Power Window Control System: Diagnosis Nissan Rogue II

Windows 4 illustrations ~4791 words

BCM (BODY CONTROL SYSTEM) (WITH INTELLIGENT KEY SYSTEM): Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK FUSE Check that the following fuse is not blown. Terminal No. Signal name Fuse No. 161 BCM power supply 7 (10A) Is the fuse blown? YES: Replace the blown fuse after repairing the affected circuit. NO: GO TO 2.
  2. CHECK POWER SUPPLY CIRCUIT Disconnect BCM connector M20. Check voltage between BCM connector M20 and ground. BCM Ground Voltage (Approx.) Connector Terminal M20 161 - Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connectors.
  3. CHECK GROUND CIRCUIT Check continuity between BCM connector M20 and ground. BCM Ground Continuity Connector Terminal M20 170 - Yes 171 Is the inspection result normal? YES: Inspection End. NO: Repair or replace harness or connectors.

BCM (BODY CONTROL SYSTEM) (WITHOUT INTELLIGENT KEY SYSTEM): Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK FUSE Check that the following fuse is not blown. Terminal No. Signal name Fuse No. 161 BCM power supply 7 (10A) Is the fuse blown? YES: Replace the blown fuse after repairing the affected circuit. NO: GO TO 2.
  2. CHECK POWER SUPPLY CIRCUIT Disconnect BCM connector M20. Check voltage between BCM connector M20 and ground. BCM Ground Voltage (Approx.) Connector Terminal M20 161 - Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connectors.
  3. CHECK GROUND CIRCUIT Check continuity between BCM connector M20 and ground. BCM Ground Continuity Connector Terminal M20 170 - Yes 171 Is the inspection result normal? YES: Inspection End. NO: Repair or replace harness or connectors.

POWER WINDOW MAIN SWITCH: Diagnosis Procedure

  1. CHECK POWER SUPPLY CIRCUIT 1 Turn ignition OFF. Disconnect main power window and door lock/unlock switch connector. Turn ignition switch ON. Check voltage between main power window and door lock/unlock switch harness connector and ground. (+) (-) Voltage (Approx.) Main power window and door lock/unlock switch Connector Terminal D6 10 Ground Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 4 .
  2. CHECK POWER SUPPLY CIRCUIT 2 Check voltage between main power window and door lock/unlock switch harness connector and ground. (+) (-) Voltage (Approx.) Main power window and door lock/unlock switch Connector Terminal D6 18 Ground Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair power supply circuit.
  3. CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between main power window and door lock/unlock switch harness connector and ground. Main power window and door lock/unlock switch Ground Continuity Connector Terminal D6 1 Yes Is the inspection result normal? YES: Inspection End. NO: Repair or replace harness.
  4. CHECK HARNESS CONTINUITY 1 Turn ignition switch OFF. Disconnect power window relay connector. Check continuity between power window relay harness connector and main power window and door lock/unlock switch harness connector. Power window relay Main power window and door lock/unlock switch Continuity Connector Terminal Connector Terminal M58 3 D6 10 Yes Check continuity between power window relay harness connector and ground. Power window relay Ground Continuity Connector Terminal M58 3 No Is the inspection result normal? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-616767-S35750020532014051900000) ". NO: Repair or replace harness.

FRONT POWER WINDOW SWITCH (PASSENGER SIDE): Diagnosis Procedure

  1. CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect front power window switch RH connector. Turn ignition switch ON. Check voltage between front power window switch RH harness connector and ground. (+) (-) Condition Voltage (Approx.) Front power window switch RH Connector Terminal D112 8 Ground Ignition switch ON Battery voltage Is the inspection result normal? YES: Inspection End. NO: GO TO 2.
  2. CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect power window relay connector. Check continuity between power window relay harness connector and front power window switch RH harness connector. Power window relay Front power window switch RH Continuity Connector Terminal Connector Terminal M58 3 D112 8 Yes Check continuity between the power window relay harness connector and ground. Power window relay Ground Continuity Connector Terminal M58 3 No Is the inspection result normal? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-616767-S35750020532014051900000) ". NO: Repair or replace harness.

