a DTC is stored.

Engine coolant temperature sensor soak monitor

If the engine coolant temperature sensor value does not change after the warmed up engine is stopped and then the next cold engine start is performed, it is determined that a malfunction has occurred. If this is detected in 2 consecutive driving cycles, the MIL is illuminated and a DTC is stored.

The engine has two temperature sensors, an engine coolant temperature sensor and an intake air temperature sensor, to detect temperature while the engine is in operation. A thermistor, whose resistance value varies according to temperature, is built into each sensor. When the temperature is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes. Based on these temperature signals output from the sensors, the ECM determines the fuel injection time and ignition timing to control the engine.

Scheme 165

HINT

1. Waiting is required to prevent the temperature of the engine from affecting the readings. If the engine has been operated recently, it will not be possible to accurately compare the readings.

1. For diagnosis, in order to duplicate the detection conditions of the DTC, it is necessary to park and leave the vehicle for 7 hours. Leaving the vehicle for 7 hours ensures that the actual engine coolant temperature and intake air temperature are very similar. When the vehicle has been left for less than 7 hours, differences in the readings may exist. However, this does not necessarily indicate a fault.

The ECM monitors the difference between the engine coolant temperature and intake air temperature when the engine is started cold to detect the engine temperature conditions accurately. The monitor runs when the engine is started cold after 7 hours or more have elapsed since the engine was stopped (ignition switch turned off) on the previous trip. If the result of (engine coolant temperature - intake air temperature) is outside of the range of -25 to 25°C (-45 to 45°F), the ECM interprets this as a malfunction in the engine coolant temperature and/or intake air temperature sensor circuit, and stores the DTC.

The engine has two temperature sensors, an engine coolant temperature sensor and an intake air temperature sensor, to detect temperature while the engine is in operation. A thermistor, whose resistance value varies according to temperature, is built into each sensor. When the temperature is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes. Based on these temperature signals output from the sensors, the ECM determines the fuel injection time and ignition timing to control the engine.

HINT

1. Waiting is required to prevent the temperature of the engine from affecting the readings. If the engine has been operated recently, it will not be possible to accurately compare the readings.

1. For diagnosis, in order to duplicate the detection conditions of the DTC, it is necessary to park and leave the vehicle for 7 hours. Leaving the vehicle for 7 hours ensures that the actual engine coolant temperature and intake air temperature are very similar. When the vehicle has been left for less than 7 hours, differences in the readings may exist. However, this does not necessarily indicate a fault.

The ECM monitors the difference between the engine coolant temperature and intake air temperature when the engine is started cold to detect the engine temperature conditions accurately. The monitor runs when the engine is started cold after 7 hours or more have elapsed since the engine was stopped (ignition switch turned off) on the previous trip. If the result of (engine coolant temperature - intake air temperature) is outside of the range of -25 to 25°C (-45 to 45°F), the ECM interprets this as a malfunction in the engine coolant temperature and/or intake air temperature sensor circuit, and stores the DTC.

The throttle position sensor is mounted on the throttle body and detects the opening angle of the throttle valve. This sensor is a non-contact type. It uses Hall-effect elements in order to yield accurate signals even in extreme driving conditions, such as at high speeds as well as very low speeds.

The throttle position sensor has 2 sensor circuits, each of which transmits a signal, VTA1 and VTA2. VTA1 is used to detect the throttle valve angle and VTA2 is used to detect malfunctions in VTA1. The sensor signal voltages vary between 0 V and 5 V in proportion to the throttle valve opening angle, and are transmitted to the VTA terminals of the ECM.

As the valve closes, the sensor output voltage decreases and as the valve opens, the sensor output voltage increases. The ECM calculates the throttle valve opening angle according to these signals and controls the throttle actuator in response to driver inputs. These signals are also used in calculations such as air-fuel ratio correction, power increase correction and fuel-cut control.

Scheme 166

HINT

1. When any of these DTCs is stored, check the throttle valve opening angle by entering the following menus: Powertrain / Engine / Data List / All Data / Throttle Position No. 1 and Throttle Position No. 2.

