Replace Dis Ignition Module (Z 16 SE, Lhd) Opel Meriva A

OHC Petrol Engine 1 illustration

1. Open bonnet
2. Remove DIS ignition module • Remove 4x ignition cable plugs • Detach DIS ignition module wiring harness plug (arrow) • Unscrew 3 bolts

Replace Dis Ignition Module (Z 16 SE, Lhd)

3. Fit DIS ignition module • Tighten 3 bolts – Tightening torque 8 Nm • Connect 5x wiring harness plugs

Important. Note ignition sequence. Cylinder numbers are marked on ignition cables and DIS ignition module.

4. Close bonnet