REAR POWER WINDOW SWITCH: Diagnosis Procedure

  1. CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch connector. Turn ignition switch ON. Check voltage between rear power window switch harness connector and ground. (+) (-) Condition Voltage (Approx.) Rear power window switch Connector Terminal LH D204 1 Ground Ignition switch ON Battery voltage RH D304 Is the inspection result normal? YES: Inspection End. NO: GO TO 2.
  2. CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect power window relay connector. Check continuity between power window relay harness connector and rear power window switch harness connector. Power window relay Rear power window switch Continuity Connector Terminal Connector Terminal M58 3 LH D204 1 Yes RH D304 Check continuity between power window relay harness connector and ground. Power window relay Ground Continuity Connector Terminal M58 3 No Is the inspection result normal? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-616767-S35750020532014051900000) ". NO: Repair or replace harness.

Diagnosis Procedure

  1. CHECK FRONT POWER WINDOW SWITCH RH INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window switch RH connector. Turn ignition switch ON. Check voltage between front power window switch RH harness connector and ground. (+) (-) Condition Voltage (Approx.) Front power window switch RH Connector Terminal D112 12 Ground Power window main switch RH UP Battery voltage DOWN 0 11 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
  2. CHECK FRONT POWER WINDOW SWITCH RH Check front power window switch RH. Refer to " «COMPONENT INSPECTION»(ref-616767-S37499934352014051900000) ". Is the inspection result normal? YES: GO TO 4 . NO: Replace front power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S22807732752014051900000) ".
  3. CHECK FRONT POWER WINDOW SWITCH RH CIRCUIT Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector. Check continuity between main power window and door lock/unlock switch harness connector and front power window switch RH harness connector. Main power window and door lock/unlock switch Front power window switch RH Continuity Connector Terminal Connector Terminal D6 16 D112 12 Yes 2 11 Check continuity between main power window and door lock/unlock switch harness connector and ground. Main power window and door lock/unlock switch Ground Continuity Connector Terminal D6 16 No 2 Is the inspection result normal? YES: Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S08845366802014051900000) ". NO: Repair or replace harness.
  4. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". : Inspection End.

Component Inspection

  1. CHECK FRONT POWER WINDOW SWITCH RH Turn ignition OFF. Disconnect front power window switch RH connector. Check front power window switch RH. Front power window switch RH Terminal Front power window switch condition Continuity D112 8 7 DOWN Yes 11 6 11 6 NEUTRAL 12 7 8 6 UP 12 7 Is the inspection result normal? YES: Inspection End. NO: Replace front power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S22807732752014051900000) ".
  1. CHECK REAR POWER WINDOW SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window switch connector. Turn ignition switch ON. Check voltage between rear power window switch harness connector and ground. (+) (-) Condition Voltage (Approx.) Rear power window switch Connector Terminal LH: D204 2 Ground Power window main switch: LH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage RH: D304 2 Power window main switch: RH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
  2. CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT INSPECTION»(ref-616767-S32005085962014051900000) ". Is the inspection result normal? YES: GO TO 4 . NO: Replace rear power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S22807732752014051900000) ".
  3. CHECK REAR POWER WINDOW SWITCH CIRCUIT Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector. Check continuity between main power window and door lock/unlock switch harness connector and rear power window switch harness connector. Main power window and door lock/unlock switch Rear power window switch Continuity Connector Terminal Connector Terminal D6 9 LH D204 2 Yes 8 3 6 RH D304 3 7 2 Check continuity between main power and door lock/unlock switch harness connector and ground. Main power window and door lock/unlock switch Ground Continuity Connector Terminal D6 9 No 8 6 7 Is the inspection result normal? YES: Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S08845366802014051900000) ". NO: Repair or replace harness.
  4. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". : Inspection End.
  1. CHECK REAR POWER WINDOW SWITCH Turn ignition switch OFF. Disconnect rear power window switch connector. Check rear power window switch terminals under the following conditions. Terminal Rear power window switch condition Continuity 1 5 DOWN Yes 3 4 3 4 NEUTRAL 2 5 1 4 UP 2 5 Is the inspection result normal? YES: Inspection End. NO: Replace rear power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S07273707072014051900000) ".

