Glass & Window System: Removal & Installation Nissan Rogue II

Windows 9 illustrations ~616 words

INSTALLATION

Installation is in the reverse order of removal.

  1. Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  2. Adhesive shall be continuously applied to assure watertightness. Glass installation shall be finished within five minutes after applying the adhesive.
  3. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger compartment air pressure when a door is closed.
  4. The molding must be installed securely so that it is in position and leaves no gap.
  5. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the windshield in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully ready to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. The curing time will increase under lower temperatures and lower humidity.

Scheme 44

Scheme 44
Scheme 44

Installation is in the reverse order of removal.

CAUTIONWhen the main power window and door lock/unlock switch or front power window and door lock/unlock switch RH is removed it is necessary to perform the initialization procedure. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT ". Tighten bolts to specification. Refer to " EXPLODED VIEW ".

Installation is in the reverse order of removal.

CAUTIONWhen the main power window and door lock/unlock switch or front power window and door lock/unlock switch RH is removed it is necessary to perform the initialization procedure. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT ". Tighten front door regulator bolts to specification. Refer to " EXPLODED VIEW ".

Installation is in the reverse order of removal.

Scheme 45

Scheme 45: Exploded View
Scheme 45: Exploded View

Scheme 46

Scheme 46: REMOVAL
Scheme 46: REMOVAL

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49
  1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-616755-S36100936762014051900000) ".
  2. Remove the rear door vapor barrier (1).
  3. Temporarily reconnect the rear power window switch.
  4. Operate the rear power window switch to raise/lower the rear door glass until the rear door glass regulator to rear door glass bolts (A) can be seen and remove.
  5. Remove screws and rear door corner finisher (1).
  6. Remove the rear door glass (1).

Installation is in the reverse order of removal.

CAUTIONTighten the rear door regulator bolts to glass specification. Refer to " EXPLODED VIEW "

Installation is in reverse order of removal.

CAUTIONTighten the rear door regulator to specification Refer to " EXPLODED VIEW "

Scheme 50

Scheme 50: REMOVAL
Scheme 50: REMOVAL
  1. Remove rear door glass regulator. Refer to " «REMOVAL AND INSTALLATION»(ref-616774-S31103685952014051900000) ".
  2. Remove screws (A) and rear door power window motor (1) from rear door glass regulator (2).

Installation is in the reverse order of removal.

Scheme 51

Scheme 51: Exploded View
Scheme 51: Exploded View

REMOVAL

  1. Remove the luggage side upper finisher. Refer to " «LUGGAGE SIDE UPPER FINISHER: REMOVAL AND INSTALLATION»(ref-616755-S08977301172014051900000) ".
  2. Remove quarter glass from the inside of vehicle using a piano wire or cutting tool and an inflatable bag. WARNING: When cutting the quarter window from the vehicle, always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands. CAUTION: Apply protective tape around the quarter glass to protect the painted surface. Be careful not to scratch the quarter window glass when removing. Do not set or stand the quarter window glass on its edge. Small chips may develop into cracks.

Installation is in the reverse order of removal.

  1. Install the quarter glass from outside the vehicle to ensure that it is even around the top, bottom and sides of the opening.
  2. Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  3. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger compartment air pressure when a door is closed.
  4. Check gap along bottom to confirm that glass does not contact sheet metal.
  5. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the glass in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully read the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. The curing time will increase under lower temperatures and lower humidity.

Installation is in the reverse order of removal.

  1. Use genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  2. Adhesive shall be continuously applied to assure watertightness. Glass installation shall be finished within five minutes after applying adhesive.
  3. While urethane adhesive is curing, open door window. This will prevent glass from being forced out by passenger compartment air pressure when door is closed.
  4. Start and finish urethane adhesive application at the bottom to assure watertightness.
  5. Inform customer that vehicle should remain stationary until urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. Materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving vehicle before urethane adhesive has completely cured may affect performance of the windshield in case of an accident.
CAUTIONDo not use adhesive which is past its usable term. Shelf life of this product is limited to six months after date of manufacture. Carefully read expiration or manufacture date printed on box. Keep primers and adhesive in cool, dry place. Ideally, they should be stored in refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. Vehicle should not be driven for at least 24 hours or until urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. Curing time will increase under lower temperatures and lower humidity.

Scheme 52

Scheme 52
Scheme 52
