Remove and Install Main AC Compressor Bracket Opel Omega B

Air Conditioning 1 illustration

Remove

1. Remove compressor – see operation "Compressor, Remove and Install – Y 25 DT" in group "D".
2. Remove fastening bolts (1) and (2).
3. Remove AC compressor main bracket.

Note. When replacing the AC compressor support, transfer ribbed V-belt tensioner for AC compressor.

Remove and Install Main AC Compressor Bracket

Install

4. Attach AC compressor support to cylinder block and timing case – tightening torque 24 Nm / 17.5 lbf. ft
5. Install compressor – see operation "Compressor, Remove and Install Y 25 DT" in group "D".