DRIVER SIDE: Diagnosis Procedure

  1. CHECK POWER WINDOW MOTOR LH INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window motor LH connector. Turn ignition switch ON. Check voltage between power window motor LH harness connector and ground. (+) (-) Condition Voltage (Approx.) Power window motor LH Connector Terminal D10 3 Ground Main power window and door lock/unlock switch UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK POWER WINDOW MOTOR CIRCUIT Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector. Check continuity between main power window and door lock/unlock switch harness connector and front power window motor LH harness connector. Main power window and door lock/unlock switch Front power window motor LH Continuity Connector Terminal Connector Terminal D8 17 D10 3 Yes 19 1 Check continuity between main power window and door lock/unlock switch harness connector and ground. Main power window and door lock/unlock switch Ground Continuity Connector Terminal D8 17 No 19 Is the inspection result normal? YES: Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S08845366802014051900000) ". NO: Repair or replace harness.
  3. CHECK FRONT POWER WINDOW MOTOR LH Check front power window motor LH. Refer to " «DRIVER SIDE: COMPONENT INSPECTION»(ref-616767-S40833004002014051900000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace front power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-616774-S27834296632014051900000) ".
  4. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". : Inspection End.

DRIVER SIDE: Component Inspection

  1. CHECK FRONT POWER WINDOW MOTOR LH Turn ignition switch OFF. Disconnect front power window motor LH connector. Check motor operate by connecting the battery voltage directly to front power window motor LH connector. Front power window motor LH connector Terminal Motor condition (+) (-) D10 1 3 DOWN 3 1 UP Is the inspection result normal? YES: Inspection End. NO: Replace front power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-616774-S27834296632014051900000) ".

PASSENGER SIDE: Diagnosis Procedure

  1. CHECK FRONT POWER WINDOW MOTOR RH INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window motor RH connector. Turn ignition switch ON. Check voltage between front power window motor RH harness connector and ground. (+) (-) Condition Voltage (Approx.) Front power window motor RH Connector Terminal D105 7 Ground Front power window switch RH UP Battery voltage DOWN 0 6 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK FRONT POWER WINDOW MOTOR RH CIRCUIT Turn ignition switch OFF. Disconnect front power window switch RH connector. Check continuity between front power window switch RH harness connector and front power window motor RH harness connector. Front power window switch RH Front power window motor RH Continuity Connector Terminal Connector Terminal D112 6 D105 3 Yes 7 1 Check continuity between front power window switch RH harness connector and ground. Front power window switch RH Ground Continuity Connector Terminal D112 6 No 7 Is the inspection result normal? YES: Replace front power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S22807732752014051900000) ". NO: Repair or replace harness.
  3. CHECK FRONT POWER WINDOW MOTOR RH Check front power window motor RH. Refer to " «PASSENGER SIDE: COMPONENT INSPECTION»(ref-616767-S32483813252014051900000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace front power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-616774-S27834296632014051900000) ".
  4. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". : Inspection End.

PASSENGER SIDE: Component Inspection

  1. CHECK FRONT POWER WINDOW MOTOR RH Turn ignition switch OFF. Disconnect front power window motor RH connector. Check motor operate by connecting the battery voltage directly to front power window motor RH connector. Front power window motor RH connector Terminal Motor condition (+) (-) D105 1 3 DOWN 3 1 UP Is the inspection result normal? YES: Inspection End. NO: Replace front power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-616774-S27834296632014051900000) ".

REAR LH: Diagnosis Procedure

  1. CHECK REAR POWER WINDOW MOTOR LH INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window motor LH connector. Turn ignition switch ON. Check voltage between rear power window motor LH harness connector and ground. (+) (-) Condition Voltage (Approx.) Rear power window motor LH Connector Terminal D205 1 Ground Rear power window switch LH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK REAR POWER WINDOW MOTOR LH CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch LH connector. Check continuity between rear power window switch LH harness connector and rear power window motor LH harness connector. Rear power window switch LH Rear power window motor LH Continuity Connector Terminal Connector Terminal D204 4 D205 3 Yes 5 1 Check continuity between rear power window switch LH connector and ground. Rear power window switch LH Ground Continuity Connector Terminal D204 4 No 5 Is the inspection result normal? YES: Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S22807732752014051900000) ". NO: Repair or replace harness.
  3. CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH: COMPONENT INSPECTION»(ref-616767-S24622044752014051900000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-616774-S31103685952014051900000) ".
  4. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". : Inspection End.
  1. CHECK REAR POWER WINDOW MOTOR LH Turn ignition switch OFF. Disconnect rear power window motor LH connector. Check motor operation by connecting the battery voltage directly to rear power window motor LH connector. Rear power window motor LH connector Terminal Motor condition (+) (-) D205 3 1 DOWN 1 3 UP Is the inspection result normal? YES: Inspection End. NO: Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-616774-S31103685952014051900000) ".

