Base Holder - Telephone System - Replace (Upgrade Kit) Opel Astra H

Remove

1. 1. Disconnect battery.
2. 2. Remove holder for mobile phone in direction of arrow

3. 3. Remove glove compartment • Open glove compartment cover • Unscrew 4x bolt (1) • Disconnect wiring harness plug • Remove glove compartment

4. 4. Remove control unit • Cut 2x cable tie (1) on control unit • Disconnect wiring harness plug (2) for base holder

5. 5. Remove base holder • Release centre console – Unclip panel – Unscrew bolt (3) • Lay wiring harness (2) • Unscrew bolt (1) • Disconnect aerial cable • Remove base holder

Install

6. 6. Fit control unit • Connect wiring harness plug • Install control unit – Connect 2x cable tie
7. 7. Attach base holder • Tighten bolt • Position wiring harness
8. 8. Connect aerial cable to base holder
9. 9. Fasten centre console • Lay wiring harness • Tighten bolt • Clip in panel
10. 10. Insert glove compartment • Connect wiring harness plug
11. 11. Fasten glove compartment • Tighten 4x screw
12. 12. Insert holder for mobile phone
13. 13. Connect battery.
14. 14. Function check
15. 15. Program volatile memories
