Driver Information System: Diagnosis Nissan Versa I

SELF-DIAGNOSIS MODE FUNCTION

1. Self-diagnosis can check for continuity between meter control circuit and each meter (speedometer, tachometer and fuel gauge).
2. Self-diagnosis can check for ODO/trip meter and A/T indicator (with A/T) or CVT indicator (with CVT) segment, low-fuel level warning lamp, low water temperature indicator lamp, and high water temperature warning lamp.

Scheme 44

Scheme 45

Scheme 46

1. Turn the ignition switch ON, and switch the ODO/trip meter to "trip A" or "trip B". NOTE: If the diagnosis function is activated with "trip A" displayed, the mileage on "trip A" will indicate "0000.0", but the actual trip mileage will be retained. (The same applies for "trip B").
2. Turn ignition switch OFF.
3. While pushing the ODO/trip meter switch (1), turn the ignition switch ON.
4. Confirm that the trip meter displays "0000.0".
5. Push the ODO/trip meter switch at least 3 times. (Within 7 seconds after the ignition switch is turned ON.)
6. All the segments on the ODO/trip meter, and simultaneously the low-fuel warning lamp indicator illuminates. At this time, the unified meter control unit is turned to self-diagnosis mode. M/T MODELS (1) A/T AND CVT MODELS (2) NOTE: Check combination meter power supply and ground circuit when self-diagnosis mode of combination meter does not start. Replace combination meter if normal. Refer to " «COMBINATION METER»(ref-337620-S00700295732009080600000) ". If any of the segments is not displayed, replace combination meter. Refer to " «COMBINATION METER»(ref-337620-S00700295732009080600000) ".
7. Each meter activates while pressing ODO/trip meter switch. (At this time, the low-fuel warning lamp turns off, low water temperature indicator lamp and high water temperature warning lamp turn on.) NOTE: If any of the meter and gages are not activated, replace combination meter. Refer to " «COMBINATION METER»(ref-337620-S00700295732009080600000) ".

HOW TO PERFORM TROUBLE DIAGNOSIS

1. Confirm the symptom or customer complaint.
2. Perform preliminary check. Refer to " «PRELIMINARY CHECK»(ref-337635-S37353876492009080600000) ".
3. According to the symptom chart, repair or replace the cause of the malfunction. Refer to " «SYMPTOM CHART»(ref-337635-S10217087472009080600000) ".
4. Does the meter operate normally? If so, GO TO 5. If not, GO TO 2 .
5. Inspection End.

Symptom Chart

SYMPTOM CHART

Scheme 47

Scheme 48

1. CHECK FUSE Check for blown combination meter fuses. FUSE CHECKING REFERENCE Power source Fuse No. Battery 13 Ignition switch ON or START 14 OK or NG OK >> GO TO 2. NG >> Be sure to eliminate cause of malfunction before installing new fuse. Refer to " «POWER SUPPLY ROUTING CIRCUIT»(ref-337618-S12320956552009080600000) ".
2. CHECK POWER SUPPLY CIRCUIT Check voltage between combination meter harness connector terminals and ground. TERMINALS VOLTAGE REFERENCE Terminals Ignition switch position (+) (-) OFF ON Combination meter connector Terminal M24 27 Ground Battery voltage Battery voltage 28 OV Battery voltage OK or NG OK >> GO TO 3. NG >> Repair harness or connector.
3. CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect combination meter connector. Check continuity between combination meter harness connector terminals and ground. TERMINALS CONTINUITY REFERENCE Combination meter connector Terminal Ground Continuity M24 21 Yes 22 23 OK or NG OK >> Replace combination meter. Refer to " «COMBINATION METER»(ref-337620-S00700295732009080600000) ". NG >> Repair harness or connector.

Vehicle Speed Signal Inspection

Symptom

1. Improper speedometer and ODO/trip meter indication.
2. Display VEHICLE SPEED CIRC [B2205] at the result of self-diagnosis for combination meter.

Engine Speed Signal Inspection

Symptom: Improper tachometer indication.

1. CHECK COMBINATION METER INPUT SIGNAL Start engine and select "METER" on CONSULT-III. Using "TACHO METER" on "DATA MONITOR", compare the value of "DATA MONITOR" with tachometer pointer of combination meter. OK or NG OK >> Perform ECM self-diagnosis. Refer to " «SELF-DIAG RESULTS MODE»(ref-319464-S21873960492009062600000) ". NG >> Replace combination meter. Refer to " «COMBINATION METER»(ref-337620-S00700295732009080600000) ".