REAR RH: Diagnosis Procedure

  1. CHECK REAR POWER WINDOW MOTOR RH INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window motor RH connector. Turn ignition switch ON. Check voltage between rear power window motor RH harness connector and ground. (+) (-) Condition Voltage (Approx.) Rear power window motor RH Connector Terminal D305 1 Ground Rear power window switch RH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK REAR POWER WINDOW MOTOR RH CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch RH connector. Check continuity between rear power window switch RH harness connector and rear power window motor RH harness connector. Rear power window switch RH Rear power window motor RH Continuity Connector Terminal Connector Terminal D304 4 D305 3 Yes 5 1 Check continuity between rear power window switch RH harness connector and ground. Rear power window switch RH Ground Continuity Connector Terminal D304 4 No 5 Is the inspection result normal? YES: Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S07273707072014051900000) ". NO: Repair or replace harness.
  3. CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH: COMPONENT INSPECTION»(ref-616767-S38397716372014051900000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-616774-S31103685952014051900000) ".
  4. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". : Inspection End.
  1. CHECK REAR POWER WINDOW MOTOR RH Turn ignition switch OFF. Disconnect rear power window motor RH connector. Check motor operation by connecting the battery voltage directly to rear power window motor RH connector. Rear power window motor RH connector Terminal Motor condition (+) (-) D305 3 1 DOWN 1 3 UP Is the inspection result normal? YES: Inspection End. NO: Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-616774-S31103685952014051900000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK POWER WINDOW RELAY CONTROL CIRCUIT Disconnect BCM connector. Turn ignition switch ON. Check voltage between BCM connector and ground. (+) (-) Voltage (Approx.) Connector Terminal Ground Battery voltage M18 23 Is the inspection result normal? YES: Replace the BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-616752-S35177724082014051900000) " (with Intelligent Key system) or " «REMOVAL AND INSTALLATION»(ref-616758-S27028751992014051900000) " (without Intelligent Key system). NO: GO TO 2.
  2. CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect BCM and power window relay. Check continuity between BCM connector and power window relay connector. BCM Power window relay Continuity Connector Terminal Connector Terminal M18 23 M58 1 Yes Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness.
  3. CHECK POWER WINDOW RELAY Check power window relay. Refer to " «COMPONENT INSPECTION»(ref-616767-S38296543102014051900000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: Replace power window relay.

Scheme 1

Scheme 1: Component Inspection
Scheme 1: Component Inspection
  1. CHECK POWER WINDOW RELAY Check power window relay. Terminal Condition Continuity Power window relay 3 5 12V direct current supply between terminals 1 and 2. Yes No current supply No Is the inspection result normal? YES: Inspection End. NO: Replace power window relay.

WITH INTELLIGENT KEY: Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

Scheme 2

Scheme 2: WITH INTELLIGENT KEY: Diagnosis Procedure
Scheme 2: WITH INTELLIGENT KEY: Diagnosis Procedure
  1. CHECK DOOR SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect malfunctioning door switch connector. Check signal between malfunctioning door switch harness connector and ground using oscilloscope. (+) (-) Signal (Reference value) Door switch Connector Terminal Driver side B71 3 Ground 7.0 - 8.0 V Passenger side B141 Rear LH B70 Rear RH B142 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK DOOR SWITCH CIRCUIT Disconnect BCM connector. Check continuity between door switch harness connector and BCM harness connector. Door switch BCM Continuity Connector Terminal Connector Terminal Front LH B71 3 B16 57 Yes Front RH B141 53 Rear LH B70 52 Rear RH B142 50 Check continuity between door switch harness connector and ground. Door switch Ground Continuity Connector Terminal Front LH B71 3 No Front RH B141 Rear LH B70 Rear RH B142 Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-616752-S35177724082014051900000) ". NO: Repair or replace harness.
  3. CHECK DOOR SWITCH Refer to " «WITH INTELLIGENT KEY: COMPONENT INSPECTION»(ref-616767-S24488906652014051900000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace malfunctioning door switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616728-S32429336942014051900000) ".
  4. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". : Inspection End.

