Audio, Visual & Navigation System (Mid Audio): Removal & Installation Nissan Versa II

Entertainment Systems 12 illustrations ~466 words

INSTALLATION

Installation is in the reverse order of removal.

Scheme 9

Scheme 9: REMOVAL
Scheme 9: REMOVAL
  1. Remove the center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-605962-S04944230152014032500000) ".
  2. Release the pawl from the back of the center console to remove the USB harness connector (1) using a suitable tool.
  3. Disconnect the harness connector from the USB connector and remove.

Installation is in the reverse order of removal.

REMOVAL

  1. Remove the center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-605962-S04944230152014032500000) ".
  2. Disconnect the harness connector from the iPod® adapter and remove.

Installation is in the reverse order of removal.

Scheme 10

Scheme 10: REMOVAL
Scheme 10: REMOVAL
  1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-605966-S16853177272014032500000) ".
  2. Remove the front door speaker screws (A).
  3. Disconnect the harness connector from front door speaker.
  4. Remove the front door speaker (1).

Installation is in the reverse order of removal.

Scheme 11

Scheme 11: REMOVAL
Scheme 11: REMOVAL
  1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-605966-S16008255642014032500000) ".
  2. Remove the rear door speaker screws (A).
  3. Disconnect the harness connector from rear door speaker.
  4. Remove the rear door speaker (1).

Installation is in the reverse order of removal.

Scheme 12

Scheme 12: Exploded View
Scheme 12: Exploded View
  1. Remove the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-605966-S10740158272014032500000) ".
  2. Disconnect the antenna cable.
  3. Remove the antenna base nut.
  4. Remove the antenna base from the roof panel.

Installation is in the reverse order of removal.

CAUTIONTighten the antenna base nut to specifications. If the antenna base nut is less than the specified torque, it will affect the function of the antenna. If the antenna base nut is greater than the specified torque, it will damage the roof panel.

Scheme 13

Scheme 13: Removal and Installation
Scheme 13: Removal and Installation
  1. Remove the steering wheel. Refer to " «REMOVAL AND INSTALLATION»(ref-605955-S26028821612014032500000) ".
  2. Remove the steering wheel rear finisher.
  3. Remove the steering wheel audio control switches screws.
  4. Remove the steering wheel audio control switches from the steering wheel.

Installation is in the reverse order of removal.

Scheme 14

Scheme 14: REMOVAL
Scheme 14: REMOVAL

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Remove the rear seat cushion assembly. Refer to " «REMOVAL AND INSTALLATION - SEAT CUSHION ASSEMBLY»(ref-605960-S32621707872014032500000) ".
  2. Remove the rear step plate (RH).
  3. Remove the rear seatback side assembly (RH).
  4. Remove the rear seatback assembly (RH).
  5. Remove the trunk floor finisher.
  6. Remove the trunk rear finisher.
  7. Remove the trunk side finisher (RH).
  8. Disconnect the Bluetooth antenna from the bluetooth control unit (A).
  9. Release the four Bluetooth antenna harness clips (B).
  10. Release the remaining Bluetooth antenna harness clip (B) and remove the Bluetooth antenna screw (C).
  11. Remove the Bluetooth antenna assembly (1).

Installation is in the reverse order of removal.

Scheme 17

Scheme 17: REMOVAL
Scheme 17: REMOVAL

Scheme 18

Scheme 18
Scheme 18
  1. Remove the trunk floor finisher.
  2. Remove the trunk rear finisher.
  3. Remove the trunk side finisher (RH)
  4. Disconnect the harness connector (A) from Bluetooth antenna.
  5. Disconnect the harness connector (B) from Bluetooth control unit.
  6. Remove the Bluetooth control unit screws (C) and the Bluetooth control unit (1).

Installation is in the reverse order of removal.

Scheme 19

Scheme 19: REMOVAL
Scheme 19: REMOVAL
  1. Remove the microphone (1) from the headlining using a suitable tool.
  2. Disconnect the harness connector from microphone and remove.

Installation is in the reverse order of removal.

Scheme 20

Scheme 20: Feeder Layout
Scheme 20: Feeder Layout
