Audio, Visual & Navigation System (Premium Audio): Removal & Installation Nissan Versa II

Entertainment Systems 14 illustrations ~585 words

INSTALLATION

Installation is in the reverse order of removal.

Scheme 50

Scheme 50: REMOVAL
Scheme 50: REMOVAL
  1. Remove the center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-605962-S04944230152014032500000) ".
  2. Release the pawl from the back of the center console to remove the USB harness connector (1) using a suitable tool.
  3. Disconnect the harness connector from the USB connector and remove.

Installation is in the reverse order of removal.

REMOVAL

  1. Remove the center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-605962-S04944230152014032500000) ".
  2. Disconnect the harness connector from the iPod® adapter and remove.

Installation is in the reverse order of removal.

Scheme 51

Scheme 51: REMOVAL
Scheme 51: REMOVAL
  1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-605966-S16853177272014032500000) ".
  2. Remove the front door speaker screws (A).
  3. Disconnect the harness connector from front door speaker.
  4. Remove the front door speaker (1).

Installation is in the reverse order of removal.

Scheme 52

Scheme 52: REMOVAL
Scheme 52: REMOVAL
  1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-605966-S16008255642014032500000) ".
  2. Remove the rear door speaker screws (A).
  3. Disconnect the harness connector from rear door speaker.
  4. Remove the rear door speaker (1).

Installation is in the reverse order of removal.

Scheme 53

Scheme 53: REMOVAL
Scheme 53: REMOVAL
  1. Remove the headlining assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-605966-S10740158272014032500000) ".
  2. Disconnect the satellite radio antenna retainers (A) using a suitable tool.
  3. Disconnect the harness connectors (B) from satellite radio antenna.
  4. Remove the satellite radio antenna nut (1).
  5. Remove the satellite radio antenna.

Installation is in the reverse order of removal.

Scheme 54

Scheme 54: Removal and Installation
Scheme 54: Removal and Installation
  1. Remove the steering wheel. Refer to " «REMOVAL AND INSTALLATION»(ref-605955-S26028821612014032500000) ".
  2. Remove the steering wheel rear finisher.
  3. Remove the steering wheel audio control switches screws.
  4. Remove the steering wheel audio control switches from the steering wheel.

Installation is in the reverse order of removal.

Scheme 55

Scheme 55: REMOVAL
Scheme 55: REMOVAL

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57
  1. Remove the rear seat cushion assembly. Refer to " «REMOVAL AND INSTALLATION - SEAT CUSHION ASSEMBLY»(ref-605960-S32621707872014032500000) ".
  2. Remove the rear step plate (RH).
  3. Remove the rear seatback side assembly (RH).
  4. Remove the rear seatback assembly (RH).
  5. Remove the trunk floor finisher.
  6. Remove the trunk rear finisher.
  7. Remove the trunk side finisher (RH).
  8. Disconnect the Bluetooth antenna from the bluetooth control unit (A).
  9. Release the four Bluetooth antenna harness clips (B).
  10. Release the remaining Bluetooth antenna harness clip (B) and remove the Bluetooth antenna screw (C).
  11. Remove the Bluetooth antenna assembly (1).

Installation is in the reverse order of removal.

Scheme 58

Scheme 58: REMOVAL
Scheme 58: REMOVAL

Scheme 59

Scheme 59
Scheme 59
  1. Remove the trunk floor finisher.
  2. Remove the trunk rear finisher.
  3. Remove the trunk side finisher (RH).
  4. Disconnect the harness connector (A) from Bluetooth antenna.
  5. Disconnect the harness connectors (B) from Bluetooth control unit.
  6. Remove the Bluetooth control unit screws (C).
  7. Remove the Bluetooth control unit (1).

Installation is in the reverse order of removal.

Scheme 60

Scheme 60: REMOVAL
Scheme 60: REMOVAL
  1. Remove the microphone (1) from the headlining using a suitable tool.
  2. Disconnect the harness connector from microphone and remove.

Installation is in the reverse order of removal.

Scheme 61

Scheme 61: REMOVAL
Scheme 61: REMOVAL
  1. Remove the combination meter. Refer to " «REMOVAL AND INSTALLATION»(ref-605949-S38113077792014032500000) " (Type A) or " «REMOVAL AND INSTALLATION»(ref-605953-S25965447392014032500000) " (Type B).
  2. Remove the AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-605972-S17189115872014032500000) ".
  3. Remove the GPS antenna screw (A), then disconnect the GPS antenna retainer (B).
  4. Remove the GPS antenna.

Installation is in the reverse order of removal.

Scheme 62

Scheme 62: Feeder Layout
Scheme 62: Feeder Layout

Scheme 63

Scheme 63: REMOVAL
Scheme 63: REMOVAL
  1. Remove trunk lid finisher. Refer to " «EXPLODED VIEW»(ref-605937-S10333986912014032500000) ".
  2. Disconnect the harness connector (B) from rear view camera.
  3. Press the rear view camera tab (A) and remove the rear view camera (1).

Installation is in the reverse order of removal.
