SPECIFICATIONS
| DESCRIPTION | SPECIFICATION |
|---|---|
| Gear Ratio | 4.10, 4.44, 4.88 |
| Rear Gear Runout | 0.12 mm (0.005 in.) |
| Rear Gear Backlash | 0.1 - 0.15 mm (0.004 - 0.006 in.) |
| Pinion Torque To Rotate (PTTR) | 5 - 8 N.m (44 - 70 in. lbs.) |
| Total Torque To Rotate (TTTR) is: PTTR plus | 1.5 N.m ± 0.5 N.m (13 in. lbs. ± 4.4 in. lbs.) |
AXLE SPECIFICATIONS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Drain Plug | 60 | 44 | |
| Differential Cover | 46 | 34 | |
| Bearing Cap (Larger) | 160 | 118 | |
| Bearing Cap (Small) | 100 | 74 | |
| Rear Gear Bolts | 175 | 139 | |
| Pinion Nut | 500 | 369 | |
| Axle Nut | 330 | 243 | |
| Hub Bearing Bolts | 200 | 147 |
TORQUE SPECIFICATIONS
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
Scheme 101
- With vehicle in neutral, position vehicle on hoist.
- Position a lift under axle and secure lift to the axle.
- Mark propeller shaft and companion flange for installation alignment reference.
- Remove propeller shaft (1) from pinion flange (3).
- Remove brake calipers, rotors, ABS wheel speed sensors.
- Remove brake hose retainer (1) bolts (2) from axle.
- Disconnect axle vent hose.
- Remove stabilizer bar link (1) nuts (2).
- Remove stabilizer bar links (1) from axle with Puller (special tool #C-3894-A, Puller, Tie Rod).
- Remove shock absorbers (1) bolts (4) from axle brackets.
- Remove track bar bolt from the axle bracket.
- Remove damper from axle bracket.
- Remove tie rod and drag link from the steering knuckles with Puller (special tool #C-3894-A, Puller, Tie Rod).
- Remove upper control arm (1) nuts (2) and bolts from axle brackets.
- Remove lower control arm (1) nuts and bolts (2) from the axle brackets.
- Lower the axle. The coil springs will drop with the axle.
- Remove coil springs from the axle bracket.