Fuel Level Sensor Signal Inspection

Symptom

1. Improper fuel gauge indication.
2. Low-fuel warning lamp indication is irregular.

Note. The following symptoms do not indicate a malfunction. Depending on vehicle position or driving circumstance, the fuel level in the tank shifts and the indication may fluctuate. If the vehicle is fueled with the ignition switch ON, the indication will update slowly. If the vehicle is tilted when the ignition switch is turned ON, fuel in the tank may flow to one direction resulting in a change of reading.

Scheme 49

Scheme 50

1. CHECK COMBINATION METER INPUT SIGNAL Select "METER" on CONSULT-III. Using "FUEL METER" on "DATA MONITOR", compare the value of "DATA MONITOR" with fuel gauge pointer of combination meter. REFERENCE VALUE OF DATA MONITOR Fuel gauge pointer Reference value of data monitor [lit.] Full Approx. 49 3/4 Approx. 34 1/2 Approx. 22 1/4 Approx. 10 Empty Approx. 4 OK or NG OK >> GO TO 2. NG >> Replace combination meter. Refer to " «COMBINATION METER»(ref-337620-S00700295732009080600000) ".
2. CHECK HARNESS CONNECTOR Turn ignition switch OFF. Check combination meter and fuel level sensor unit terminals (meter-side and harness-side) for poor connection. OK or NG OK >> GO TO 3. NG >> Repair or replace terminals or connectors.
3. CHECK FUEL LEVEL SENSOR UNIT CIRCUIT Disconnect combination meter connector and fuel level sensor unit connector. Check continuity between combination meter harness connector (A) and fuel level sensor unit and fuel pump harness connector (B). TERMINALS CONTINUITY REFERENCE A B Continuity Connector Terminal Connector Terminal M24 6 B100 2 Yes Check continuity between combination meter harness connector (A) and ground. TERMINALS CONTINUITY REFERENCE A Ground Continuity Connector Terminal M24 6 No OK or NG OK >> GO TO 4. NG >> Repair harness or connector.
4. CHECK FUEL LEVEL SENSOR UNIT GROUND CIRCUIT Check continuity between combination meter harness connector (A) and fuel level sensor unit and fuel pump harness connector (B). TERMINALS CONTINUITY REFERENCE A B Continuity Connector Terminal Connector Terminal M24 24 B100 5 Yes Check continuity between combination meter harness connector (A) and ground. TERMINALS CONTINUITY REFERENCE A Ground Continuity Connector Terminal M24 24 No OK or NG OK >> GO TO 5. NG >> Repair harness or connector.
5. CHECK FUEL LEVEL SENSOR UNIT Check fuel level sensor unit. Refer to " «FUEL LEVEL SENSOR UNIT CHECK»(ref-337635-S30759147902009080600000) ". OK or NG OK >> Check fuel level sensor unit installation, and check whether the float arm interferes or binds with any of the internal components in the fuel tank. Repair or replace malfunctioning part, if necessary. NG >> Replace fuel level sensor unit.

1. Confirm the symptom and customer complaint.
2. Understand the outline of system. Refer to " «SYSTEM DESCRIPTION»(ref-337635-S15225007392009080600000) ".
3. Perform the preliminary inspection. Refer to " «PRELIMINARY INSPECTION»(ref-337635-S00806574872009080600000) ".
4. According to symptom chart, repair or replace the cause of the malfunction. Refer to " «SYMPTOM CHART»(ref-337635-S01511447352009080600000) ".
5. Does warning chime system operate normally? If it operates normally, GO TO 6. If not, GO TO 4 .
6. Inspection End.

PRELIMINARY INSPECTION

1. CHECK BCM Perform self-diagnosis of BCM. Refer to " «CONSULT-III Function (BCM)»(ref-337635-S37406395902009080600000) ". Self-diagnostic results content No malfunction detected >> GO TO 2. Malfunction detected >> Check applicable parts, and repair or replace corresponding parts.
2. CHECK COMBINATION METER Perform self-diagnosis of combination meter. Refer to " «CONSULT-III Function (METER)»(ref-337635-S21043783972009080600000) ". Self-diagnostic results content No malfunction detected >> Inspection End. Malfunction detected >> Check applicable parts, and repair or replace corresponding parts.

SYMPTOM CHART

Scheme 51

Scheme 52

1. CHECK CHIME OPERATION Select "BUZZER" of "BCM" on CONSULT-III. Perform "LIGHT WARN ALM" or "IGN KEY WARN ALM" of "ACTIVE TEST". Does chime sound? YES >> Combination meter buzzer circuit is OK. Return to " «SYMPTOM CHART»(ref-337635-S01511447352009080600000) ". NO >> GO TO 2.
2. CHECK COMBINATION METER INPUT SIGNAL Select "METER" on CONSULT-III. Turn on hazard switch or lighting switch while monitoring "BUZZER" of "DATA MONITOR" and check operation status. "BUZZER" While hazard switch or lighting switch is ON: ON and OFF repeatedly Except above: OFF OK or NG OK >> Check battery power supply circuit of combination meter. If OK, replace combination meter. Refer to " «COMBINATION METER»(ref-337620-S00700295732009080600000) ". NG >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION OF BCM»(ref-337631-S05941440782009080600000) ".

