Block Diagram, Engine Z 14 XE Opel Corsa C

DOHC Petrol Engine 3 illustrations

Block Diagram for Engine Z 14 Xe

15Ignition ON (terminal 15)
30Battery positive (terminal 30)
31Ground (terminal 31)
A40Direct injection ignition coil
A84_AMultec�S (F) control unit
A111Throttle valve module
B22Pedal position sensor
B28Camshaft sensor
B30Crankshaft pulse pick�up
B39Coolant temperature sensor
B56Oxygen sensor, mixture regulation, heated
B57Oxygen sensor, catalytic converter control
B64Intake air temperature sensor
B65Knock control sensor
B67Vacuum sensor on intake manifold

10.5.3 Block Diagram for Engine Z 14 Xe

15Ignition ON (terminal 15)
30Battery positive (terminal 30)
31Ground (terminal 31)
F2Fuse
F3Fuse
F9Fuse
F30Fuse
F46Fuse
K26Engine control relay
K35Fuel pump relay
L2_ACylinder 1 injector
L2_BCylinder 2 injector
L2_CCylinder 3 injector
L2_DCylinder 4 injector
M8Fuel pump
S87Oil pressure switch
XDDiagnostic plug

10.5.3 Block Diagram for Engine Z 14 Xe

31Ground (terminal 31)
A15Body Control Modules
A37ABS control unit & traction control
A38Anti�lock brake system control unit
A75Control unit, electric power steering
A84_AMultec�S (F) control unit
A110Immobiliser
A112_AAT control unit
B18Pressure sensor, air conditioning
B53Fuel supply sensor
K5Compressor relay
(Compressor) Air conditioning
K30(1)Radiator fan relay
K30(2)Radiator fan relay
(Air conditioning)
K30(3)Radiator fan relay
(Air conditioning)
P3Instrument module
S41Clutch switch
(Cruise control in preparation)
S216Brake lamp switch
Y56Exhaust gas recirculation solenoid valve
Y57Tank vent solenoid valve
