Component Description
| Part name | Description |
|---|---|
| Audio unit | Controls audio system functions It inputs AM/FM radio wave signals from rod antenna Outputs sound signal to front door speakers Outputs sound signal to rear door speakers (if equipped) |
| Front door speakers | Outputs sound signal from audio unit Outputs high, mid and low range sounds |
| Rear door speakers (if equipped) | Outputs sound signal from audio unit Outputs high, mid and low range sounds |
| Rod antenna | Receives AM/FM radio wave signals and outputs signals to audio unit |
Scheme 94
Description
The audio unit sends sound signals to the front door speakers using the front door speaker circuits.
The audio unit sends audio signals to the rear door speakers using the rear door speaker circuits.
The majority of the audio concerns are the result of outside causes (bad CD, electromagnetic interference, etc.).