1. Throttle Position No. 1 is the VTA1 signal, and Throttle Position No. 2 is the VTA2 signal. Reference (Normal Condition) Techstream Display Accelerator Pedal Fully Released Accelerator Pedal Fully Depressed Throttle Position No. 1 0.5 to 1.1 V 3.2 to 4.8 V Throttle Position No. 2 2.1 to 3.1 V 4.6 to 4.98 V

The ECM uses the throttle position sensor to monitor the throttle valve opening angle. There are several checks that the ECM performs to confirm that the throttle position sensor is operating properly.

P0120, P0122, P0123, P0220, P0222, P0223 and P2135

1. A specific voltage difference is expected between the sensor terminals, VTA1 and VTA2, for each throttle valve opening angle. If the difference between VTA1 and VTA2 is incorrect, the ECM interprets this as a malfunction in the sensor and stores a DTC.
2. VTA1 and VTA2 each have a specific voltage range. If VTA1 or VTA2 is outside the normal operating range, the ECM interprets this as a malfunction in the sensor and stores a DTC.
3. VTA1 and VTA2 should never be close to the same voltage level. If VTA1 is within 0.02 V of VTA2, the ECM determines that there is a short circuit in the sensor and stores a DTC.

If the malfunction is not repaired successfully, a DTC is stored 10 seconds after the engine is next started.

P0121

1. This sensor transmits two signals: VTA1 and VTA2. VTA1 is used to detect the throttle opening angle and VTA2 is used to detect malfunctions in VTA1. The ECM performs several checks to confirm that the throttle position sensor and VTA1 are operating properly. For each throttle opening angle, a specific voltage difference is expected between the outputs of VTA1 and VTA2. If the output voltage difference between the two signals deviates from the normal operating range, the ECM interprets this as a malfunction of the throttle position sensor. The ECM illuminates the MIL and stores the DTC. If the malfunction is not repaired successfully, the DTC is stored 2 seconds after the engine is next started.

The throttle position sensor is mounted on the throttle body and detects the opening angle of the throttle valve. This sensor is a non-contact type. It uses Hall-effect elements in order to yield accurate signals even in extreme driving conditions, such as at high speeds as well as very low speeds.

The throttle position sensor has 2 sensor circuits, each of which transmits a signal, VTA1 and VTA2. VTA1 is used to detect the throttle valve angle and VTA2 is used to detect malfunctions in VTA1. The sensor signal voltages vary between 0 V and 5 V in proportion to the throttle valve opening angle, and are transmitted to the VTA terminals of the ECM.

As the valve closes, the sensor output voltage decreases and as the valve opens, the sensor output voltage increases. The ECM calculates the throttle valve opening angle according to these signals and controls the throttle actuator in response to driver inputs. These signals are also used in calculations such as air-fuel ratio correction, power increase correction and fuel-cut control.

HINT

1. When any of these DTCs is stored, check the throttle valve opening angle by entering the following menus: Powertrain / Engine / Data List / All Data / Throttle Position No. 1 and Throttle Position No. 2.

1. Throttle Position No. 1 is the VTA1 signal, and Throttle Position No. 2 is the VTA2 signal. Reference (Normal Condition) Techstream Display Accelerator Pedal Fully Released Accelerator Pedal Fully Depressed Throttle Position No. 1 0.5 to 1.1 V 3.2 to 4.8 V Throttle Position No. 2 2.1 to 3.1 V 4.6 to 4.98 V

The ECM uses the throttle position sensor to monitor the throttle valve opening angle. There are several checks that the ECM performs to confirm that the throttle position sensor is operating properly.

P0120, P0122, P0123, P0220, P0222, P0223 and P2135

1. A specific voltage difference is expected between the sensor terminals, VTA1 and VTA2, for each throttle valve opening angle. If the difference between VTA1 and VTA2 is incorrect, the ECM interprets this as a malfunction in the sensor and stores a DTC.
2. VTA1 and VTA2 each have a specific voltage range. If VTA1 or VTA2 is outside the normal operating range, the ECM interprets this as a malfunction in the sensor and stores a DTC.
3. VTA1 and VTA2 should never be close to the same voltage level. If VTA1 is within 0.02 V of VTA2, the ECM determines that there is a short circuit in the sensor and stores a DTC.

