SPECIFICATIONS
| DESCRIPTION | SPECIFICATION |
|---|---|
| Axle Ratio | 3.73, 4.10, 4.56 |
| Ring Gear Diameter | 266 mm (10.5 in.) |
| Ring Gear Backlash | 0.13 - 0.18 mm (0.005 - 0.007 in.) |
| Pinion Torque To Rotate - New Bearings | 1.69 - 2.82 N.m (15 - 25 in. lbs.) |
| Pinion Torque To Rotate - Original Bearings | 1 - 2 N.m (10 - 20 in. lbs.) |
| Total Torque To Rotate - New Bearings | 3.4 - 5.6 N.m (30 - 50 in. lbs.) |
| Total Torque To Rotate - Original Bearings | 2.8 - 5.1 N.m (25 - 45 in. lbs.) |
| Fill Level - From Bottom of Fill Hole | 25 mm (1 in.) ± 6 mm (1/4 in.) |
AXLE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Fill Hole Plug | 32 | 24 | |
| Differential Cover Bolts | 40 | 30 | |
| Bearing Cap Bolts | 165 | 122 | |
| Ring Gear Bolts | 237 | 175 | |
| Axle Flange Bolts | 129 | 95 | |
| Adjuster Lock Bolt | 25 | 18 | |
| Sensor Target Magnet Bolt | 7 | 62 |
TORQUE
Scheme 395
Scheme 396
- With vehicle in neutral, position vehicle on hoist.
- Position a lift under axle and secure lift to the axle.
- Remove all brake components.
- Remove axle vent hose.
- Mark propeller shaft and companion flange for installation alignment reference.
- Remove propeller shaft.
- Remove shock absorbers (3) from axle (2).
- Remove U-bolts (5) from axle.
- Remove axle from the vehicle.
