Removal & Installation
Remove OBD-II connector. Remove knee shield above pedal bracket. Remove air duct to access relay retainer. (Scheme 2) Remove relay retainer screw. Remove DICE module bracket screws. Disconnect electrical connectors. Lift out DICE module. (Scheme 3) To install, reverse removal procedure.
Scheme 2
Scheme 2: Removal & Installation
Scheme 3
Body Computer System Wiring Diagram (1999-2000 9-3 - 1 Of 2). Scheme 4
Scheme 4: Body Computer System Wiring Diagram (1999-2000 9-3 - 1 Of 2)
Body Computer System Wiring Diagram (1999-2000 9-3 - 2 Of 2). Scheme 5
Scheme 5: Body Computer System Wiring Diagram (1999-2000 9-3 - 2 Of 2)
