Engine Controls Connector End Views
| Connector 1: | Accelerator Pedal Position (APP) Sensor |
|---|
| Connector 2: | Camshaft Position (CMP) Actuator Solenoid - Exhaust |
| Connector 3: | Camshaft Position (CMP) Actuator Solenoid - Intake |
| Connector 4: | Camshaft Position (CMP) Sensor - Exhaust |
| Connector 5: | Camshaft Position (CMP) Sensor - Intake |
| Connector 6: | Crankshaft Position (CKP) Sensor |
| Connector 7: | Engine Coolant Temperature (ECT) Sensor |
| Connector 8: | Evaporative Emission (EVAP) Canister Purge Solenoid |
| Connector 9: | Evaporative Emission (EVAP) Canister Vent Solenoid |
| Connector 10: | Fuel Injector 1 |
| Connector 11: | Fuel Injector 2 |
| Connector 12: | Fuel Injector 3 |
| Connector 13: | Fuel Injector 4 |
| Connector 14: | Fuel Rail Pressure (FRP) Sensor |
| Connector 15: | Fuel Pump and Sender Assembly |
| Connector 16: | Fuel Tank Pressure (FTP) Sensor |
| Connector 17: | Heated Oxygen Sensor (HO2S) 1 |
| Connector 18: | Heated Oxygen Sensor (HO2S) 2 |
| Connector 19: | High Pressure Fuel Pump |
| Connector 20: | Ignition Coil 1 |
| Connector 21: | Ignition Coil 2 |
| Connector 22: | Ignition Coil 3 |
| Connector 23: | Ignition Coil 4 |
| Connector 24: | Intake Air Pressure and Temperature Sensor |
| Connector 25: | Knock Sensor (KS) - 1 |
| Connector 26: | Knock Sensor (KS) - 2 |
| Connector 27: | Manifold Absolute Pressure (MAP) Sensor |
| Connector 28: | Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor |
| Connector 29: | Throttle Body |
| Connector 30: | Turbo Bypass Valve Control Solenoid |
| Connector 31: | Turbocharger Wastegate Solenoid |
Accelerator Pedal Position (App) Sensor
Connector Part Information OEM: 15326829 Description: 6-Way F GT 150 Series Sealed (BK)
Accelerator Pedal Position (App) Sensor
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.35 PU | 1272 | Low Reference |
| B | 0.35 L-BU | 1162 | TP Sensor 2 Signal |
| C | 0.35 TN | 1274 | 5-Volt Reference 3 |
| D | 0.35 BN | 1271 | Low Reference |
| E | 0.35 D-BU | 1161 | TP Sensor 1 Signal |
| F | 0.35 WH/BK | 1164 | 5-Volt Reference 2 |
Camshaft Position (Cmp) Actuator Solenoid - Exhaust
Connector Part Information OEM: 15336004 Description: 2-Way F GT 150 Series Sealed (BK)
Camshaft Position (Cmp) Actuator Solenoid - Exhaust
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 PK/BK | 5293 | Powertrain Main Relay Fused Supply (4) |
| B | 0.5 L-GN | 5282 | Camshaft Phaser Exhaust Solenoid Control |
Camshaft Position (Cmp) Actuator Solenoid - Intake
Connector Part Information OEM: 15335987 Description: 2-Way F GT 150 Series Sealed (BK)
Camshaft Position (Cmp) Actuator Solenoid - Intake
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 PK/BK | 5293 | Powertrain Main Relay Fused Supply (4) |
| B | 0.5 PU | 5284 | Camshaft Phaser Intake Solenoid Control |
Camshaft Position (Cmp) Sensor - Exhaust
Connector Part Information OEM: 15326808 Description: 3-Way F GT 150 Series Sealed (BK)
Camshaft Position (Cmp) Sensor - Exhaust
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 GY | 705 | 5-Volt Reference 2 |
| B | 0.5 TN | 552 | Low Reference |
| C | 0.5 D-GN | 5273 | Camshaft Position Exhaust Sensor Signal 1 |