WITH INTELLIGENT KEY: Component Inspection

  1. CHECK DOOR SWITCH Turn ignition switch OFF. Disconnect malfunctioning door switch connector. Check continuity between door switch terminals. Door switch Condition Continuity Terminal 3 Ground contact is part of the switch. Door switch Pressed No Released Yes Is the inspection result normal? YES: Inspection End. NO: Replace malfunctioning door switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616728-S32429336942014051900000) ".

WITHOUT INTELLIGENT KEY: Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK DOOR SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect malfunctioning door switch connector. Check signal between malfunctioning door switch harness connector and ground using oscilloscope. (+) (-) Signal (Reference value) Door switch Connector Terminal Front LH B71 3 Ground 7.0 - 8.0 V Front RH B141 Rear LH B70 Rear RH B142 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK DOOR SWITCH CIRCUIT Disconnect BCM connector. Check continuity between door switch harness connector and BCM harness connector. Door switch BCM Continuity Connector Terminal Connector Terminal Front LH B71 3 B16 57 Yes Front RH B141 53 Rear LH B70 52 Rear RH B142 50 Check continuity between door switch harness connector and ground. Door switch Ground Continuity Connector Terminal Front LH B71 3 No Front RH B141 Rear LH B70 Rear RH B142 Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-616758-S27028751992014051900000) ". NO: Repair or replace harness.
  3. CHECK DOOR SWITCH Refer to " «COMPONENT INSPECTION»(ref-616728-S03080116842014051900000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace malfunctioning door switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616773-S17116948412014051900000) ".
  4. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". : Inspection End.

WITHOUT INTELLIGENT KEY: Component Inspection

  1. CHECK DOOR SWITCH Turn ignition switch OFF. Disconnect door switch connector. Check door switch. Terminal Door switch condition Continuity Door switch 3 Ground part of door switch Pressed No Released Yes Is the inspection result normal? YES: Inspection End. NO: Replace malfunctioning door switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616773-S17116948412014051900000) ".

Symptom Table

SymptomReference
None of the power windows can be operated using any switch.Refer to " DIAGNOSIS PROCEDURE ".
Driver side power window alone does not operate.Refer to " DIAGNOSIS PROCEDURE ".
Front passenger side power window does not operate (with both power window main switch and front passenger side power window switch).Refer to " WITH BOTH POWER WINDOW MAIN SWITCH AND FRONT PASSENGER SIDE POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE ".
Front passenger side power window does not operate (with front power window switch only).Refer to " WITH FRONT POWER WINDOW SWITCH ONLY: DIAGNOSIS PROCEDURE ".
Rear LH side power window does not operate (with both power window main switch and rear power window switch LH).Refer to " WITH BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW SWITCH LH: DIAGNOSIS PROCEDURE ".
Rear LH side power window does not operate (with rear power window switch LH only).Refer to " WITH REAR POWER WINDOW SWITCH LH ONLY: DIAGNOSIS PROCEDURE ".
Rear RH side power window does not operate (with both power window main switch and rear power window switch RH).Refer to " WITH BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW SWITCH RH: DIAGNOSIS PROCEDURE ".
Rear RH side power window does not operate (with rear power window switch RH only).Refer to " WITH REAR POWER WINDOW SWITCH RH ONLY: DIAGNOSIS PROCEDURE ".
Anti-pinch system does not operate normally (drivers side).Refer to " DIAGNOSIS PROCEDURE ".
Power window retained power operation does not operate properly.Refer to " DIAGNOSIS PROCEDURE ".
Auto operation does not operate manual operate normally (driver side).Refer to " DIAGNOSIS PROCEDURE ".
Power window lock switch does not function.Refer to " DIAGNOSIS PROCEDURE ".
  1. CHECK BCM POWER SUPPLY AND GROUND CIRCUIT Check BCM power supply and ground circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-616752-S19504523932014051900000) " (with Intelligent Key system) or " «DIAGNOSIS PROCEDURE»(ref-616758-S14733872652014051900000) " (without Intelligent Key system). Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
  2. CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH POWER SUPPLY AND GROUND CIRCUIT Check main power window and door lock/unlock switch power supply and ground circuit. Refer to " «POWER WINDOW MAIN SWITCH: DIAGNOSIS PROCEDURE»(ref-616767-S24089893762014051900000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .
  1. CHECK FRONT POWER WINDOW MOTOR LH Check power window motor. Refer to " «DRIVER SIDE: COMPONENT FUNCTION CHECK»(ref-616767-S27138022132014051900000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
  2. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .

