CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART)
Determine CAN system type based on vehicle equipment.
Note. This chart is used if CONSULT-III does not automatically recognize CAN system type. There are two styles for CAN system type specification charts. Depending on the number of available system types, either style A or style B may be used.
CAN System Type Specification Chart (Style A)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 1
CAN System Type Specification Chart (Style B)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 2
CAN System Specification Chart
Note. Refer to " TROUBLE DIAGNOSIS PROCEDURE " for how to use CAN system specification chart.
| Body type | Hatchback/Sedan | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Axle | 2WD | |||||||||
| Engine | MR18DE | |||||||||
| Transmission | M/T | A/T | CVT | |||||||
| Brake control | ABS | ABS | ABS | |||||||
| Intelligent Key system | X | X | X | X | ||||||
| CAN system type | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 |
| Start CAN Diagnosis (CONSULT-III) | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 |
| X: Applicable | ||||||||||
CAN SYSTEM SPECIFICATION CHART
