Abbreviation List
Unit name abbreviations in CONSULT CAN diagnosis and in this article are as per the following list.
| Abbreviation | Unit name |
|---|---|
| 4WD | AWD control unit |
| A-BAG | Air bag diagnosis sensor unit |
| ABS | ABS actuator and electric unit (control unit) |
| AV | AV control unit |
| AVM | Around view monitor control unit |
| BCM | BCM |
| CCM | Chassis control module |
| DLC | Data link connector |
| ECM | ECM |
| EPS | EPS control unit |
| HVAC | A/C auto amp. (with auto A/C) |
| Front air control (without auto A/C) | |
| ICC | Distance sensor |
| IPDM-E | IPDM E/R |
| M&A | Combination meter |
| PWBD | Automatic back door control module |
| STRG | Steering angle sensor |
| TCM | TCM |
DESCRIPTION
- CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.
- The following control units include a gateway function and communicate signals between the different CAN communication circuits.
| CAN communication circuit | Gateway control unit | Reference |
|---|---|---|
| CAN communication circuit 1 <==> CAN communication circuit 2 | BCM | " SYSTEM DESCRIPTION " |
CAN Communication Signal Generation
Scheme 17
Scheme 18
Scheme 19
- Termination circuits (resistors) are connected across the CAN communication system. When transmitting a CAN communication signal, each control unit passes a current to the CAN-H line and the current returns to the CAN-L line.
- The current flows separately into the termination circuits connected across the CAN communication system and the termination circuits drop voltage to generate a potential difference between the CAN-H line and the CAN-L line. NOTE: A signal with no current passage is called "Recessive" and one with current passage is called "Dominant".
- The system produces digital signals for signal communications, by using the potential difference.
The Construction of CAN Communication Signal (Message)
Scheme 20
| No. | Message name | Description |
|---|---|---|
| 1 | Start of frame (1 bit) | Start of message. |
| 2 | Arbitration of field (11 bit) | Priorities of message-sending are shown when there is a possibility that multiple messages are sent at the same time. |
| 3 | Control field (6 bit) | Signal quantity in data field is shown. |
| 4 | Data field (0-64 bit) | Actual signal is shown. |
| 5 | CRC field (16 bit) | The transmitting control unit calculates sending data in advance and writes the calculated value in a message. The receiving control unit calculates received data and judges that the data reception is normal when the calculated value is the same as the value written in the sent data. |
| 6 | ACK field (2 bit) | The completion of normal reception is sent to the transmitting unit. |
| 7 | End of frame (7 bit) | End of message. |
CAN Communication Line
The CAN communication line is a twisted pair wire consisting of strands of CAN-H and CAN-L and has noise immunity.
Scheme 21
Note. The CAN communication system has the characteristics of noise-resistant because this system produces digital signals by using the potential difference between the CAN-H line and the CAN-L line and has the twisted pair wire structure.
Since the CAN-H line and the CAN-L line are always adjacent to each other, the same degree of noise occurs, respectively, when a noise (1) occurs. Although the noise changes the voltage, the potential difference (2) between the CAN-H line and the CAN-L line is insensitive to noise. Therefore, noise-resistant signals can be obtained.
Scheme 22
CAN Signal Communications
Each control unit of the CAN communication system transmits signals through the CAN communication control circuit included in the control unit and receives only necessary signals from each control unit to perform various kinds of control.
Scheme 23
Scheme 24
- Example: Transmitted signals
- Example: Received signals
Note. The above signal names and signal communications are provided for reference purposes. For CAN communications signals of this vehicle, refer to " CAN COMMUNICATION SYSTEM: CAN COMMUNICATION SIGNAL CHART ".