WITH BOTH POWER WINDOW MAIN SWITCH AND FRONT PASSENGER SIDE POWER WINDOW SWITCH: Diagnosis Procedure

  1. CHECK FRONT POWER WINDOW SWITCH RH Check front power window switch RH. Refer to " «COMPONENT FUNCTION CHECK»(ref-616767-S41373608582014051900000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts
  2. CHECK FRONT POWER WINDOW MOTOR RH Check front power window motor RH. Refer to " «PASSENGER SIDE: COMPONENT FUNCTION CHECK»(ref-616767-S34086808842014051900000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .

WITH FRONT POWER WINDOW SWITCH ONLY: Diagnosis Procedure

  1. CHECK FRONT POWER WINDOW SWITCH RH POWER SUPPLY AND GROUND CIRCUIT Check front power window switch RH power supply and ground circuit. Refer to " «FRONT POWER WINDOW SWITCH (PASSENGER SIDE): DIAGNOSIS PROCEDURE»(ref-616767-S42837320512014051900000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
  2. CHECK FRONT POWER WINDOW SWITCH RH Check front power window switch RH. Refer to " «COMPONENT FUNCTION CHECK»(ref-616767-S41373608582014051900000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .

WITH BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW SWITCH LH: Diagnosis Procedure

  1. CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-616767-S04732593352014051900000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
  2. CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH: COMPONENT FUNCTION CHECK»(ref-616767-S35295733852014051900000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .

WITH REAR POWER WINDOW SWITCH LH ONLY: Diagnosis Procedure

  1. CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-616767-S11260376042014051900000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
  2. CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-616767-S04732593352014051900000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .

WITH BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW SWITCH RH: Diagnosis Procedure

  1. CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-616767-S04732593352014051900000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
  2. CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH: COMPONENT FUNCTION CHECK»(ref-616767-S42652192872014051900000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .

WITH REAR POWER WINDOW SWITCH RH ONLY: Diagnosis Procedure

  1. CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-616767-S11260376042014051900000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
  2. CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-616767-S04732593352014051900000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .
  1. PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT»(ref-616767-S41689515492014051900000) ". Is the inspection result normal? YES: Inspection End. NO: GO TO 2.
  2. CHECK ENCODER CIRCUIT Check encoder circuit. Refer to " «COMPONENT FUNCTION CHECK»(ref-616767-S22353696062014051900000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .
  1. CHECK DOOR SWITCH Check door switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-616728-S07435184772014051900000) " (with Intelligent Key system) or " «COMPONENT FUNCTION CHECK»(ref-616773-S24355598422014051900000) " (without Intelligent Key system). Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
  2. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .
  1. PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT»(ref-616767-S41689515492014051900000) ". Is the inspection result normal? YES: Inspection End. NO: GO TO 2.
  2. CHECK ENCODER Check encoder. Refer to " «COMPONENT FUNCTION CHECK»(ref-616767-S22353696062014051900000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". NO: GO TO 1 .
  1. REPLACE MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Replace main power window and door lock/unlock switch. : Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S22807732752014051900000) ".

Scheme 3

Scheme 3: REMOVAL
Scheme 3: REMOVAL

Scheme 4

Scheme 4
Scheme 4
  1. Remove the front door pull handle bracket (LH). Refer to " «REMOVAL AND INSTALLATION»(ref-616755-S20321696632014051900000) ".
  2. Release pawls using a suitable tool (A) and remove main power window and door lock/unlock switch finisher (1).
  3. Disconnect the harness connectors from the main power window and door lock/unlock switch.
  4. Release the pawls, then separate the main power window and door lock/unlock switch (1) from the switch finisher (2).
