System Description

BCM (body control module) controls the operation of various electrical units installed on the vehicle.

CAN Communication System Description

Refer to " SYSTEM DESCRIPTION ".

Scheme 27

Scheme 27: Schematic

Scheme 28

Scheme 28

Scheme 29

Scheme 29: BCM Terminal Arrangement

DESCRIPTION

CONFIGURATION has three functions as follows

  1. READ CONFIGURATION is the function to read (extract) vehicle configuration of current BCM.
  2. WRITE CONFIGURATION-Manual selection is the function to select and write vehicle configuration on BCM manually.
  3. WRITE CONFIGURATION-Config file is the function to write vehicle configuration with the data extracted from current BCM.
  4. For READ CONFIGURATION and WRITE CONFIGURATION-Config file, refer to CONSULT-III Operation Manual.
  5. For WRITE CONFIGURATION-Manual selection using the following flow chart, identify the correct model and configuration list. Confirm and/or change setting value for each item according to the configuration list. Depending on CONSULT-III software version being used, some or all of the write configuration items shown in the following configuration lists may be displayed. If an item does not appear on the CONSULT-III WRITE CONFIGURATION-Manual selection screen(s), then it is an auto setting item and it cannot be manually set or changed.

Note. Confirm vehicle model on IDENTIFICATION PLATE. Refer to MODEL VARIATION .

ITEMSET VAL
KEYLESS ENTRYWITH <--> WITHOUT
I-KEYWITH <--> WITHOUT
DTRLWITH <--> WITHOUT
THEFT ALARMWITH <--> WITHOUT
CAUTIONWhen replacing BCM, you must perform WRITE CONFIGURATION with CONSULT-III. Complete the procedure of WRITE CONFIGURATION in order. If you set incorrect WRITE CONFIGURATION, incidents will occur. Configuration is different for each vehicle model. Confirm configuration of each vehicle model.

Scheme 30

Scheme 30: REMOVAL
  1. Remove the glove box. Refer to " «GLOVE BOX ASSEMBLY»(ref-337620-S18878694242009080600000) ".
  2. Remove the BCM screws, disconnect the connectors and remove the BCM (1).