Camshaft Position (Cmp) Sensor - Intake
Connector Part Information OEM: 15326808 Description: 3-Way F GT 150 Series Sealed (BK)
Camshaft Position (Cmp) Sensor - Intake
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 GY | 705 | 5-Volt Reference 2 |
| B | 0.5 TN | 552 | Low Reference |
| C | 0.5 OG | 5275 | Camshaft Position Intake Sensor Signal |
Crankshaft Position (Ckp) Sensor
Connector Part Information OEM: 31403-3700 (Delphi # 13521040) Description: 3-Way F MX64 Series, Sealed (BK)
Crankshaft Position (Ckp) Sensor
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.35 GY | 605 | 5-Volt Reference 3 |
| 2 | 0.35 TN | 452 | Low Reference |
| 3 | 0.35 YE | 573 | Crankshaft Position Sensor Signal |
Engine Coolant Temperature (ECT) Sensor
Connector Part Information OEM: 15449028 Description: 2-Way F GT 150 Sealed (BK)
Engine Coolant Temperature (ECT) Sensor
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 TN | 2761 | Low Reference |
| B | 0.5 YE | 410 | ECT Sensor Signal |
Evaporative Emission (Evap) Canister Purge Solenoid
Connector Part Information OEM: 12052643 Description: 2-Way F Metri-Pack 150 Series Sealed (RD)
Evaporative Emission (Evap) Canister Purge Solenoid
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 PK/BK | 5291 | Ignition 1 Voltage |
| B | 0.5 D-GN/WH | 428 | EVAP Canister Purge Solenoid Control |
Evaporative Emission (Evap) Canister Vent Solenoid
Connector Part Information OEM: 12052643 Description: 2-Way F Metri-Pack 150 Series Sealed (RD)
Evaporative Emission (Evap) Canister Vent Solenoid
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 RD/WH | 140 | Battery Positive Voltage |
| B | 0.5 WH | 1310 | EVAP Canister Vent Solenoid Control |
Fuel Injector 1
Connector Part Information OEM: 1 928 403 874 Description: 2-Way F Kompakt 2.8 Series Sealed (BK)
Fuel Injector 1
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 1.0 TN | 4801 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 1 |
| 2 | 1.0 TN | 4901 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 1 |
Fuel Injector 2
Connector Part Information OEM: 1 928 403 874 Description: 2-Way F Kompakt 2.8 Series Sealed (BK)
Fuel Injector 2
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 1.0 TN | 4802 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 2 |
| 2 | 1.0 TN | 4902 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 2 |
Fuel Injector 3
Connector Part Information OEM: 1 928 403 874 Description: 2-Way F Kompakt 2.8 Series Sealed (BK)
Fuel Injector 3
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 1.0 TN | 4803 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 3 |
| 2 | 1.0 TN | 4903 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 3 |
Fuel Injector 4
Connector Part Information OEM: 1 928 403 874 Description: 2-Way F Kompakt 2.8 Series Sealed (BK)
Fuel Injector 4
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 1.0 TN | 4804 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 4 |
| 2 | 1.0 TN | 4904 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 4 |
Fuel Rail Pressure (Frp) Sensor
Connector Part Information OEM: 1 928 403 966 Description: 3-Way F 2.8 Series Sealed (BK)
Fuel Rail Pressure (Frp) Sensor
