Replace Radio Installation Frame Opel Astra H

Remove

1. 1. Remove radio • Introduce removal bar into openings (arrows) until it engages – Press both removal bars outwards and at the same time withdraw the radio from the holder.
2. 2. Disconnect wiring harness plug • Disconnect 2x wiring harness plug (1) and (2)

3. 3. Unclip radio installation frame (arrows) and remove

Install

4. 4. Install radio installation frame
5. 5. Connect wiring harness plug • Connect 2x wiring harness plug
6. 6. Install radio • Push radio into holder until it audibly engages
7. 7. Program radio