Scheme 53

Scheme 54

Scheme 55

1. CHECK BCM INPUT SIGNAL With CONSULT-III Select "BCM". With "DTA MONITOR" of "BUZZER", confirm "DOOR SW-DR" when the driver's door is operated. "DOOR SW-DR" When driver's door is opened: ON When driver's door is closed: OFF Without CONSULT-III Check voltage between BCM harness connector and ground. TERMINALS VOLTAGE REFERENCE Terminals Condition Voltage (Approx.) (+) (-) BCM connector Terminal M19 47 Ground Driver's door is opened 0 Driver's door is closed Battery voltage OK or NG OK >> Front door switch LH signal is OK. Return to " «SYMPTOM CHART»(ref-337635-S01511447352009080600000) ". NG >> GO TO 2.
2. CHECK FRONT DOOR SWITCH LH CIRCUIT Turn ignition switch OFF. Disconnect BCM connector and front door switch LH connector. Check continuity between BCM harness connector (A) and front door switch LH harness connector (B). TERMINALS CONTINUITY REFERENCE A B Continuity Connector Terminal Connector Terminal M19 47 B8 2 Yes Check continuity between BCM harness connector (A) and ground. TERMINALS CONTINUITY REFERENCE A Ground Continuity Connector Terminal M19 47 No OK or NG OK >> GO TO 3. NG >> Repair harness or connector.
3. CHECK FRONT DOOR SWITCH LH Check front door switch LH. Refer to " «FRONT DOOR SWITCH LH»(ref-337635-S19419150502009080600000) ". OK or NG OK >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION OF BCM»(ref-337631-S05941440782009080600000) ". NG >> Replace front door switch LH.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. CHECK FUSE Check if the key switch and key lock solenoid 10A fuse [No. 14, located in the fuse block (J/B)] is blown. OK or NG OK >> GO TO 2. NG >> Be sure to repair the cause of malfunction before installing new fuse. Refer to " «POWER SUPPLY ROUTING CIRCUIT»(ref-337618-S12320956552009080600000) ".
2. CHECK BCM INPUT SIGNAL With CONSULT-III Select "BCM". With "DATA MONITOR" of "BUZZER", confirm "KEY ON SW" when the key is operated. "KEY ON SW" When key is inserted into ignition key cylinder: ON When key is removed from ignition key cylinder: OFF Without CONSULT-III Check voltage between BCM harness connector and ground. TERMINALS VOLTAGE REFERENCE Terminals Condition Voltage (Approx.) (+) (-) BCM connector Terminal M18 37 Ground Key is inserted Battery voltage Key is removed 0 V OK or NG OK >> Key switch signal is OK. Return to " «SYMPTOM CHART»(ref-337635-S01511447352009080600000) ". NG >> GO TO 3.
3. CHECK KEY SWITCH Turn ignition switch OFF. Disconnect key switch and key lock solenoid connector. Check continuity between key switch and key lock solenoid terminals 1 and 2. TERMINALS CONTINUITY REFERENCE Terminals Condition Continuity 1 2 When key is inserted into ignition key cylinder Yes When key is removed from ignition key cylinder No OK or NG OK >> GO TO 4. NG >> Replace key switch and key lock solenoid.
4. CHECK KEY SWITCH CIRCUIT Disconnect BCM connector. Check continuity between BCM harness connector (A) and key switch and key lock solenoid harness connector (B). TERMINALS CONTINUITY REFERENCE A B Continuity Connector Terminal Connector Terminal M18 37 M27 1 Yes Check continuity between BCM harness connector (A) and ground. TERMINALS CONTINUITY REFERENCE A Ground Continuity Connector Terminal M18 37 No OK or NG OK >> GO TO 5. NG >> Repair harness or connector.
5. CHECK KEY SWITCH POWER SUPPLY CIRCUIT Check voltage between key switch and key lock solenoid harness connector and ground. TERMINALS VOLTAGE REFERENCE Terminals Voltage (Approx.) (+) (-) Key switch and key lock solenoid connector Terminal M27 2 Ground Battery voltage OK or NG OK >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION OF BCM»(ref-337631-S05941440782009080600000) ". NG >> Repair harness or connector.