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.5 GY | 808 | Sensor Low Reference |
| 2 | 0.5 GY | 2918 | Fuel Rail Pressure Sensor Signal |
| 3 | 0.5 GY | 598 | 5-Volt Reference 1 |
Fuel Pump and Sender Assembly
Connector Part Information OEM: 15326631 Description: 4-Way F GT 280 Series Sealed (BK)
Fuel Pump and Sender Assembly
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 1.0 BK | 750 | Ground |
| B | 0.5 PU | 1589 | Fuel Level Sensor Signal |
| C | 0.5 TN | 2759 | Low Reference |
| D | 1.0 GY | 120 | Fuel Pump Supply Voltage |
Fuel Tank Pressure (Ftp) Sensor
Connector Part Information OEM: 12059595 Description: 3-Way F Metri-Pack 150 Series Sealed (BK)
Fuel Tank Pressure (Ftp) Sensor
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 TN | 2759 | Low Reference |
| B | 0.5 D-GN | 890 | Fuel Tank Pressure Sensor Signal |
| C | 0.5 GY | 2709 | 5-Volt Reference 1 |
Heated Oxygen Sensor (HO2S) 1
Connector Part Information OEM: 1 928 404 900 Description: 6-Way F Sealed (BK)
Heated Oxygen Sensor (HO2S) 1
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.5 WH | 5279 | Heated Oxygen Sensor Pump Current - Sensor 1 |
| 2 | 0.5 TN/WH | 3111 | Heated Oxygen Sensor Low Signal - Sensor 1 |
| 3 | 0.5 GY/WH | 3113 | Heated Oxygen Sensor Heater Low Control - Sensor 1 |
| 4 | 0.5 PK/BK | 5291 | Ignition 1 Voltage |
| 5 | 0.5 L-GN | 5278 | Heated Oxygen Sensor Input Pump Current - Sensor 1 |
| 6 | 0.5 PU/WH | 3110 | Heated Oxygen Sensor High Signal - Sensor 1 |
Heated Oxygen Sensor (HO2S) 2
Connector Part Information OEM: 15326423 Description: 4-Way M Metri-Pack 150 Series Sealed (BK)
Heated Oxygen Sensor (HO2S) 2
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 TN/WH | 3121 | Heated Oxygen Sensor Low Signal - Sensor 2 |
| B | 0.5 PU | 3120 | Heated Oxygen Sensor High Signal - Sensor 2 |
| C | 0.5 GY/WH | 3122 | Heated Oxygen Sensor Heater Low Control - Sensor 2 |
| D | 0.5 PK/BK | 5291 | Ignition 1 Voltage |
High Pressure Fuel Pump
Connector Part Information OEM: 1 928 403 874 Description: 2-Way F Kompakt 2.8 Series Sealed (BK)
High Pressure Fuel Pump
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 1.0 PU | 7300 | High Pressure Fuel Pump Actuator Low Control |
| 2 | 1.0 YE | 7301 | High Pressure Fuel Pump Actuator High Control |
Ignition Coil 1
Connector Part Information OEM: 7283-3392-30 Description: 4-Way F GT 150 Series (BK)
Ignition Coil 1
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.5 BK | 450 | Ground |
| 2 | 0.35 BN | 2129 | Low Reference |
| 3 | 0.35 PU | 2121 | IC 1 Control |
| 4 | 0.5 PK/BK | 5292 | Ignition 1 Voltage |
Ignition Coil 2
Connector Part Information OEM: 7283-3392-30 Description: 4-Way F GT 150 Series (BK)
Ignition Coil 2
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.5 BK | 450 | Ground |
| 2 | 0.35 BN/WH | 2130 | Low Reference |
| 3 | 0.35 OG/WH | 2122 | IC 2 Control |
| 4 | 0.5 PK/BK | 5292 | Ignition 1 Voltage |
Ignition Coil 3
Connector Part Information OEM: 7283-3392-30 Description: 4-Way F GT 150 Series (BK)
Ignition Coil 3
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.5 BK | 450 | Ground |
| 2 | 0.35 BN | 2129 | Low Reference |
| 3 | 0.35 L-BU | 2123 | IC 3 Control |
