B142B-VES UNIT HIGH TEMPERATURE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When Monitored

With the ignition on. VES active.

Set Condition

The Video Screen Module temperature is above 90°C (194°F).

Possible Causes

B14CE-VES BRIGHTNESS UP INPUT BUTTON STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on. VES active.

The Video Screen Module detects a closed switch for 60 seconds.

B14CF-VES BRIGHTNESS DOWN INPUT BUTTON STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on. VES active.

The Video Screen Module detects a closed switch for 60 seconds.

Ignition on, and the radio is in the video mode.

No video is displayed on the rear video screen.

Scheme 482

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. Set the radio in the video mode. With the scan tool, record and erase the VES DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the ignition on and set the radio in the video mode. With the scan tool, read the active VES DTCs. Does the scan tool display active: B14E0-CHANNEL 1 VIDEO CONTINUITY? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
2. CHECK THE (X534) VIDEO 1 SIGNAL, THE (X535) COMMON, AND THE (X536) SHIELD CIRCUITS FOR AN OPEN CIRCUIT Disconnect the radio C3 harness connector. Disconnect the Video Screen Module C1 harness connector. Measure the resistance of the (X534), (X535), and (X536) circuits between the Video Screen Module harness connector and radio C3 harness connector. Is the resistance below 5.0 Ohms on the (X534), (X535), or (X536) circuits? Yes Replace the Video Screen Module. Refer to «MONITOR, Media System , Removal»(ref-457804-S07239744692012030200000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Repair the appropriate circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

Scheme 483

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on, and the radio is in the video mode.

The VES detects an open condition on the Channel 1 Audio Left circuit.

Scheme 484

Scheme 485

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. Set the radio in the video mode. With the scan tool, record and erase the VES DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the ignition on and set the radio in the video mode. With the scan tool, read the active VES DTCs. Does the scan tool display active: B14E1-CHANNEL 1 AUDIO LEFT CONTINUITY? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
2. CHECK THE (X539) CHANNEL 1 AUDIO LEFT OPEN CIRCUIT FOR AN OPEN Disconnect the radio C3 harness connector. Disconnect the Video Screen Module C1 harness connector. Measure the resistance of the (X539) Channel 1 Audio Left circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 3 . No Repair the (X539) Channel 1 Audio Left circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
3. CHECK THE (X540) CHANNEL 1 AUDIO RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (X540) Channel 1 Audio Return circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Video Screen Module. Refer to «MONITOR, Media System , Removal»(ref-457804-S07239744692012030200000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Repair the (X540) Channel 1 Audio Return circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

B14E2-CHANNEL 1 AUDIO RIGHT CONTINUITY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on, and the radio is in the video mode.

The VES detects an open condition on the Channel 1 Audio Right circuit.

Scheme 486

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. Set the radio in the video mode. With the scan tool, record and erase the VES DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the ignition on and set the radio in the video mode. With the scan tool, read the active VES DTCs. Does the scan tool display active: B14E2-CHANNEL 1 AUDIO RIGHT CONTINUITY? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
2. CHECK THE (X538) CHANNEL 1 AUDIO RIGHT OPEN CIRCUIT FOR AN OPEN Disconnect the radio C3 harness connector. Disconnect the Video Screen Module C1 harness connector. Measure the resistance of the (X538) Channel 1 Audio Right circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 3 . No Repair the (X538) Channel 1 Audio Right circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
3. CHECK THE (X540) CHANNEL 1 AUDIO RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (X540) Channel 1 Audio Return circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Video Screen Module. Refer to «MONITOR, Media System , Removal»(ref-457804-S07239744692012030200000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Repair the (X540) Channel 1 Audio Return circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

Scheme 487

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on, and the radio is in the video mode.

No video is displayed on the rear video screen.

Scheme 488

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. Set the radio in the video mode. With the scan tool, record and erase the VES DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the ignition on and set the radio in the video mode. With the scan tool, read the active VES DTCs. Does the scan tool display active: B14E3-CHANNEL 2 VIDEO CONTINUITY? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
2. CHECK THE (X541) VIDEO 2 SIGNAL, THE (X542) COMMON, AND THE (X543) SHIELD CIRCUITS FOR AN OPEN CIRCUIT Disconnect the radio C3 harness connector. Disconnect the Video Screen Module C1 harness connector. Measure the resistance of the (X541), (X542), and (X543) circuits between the Video Screen Module harness connector and radio C3 harness connector. Is the resistance below 5.0 Ohms on the (X541) (X542) or (X543) circuits? Yes Replace the Video Screen Module. Refer to «MONITOR, Media System , Removal»(ref-457804-S07239744692012030200000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Repair the appropriate circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

Scheme 489

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on, and the radio is in the video mode.

The VES detects an open condition on the Channel 2 Audio Left circuit.

