Driver Information System: Wiring Nissan Versa I

Wiring Diagram - METER

Note. For references to PG-Power, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 63

Scheme 64

Scheme 65

Check Fuel Level Sensor Unit and Fuel Pump Harness

Check continuity at the following terminals.

TERMINALS CONTINUITY REFERENCE

Scheme 66

1. If the results of check are NG, replace fuel pump assembly. If the results of check are OK, replace fuel level sensor unit.

Wiring Diagram - WARN

Note. For references to PG-Power, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. CHECK OIL PRESSURE WARNING LAMP OPERATION Activate IPDM E/R auto active test. Refer to " «AUTO ACTIVE TEST»(ref-337618-S19901098922009080600000) ". Does oil pressure warning lamp blink? YES >> GO TO 2. NO >> GO TO 5 .
2. CHECK IPDM E/R INPUT SIGNAL Turn ignition switch ON. Check voltage between IPDM E/R harness connector and ground. VOLTAGE SPECIFICATION Terminals Condition Voltage (Approx.) (+) (-) IPDM E/R connector Terminal E46 37 Ground Engine stopped 0 V OK or NG OK >> Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-337618-S28938113412009080600000) ". NG >> GO TO 3.
3. CHECK OIL PRESSURE SWITCH Turn ignition switch OFF. Disconnect oil pressure switch connector. Check oil pressure switch. Refer to " «OIL PRESSURE SWITCH»(ref-337635-S11216549732009080600000) ". OK or NG OK >> GO TO 4. NG >> Replace oil pressure switch.
4. CHECK OIL PRESSURE SWITCH CIRCUIT Disconnect IPDM E/R connector. Check continuity between IPDM E/R harness connector (A) and oil pressure switch harness connector (B). TERMINALS CONTINUITY REFERENCE A B Continuity Connector Terminal Connector Terminal E46 37 F32 1 Yes OK or NG OK >> Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-337618-S28938113412009080600000) ". NG >> Repair harness or connector.
5. CHECK CAN COMMUNICATION Select "METER" on CONSULT-III, and perform self-diagnosis of combination meter. Self-diagnostic results content No malfunction detected >> GO TO 6. Malfunction detected >> Check applicable parts, and repair or replace as necessary.
6. CHECK COMBINATION METER INPUT SIGNAL Select "METER" on CONSULT-III. Operate ignition switch with "OIL W/L" of "DATA MONITOR" and check operation status. "OIL W/L" When ignition switch is in ON position (Engine stopped.): ON When engine running: OFF OK or NG OK >> Replace combination meter. Refer to " «COMBINATION METER»(ref-337620-S00700295732009080600000) ". NG >> Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-337618-S28938113412009080600000) ".

Wiring Diagram - AT/IND

Note. For references to PG-Power, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 78

Scheme 79

Scheme 80

1. CHECK SEGMENT OF A/T INDICATOR Perform self-diagnosis of combination meter. Refer to " «OPERATION PROCEDURE»(ref-337635-S02021108292009080600000) ". Are all segments displayed? YES >> GO TO 2. NO >> Replace combination meter. Refer to " «COMBINATION METER»(ref-337620-S00700295732009080600000) ".
2. CHECK COMBINATION METER (CONSULT-III) Connect CONSULT-III. Select "METER" on CONSULT-III, and perform self-diagnosis of combination meter. Refer to " «SELF-DIAGNOSTIC RESULTS»(ref-337635-S08049332002009080600000) ". Self-diagnostic results content No malfunction detected >> GO TO 3. Malfunction detected >> Check applicable parts, and repair or replace as necessary.
3. CHECK COMBINATION METER INPUT SIGNAL Use "DATA MONITOR" of "METER" on CONSULT-III. Confirm each indication on the monitor when operating the A/T selector lever. SWITCH OPERATION AND OPERATION STATUS CONSULT-III display Switch operation Operation status P RANGE IND P range position ON Except for P range position OFF R RANGE IND R range position ON Except for R range position OFF N RANGE IND N range position ON Except for N range position OFF D RANGE IND D range position ON Except for D range position OFF 2 RANGE IND 2 range position ON Except for 2 range position OFF 1 RANGE IND 1 range position ON Except for 1 range position OFF OK or NG OK >> Replace combination meter. Refer to " «COMBINATION METER»(ref-337620-S00700295732009080600000) ". NG >> GO TO 4.
4. CHECK SELF-DIAGNOSIS RESULTS OF TCM Perform self-diagnosis of TCM. Refer to " «SELF-DIAGNOSTIC RESULT MODE»(ref-337615-S23700200462009080600000) ". OK or NG OK >> Check TCM input/output signal. Repair or replace malfunctioning part, if necessary. Refer to " «INPUT/OUTPUT SIGNAL OF TCM»(ref-337615-S38272141622009080600000) ". NG >> Check applicable part, and repair or replace as necessary.

Wiring Diagram - CVTIND

Note. For references to PG-Power, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 81

Scheme 82

Wiring Diagram - CHIME

Note. For references to PG-Power, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 83

Scheme 84