| 4 | 0.5 PK/BK | 5292 | Ignition 1 Voltage |
Ignition Coil 4
Connector Part Information OEM: 7283-3392-30 Description: 4-Way F GT 150 Series (BK)
Ignition Coil 4
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.5 BK | 450 | Ground |
| 2 | 0.35 BN/WH | 2130 | Low Reference |
| 3 | 0.35 D-GN/WH | 2124 | IC 4 Control |
| 4 | 0.5 PK/BK | 5292 | Ignition 1 Voltage |
Intake Air Pressure and Temperature Sensor
Connector Part Information OEM: 12162187 Description: 4-Way F Metri-Pack 150.2 Series Sealed, Pull to Seat (BK)
Intake Air Pressure and Temperature Sensor
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 TN | 407 | Low Reference |
| B | 0.5 L-BU | 7329 | Pre-Throttle Air Temp and Press (TMAP) Temperature Signal |
| C | 0.5 GY | 597 | 5-Volt Reference 1 |
| D | 0.5 PU | 7330 | Pre-Throttle Air Temp and Press (TMAP) Air Pressure Signal |
Knock Sensor (Ks) - 1
Connector Part Information OEM: 12077900 Description: 2-Way F Metri-Pack 280 Series Sealed (BK)
Knock Sensor (Ks) - 1
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 D-BU | 496 | KS 1 Signal |
| B | 0.5 GY | 1716 | KS 1 Signal |
Knock Sensor (Ks) - 2
Connector Part Information OEM: 12077900 Description: 2-Way F Metri-Pack 280 Series Sealed (BK)
Knock Sensor (Ks) - 2
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 L-BU | 1876 | KS 2 Signal |
| B | 0.5 GY | 2303 | KS 2 Signal |
Manifold Absolute Pressure (MAP) Sensor
Connector Part Information OEM: 184032-1 Description: 3-Way F SSC Sealed Series (BK)
Manifold Absolute Pressure (MAP) Sensor
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.5 GY | 597 | 5-Volt Reference 1 |
| 2 | 0.5 TN | 407 | Low Reference |
| 3 | 0.5 L-GN | 432 | MAP Sensor Signal |
Mass Air Flow (Maf)/intake Air Temperature (IAT) Sensor
Connector Part Information OEM: 15326822 Description: 5-Way F GT 150 Series Sealed (BK)
Mass Air Flow (Maf)/intake Air Temperature (IAT) Sensor
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.35 YE | 492 | MAF Sensor Signal |
| B | 0.35 BK/WH | 451 | Ground |
| C | 0.35 PK/BK | 5291 | Ignition 1 Voltage |
| D | 0.35 TN | 2760 | Low Reference |
| E | 0.35 L-BU | 6289 | Induction Air Temperature Sensor Signal |
Throttle Body
Connector Part Information OEM: 15355297 Description: 6-Way F GT 150 Series Sealed (BK)
Throttle Body
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.8 BN | 582 | TAC Motor Control - 2 |
| B | 0.8 YE | 581 | TAC Motor Control - 1 |
| C | 0.5 TN | 2752 | Low Reference |
| D | 0.5 D-GN | 485 | TP Sensor 1 Signal |
| E | 0.5 GY | 2701 | 5-Volt Reference 3 |
| F | 0.5 PU | 486 | TP Sensor 2 Signal |
Turbo Bypass Valve Control Solenoid
Connector Part Information OEM: 1 928 402 571 Description: 2-Way F Sealed (BK)
Turbo Bypass Valve Control Solenoid
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.5 D-GN | 6391 | Turbo Bypass Valve Control |
| 2 | 0.5 PK/BK | 5293 | Powertrain Main Relay Fused Supply (4) |
Turbocharger Wastegate Solenoid
Connector Part Information OEM: 1 928 402 571 Description: 2-Way F Sealed (BK)
Turbocharger Wastegate Solenoid
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.5 YE | 258 | Wastegate Solenoid Control |
| 2 | 0.5 PK/BK | 5293 | Powertrain Main Relay Fused Supply (4) |
