Audio, Visual & Navigation System (Base Audio): Other Nissan Versa II

Entertainment Systems 9 illustrations ~789 words

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS articles of this Service Information.

WARNINGTo avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNINGWhen working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.

Precaution for Work

  1. When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
  2. When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
  3. Protect the removed parts with a shop cloth and prevent them from being dropped.
  4. Replace a deformed or damaged clip.
  5. If a part is specified as a non-reusable part, always replace it with a new one.
  6. Be sure to tighten bolts and nuts securely to the specified torque.
  7. After installation is complete, be sure to check that each part works properly.
  8. Follow the steps below to clean components: Water soluble dirt
  9. Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
  10. Then rub with a soft, dry cloth. Oily dirt
  11. Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
  12. Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
  13. Then rub with a soft, dry cloth. Do not use organic solvent such as thinner, benzene, alcohol or gasoline. For genuine leather seats, use a genuine leather seat cleaner.

Special Service Tools

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Tool number (Kent-Moore No.) Tool name Description - (J-46534) Trim tool set Removing trim components

Scheme 101

Scheme 101: Special Service Tools
Scheme 101: Special Service Tools

Commercial Service Tools

Tool name Description Power tool Loosening nuts, screws and bolts

Scheme 102

Scheme 102: Component Parts Location
Scheme 102: Component Parts Location

AUDIO SYSTEM

The audio system consists of the following components

  1. Audio unit
  2. Rod antenna
  3. Front door speakers
  4. Rear door speakers (if equipped)

When the audio system is ON, radio signals are received by the rod antenna. The audio unit then sends sound signals to the front door speakers and rear door speakers (if equipped).

Refer to Owner's Manual for audio system operating instructions.

Scheme 103

Scheme 103: TERMINAL LAYOUT
Scheme 103: TERMINAL LAYOUT

PHYSICAL VALUES

Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 2 (GR) 3 (P) Sound signal front door speaker LH Output Ignition switch ON Audio output 4 (W) (1) 5 (R) (1) Sound signal rear door speaker LH Output Ignition switch ON Audio output 7 (L) Ground ACC power supply Input Ignition switch ACC or ON - Battery voltage 8 (B) Ground ILL control Input Ignition switch ACC or ON - 0 V 9 (LG) Ground Light switch Input Ignition switch ACC or ON - Battery voltage 11 (O) 12 (V) Sound signal front door speaker RH Output Ignition switch ON Audio output 13 (L) (1) 14 (Y) (1) Sound signal rear door speaker RH Output Ignition switch ON Audio output 19 (Y) Ground Battery power supply Input Ignition switch OFF - Battery voltage (1) With rear door speakers

Scheme 104

Scheme 104: Wiring Diagram
Scheme 104: Wiring Diagram

Scheme 105

Scheme 105
Scheme 105

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108

Scheme 109

Scheme 109: OVERALL SEQUENCE
Scheme 109: OVERALL SEQUENCE

DETAILED FLOW

  1. GET INFORMATION FOR SYMPTOM Get detailed information from the customer about the symptom (the condition and the environment when the incident/malfunction occurred). : GO TO 2.
  2. CONFIRM THE SYMPTOM Try to confirm the symptom described by the customer. Verify relation between the symptom and the condition when the symptom is detected. Refer to " «SYMPTOM TABLE»(ref-605983-S35933540462014032500000) ". : GO TO 3.
  3. DETECT MALFUNCTIONING PART BY DIAGNOSTIC PROCEDURE Inspect according to Diagnostic Procedure of the system. Is malfunctioning part detected? YES: GO TO 4. NO: GO TO 2 .
  4. REPAIR OR REPLACE THE MALFUNCTIONING PART Repair or replace the malfunctioning part. Reconnect parts or connectors disconnected during Diagnostic Procedure. : GO TO 5.
  5. FINAL CHECK Refer to confirmed symptom in step 2 , and make sure that the symptom is not detected. Has the symptom been repaired? YES: Inspection End. NO: GO TO 2 .
SymptomPossible causeReference
InoperativeAudio unit power supply and ground circuit Audio unitPOWER SUPPLY AND GROUND CIRCUIT AUDIO UNIT
All speakers do not soundSpeaker circuit shorted to ground Audio unit power supply and ground circuit Audio unitBASE AUDIO SYSTEM POWER SUPPLY AND GROUND CIRCUIT AUDIO UNIT
One or several speakers do not soundFront door speaker Rear door speaker (if equipped)FRONT DOOR SPEAKER REAR DOOR SPEAKER
Buzz/rattle sound from speakerThe majority of buzz/rattle sounds are not indicative of an issue with the speaker, usually something nearby the speaker is causing the buzz/rattle.Refer to "SQUEAK AND RATTLE TROUBLE DIAGNOSIS" in the appropriate interior trim article.

CD

SymptomPossible causeReference
CD cannot be insertedAudio unitAUDIO UNIT
CD cannot be ejected
The CD cannot be played
The sound skips, stops suddenly, or is distorted