If the malfunction is not repaired successfully, a DTC is stored 10 seconds after the engine is next started.

P0121

1. This sensor transmits two signals: VTA1 and VTA2. VTA1 is used to detect the throttle opening angle and VTA2 is used to detect malfunctions in VTA1. The ECM performs several checks to confirm that the throttle position sensor and VTA1 are operating properly. For each throttle opening angle, a specific voltage difference is expected between the outputs of VTA1 and VTA2. If the output voltage difference between the two signals deviates from the normal operating range, the ECM interprets this as a malfunction of the throttle position sensor. The ECM illuminates the MIL and stores the DTC. If the malfunction is not repaired successfully, the DTC is stored 2 seconds after the engine is next started.

1. Refer to DTC P0115. Refer to «DESCRIPTION»(ref-615237-S08525449312014050900000). DTC No. DTC Detection Condition Trouble Area P0125 Engine coolant temperature does not reach the closed-loop enabling temperature for 20 minutes (this period varies with the engine coolant temperature at engine start) (2 trip detection logic). Engine coolant temperature sensor Cooling system Thermostat

The resistance of the engine coolant temperature sensor varies in proportion to the actual engine coolant temperature. The ECM supplies a constant voltage to the sensor and monitors the output voltage signal of the sensor. The output voltage signal varies according to the changing resistance of the sensor. After the engine is started, the engine coolant temperature is monitored through this signal. If the engine coolant temperature sensor indicates that the engine is not yet warm enough for closed-loop fuel control despite a specified period of time having elapsed since the engine was started, the ECM interprets this as a malfunction in the sensor or cooling system and stores the DTC.

Example

The engine coolant temperature is 0°C (32°F) at engine start. After approximately 1 minute of running time, the engine coolant temperature sensor still indicates that the engine is not warm enough to begin closed-loop fuel (air-fuel ratio feedback) control. The ECM interprets this as a malfunction in the sensor or cooling system and stores the DTC.

1. Refer to DTC P0115. Refer to «DESCRIPTION»(ref-615237-S01254122582014050900000). DTC No. DTC Detection Condition Trouble Area P0125 Engine coolant temperature does not reach the closed-loop enabling temperature for 20 minutes (this period varies with the engine coolant temperature at engine start) (2 trip detection logic). Engine coolant temperature sensor Cooling system Thermostat

The resistance of the engine coolant temperature sensor varies in proportion to the actual engine coolant temperature. The ECM supplies a constant voltage to the sensor and monitors the output voltage signal of the sensor. The output voltage signal varies according to the changing resistance of the sensor. After the engine is started, the engine coolant temperature is monitored through this signal. If the engine coolant temperature sensor indicates that the engine is not yet warm enough for closed-loop fuel control despite a specified period of time having elapsed since the engine was started, the ECM interprets this as a malfunction in the sensor or cooling system and stores the DTC.

Example

The engine coolant temperature is 0°C (32°F) at engine start. After approximately 1 minute of running time, the engine coolant temperature sensor still indicates that the engine is not warm enough to begin closed-loop fuel (air-fuel ratio feedback) control. The ECM interprets this as a malfunction in the sensor or cooling system and stores the DTC.

This DTC is stored when the engine coolant temperature does not reach 75°C (167°F) despite sufficient engine warmup time having elapsed.

Scheme 167

The ECM estimates the engine coolant temperature based on the starting temperature, engine load and engine speed. The ECM then compares the estimated temperature with the actual engine coolant temperature. When the estimated engine coolant temperature reaches 75°C (167°F), the ECM checks the actual engine coolant temperature. If the actual engine coolant temperature is below 75°C (167°F), the ECM interprets this as a malfunction in the thermostat or the engine cooling system and stores the DTC.

See also:
• DESCRIPTION
• ON-VEHICLE INSPECTION [05/2013 - ] - Step 1
