Connect TECH 2 scan tool to Data Link Connector (DLC). Replace EVAP canister purge valve. see scheme 11 Use scan tool to select ACTIVATE: EVAP DIAGNOSTICS. Follow scan tool instructions. If after performing test, scan tool display reads OK, clear all system DTCs. If display reads NOT READY, back up to INITIATING DIAGNOSTICS and retest. If DTC P0441 is displayed, substitute known good ECM and retest system. See ENGINE CONTROL MODULE (ECM) under COMPUTERIZED ENGINE CONTROLS in REMOVAL, OVERHAUL & INSTALLATION article.
Home/Saab/9-3/Saab 9-3 I (1998-2003)/Repair manual/Testing & Diagnostics/DTC P0441: EVAP PURGE VALVE MALFUNCTION
