Infotainment Opel Astra H

All Infotainment components communicate via the MS CAN bus. The main unit of the Infotainment system is always a radio (EHU - Entertainment Head Unit), which, depending on the equipment fitted, may also contain navigation and telephone functions. Additional components may also include, depending on the equipment fitted, the Twin Audio System, DAB (Digital Audio Broadcasting), various displays (TID, BID, GID, CID), aerials and a telephone kit for mobile phones.

Diagnostics

All components of the Infotainment system have a diagnostics facility; the data are transmitted via the CAN bus and can be retrieved at the diagnostics plug.

Overview of Control Panels

R10

Radio with RDS tuner, TID and 2 speakers

CC20

Radio with RDS tuner, cassette player, TID and 7 speakers. Optional: connection kit for mobile phone

CD30 MP3

Radio with RDS tuner, CD / MP3 player, TID and 7 speakers. Optional: connection kit for mobile phone; BID; GID; steering wheel controls

CD30 MP3 (Rear Seat Audio)

Radio with RDS tuner, CD / MP3 player, RSA, TID and 7 speakers. Optional: connection kit for mobile phone; BID; GID; steering wheel controls

CD50 Phone

Radio with RDS tuner, CD / MP3 player, integral phone with voice control, telematics, GID, steering wheel controls and 7 speakers

CD60 M Media

Radio with RDS tuner, CD / MP3 player, integral phone with voice control, telematics, navigation system, GID, steering wheel controls and 7 speakers

CD80 M Media

Radio with RDS tuner, integral 6xCD changer/MP3 player, integral phone with voice control, telematics, navigation system, GID, steering wheel controls and 7 speakers

CD70 Navi

Radio with RDS tuner, CD/MP3 player, navigation system with separate CD-ROM drive, GID, steering wheel controls and 7 speakers. Optional:

CID, connection kit for mobile phone

CDC40 Opera

Premium radio with twin RDS tuner and DSP digital sound processor, integral 6x CD changer /MP3 player, GID, steering wheel controls and premium speaker system with 9 speakers

Optional: CID, DAB, RSA, connection kit for mobile phone

Block Diagram - Ehu (Entertainment Head Unit)

Components

Plug

Additional Components

DAB

The DAB (Digital Audio Broadcast) auxiliary module is installed in the passenger compartment behind the glove compartment for some radios. DAB is a receiver module for terrestrial (i.e. via normal aerials) digital radio. This will be the standard in Germany in a few years' time. DAB receives its data via the DAB aerial incorporated into the normal aerial. The module is operated via the radio (EHU).

Twin Audio system

The Twin Audio System enables the rear passengers to listen, via headphones, to a different music source from that being played through the loudspeakers (example, radio programme being broadcast via the speakers, CD via the Twin Audio System). The Twin Audio control panel for operating the system and connecting the headphones is located in the centre console extension. If the Twin Audio System is switched on, the rear speakers are automatically switched off. The Twin Audio System can only be combined with certain radio models as the equipment must be capable of reproducing two separate signal sources.

Displays

In addition to the functions listed below, all displays contain a gateway (transfer) function for bus systems. The displays are connected to both the LS and the MS bus systems and transfer data between the LS and MS bus.

TID (Triple Info Display)

Monochrome display, 1 line of text

The following is displayed: Time, date, outside temperature with ice warning, various radio displays (if an ECC is installed in the vehicle, the GID is used instead of the TID)

BID (Board Info Display)

Monochrome display, 2 lines of text. The following is displayed: Time, date, outside temperature, various radio displays, trip computer, Check Control

GID (Graphic Info Display)

Monochrome display, dot matrix (graphics capable)

The following is displayed: Time, date, outside temperature, various radio displays, trip computer, telematics, navigation, Check Control, ECC

Cid (Colour Info Display)

Colour display, dot matrix (graphics capable)

The following is displayed: Time, date, outside temperature, various radio displays, trip computer, telematics, navigation, Check Control, ECC

Block Diagram - Display

Components