Key Switch and Ignition Knob Switch Signal Inspection (With Intelligent Key, When Mechanical Key Is Used)

1. CHECK FUSE Check if the key switch and ignition knob switch 10A fuse (No. 31, located in the fuse and fusible link box) is blown. OK or NG OK >> GO TO 2. NG >> Be sure to repair the cause of malfunction before installing new fuse. Refer to " «POWER SUPPLY ROUTING CIRCUIT»(ref-337618-S12320956552009080600000) ".
2. CHECK BCM INPUT SIGNAL With CONSULT-III Select "BCM". With "DATA MONITOR" of "BUZZER", confirm "KEY ON SW" when the key is operated. "KEY ON SW" When key is inserted into ignition key cylinder: ON When key is removed from ignition key cylinder: OFF Without CONSULT-III Check voltage between BCM harness connector and ground. TERMINALS VOLTAGE REFERENCE Terminals Condition Voltage (Approx.) (+) (-) BCM connector Terminal M18 37 Ground Key is inserted Battery voltage Key is removed 0 OK or NG OK >> Key switch and ignition knob switch signal is OK. Return to " «SYMPTOM CHART»(ref-337635-S01511447352009080600000) ". NG >> GO TO 3.
3. CHECK KEY SWITCH Turn ignition switch OFF. Disconnect key switch and ignition knob switch connector. Check continuity between key switch and ignition knob switch terminals 1 and 2. TERMINALS CONTINUITY REFERENCE Terminals Condition Continuity 1 2 When key is inserted into ignition key cylinder Yes When key is removed from ignition key cylinder No OK or NG OK >> GO TO 4. NG >> Replace key switch and ignition knob switch.
4. CHECK KEY SWITCH CIRCUIT Disconnect BCM connector. Check continuity between BCM harness connector (A) and key switch and ignition knob switch harness connector (B). TERMINALS CONTINUITY REFERENCE A B Continuity Connector Terminal Connector Terminal M18 37 M73 1 Yes Check continuity between BCM harness connector (A) and ground. TERMINALS CONTINUITY REFERENCE A Ground Continuity Connector Terminal M18 37 No OK or NG OK >> GO TO 5. NG >> Repair harness or connector.
5. CHECK KEY SWITCH POWER SUPPLY CIRCUIT Check voltage between key switch and ignition knob switch harness connector and ground. TERMINALS VOLTAGE REFERENCE Terminals Voltage (Approx.) (+) (-) Key switch and key lock solenoid connector Terminal M73 2 Ground Battery voltage OK or NG OK >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION OF BCM»(ref-337631-S05941440782009080600000) ". NG >> Repair harness or connector.

Scheme 61

1. CHECK BCM INPUT SIGNAL Select "BCM". With "DATA MONITOR" of "BUZZER", confirm "LIGHT SW 1ST" when the lighting switch is operated. "LIGHT SW 1ST" Lighting switch (1st position): ON Lighting switch (OFF): OFF OK or NG OK >> Lighting switch signal is OK. Return to " «SYMPTOM CHART»(ref-337635-S01511447352009080600000) ". NG >> Check the lighting switch. Refer to " «COMBINATION SWITCH INSPECTION»(ref-337636-S21535431662009080600000) ".

Scheme 62

1. CHECK PARKING BRAKE SWITCH SIGNAL INPUT (COMBINATION METER) Turn ignition switch ON. Check voltage between combination meter harness connector M24 terminal 10 and ground. TERMINALS VOLTAGE REFERENCE Terminals Condition Voltage (Approx.) (+) (-) Combination meter connector Terminal M24 10 Ground Parking brake released Battery voltage Parking brake applied 0 OK or NG OK >> Replace combination meter. Refer to «FUEL LEVEL SENSOR UNIT CHECK»(ref-337635-S30759147902009080600000) NG >> GO TO 2.
2. CHECK PARKING BRAKE SWITCH CIRCUIT Turn ignition switch OFF. Disconnect combination meter connector and parking brake switch connector. Check continuity between combination meter harness connector (A) and parking brake switch harness connector (B). TERMINALS CONTINUITY REFERENCE A B Continuity Connector Terminal Connector Terminal M24 10 M17 1 Yes Check continuity between combination meter harness connector (A) and ground. TERMINALS CONTINUITY REFERENCE A Ground Continuity Connector Terminal M24 10 No OK or NG OK >> GO TO 3. NG >> Repair harness or connector.
3. CHECK PARKING BRAKE SWITCH Check parking brake switch. Refer to «ELECTRICAL COMPONENT INSPECTION»(ref-337635-S37951909552009080600000) OK or NG OK >> Check parking brake switch case ground. NG >> Replace parking brake switch.