Scheme 490

Scheme 491

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. Set the radio in the video mode. With the scan tool, record and erase the VES DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the ignition on and set the radio in the video mode. With the scan tool, read the active VES DTCs. Does the scan tool display active: B14E4-CHANNEL 2 AUDIO LEFT CONTINUITY? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
2. CHECK THE (X545) CHANNEL 2 AUDIO LEFT OPEN CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the radio C3 harness connector. Disconnect the Video Screen Module C1 harness connector. Measure the resistance of the (X545) Channel 2 Audio Left circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 3 . No Repair the (X545) Channel 2 Audio Left circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
3. CHECK THE (X546) CHANNEL 2 AUDIO RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (X546) Channel 2 Audio Return circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Video Screen Module. Refer to «MONITOR, Media System , Removal»(ref-457804-S07239744692012030200000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Repair the (X546) Channel 2 Audio Return circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

B14E5-CHANNEL 2 AUDIO RIGHT CONTINUITY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on, and the radio is in the video mode.

The VES detects an open condition on the Channel 2 Audio Right circuit.

Scheme 492

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. Set the radio in the video mode. With the scan tool, record and erase the VES DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the ignition on and set the radio in the video mode. With the scan tool, read the active VES DTCs. Does the scan tool display active: B14E5-CHANNEL 2 AUDIO RIGHT CONTINUITY? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
2. CHECK THE (X544) CHANNEL 2 AUDIO RIGHT OPEN CIRCUIT FOR AN OPEN Disconnect the radio C3 harness connector. Disconnect the Video Screen Module C1 harness connector. Measure the resistance of the (X544) Channel 2 Audio Right circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 3 . No Repair the (X544) Channel 2 Audio Right circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
3. CHECK THE (X546) CHANNEL 2 AUDIO RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (X546) Channel 2 Audio Return circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Video Screen Module. Refer to «MONITOR, Media System , Removal»(ref-457804-S07239744692012030200000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Repair the (X546) Channel 2 Audio Return circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

Scheme 493

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on, and the radio is in the video mode.

The VES detects an open condition on the Channel 3 Audio Left circuit.

Scheme 494

Scheme 495

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. Set the radio in the video mode. With the scan tool, record and erase the VES DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the ignition on and set the radio in the video mode. With the scan tool, read the active VES DTCs. Does the scan tool display active: B14E7-CHANNEL 3 AUDIO LEFT CONTINUITY? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
2. CHECK THE (X551) CHANNEL 3 AUDIO LEFT OPEN CIRCUIT FOR AN OPEN Disconnect the radio C3 harness connector. Disconnect the Video Screen Module C1 harness connector. Measure the resistance of the (X551) Channel 3 Audio Left circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 3 . No Repair the (X551) Channel 3 Audio Left circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
3. CHECK THE (X552) CHANNEL 3 AUDIO RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (X552) Channel 3 Audio Return circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Video Screen Module. Refer to «MONITOR, Media System , Removal»(ref-457804-S07239744692012030200000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Repair the (X552) Channel 3 Audio Return circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

B14E8-CHANNEL 3 AUDIO RIGHT CONTINUITY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on, and the radio is in the video mode.

The VES detects an open condition on the Channel 3 Audio Right circuit.

Scheme 496

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. Set the radio in the video mode. With the scan tool, record and erase the VES DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the ignition on and set the radio in the video mode. With the scan tool, read the active VES DTCs. Does the scan tool display active: B14E8-CHANNEL 3 AUDIO RIGHT CONTINUITY? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
2. CHECK THE (X550) CHANNEL 3 AUDIO RIGHT OPEN CIRCUIT FOR AN OPEN Disconnect the radio C3 harness connector. Disconnect the Video Screen Module C1 harness connector. Measure the resistance of the (X550) Channel 3 Audio Right circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 3 . No Repair the (X550) Channel 3 Audio Right circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
3. CHECK THE (X552) CHANNEL 3 AUDIO RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (X552) Channel 3 Audio Return circuit between the radio C3 harness connector and the Video Screen Module C1 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Video Screen Module. Refer to «MONITOR, Media System , Removal»(ref-457804-S07239744692012030200000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Repair the (X552) Channel 3 Audio Return circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

B210A-SYSTEM VOLTAGE LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

This is a CAN message that the battery voltage was below 10 volts for over 20 seconds.

B210B-SYSTEM VOLTAGE HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

This is a CAN message that the battery voltage was above 16 volts for over 20 seconds.

B210D-BATTERY VOLTAGE LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage less than 10 volts for more than 20 seconds.

B210E-BATTERY VOLTAGE HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 16 volts for more than 20 seconds.

Ignition on.

Video Screen Module experiences a reset event.

B222B-VEHICLE ENTERTAINMENT SYSTEM INTERNAL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Video Screen Module detects an internal failure.

B222C-VEHICLE CONFIGURATION NOT PROGRAMMED

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Vehicle configuration information not programmed into the TIPM.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

The controller detects a short to ground on the CAN Interior Bus (125K) (+) circuit or a short to voltage on the CAN Interior Bus (125K) (-) circuit.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

The controller detects a short to ground on the CAN Interior Bus (125K) (+) circuit or a short to voltage on the CAN Interior Bus (125K) (-) circuit.

Continuously when the ignition is on.

The battery voltage between 10.0 and 16.0 Volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

Continuously when the ignition is on.

The battery voltage is between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Instrument Cluster (CCN) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Wireless Ignition Node (WIN) for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fused installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Radio for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Satellite Video Receiver (SDARV) for approximately two to five seconds.
