Audio, Visual & Navigation System (Base Audio): Removal & Installation Nissan Versa II

Entertainment Systems 4 illustrations ~144 words

INSTALLATION

Installation is in the reverse order of removal.

Scheme 95

Scheme 95: REMOVAL
Scheme 95: REMOVAL
  1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-605966-S16853177272014032500000) ".
  2. Remove the front door speaker screws (A).
  3. Disconnect the harness connector from front door.
  4. Remove the front door speaker (1).

Installation is in the reverse order of removal.

Scheme 96

Scheme 96: REMOVAL
Scheme 96: REMOVAL
  1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-605966-S16008255642014032500000) ".
  2. Remove the rear door speaker screws (A).
  3. Disconnect the harness connector from rear door speaker.
  4. Remove the rear door speaker (1).

Installation is in the reverse order of removal.

Scheme 97

Scheme 97: Exploded View
Scheme 97: Exploded View

REMOVAL

  1. Remove the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-605966-S10740158272014032500000) ".
  2. Disconnect the antenna cable.
  3. Remove the antenna base nut.
  4. Remove the antenna base from the roof panel.

Installation is in the reverse order of removal.

CAUTIONTighten the antenna base nut to specifications. If the antenna base nut is less than the specified torque, it will affect the function of the antenna. If the antenna base nut is greater than the specified torque, it will damage the roof panel.

Scheme 98

Scheme 98: Feeder Layout
Scheme 98: Feeder Layout
